2ANLP-HOBOMINI01PROFESSIONAL BI-COLOR LED LIGHT

WORLD DESIGN INDEX TOP 10 2018-2022 Lighting MINI PROFESSIONAL, PORTABLE CONTINUOUS LIGHT 01 MINI PROFESSIONAL, PORTABLE CONTINUOUS LIGHT OPERATION MANUAL MINI 02 PROFESSIONAL, PORTABLE CONTINUOUS LIGHT PRODUCT INTRODUCTION MINI — a stylish micro-studio in the palm of your hand, the 20W Mini can go with you anywhere, so you get the perfect shot to share with your audience MINI MINI 03 WARNINGS • Don't disassemble the product by yourself. If the product requires repair, kindly contact our maintenance personnel. Product failures caused by unauthorized disassembly are not covered by warranty, and hence their repair will be chargeable; • The product is designed to be actively cooled by fans. Don't block the fan ducts of the product during operation. The product is a high power light source, so the user should not in any case, operate the product if it is covered. Don't touch the heat generating parts of the product during operation to avoid scalding injury; • The power must be switched off during assembly before operation and disassembly after operation; • Don't submerge the product in water or other liquid/s to avoid safety risk and product failure; • After product use, touch, disassemble and store the product only after it has been sufficiently cooled to avoid scald injury; • The product contains batteries. Don't store the batteries in hot environments and keep them away from fire; • Please only use originally supplied accessories to avoid product failure/s; • Please only use the brand-specific adapter and power cable supplied to avoid damage to the product. • Please thoroughly read the manual prior to operating the product and operate the product in strict accordance with the manual; MINI 04 Kit Umbrella Reflector Port, Setting menu Setting Menu/ Brightness Adjustment Color Temperature Adjustment/ Power On/Off Power Plug Port 05 MINI Features Lit Bluetooth on Unlit Unlit Blue and lit Red and flashing Red and flashing Bluetooth off Fan on Brightness exceeds 20% when fan is off Fan off New firmware revision ready to be upgraded Installation 1.Installation of desktop tripod Align the nut of the desktop tripod with the screw mount at the bottom of the light body and then fasten it. 1 2 3 2.Installation of barndoor Align the mounts of the barndoor with the edge of the lens and then fasten it. 1 2 06 MINI * The honeycomb plate, filter disc, and dome diffuser are equipped with magnets, and hence can be mounted together with the barndoor. * The desktop tripod is contained in creator kit, or it can be separately purchased. Power Supply 1.This product can be charged through the Type-C port at the back of the light body. 07 MINI Operation 1.Press the color temperature adjustment (power on/off) knob and then rotate it according to the tutorial on screen. Startup interface 2.The power can be switched off by long pressing the color temperature adjustment knob (Setting Menu) for 0.5 seconds. ON 08 MINI 3.Condenser lens The beam angle can