2AP35-SR07PM04H41Solar LED Light

Power Switch E SOLAR LED PATH LIGHT WITH MOTION SENSOR (FACTORY LINKED) ITEM: SR07PM04H-41 A: Solar Panel B: Pole 1 C: Pole 2 Motion Sensor TROUBLESHOOTING INSTRUCTIONS ASSEMBLY FOR FIRST TIME USE: Solar lights need to charge in full sunlight for 8 - 12 hours in direct sunlight, with the power switch in the “ON” position, to fully charge the battery. Insert the solar panel (Part A) into the pole 1 (PartB), Insert the pole 1 (PartB) into the pole 2 (Part C), pull out the ground stake (Part D) at the bottom of the pole 2 (Part C) and plug it back into the the pole 2 (Part C). Applying pressure to the pole, carefully insert the complete assembly (Part A, B & C) into the ground where desired. NOTE: If the ground is hard and packed, moisten the ground with water before inserting the stake to avoid breakage. If light doesn't turn on, remove battery, wipe both ends with a clean, dry cloth and reinstall battery. Check the battery to ensure that it is making secure contact with the terminals. If this doesn't work, replace with new battery. Slide the power switch to the "OFF" position. Use a Phillips head screwdriver to remove the 3 screws holding the base in place. Replace old battery with a new 3.7V, 800 mAh lithium (14500) rechargeable battery. Replace the base by aligning it properly and replacing the 3 screws removed earlier. Slide the power switch to the “ON” position. For optimal performance, place fixture in sunlight for 8-12 hours, with power switch in the “ON” position, to fully charge battery. For additional help and information regarding installation, contact Customer Service at 1-844-551-0680, 8am-5pm,CST Monday – Friday [email protected] WARNING: Do not dispose of lithium batteries in municipal waste stream or by re as batteries may explode. Do not open, short circuit, or destroy batteries. Dispose of batteries in accordance with Local, State, and Federal regulations. Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel cadmium, nickel metal hydride or lithium ion) batteries . and Westinghouse are trademarks of Westinghouse Electric Corporation. Used under license by Sky Rich Star Limited. All Rights Reserved. Solar panel Battery Screws Base SOME PARTS MAY COME PRE-ASSEMBLED Power Switch NOTE: The solar lights will stay on for 30 seconds when triggered by motion delivering up to 400 lumens and revert back to standby mode delivering up to 20 lumens until motion is detected. The solar lights use radio frequency technology to link. The solar lights should not be greater than 65.6 feet (20 m) apart for linked function to work properly. When one solar light is triggered by motion, all lights will activate and deliver up to 400 lumens. The package includes (4) solar lights. These (4) solar lights are factory linked, and can not be linked with more of the same type light or any other lights. NOTE: If there are performance or quality issues, all solar lights need to be replaced with another set. REPLACING THE BATTERY D: Ground Stake FCC WARNING Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Notes: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency enerqy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no quarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio / TV technician for help. RF EXPOSURE: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. S LUZ LED SOLAR CON SENSOR DE MOVIMIENTO (ENLACE DE FÁBRICA) ARTÍCULO: SR07PM04H-41 A: Panel solar B: Poste 1 C: Poste 2 Interruptor de encendido Sensor de movimiento SOLUCIÓN DE PROBLEMAS INSTRUCCIONES ENSAMBLE PARA USO PRIMERO: Es necesario cargar la lámpara solar á la luz directa del Sol durante 8 á 12 horas con el interruptor de alimentación en posición "on", para cargar total mente la batería. Si no se enciende la luz, extraiga la batería, limpie ambos extremos con un paño limpio y seco, y reinstale la batería. Revise la batería para asegurarse que estén haciendo contacto rmemente con las terminales. Si esto no funciona, reemplácelas con batería nuevas. Deslice el interruptor a su posición de "OFF" (apagado). Use un destornillador Phillips (estrella) para retirar los 3 tornillos que sostienen la base. Reemplace la batería antigua con un nueva batería recargable de litio (14500) de 3.7V, 800 mAh. Vuelva a colocar la base alineándola adecuadamente y vuelva a colocar los 8 tornillos que retiró anteriormente. Deslice el interruptor a su posición de "ON" (prendido). Para un rendimiento óptimo…

Text truncated - open the document above for the full version.

