2ANLP-MINIMAXHOBOLITE MINI MAX

40W BI-COLOR CONTINUOUS LED LIGHT OPERATION MANUAL MINI MAX Features ENG Quick turn off/lock screen Lens quick release button Main interface V-mount Light effect selection Menu settings Power switch / Color temperature adjustment Quick release button for Max Battery 99Wh /AC Dual Port Adapter Brightness adjustment DC port: output 12V, Max 3A Type-C port: can simultaneously output maximum power of 45W each D-TAP port: input Max 7A, output 14.4V Max 15A Operating instructions Lens disassembly/installation: 1. Press and hold the quick release button, rotate the lens counterclockwise and pull it out. 2. Insert the lens into the lamp body slot and rotate it clockwise to fix it for installation. V-mount Battery capacity display button Mini Max Adjustable Lens Power on/off operation: 1. Long press the power switch for 1.5 seconds, then turn the knob clockwise to turn on the light. 2. Long press the power switch for 1.5 seconds to turn off the light. Main interface: 1. Short press the "Main Interface" button to enter the main interface. 2. Rotate the brightness adjustment knob and color temperature adjustment knob to adjust the brightness and color temperature separately. 3. Short press the brightness adjustment knob or color temperature adjustment knob to quickly adjust the gear: the brightness can be quickly adjusted to 0%, 25%, 50%, 75%, and 100%; The color temperature can be quickly adjusted to 2700K, 3500K, 4500K, 5500K, 6500K. Light effect selection: 1. Short press the "Light Effect Selection" button to enter the light effect selection interface. Rotate the power switch knob to select the light effect. 2. There are a total of 8 lighting effects to choose from. Menu selection: 1. Short press the "Menu Settings" button to enter the main menu interface, rotate the power switch knob to select the menu. 2. Short press the power switch knob to enter the submenu, and rotate the power switch knob to select the submenu. Quick turn off / lock screen: 1. Short press the "Quick Turn Off/Lock Screen" button to quickly turn off/on the lights. 2. Long press the "Quick Turn Off/Lock Screen" button to lock the screen, but after locking the screen, no interface operations can be performed. WARNINGS • Please thoroughly read the manual prior to operating the product and operate in strict accordance with the manual. Don't disassemble the product by yourself. If the productrequires repair, contact our maintenance personnel. Product failures caused by unauthorized disassembly arenot covered by warranty, and will be chargeable. The product is designed to be actively cooled by fans. Don't block the fan ducts of the product during operation. Don't touch the heat generating parts of the product during operation to avoid scalding injury. The power must be switched off during set-up and break down of the product. Don't submerge the product in water or other liquid/s toavoid safety risk and product failure. Allow the product to properly cool after each use before storage. Only use the originally supplied accessories to avoid product failure/s. Only use thesupplied charging adapter and power cableto avoid damage to the product. • • • • • • • • • Disassembly and assembly of battery pack/AC adapter: Disassembly: Hold down the quick release button and pull out the battery pack/AC adapter upwards. Installation: Align the V-mount connector with the slot and insert it downwards. Short press the battery capacity display button on the battery pack to display real-time power. Product Specifications MINI MAX -10~40°C / 14~104°F 4000lm 40W 3200lm AC 100-240V, 50~60Hz DC 12-24V 14.4V 6900mAh, 99.36Wh 96 96 2700-6500K 0-100% Bluetooth 20m / 65.6ft 22dB@1m IP54 IP65 110x89.3x98.9mm / 4.33x3.52x3.89in 695g / 1.53lbs Power Lumens(6500K) Lumens(2700K) Battery(DC powered version) CRI TLCI CCT Dimming Wireless Method Wireless Operating Range Dimension (Light) NetWeight (Light) Input Operating Temperature Noise Protection Class (light) Protection Class (battery pack) INSPECTION: PASS Warranty Card Product No. Product name Purchase date User name User telephone User address Dealer stamp AEC LIGHTING SOLUTIONS CO., LTD. Add: 2548 Bao’an Highway, Jiading District, Shanghai 201801, China App Download You can download the Hobolite app in the (Apple) App Store and Google Play store by scanning the following QR code. www.hobolite.com Hobolite Hobolite Scan QR code Warranty Terms We provide a two-year warranty period for the original buyer of the product. For the detailed warranty scope, please log in our website www.hobolite.com. The warranty does not cover: Important notes: The warranty will be invalid if: Damage caused by improper use, false wiring, incompatible, poor quality or mis-adjusted external devices. • • • Damage to the appearance of the product from mishandling or abuse. •Exposure to rain or water. • • • Damage caused by transportation. Please contact your dealer to issue a claim. Please retain your original purchase invoice and warranty card and ensure that the complete supplier information is on the invoice, including the purchase date and product serial number, which will be needed when making a claim against the warranty. The product serial number has been torn off or can't be identified. The product has been repaired or modified by unauthorized persons. FCC Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o…

Text truncated - open the document above for the full version.