be adjusted by rotating the condenser lens. 09 MINI 4.Light control 4.1 Brightness adjustment Rotate the brightness adjustment knob, range is 1% - 100% (16 lm – 1,600 lm). The brightness unit can be switched to INT (%) or LM in setting menu. 4.2 Color temperature adjustment Rotate the color temperature adjustment knob to adjust the color temperature, range is 2,700 K - 6,500 K. 10 MINI 4.3 Lighting effects Enter the effects page via setting menu to activate different lighting effects. Place the NFC sensing area of the mobile device against the area with "NFC" mark on the light body, this will immediately launch the Hobolite App. 5.NFC connection NFC 11 MINI Flash Effect Flame ScreenLightning TV Pulse Effect Fireworks ShutterExplosion 6.Bluetooth match & reset Select the bluetooth - pairing & reset option in the setting page to reset the bluetooth of the light and activate the pairing state for 60s. If pairing fails, repeat the operation. 1 2 On Off 7.Firmware update When a firmware is ready to be upgraded, a red " " will appear at the upper right corner of the screen. 12 MINI 13 MINI On Off www.hobolite.com Hobolite Hobolite Scan QR code App Download You can download the Hobolite app in the (Apple) App Store and Google Play store by scanning the following QR code. Please visit the official website (www.hobolite.com) for more detailed instructions. 14 MINI Product Specifications MINI Power Luminous Flux (6500K) Luminous Flux (2700K) Battery CRI TLCI CCT Dimming Wireless Method Wireless Operating Range DimensionLight Net WeightLight Input Operating Temperature Noise 1600lm 20W 1200lm AC 100-240V, 50~60Hz DC 5V/9V 7.4V 3000mAh, 22.2Wh 96 96 2700-6500K 0-100% Bluetooth 20m / 65.6ft 26db@1m -10~40°C / 14~104°F 65x82.6x104.2mm / 2.56x3.25x4.1in 430g / 0.95Lbs LUXFC 2700K 4000K 6500K 2702 3200 3530 251 297 328 MINI LUXFC 2700K 4000K 6500K 300 353 400 28 33 37 MINI LUXFC 2700K 4000K 6500K 130 155 175 12 14 16 MINI 15 1M - NO ACCESSORY (MINI - ADJUST THE LENS TO THE HIGHEST FLOOD LIGHT GRADE) MINI Optical Properties 3M - NO ACCESSORY (MINI - ADJUST THE LENS TO THE HIGHEST FLOOD LIGHT GRADE) 5M - NO ACCESSORY (MINI - ADJUST THE LENS TO THE HIGHEST FLOOD LIGHT GRADE) LUXFC 2700K 4000K 6500K 6000 7200 8060 557 669 749 MINI LUXFC 2700K 4000K 6500K 701 853 954 65 79 89 MINI LUXFC 2700K 4000K 6500K 278 342 380 26 32 35 MINI 16 1M - ADD HOBOLITE LENS (MINI - ADJUST THE LENS TO THE HIGHEST SPOT LIGHT GRADE) 3M - ADD HOBOLITE LENS (MINI - ADJUST THE LENS TO THE HIGHEST SPOT LIGHT GRADE) 5M - ADD HOBOLITE LENS (MINI - ADJUST THE LENS TO THE HIGHEST SPOT LIGHT GRADE) MINI Optical Properties (LM) CCT(K) DOMINANT WAVELENGTH(NM) TCLI CQS 969510596959598969596969894 RFRGRARER1R2R3R4R5R6R7R8 MINI 3454K 100%LM 1431.73327583.599 TEST ITEM R9 87979385969797 R10R11R12R13R14R15 (LM) CCT(K) DOMINANT WAVELENGTH(NM) TCLI CQS 979410595939197948392959891 RFRGRARER1R2R3R4R5R6R7R8 MINI 3454K 10%LM 187.183495583.598 TEST ITEM R9 78959495969693 R10R11R12R13R14R15 (LM) CCT(K) DOMINANT WAVELENGTH(NM) TCLI CQS …

