80W BI-COLOR CONTINUOUS LED LIGHT OPERATION MANUAL AVANT MAX Features ENG Quick turn off/lock screen Lens quick release button Main interface V-mount Light effect selection Avant Max Lens Menu settings Power switch / Color temperature adjustment Quick release button for Max Battery 99Wh /AC Dual Port Adapter Brightness adjustment DC port: output 12V, Max 3A Type-C port: can simultaneously output maximum power of 45W each D-TAP port: input Max 7A, output 14.4V Max 15A DC port: Input DC 12-20V, Max 6.7A Operating instructions Lens disassembly/installation: 1. Press and hold the quick release button, rotate the lens counterclockwise and pull it out. 2. Insert the lens into the lamp body slot and rotate it clockwise to fix it for installation. V-mount Battery capacity display button Power on/off operation: 1. Long press the power switch for 1.5 seconds, then turn the knob clockwise to turn on the light. 2. Long press the power switch for 1.5 seconds to turn off the light. Main interface: 1. Short press the "Main Interface" button to enter the main interface. 2. Rotate the brightness adjustment knob and color temperature adjustment knob to adjust the brightness and color temperature separately. 3. Short press the brightness adjustment knob or color temperature adjustment knob to quickly adjust the gear: the brightness can be quickly adjusted to 0%, 25%, 50%, 75%, and 100%; The color temperature can be quickly adjusted to 2700K, 3500K, 4500K, 5500K, 6500K. Light effect selection: 1. Short press the "Light Effect Selection" button to enter the light effect selection interface. Rotate the power switch knob to select the light effect. 2. There are a total of 8 lighting effects to choose from. Menu selection: 1. Short press the "Menu Settings" button to enter the main menu interface, rotate the power switch knob to select the menu. 2. Short press the power switch knob to enter the submenu, and rotate the power switch knob to select the submenu. Quick turn off / lock screen: 1. Short press the "Quick Turn Off/Lock Screen" button to quickly turn off/on the lights. 2. Long press the "Quick Turn Off/Lock Screen" button to lock the screen, but after locking the screen, no interface operations can be performed. WARNINGS • Please thoroughly read the manual prior to operating the product and operate in strict accordance with the manual. Don't disassemble the product by yourself. If the productrequires repair, contact our maintenance personnel. Product failures caused by unauthorized disassembly arenot covered by warranty, and will be chargeable. The product is designed to be actively cooled by fans. Don't block the fan ducts of the product during operation. Don't touch the heat generating parts of the product during operation to avoid scalding injury. The power must be switched off during set-up and break down of the product. Don't submerge the product in water or other liquid/s toavoid safety risk and product failure. Allow the product to properly cool after each use before storage. Only use the originally supplied accessories to avoid product failure/s. Only use thesupplied charging adapter and power cableto avoid damage to the product. • • • • • • • • • Disassembly and assembly of battery pack/AC adapter: Disassembly: Hold down the quick release button and pull out the battery pack/AC adapter upwards. Installation: Align the V-mount connector with the slot and insert it downwards. Short press the battery capacity display button on the battery pack to display real-time power. Product Specifications AVANT MAX -10~40°C / 14~104°F 7000lm 80W 5700lm AC 100-240V, 50~60Hz DC 12-24V 14.4V 6900mAh, 99.36Wh 96 96 2700-6500K 0-100% Bluetooth 20m / 65.6ft 22dB@1m IP54 IP65 122.9x93.8x99mm / 4.84x3.69x3.9in 915g / 2.02lbs Power Lumens(6500K) Lumens(2700K) Battery(DC powered version) CRI TLCI CCT Dimming Wireless Method Wireless Operating Range Dimension (Light) NetWeight (Light) Input Operating Temperature Noise Protection Class (light) Protection Class (battery pack) INSPECTION: PASS Warranty Card Product No. Product name Purchase date User name User telephone User address Dealer stamp AEC LIGHTING SOLUTIONS CO., LTD. Add: 2548 Bao’an Highway, Jiading District, Shanghai 201801, China App Download You can download the Hobolite app in the (Apple) App Store and Google Play store by scanning the following QR code. www.hobolite.com Hobolite Hobolite Scan QR code Warranty Ter ms We provide a two-year warranty period for the original buyer of the product. For the detailed warranty scope, please log in our website www.hobolite.com. The warranty does not cover: Important notes: The warranty will be invalid if: Damage caused by improper use, false wiring, incompatible, poor quality or mis-adjusted external devices. • • • Damage to the appearance of the product from mishandling or abuse. •Exposure to rain or water. • • • Damage caused by transportation. Please contact your dealer to issue a claim. Please retain your original purchase invoice and warranty card and ensure that the complete supplier information is on the invoice, including the purchase date and product serial number, which will be needed when making a claim against the warranty. The product serial number has been torn off or can't be identified. The product has been repaired or modified by unauthorized persons. FCC Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined…