* the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. AEC Lighting Solutions Co., Ltd U.S. Agent Designation for Service of Process - Certification Attestation Letter DATE 2024/8/22 ATTN.: Reviewing Engineer FCC ID: 2ANLP-MINIMAX Applicant FRN: 0026784769 Per section 2.911(d)(7) of the FCC rules, AEC Lighting Solutions Co., Ltd (“the applicant”)certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process Company Name: HOBOLITE LLC. FRN: 0033478256 Physical U.S. Company Address: 401N MICHIGAN AVE STE 1200, CHICAGO, IL 60611, United States Agent name: Aixia Bian Agent Email Address: [email protected] Tel: 507513-3745 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed: Printed name: Bruce li Title: CQO Company Name: AEC Lighting Solutions Co., Ltd Date: 8/22/2024 Agent Signed (if different to Applicant): Signed: Signed: Printed name: Aixia Bian Title: Compliance manager Company Name: HOBOLITE LLC. Date: 8/22/2024

AEC Lighting Solutions Co., Ltd. (August 16, 2024) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 ATTN.: Reviewing Engineer FCC ID: FCC ID: 2ANLP-MINIMAX AEC Lighting Solutions Co., Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. AEC Lighting Solutions Co., Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: Name Bruce Li Position Manager Company Name AEC Lighting Solutions Co., Ltd Address No.2548 Baoan Road Jiading District Shanghai, 201801 China Tel 86-21-69153369 Fax 86-21-69153321 Email [email protected]

Differences Description We AEC Lighting Solutions Co., Ltd. state: Product name: HOBOLITE MINI MAX Model: MINI MAX, 102004, 102005, 102006 All models of all models of PCB design, software, electric circuit, radio frequency characteristics, appearance are consistent Signature: Name Bruce Li Position Manager Company Name AEC Lighting Solutions Co., Ltd Address No.2548 Baoan Road Jiading District Shanghai, 201801 China Tel 86-21-69153369 Fax 86-21-69153321 Email [email protected]

AEC Lighting Solutions Co., Ltd. (August 16, 2024) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (HOBOLITE MINI MAX / MINI MAX, SUK, 102004, 102005, 102006 # 2ANLP-MINIMAX #) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Schematics, Block diagram, Operation description) required to be submitted with this application be permanently withheld from public review. These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Please contact me if there is any information you may need. Sincerely, Signature: Name Bruce Li Position Manager Company Name AEC Lighting Solutions Co., Ltd Address No.2548 Baoan Road Jiading District Shanghai, 201801 China Tel 86-21-69153369 Fax 86-21-69153321 Email [email protected]

AEC Lighting Solutions Co., Ltd. (August 16, 2024) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen Alpha Product Testing Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name Bruce Li Position Manager Company Name AEC Lighting Solutions Co., Ltd Address No.2548 Baoan Road Jiading District Shanghai, 201801 China Tel 86-21-69153369 Fax 86-21-69153321 Email [email protected]

FCC ID: 2ANLP-MINIMAX FCC ID: 2ANLP-MINIMAX FCC ID: 2ANLP-MINIMAX FCC ID: 2ANLP-MINIMAX

FCC ID: 2ANLP-MINIMAX FCC ID: 2ANLP-MINIMAX FCC ID: 2ANLP-MINIMAX FCC ID: 2ANLP-MINIMAX FCC ID: 2ANLP-MINIMAX FCC ID: 2ANLP-MINIMAX FCC ID: 2ANLP-MINIMAX FCC ID: 2ANLP-MINIMAX FCC ID: 2ANLP-MINIMAX TX ANT

FCC ID: 2ANLP-MINIMAX RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2480MHz: 4.716 dBm(2.962 mW) output power] (2.962mW /5mm) ·[√2.480 (GHz)]= 0.933 <3.0 for 1-g SAR Then SAR evaluation is not required

