2ALEPT0006600Kona Micro PoE Gateway is a LoRa base station

TEKTELIC Communications Incorporated

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Feb 17, 2020
Application Purpose: Original Equipment
Date of Application: Feb 17, 2020
Equipment Note: Kona Micro PoE Gateway is a LoRa base station
Frequency Range: 923.00000000 - 928.00000000
Company: TEKTELIC Communications Incorporated
Country: Canada

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

PROPRIETARY: The information contained in this document is the property of TEKTELIC Communications Inc. Except as specifically authorized in writing by TEKTELIC, the holder of this document shall keep all information contained herein confidential, and shall protect the same in whole or in part from disclosure to all third parties. © 2020 TEKTELIC Communications Inc., all rights reserved. All products, names, and services are trademarks and registered trademarks of their respective companies. TEKTELIC Communications Inc. 7657 10 th Street NE Calgary, AB, Canada T2E 8X2 Phone: (403) 338-6900 KONA MICRO POE GATEWAY USER GUIDE Document Type: User Guide Document Number: T0006600_UG Document Issue: 1.4 Document Status: Approved Product Name: Kona Micro PoE Gateway Product Code: See Table 1 Issue Date: February 12, 2020 Kona Micro PoE Gateway T0006600_UG Version 1.4 TEKTELIC Communications Inc. Confidential Page 2 of 15 Document Revision Revision Issue Date Status Editor Comments 0.1 Oct. 8, 2019 Obsolete Z. Herasymiuk First release 1.0 Oct. 17, 2019 Obsolete S. Morrison Updated to new format 1.1 Nov. 6, 2019 Obsolete Z. Herasymiuk Updated Sec. 1.2, Figure 2, Table 2 1.2 Dec. 20, 2019 Approved S. Morrison Final updates & corrections 1.3 February 12, 2020 Approved T. Danshin Simplified Table 1 (NA products only), updated FCC minimum distances. 1.4 February 12, 2020 Approved T. Danshin Corrected ISED notice T-code, clarified antenna statements and included French translation Kona Micro PoE Gateway T0006600_UG Version 1.4 TEKTELIC Communications Inc. Confidential Page 3 of 15 Table of Contents List of Tables ................................................................................................................................... 4 1 Product Description ................................................................................................................. 5 1.1 Overview .......................................................................................................................... 5 1.2 Physical Interfaces ............................................................................................................ 7 1.3 Specifications.................................................................................................................... 7 2 Installation ............................................................................................................................... 9 2.1 Overview .......................................................................................................................... 9 2.2 Unpacking and Inspection ................................................................................................ 9 2.3 Kona Micro PoE Gateway Mounting ................................................................................ 9 2.4 DC Power Cable Installation ........................................................................................... 11 2.5 Battery Installation ......................................................................................................... 12 2.6 RF Cable Installation ....................................................................................................... 13 2.7 Copper Ethernet Cable Installation ................................................................................ 13 3 Radio Compliance Statements .............................................................................................. 14 Kona Micro PoE Gateway T0006600_UG Version 1.4 TEKTELIC Communications Inc. Confidential Page 4 of 15 List of Tables Table 1: Kona Micro Gateway Models ............................................................................................ 5 Table 2: Kona Micro PoE Gateway Interface Connector Types ...................................................... 7 Table 3: Kona Micro PoE Gateway Specifications ........................................................................... 8 Kona Micro PoE Gateway T0006600_UG Version 1.4 TEKTELIC Communications Inc. Confidential Page 5 of 15 1 Product Description 1.1 Overview The Kona Micro PoE Gateway is a LoRaWAN IoT gateway that supports the full range of LoRa WAN channels. The Gateway supports one external LoRa antenna, copper Ethernet backhaul, and optional 3G/4G wireless backhaul. All Gateway models are powering from an AC-DC power adapter and may optionally have an internal backup battery provisioned. Table 1 presents the currently available Kona Micro PoE Gateway models. Any model may have a backup battery provisioned. Table 1: Kona Micro PoE Gateway Models Model 3G/4G modem Region Frequency Band Supports Battery Backup T0006268 Yes North America 915 Yes T0006267 No North America 915 Yes Figure 1 illustrates the Kona Micro PoE Gateway external form-factor with the front view on the top and rear view on the bottom. All models share the same mechanical form-factor. Kona Micro PoE Gateway T0006600_UG Version 1.4 TEKTELIC Communications Inc. Confidential Page 6 of 15 Figure 1: Kona Micro PoE Gateway Kona Micro PoE Gateway T0006600_UG Version 1.4 TEKTELIC Communications Inc. Confidential Page 7 of 15 1.2 Physical Interfaces Figure 2 illustrates the connector layout for the Kona Micro PoE Gateway. Figure 2: Kona Micro Gateway Bulkhead Layout The Gateway connectors are listed in Table 2. Table 2: Kona Micro PoE Gateway Interface Connector Types Interface Connector Type Mating Connector LoRa Antenna Ports Reverse SMA female Industry standard Reverse SMA male DC Power Input Port Barrel Jack DC Barrel plug 2.1 mm (inner), 5.5 mm (outer) Center positive Ethernet Port RJ-45 Industry standard RJ45 plug (PoE compliant) 1.3 Specifications The Kona Micro PoE Gateway specifications are listed in Table 3. DC Power LoRa RF Antenna Ethernet (PoE Compliant) Kona Micro PoE Gateway T0006600_UG Version 1.4 TEKTELIC Communications Inc. Confidential Page 8 of 15 Table 3: Kona Micro PoE Gateway Specifications Attribute Specification Dimensions 120 (L)…