Text truncated - open the document above for the full version.

* the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. AEC Lighting Solutions Co., Ltd U.S. Agent Designation for Service of Process - Certification Attestation Letter 3/28/2023 Nem ko Nort h America, Inc. 303 Ri ver Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2ANLP-HOBOMINI01, 2ANLP-HOBOANVAT01, 2ANLP-HOBOPRO01, 2ANLP- HOBOCONTROL Per sect ion 2.911(d)(7) of th e FCC rules, AE C Lighting Solutions Co. , Ltd (“t he applicant”) certifies tha t the equipment for whic h authorization is sough t is designated to th e following U.S. agent* fo r service of process: Comp any Name : HOBOLITE LCC Physical U.S. Company Address: 401N MICHIGAN AVE STE 1200, CHICAGO, IL 60611 Agent contact name/Title : Weisun Rao/Compliance manager Agent Em ail Address: [email protected] Te l No. : (507)513-3745 FRN No. : 0033478256 Th e above contact perso n accepts th e obligation fo r servic e of process. Th e applicant accepts to maint ain an agent fo r no less th an one yea r after t he grante e has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different to Applicant): Signed: Printed name: Astro Ma Title: Lab supervisor Company Name: AEC Lighting Solutions Co., Ltd Date: 3/28/2023 Signed: Printed name: Weisun Rao Title: Compliance manager Company Name: HOBOLITE LCC Date: 3/28/2023

AEC Lighting Solutions Co., Ltd Covered Equipment Certification Attestation Letter DATE Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2ANLP-HOBOMINI01, 2ANLP-HOBOANVAT01, 2ANLP-HOBOPRO01, 2ANLP-HOBOCONTROL AEC Lighting Solutions Co., Ltd (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. AEC Lighting Solutions Co., Ltd (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Astro Ma Title: Lab supervisor Company Name: AEC Lighting Solutions Co., Ltd Date: 3/21/2023 March 21, 2023