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008300895 Website: http://www.a-lab.cn/certificate FCC TEST REPORT FCC ID: 2ANLP-MINIMAX On Behalf of AEC Lighting Solutions Co., Ltd. HOBOLITE MINI MAX Model No.: MINI MAX, 102004, 102005, 102006 Prepared for : AEC Lighting Solutions Co., Ltd. Address : No. 2548 Baoan Road Jiading District, 201801 Shanghai, P.R. China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Report Number : A2406039-C02-R01 Date of Receipt : June 11, 2024 Date of Test : June 11, 2024 - August 22, 2024 Date of Report : August 22, 2024 Version Number : V0 Test Result : Pass Page 2 of 38 Report No.: A2406039-C02-R01 TABLE OF CONTENTS Description Page 1. Summary of Standards And Results -------------------------------------------------------------------------------- 5 1.1. Description of Standards and Results ------------------------------------------------------------------------ 5 2. General Information ------------------------------------------------------------------------------------------------------ 6 2.1. Description of Device (EUT) ------------------------------------------------------------------------------------ 6 2.2. Accessories of Device (EUT) ----------------------------------------------------------------------------------- 7 2.3. Tested Supporting System Details----------------------------------------------------------------------------- 7 2.4. Block Diagram of connection between EUT and simulators -------------------------------------------- 7 2.5. Test Mode Description -------------------------------------------------------------------------------------------- 7 2.6. Test Conditions ----------------------------------------------------------------------------------------------------- 8 2.7. Test Facility ---------------------------------------------------------------------------------------------------------- 8 2.8. Measurement Uncertainty --------------------------------------------------------------------------------------- 8 2.9. Test Equipment List ----------------------------------------------------------------------------------------------- 9 3. Spurious Emission ------------------------------------------------------------------------------------------------------- 10 3.1. Test Limits ---------------------------------------------------------------------------------------------------------- 10 3.2. Test Procedure ---------------------------------------------------------------------------------------------------- 12 3.3. Test Setup ---------------------------------------------------------------------------------------------------------- 13 3.4. Test Results -------------------------------------------------------------------------------------------------------- 14 4. Power Line Conducted Emission ----------------------------------------------------------------------------------- 20 4.1. Test Limits ---------------------------------------------------------------------------------------------------------- 20 4.2. Test Procedure ---------------------------------------------------------------------------------------------------- 20 4.3. Test Setup ---------------------------------------------------------------------------------------------------------- 20 4.4. Test Results -------------------------------------------------------------------------------------------------------- 20 5. Conducted Maximum Output Power ------------------------------------------------------------------------------- 23 5.1. Test limits ----------------------------------------------------------------------------------------------------------- 23 5.2. Test Procedure ---------------------------------------------------------------------------------------------------- 23 5.3. Test Setup ---------------------------------------------------------------------------------------------------------- 23 5.4. Test Results -------------------------------------------------------------------------------------------------------- 23 6. Peak Power Spectral Density ----------------------------------------------------------------------------------------- 24 6.1. Test limits ----------------------------------------------------------------------------------------------------------- 24 6.2. Test Procedure ---------------------------------------------------------------------------------------------------- 24 6.3. Test Setup ---------------------------------------------------------------------------------------------------------- 24 6.4. Test Results -------------------------------------------------------------------------------------------------------- 24 7. Bandwidth ------------------------------------------------------------------------------------------------------------------ 27 7.1. Test limits ----------------------------------------------------------------------------------------------------------- 27 7.2. Test Procedure ---------------------------------------------------------------------------------------------------- 27 7.3. Test Setup ---------------------------------------------------------------------------------------------------------- 27 7.4. Test Results -------------------------------------------------------------------------------------------------------- 27 8. Band Edge Check -------------------------------------------------------------------------------------------------------- 32 8.1. Test limits ----------------------------------------------------------------------------------------------------------- 32 8.2. Test Procedure ---------------------------------------------------------------------------------------------------- 32 8.3. Test Setup --------------------------------…

Text truncated - open the document above for the full version.

Frequency（Hz）EfficiencyGain（dBi） 240000000032%-0.41平果图 241000000029%-0.92 242000000026%-1.41 243000000025%-1.46 244000000023%-1.51 245000000022%-1.73 246000000020%-1.86 247000000020%-1.74 248000000019%-1.94 249000000018%-2.19 250000000017%-2.24 E1 SideX-Z E2面X-Y H面Y-Z -40 ̊C ~ +85 ̊C Working Frequency Range Gain Azimuth Beamwidth Impedance Operation Temperature Key component name Model PCB antenna L14.0mm W7.1mm T1.0mm 2.4 GHz ～ 2.5GHz -0.41 dBi (max) Omni-directional 50Ω Specifications/ParametersManufacturer Suzhou Peilin Network Technology Co., Ltd14mm*7.1mm*1.0mmRabbit-B-ANT

FCC ID: 2ANLP-MINIMAX 1.1. Photo of Radiated Emission test FCC ID: 2ANLP-MINIMAX 1.2. Photo of Conducted Emission test