Text truncated - open the document above for the full version.

Cover Letter(s)

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: February 10, 2020 SUBJECT: FCC ID: 2ALEPT0006600 To Whom It May Concern: We, the undersigned, hereby authorize Marc Rousseau at Electronics Test Centre – Airdrie (MPB Technologies Inc.) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Electronics Test Center – Airdrie (MPB Technologies Inc.) on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti- Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Tom Danshin, P.Eng Senior System Engineer TEKTELIC Communications Inc.

Cover Letter(s)

Rev 11/20/07 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ALEPT0006600 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description, Parts List, Tune Up Info T0006600_BlkDia.pdf T0006600_Sch.pdf T0006600_OpDesc.pdf T0006600_PartList.pdf T0006600_TuneProc.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Tom Danshin

Cover Letter(s)

PROPRIETARY: The information contained in this document is the property of Tektelic Communications Inc. Except as specifically authorized in writing by Tektelic, the holder of this document shall keep all information contained herein confidential, and shall protect the same in whole or in part from disclosure to all third parties. Copyright © 2020 Tektelic Communications Inc. All Rights Reserved. TEKTELIC COMMUNICATIONS INC. Document type: PRODUCT INTEGRITY TEST PLAN Document number: T0006600_Family_Certification_Information Document version: 1.3 Document Status: Approved Product name: Kona Micro Indoor Gateway Product codes: T0006267, T0006268 TEKTELIC Communications Inc. Product Integrity Test Plan T0006600_PITP_FCI Version 1.3 TEKTELIC Communications Inc. Confidential Page 2 of 6 Revision History Version Date Comments 1.0 February 10, 2020 Initial Release 1.1 February 11, 2020 Fixed typos in table 1-1. Updated block diagram to show 2 cellular antennas. 1.2 February 12, 2020 Fixed document number in footer 1.3 February 18, 2020 Removed block diagram and reference TEKTELIC Communications Inc. Product Integrity Test Plan T0006600_PITP_FCI Version 1.3 TEKTELIC Communications Inc. Confidential Page 3 of 6 Contents 1 Family Certification Information ............................................................................................. 4 2 References ............................................................................................................................... 6 TEKTELIC Communications Inc. Product Integrity Test Plan T0006600_PITP_FCI Version 1.3 TEKTELIC Communications Inc. Confidential Page 4 of 6 1 Family Certification Information The T0006600 Kona Micro PoE Gateway family consists of two variants with backhaul options (3G/4G cellular wireless yes/no). All variants have a copper Ethernet port that is also the 802.3af PoE power interface. All variants use the same internal T0004850 radio/digital PCBA. The individual LoRa transceivers in each variant are all electrically identical. The 3G/4G radio modem options are integrated internally at the factory by installing approved commercial modules into connectors on the radio/digital PCBA. If a modem is installed, so is an internal 3G/4G cellular antenna. There is no post factory module configuration allowed. Table 1-1 presents the Gateway variants which are being certified. For the purposes of design verification and certification, one variant may be considered as covering all test cases. Table 1-1 Kona Micro Indoor Variants Variant Hardware Version ID (HVIN) Product Description Direct DC or PoE Power Copper Eth. 3G/4G with internal Ant. LoRa Ant. -1 T0006267 LORA GATEWAY MODULE, KONA MICRO, PoE, NA 1 1 0 1 -2 T0006268 LORA GATEWAY MODULE, KONA MICRO, PoE, NA, LTE MODEM 1 1 1 1 An illustration of the common Kona Micro Indoor Gateway dimensions can be seen in Figure 1-1. TEKTELIC Communications Inc. Product Integrity Test Plan T0006600_PITP_FCI Version 1.3 TEKTELIC Communications Inc. Confidential Page 5 of 6 Figure 1-1 Kona Micro Indoor Gateway The bulkhead connectors are identical for all of the variants. TEKTELIC Communications Inc. Product Integrity Test Plan T0006600_PITP_FCI Version 1.3 TEKTELIC Communications Inc. Confidential Page 6 of 6 2 References There are no sources in the current document.