March 7, 2023 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ANLP-HOBOMINI01 Product Name: PROFESSIONAL BI-COLOR LED LIGHT Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential  BOM Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name Astro Ma Position Lab supervisor Company Name AEC Lighting Solutions Co., Ltd Address 2548 Bao’an Highway, Jiading District, Shanghai 201801, China Tel 86-21-69153369 Fax 86-21-69153321 Email [email protected]

FCC ID: 2ANLP-HOBOMINI01 FCC ID: 2ANLP-HOBOMINI01 FCC ID: 2ANLP-HOBOMINI01 FCC ID: 2ANLP-HOBOMINI01

4.5cm 2.5cm Label Location FCC ID: 2ANLP-HOBOMINI01 AEC Lighting Solutions Co., Ltd Product name: PROFESSIONAL BI-COLOR LED LIGHT Model No.: MINI 102001 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AVG9-DMS02 FCC ID: 2AVG9-DMS02 FCC ID: 2AVG9-DMS02 FCC ID: 2AVG9-DMS02 FCC ID: 2AVG9-DMS02 FCC ID: 2AVG9-DMS02 FCC ID: 2AVG9-DMS02 ANT FCC ID: 2AVG9-DMS02 FCC ID: 2AVG9-DMS02 FCC ID: 2AVG9-DMS02 FCC ID: 2AVG9-DMS02 FCC ID: 2AVG9-DMS02

FCC ID: 2ANLP-HOBOMINI01 Prediction of MPE at a given distance 1. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) 2. Test Procedure Equation from page 18 of OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to the antenna G = numeric gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna FCC ID: 2ANLP-HOBOMINI01 3. Result Worse case is as below: Mode Frequency (MHz) Prediction distance (cm) RF output power MPE (mW/cm 2 ) Limit (mW/cm 2 ) SAR Test Exclusion dBm mW BLE GFSK 2402 20 8.835 7.6472 0.00241 1 Yes Then SAR evaluation is not required.

FCC TEST REPORT FCC ID: 2ANLP-HOBOMINI01 On Behalf of AEC Lighting Solutions Co., Ltd PROFESSIONAL BI-COLOR LED LIGHT Model No.: MINI 102001 Prepared for : AEC Lighting Solutions Co., Ltd Address : 2548 Bao’an Highway, Jiading District, Shanghai 201801, China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2209170-C01-R03 Date of Receipt : October 8, 2022 Date of Test : October 8, 2022-December 15, 2022 Date of Report : December 15, 2022 Version Number : V0 Page 2 of 52 Report No.: A2209170-C01-R03 TABLE OF CONTENTS Description Page 1. Summary Of Standards And Results -------------------------------------------------------------------------------- 5 1.1. Description of Standards and Results ------------------------------------------------------------------------ 5 2. General Information ------------------------------------------------------------------------------------------------------ 6 2.1. Description of Device (EUT) ------------------------------------------------------------------------------------ 6 2.2. Accessories of Device (EUT) ----------------------------------------------------------------------------------- 7 2.3. Tested Supporting System Details----------------------------------------------------------------------------- 7 2.4. Block Diagram of connection between EUT and simulators -------------------------------------------- 7 2.5. Test Mode Description -------------------------------------------------------------------------------------------- 7 2.6. Test Conditions ----------------------------------------------------------------------------------------------------- 7 2.7. Test Facility ---------------------------------------------------------------------------------------------------------- 8 2.8. Measurement Uncertainty --------------------------------------------------------------------------------------- 8 2.9. Test Equipment List ----------------------------------------------------------------------------------------------- 9 3. Spurious Emission ------------------------------------------------------------------------------------------------------- 11 3.1. Test Limits ---------------------------------------------------------------------------------------------------------- 11 3.2. Test Procedure ---------------------------------------------------------------------------------------------------- 12 3.3. Test Setup ---------------------------------------------------------------------------------------------------------- 12 3.4. Test Results -------------------------------------------------------------------------------------------------------- 14 4. Power Line Conducted Emission ----------------------------------------------------------------------------------- 20 4.1. Test Limits ---------------------------------------------------------------------------------------------------------- 20 4.2. Test Procedure ---------------------------------------------------------------------------------------------------- 20 4.3. Test Setup ---------------------------------------------------------------------------------------------------------- 20 4.4. Test Results -------------------------------------------------------------------------------------------------------- 21 5. Conducted Maximum Output Power ------------------------------------------------------------------------------- 23 5.1. Test limits ----------------------------------------------------------------------------------------------------------- 23 5.2. Test Procedure ---------------------------------------------------------------------------------------------------- 23 5.3. Test Setup ---------------------------------------------------------------------------------------------------------- 23 5.4. Test Results -------------------------------------------------------------------------------------------------------- 23 6. Peak Power Spectral Density ----------------------------------------------------------------------------------------- 24 6.1. Test limits ----------------------------------------------------------------------------------------------------------- 24 6.2. Test Procedure ---------------------------------------------------------------------------------------------------- 24 6.3. Test Setup ---------------------------------------------------------------------------------------------------------- 24 6.4. Test Results -------------------------------------------------------------------------------------------------------- 24 7. Bandwidth ------------------------------------------------------------------------------------------------------------------ 27 7.1. Test limits ----------------------------------------------------------------------------------------------------------- 27 7.2. Test Procedure ---------------------------------------------------------------------------------------------------- 27 7.3. Test Setup ---------------------------------------------------------------------------------------------------------- 27 7.4. Test Results -------------------------------------------------------------------------------------------------------- 27 8. Band Edge Check -------------------------------------------------------------------------------------------------------- 31 8.1. Test limits ----------------------------------------------------------------------------------------------------------- 31 8.2. Test Procedure ---------------------------------------------------------------------------------------------------- 31 8.3. Test Setup ---------------------------------------------------------------------------------------------------------- 31 8.4. Test Results -------------------------------------------------------------------------------------------------------- 31 9. Antenna Requirement ----------------------------------------------------------------------------------------------…

