Network PTZ Cameras Quick Guide V1.00 1 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! ⚫ Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use. ⚫ Please use self-adhesive waterproof tape (supplied with some products) to protect the cables. ⚫ Use waterproof components to protect the network cable. Waterproof the power cable separately if you don’t use it. The video cable does not need waterproof treatment. 1. Use insulation tape (not included in the package) to insulate the connection part of each cable. 2. Waterproof the cables with self-adhesive waterproof tape. (1) Fully stretch the waterproof tape at both ends. (2) Wrap the connection part and the cable ends tightly with waterproof tape. Make sure the tape is fully stretched during the process. (3) Tighten the tape at both ends to prevent water leakage. Connection part Insulation tape Wrap the unused cables together into a bundle TightenTighten Waterproof tape Tighten 2 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4. If your camera has a DC cable and you will not use it, insert the plug into the interface. 5. (Optional) After the waterproof treatment is completed, put the cables into a waterproof junction box (purchased separately). CAUTION! ⚫ The cable connector must not be exposed and must be kept away from water. ⚫ Restore and fasten the device after dismounting. ⚫ Place the power adapter in a power distribution box. D C i n t e r f a c e P l u g 3 1 Packing List Contact your local dealer if the package is damaged or incomplete. The components may vary with device model. No. Name Qty Unit 1 Camera 1 PCS 2 Waterproof components 1 Set 3 Drill template 1 PCS 4 Screw components 1 Set 5 User manual 1 Set 2 Safety Informations Installation and removal of the unit and its accessories must be carried out by qualified personnel. You must read all of the safety instructions before installation and operation. 2.1 Installation ⚫ Use a power adapter or a PoE device that meets requirements. Otherwise, the device may be damaged. ⚫ Make sure the length of the power cable between the power adapter and the camera is not too long, otherwise the voltage of the camera is lowered, causing the camera to work abnormally. If it is required to lengthen the power cable, lengthen the cable between the power adapter and the mains. ⚫ Do not overbend the cables during the installation, otherwise, poor cable contact may cause malfunction. ⚫ When connecting to an external interface, use an existing connection terminal, and ensure that the cable terminal (latch or clamp) is in good condition and properly fastened. Ensure that the cable is not tense during mounting, with a proper margin reserved to avoid poor port contact or loosening caused by shock or shake. ⚫ During transportation, special attention is required to protect the transparent dome cover from friction, scratch and stain, etc. Do not remove the protective 4 film from the cover until mounting is finished. Remove the protective film before powering on the device. ⚫ Contact professionals for maintenance information. Do not attempt to dismantle the device by yourself. We shall not assume any responsibility for problems caused by unauthorized repair or maintenance. 2.2 Maintenance ⚫ If there is grease or a dust stain on the front glass surface, clean the glass surface gently from the center outward using anti-static gloves or an oil-free cloth. If the grease or the stain still remains, use anti-static gloves or an oil-free cloth dipped with detergent and clean the glass surface gently until it is clean. ⚫ If there is dust on the front glass surface, remove the dust gently using an oil- free brush or a rubber dust blowing ball. ⚫ Do not use organic solvents (benzene, alcohol, etc) to clean the camera. 3 Appearance 3.1 Dimensions 5 3.2 Cable Connection Tail cables may vary with device model. The following figure shows an example. IP Network Power cable Network cable 4 Installation 4.1 (Optional) Install SD Card You need to install a Micro SD card first if you want to save video on an on-board SD card. NOTE! ⚫ You need to format the Micro SD card before use. The Micro SD card can be formatted on the camera's Web interface. ⚫ For recommended SD card specifications, please contact your dealer or technical support. The figure below is for illustrative purpose only. The actual card slot position may vary. Micro SD card 6 WARNING! ⚫ Before you insert or remove the Micro SD card, be sure to disconnect power and wait till the camera stops operation; otherwise, the camera or the Micro SD card may be damaged. ⚫ Do not disassemble the device in high humidity environment. The high humidity inside the device will cause lens fogging. 4.2 Wall Mount 1. Locate the positions of holes by pasting the drill template. CAUTION! Keep the line formed by the two holes on the template bottom horizontal. Drill template 2. Drill holes according to the template. 3. Knock in the plastic anchors of self-tapping screws, and make sure that they are tightened up. 7 Plastic anchors 4. Insert the self-tapping screws through the guide holes on the camera base, and use a screwdriver to fasten it onto the wall. Self - tapping screws Plastic anchors 5 Startup After you have installed the device, connect one end of the power adapter (which needs to be purchased separately) to power supply, and the other end to the power interface to start up the device. 6 Web Login Log in to the Web interface to manage and maintain the device. 8 1. Open your browser, input the camera’s IP address 192.168.1.13 in the address bar and then press Enter to open the login page. 2. Enter the username and password (admin/123456 by default) and…