External Photos

FCC ID: 2ALEPT0006600 IC: 22504-T0006600 External Photos Top view FCC ID: 2ALEPT0006600 IC: 22504-T0006600 External Photos Bottom view FCC ID: 2ALEPT0006600 IC: 22504-T0006600 External Photos 1 st Side (view) FCC ID: 2ALEPT0006600 IC: 22504-T0006600 External Photos 2 nd Side View FCC ID: 2ALEPT0006600 IC: 22504-T0006600 External Photos 3 rd Side View FCC ID: 2ALEPT0006600 IC: 22504-T0006600 External Photos 4 th Side View

ID Label/Location Info

FCC ID: 2ALEPT0006600 Label & Location IC ID: 22504-T0006600 All labels are 1” x 2” PLACE SAFTY AND REGULATORY LABEL AT LOCATION SHOWN FCC ID: 2ALEPT0006600 Label & Location IC ID: 22504-T0006600 Label Detail for T0006268 FCC ID: 2ALEPT0006600 Label & Location IC ID: 22504-T0006600 Label Detail for T0006267

Internal Photos

FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Internal Photo Inside Battery Holder Battery Holder no Battery FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Internal Photo Battery Holder with Battery FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Internal Photo Top Cover Removed Pre-certified 3G/4G Cellular modem FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Internal Photo Inside View Top Cover Removed FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Internal Photo Inside View without PCB FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Internal Photo Inside View with Cellular Modem antenna Auxiliary RF Connector Rx Antenna Main RF Connector (Tx/Rx Antenna) FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Internal Photo PCB Top View with Cellular Modem Main RF Connector (Tx/Rx Path) Auxiliary RF Connector Rx Path FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Internal Photo PCB Top View without Cellular Modem FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Internal Photo PCB Bottom View LoRa Antenna connector Micro SD Connector AC/DC Adaptor Connector Ethernet PoE connector Micro USB Connector FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Internal Photo PCB unshielded Bottom View