Text truncated - open the document above for the full version.

Approval sheet Page 1 of 9 ASC_RFANT5220110A0T_V15 Jun. 2014 Manufacturer Walsin Technology Corporation 10th Floor, 480 Ruiguang Road, Neihu District, Taipei *Contents in this sheet are subject to change without prior notice. RFANT Pb free Series – RoHS Compliance MULTILAYER CERAMIC ANTENNA Halogens Free Product 2.4 GHz ISM Band Working Frequency P/N: RFANT5220110A0T Approval sheet Page 2 of 9 ASC_RFANT5220110A0T_V15 Jun. 2014 FEATURES 1. Surface Mounted Devices with a small dimension of 5.2 x 2.0 x 1.1 mm 3 meet future miniaturization trend. 2. Embedded and LTCC (Low Temperature Co-fired Ceramic) technology is able to future integrate with system design as well as beautifying the housing of final product. 3. High Stability in Temperature / Humidity Change APPLICATIONS 1. Bluetooth 2. Wireless LAN 3. HormRF 4. ISM band 2.4GHz wireless applications CONSTRUCTION DIMENSIONS Figure Symbol Dimension (mm) L 5.20 ± 0.20 W 2.00 ± 0.20 T 1.15 ± 0.10 A 0.40 ± 0.25 PIN Connection 1 Feeding 2 Identification Mark 3 Soldering terminal P1 P3 P2 Approval sheet Page 3 of 9 ASC_RFANT5220110A0T_V15 Jun. 2014 ELECTRICAL CHARACTERISTICS RFANT5220110A0T Specification Working Frequency Range 2.4 GHz ～ 2.5GHz Gain 2 dB (Typical) VSWR 2 max. Polarization Linear Azimuth Beamwidth Omni-directional Impedance 50Ω Rated Power (max.) 3 Watts Maximum Input Power 5 Watts for 5 minutes Operation Temperature -40 ̊C ~ +85 ̊C Remark: The specification is defined based on the test board dimension as in below SOLDER LAND PATTERN DESIGN Figure Approval sheet Page 4 of 9 ASC_RFANT5220110A0T_V15 Jun. 2014 Antenna on Test Board ( FR4 Thickness 0.8mm) Antenna S11 on Test Board Bandwidth >150MHzBandwidth >150MHz Empty Area Empty Area 18x9 mm 50Ω ΩΩ ΩFeed line GROUND 30x18 mm 1mm 3.3mm 1.5mm WTC 2.5mm 18mm Empty Area Empty Area 18x9 mm 50Ω ΩΩ ΩFeed line GROUND 30x18 mm 1mm 3.3mm 1.5mm WTC 2.5mm 18mm Approval sheet Page 5 of 9 ASC_RFANT5220110A0T_V15 Jun. 2014 RADIATION PATTERN Radiation Pattern and Gain were dependent on measurement board design. The specification of RFANT5220110A0T antenna was measured based on the PCB size and installation position as shown in the below figure Test Board Vertical Horizontal Y - Z Plane Average Gain= -0.82 dBi Peak Gain = 1.69 dBi Average Gain =-3.22 dBi Peak Gain= -5.42 dBi Average Gain=-8.98 dBi X - Z Plane Average Gain=-0.91 dBi Peak Gain= -5.97 dBi Average Gain=-3.24dBi Peak Gain= 2.66 dBi Average Gain= -8.61 dBi X - Y Plane Average Gain= -0.68 dBi Peak Gain= -5.97 dBi Average Gain=-3.12 dBi Peak Gain= 2.59 dBi Average Gain= -9.24 dBi Y Z WTC X Y Z WTC X Y Z WTC X Y Z WTC X Y Z WTC X Y Z WTC X z Y z Y z X z X X Y X Y Empty Area GROUND 30x18 mm WTC X Y Z Empty Area GROUND 30x18 mm WTC X Y Z X Y Z Approval sheet Page 6 of 9 ASC_RFANT5220110A0T_V15 Jun. 2014 RELIABILITY TEST Test item Test condition / Test method Specification Solderability JIS C 0050-4.6 JESD22-B102D *Solder bath temperature：235 ± 5°C *Immersion time：2 ± 0.5 sec Solder：Sn3Ag0.5Cu for lead-free At least 95% of a surface of each terminal electrode must be covered by fresh solder. Leaching (Resistance to dissolution of metallization) IEC 60068-2-58 *Solder bath temperature：260 ± 5°C *Leaching immersion time：30 ± 0.5 sec Solder : SN63A Loss of metallization on the edges of each electrode shall not exceed 25%. Resistance to soldering heat JIS C 0050-5.4 *Preheating temperature：120~150°C, 1 minute. *Solder temperature：270±5°C *Immersion time：10±1 sec Solder：Sn3Ag0.5Cu for lead-free Measurement to be made after keeping at room temperature for 24±2 hrs No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Loss of metallization on the edges of each electrode shall not exceed 25%. Drop Test JIS C 0044 Customer’s specification. *Height：75 cm *Test Surface：Rigid surface of concrete or steel. *Times：6 surfaces for each units；2 times for each side. No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Vibration JIS C 0040 *Frequency：10Hz~55Hz~10Hz(1min) *Total amplitude：1.5mm *Test times：6hrs.(Two hrs each in three mutually perpendicular directions) No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Adhesive Strength of Termination JIS C 0051- 7.4.3 *Pressurizing force： 5N(≦0603)；10N(>0603) *Test time：10±1 sec No remarkable damage or removal of the termination. Bending test JIS C 0051- 7.4.1 The middle part of substrate shall be pressurized by means of the pressurizing rod at a rate of about 1 mm/s per second until the deflection becomes 1mm/s and then pressure shall be maintained for 5±1 sec. Measurement to be made after keeping at room temperature for 24±2 hours No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Approval sheet Page 7 of 9 ASC_RFANT5220110A0T_V15 Jun. 2014 Temperature cycle JIS C 0025 1. 30±3 minutes at -40°C±3°C, 2. 10~15 minutes at room temperature, 3. 30±3 minutes at +85°C±3°C, 4. 10~15 minutes at room temperature, Total 100 continuous cycles Measurement to be made after keeping at room temperature for 24±2 hrs No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. High temperature JIS C 0021 *Temperature：85°C±2°C *Test duration：1000+24/-0 hours Measurement to be made after keeping at room temperature for 24±2 hrs No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Humidity (steady conditions) JIS C 0022 *Humidity：90% to 95% R.H. *Temperature：40±2°C *…

Text truncated - open the document above for the full version.

FCC ID: 2ANLP-HOBOMINI01 Radiated Emission FCC ID: 2ANLP-HOBOMINI01 Conducted Emission