RF Exposure Info

FCC ID: 2ALEPT0006600 FCC RF Exposure Calculation 1 The Device is a carrier grade gateway designed for IoT applications. The Kona Micro POE gateway is designed to be used as indoor table top equipment for home or small office. The device has 1 antenna port, which must be used with antenna respecting the requirement specified in the technical documentation. Gateway evaluated for RF radiation exposure according to the provisions of FCC §2.1091, MPE guidelines identified in FCC §1.1310 and FCC KDB 447498:2015. Limits for General Population/Uncontrolled Exposure: 47 CFR 1.1310 Table 1 (B) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) 0.3-1.34 614 1.63 *100 30 1.34-30 824/f 2.19/f *180/f 2 30 30-300 27.5 0.073 0.2 30 300-1,500 f/1500 30 1,500-100,000 1.0 30 Where f is in MHz The worst-case scenario at 923 MHz is S = 0.615 mW/cm 2 , for uncontrolled exposure Equations To determine the minimum safe distance, each transmitted power density is calculated using the equation, S = EIRP / ( 4πR 2 ) Where: S, power density in ‘mW/cm 2 ’ EIRP, Effective Isotropic Radiated Power in ‘mW’ R, distance to the center of the radiation of the antenna in ‘cm’ FCC ID: 2ALEPT0006600 FCC RF Exposure Calculation 2 The power density calculations for the EM7355 at an exposure minimum separation distance of 20cm are shown in the table below for each mode of operation. The worst case value is highlighted below. When EM7455 module transmits as a stand-alone mobile device, the source-based time-averaged EIRP is calculated by summing up conducted power and antenna gain. A 100% duty cycle is used for calculations to present a worse-case analysis. Technology Frequency (MHz) Max. Avg Cond. Actual Antenna Gain (dBi) Avg EIRP (W) [Pd] Power density (mW/cm^2) @20 cm [Limit] FCC MPE Limit Ratio Pd/limit WCDMA Band II LTE Band 2 1850-1910 0.25 3.4 0.550 0.109 1 0.109 WCDMA Band IV LTE Band 4 1710-1755 0.25 3.4 0.550 0.109 1 0.109 WCDMA Band V LTE Band 5 824-849 0.25 2.9 0.490 0.097 0.549 0.177 LTE Band 7 2500-2570 0.20 3.8 0.480 0.095 1 0.095 LTE Band 12 699-716 0.25 2.9 0.490 0.097 1 0.097 LTE Band 13 777-787 0.25 2.9 0.490 0.097 0.518 0.187 LTE Band 25 1850-1915 0.25 3.4 0.550 0.109 1 0.109 LTE Band 26 814-849 0.25 2.9 0.490 0.097 0.543 0.179 LTE Band 30 2305-2315 0.20 3.8 0.480 0.095 1 0.095 LTE Band 41 2496-2690 0.20 3.8 0.480 0.095 1 0.095 LoRa RF conducted power measurement and antenna gain as per ETC test report t29e20a131-FCC are reported below. The worst case value is highlighted below. Technology Frequency (MHz) Measured Power (Conducted) (dBm) Antenna Gain (dBi) Measured EIRP (dBm) Measured EIRP (W) [Pd] Power density (mW/cm^2) @ 20cm [Limit] FCC MPE Limit (mW/cm^2) Ratio Pd/limit LoRa 923.3 26.87 0 26.87 0.486 0.0967 0.615 0.157 925.1 26.83 0 26.83 0.482 0.0960 0.617 0.156 927.5 26.70 0 26.70 0.468 0.0931 0.618 0.151 After Tune up 27.5 0 27.5 0.562 0.112 0.615 0.182 Conclusion Both GSM and LoRa can transmit simultaneously. The formula to calculate the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + .... < 1 Where, CPD: Calculated Power Density LPD: Limit of Power Density GSM / Limit + LoRa / Limit = 0.187 + 0.182 = 0.369 Therefore, the maximum exposure at a distance of 20 cm is less than the maximum allowed exposure.

Test Report

This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Page 1 of 44 Test Report Prepared By: Electronics Test Centre 27 East Lake Hill Airdrie, Alberta Canada T4A 2K3 [email protected] http://www.etc-mpb.com Telephone: 1-403-912-0037 ETC Report #: t29e20a131-FCC Release 1 Test Dates: February 3, 4, 6 of 2020 Report date: February 14, 2020 EMC testing of the Tektelic Communication Inc. Kona Micro PoE Gateway in accordance with FCC Part 15.247, ANSI C63.4: 2014 and ANSI C63.10: 2013 as referenced by FCC OET KDB 558074 D01 15.247 Measurement Guidance v05r02. FCC ID: 2ALEPT0006600 Prepared for: Tektelic Communication Inc. 7657 10 th Street NE Calgary, Alberta Canada T2E 8X2 Telephone: 1-403-338-6910 _________________________ _________________________ Imran Akram Marc Rousseau [email protected] [email protected] EMC Technologist QA Manager Electronics Test Centre (Airdrie) Electronics Test Centre (Airdrie) Test Sample: Kona Micro PoE Gateway FCC ID: 2ALEPT0006600 FCC Part 15.247 (902 – 928 MHz) Report #: t29e20a131- FCC Release 1 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Page 2 of 44 REVISION RECORD ISSUE DATE YYYY-MM-DD AUTHOR REVISIONS DRAFT 1 2020-02-03 I. Akram Initial draft submitted for review. Release 1 2020-02-14 M. Rousseau Sign off Test Sample: Kona Micro PoE Gateway FCC ID: 2ALEPT0006600 FCC Part 15.247 (902 – 928 MHz) Report #: t29e20a131- FCC Release 1 This report shall not be reproduced, except in full, without prior written approval of MPB Technologies Page 3 of 44 TABLE OF CONTENTS 1.0 INTRODUCTION 5 1.1 Scope ......................................................................................................................................5 1.2 Applicant ................................................................................................................................5 1.3 Test Sample Description .........................................................................................................5 1.4 General Test Conditions and Assumptions .............................................................................5 1.5 Scope of Testing .....................................................................................................................7 1.5.1 Test Methodology .................................................................................................... 7 1.5.2 Variations in Test Methodology ............................................................................... 7 1.5.3 Test Sample Verification, Configuration & Modifications ...................................... 7 1.5.4 Uncertainty of Measurement: ................................................................................... 7 2.0 TEST CONCLUSION 8 2.1 AC Power Line Conducted Emissions: ..................................................................................9 2.1.1 Test Guidance: ANSI C63.4-2014, Clause 7.3.1 & ANSI C63.10: 2013 ................. 9 2.1.2 Deviations From The Standard: ............................................................................... 9 2.1.3 Test Equipment ........................................................................................................ 9 2.1.4 Test Sample Verification, Configuration & Modifications .................................... 10 2.1.5 Conducted Emissions Data: .................................................................................. 11 2.2.1 Test Guidance: FCC KDB 558074 D01 15.247 Measurement Guidance v05r02/ ANSI C63.10 clause 11.8 ..................................................................................................... 14 2.2.2 Deviations From The Standard: ............................................................................. 14 2.2.3 Test Equipment ...................................................................................................... 14 2.2.4 Test Sample Verification, Configuration & Modifications .................................... 15 2.2.5 Channel Occupied Bandwidth Data: ...................................................................... 15 2.3 Maximum conducted (average) output power ...................................................................... 17 2.3.1 Test Guidance: FCC KDB 558074 D01 15.247 Measurement Guidance v05r02/ ANSI C63.10 Sub clause 11.9.2.2 ........................................................................................ 17 2.3.2 Deviations From The Standard: ............................................................................. 17 2.3.3 Test Equipment ...................................................................................................... 18 2.3.4 Test Sample Verification, Configuration & Modifications .................................... 18 2.3.5 Average Output Power Data (DTS Mode) ............................................................. 18 2.4 Power Spectral Density (DTS Mode) ................................................................................... 21 2.4.1 Test Guidance: FCC KDB 558074 D01 15.247 Measurement Guidance v05r02/ Sub clause 11.10 of ANSI C63.10 ............................................................................................... 21 2.4.2 Deviations From The Standard: ............................................................................. 21 2.4.3 Test Equipment ...................................................................................................... 21 2.4.4 Test Sample Verification, Configuration & Modifications .................................... 22 2.4.5 Average PSD Data (500 KHz DTS) ....................................................................... 22 2.5 Band Edge Attenuation (DTS Mode) ................................................................................... 24 2.5.1 Test Guidance: ANSI C63.10-2013 Clause 11.11, 11.13.2 / FCC KDB 558074 D01 15.247 Measurement Guidance v05r02 Clause 8.7 ...…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Test Setup Photo EUT Antenna Port Conducted Measurement Test Setup: FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Test Setup Photo 1 st Axis FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Test Setup Photo 2 nd Axis FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Test Setup Photo 3 rd Axis FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Test Setup Photo Radiated Emission below 30 MHz Test Setup: FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Test Setup Photo Radiated Emission 30 MHz to 1 GHz Test Setup: FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Test Setup Photo Radiated Emission 1 GHz – 10 GHz Test Setup: FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Test Setup Photo AC port Conducted Test Setup (POE Adaptor) FCC ID: 2ALEPT0006600 IC: 22504-T0006600 EUT Test Setup Photo AC port Conducted Test Setup (AC/DC Adaptor)

Contact Information

Applicant

David Tholl(Chief Technology Officer)

[email protected]14033386902Fax: 14033386949

Test Firm

Electronics Test Centre-Airdrie (MPB Technologies)Marc Rousseau

[email protected]403-912-0037Fax: 403-912-0083

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	923 MHz - 928 MHz	486.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is conducted. Device must be operated to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