INTERNATIONAL DEVELOPMENT COMPANY 899 Henrietta Creek Road, Roanoke, Texas 76262, United States Confidentiality Request Date: 2022-12-15 FEDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 SUBJECT: FCC Application for FCC ID: 2AP35-SR07PM04H41 To whom it may concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. ☒ Block Diagram ☐ Tune-Up Information ☒ Operational Description ☐ Security Information ☒ Schematics ☐ Software Defined Radio (SDR) Information ☒ Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); ☒ External Photos ☒ Test Setup Photos ☒ Internal Photos ☒ User Manual ☐ For 45 days, pursuant to Public Notice DA 04-1705. or ☒ For 180 days pursuant to KDB 726920 D01. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signatory [zhiquan li, Manager]

INTERNATIONAL DEVELOPMENT COMPANY 899 Henrietta Creek Road, Roanoke, Texas 76262, United States POWER OF ATTORNEY Date: 2022-12-15 FEDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 SUBJECT: FCC Application for FCC ID: 2AP35-SR07PM04H41 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group (Shenzhen) Co., Ltd. Jandy So on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Testing Group (Shenzhen) Co., Ltd. Jandy So on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, INTERNATIONAL DEVELOPMENT COMPANY are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Signatory [zhiquan li, Manager]

Reference No.: WTH22X12242882W001 Page 2 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTH22X12242882W001 Page 3 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTH22X12242882W001 Page 4 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6

Reference No.: WTH22X12242882W001 Page 1 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTH22X12242882W001 Page 5 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 Reference No.: WTH22X12242882W001 Page 6 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Solder Board-Component View 3 Reference No.: WTH22X12242882W001 Page 7 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 4 Solder Board-Component View 5 Reference No.: WTH22X12242882W001 Page 8 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Antenna View

TK-SL-170 Antenna specification 序 号 Seri al 物料编码 Part No. 物料描述 Description数量 QTY.位置 Location NO. 备注 Remark All the material conform to the ROHS standards 1305000071577 2.4G Antenna 1007 26AWG white 67.5mm One end stripping 1.5mm Upper tin 1 Antenna White 67.5mm Immersion Tin 1.5mm

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 29 TEST REPORT Reference No. .................... : WTH22X12242882W001 FCC ID ................................ : 2AP35-SR07PM04H41 Applicant ........................... : INTERNATIONAL DEVELOPMENT COMPANY Address.............................. : 899 Henrietta Creek Road,Roanoke, Texas 76262 USA. Manufacturer ..................... : Zhongshan Quanxin Lighting & Electrical Corp., Ltd. Address.............................. : Zone A, Building 1, No.1, Hongji Road, West District, Zhongshan City, Guangdong Province Product Name ................... : Solar LED Light Model No... ......................... : SR07PM04H-41 Standards .......................... : FCC Part 15.249 Date of Receipt sample .... : 2022-12-02 Date of Test........................ : 2022-12-02 to 2022-12-12 Date of Issue ..................... : 2022-12-12 Test Report Form No. ....... : WTX_Part 15_249W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Mike Shi Silin Chen Reference No.: WTH22X12242882W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 29 TABLE OF CONTENTS 1. GENERAL INFORMATION ....................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .........................................................................4 1.2 TEST STANDARDS .................................................................................................................................................5 1.3 TEST METHODOLOGY ...........................................................................................................................................5 1.4 TEST FACILITY ......................................................................................................................................................5 1.5 EUT SETUP AND TEST MODE ..............................................................................................................................6 1.6 MEASUREMENT UNCERTAINTY .............................................................................................................................7 1.7 TEST EQUIPMENT LIST AND DETAILS ...................................................................................................................8 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 11 3. ANTENNA REQUIREMENTS .............................................................................................................................. 12 3.1 STANDARD APPLICABLE ..................................................................................................................................... 12 3.2 TEST RESULT ...................................................................................................................................................... 12 4. RADIATED EMISSIONS ....................................................................................................................................... 13 4.1 STANDARD APPLICABLE ..................................................................................................................................... 13 4.2 TEST PROCEDURE .............................................................................................................................................. 13 4.3 CORRECTED AMPLITUDE & MARGIN CALCULATION ........................................................................................... 16 4.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 16 5. OUT OF BAND EMISSIONS ................................................................................................................................ 21 5.1 STANDARD APPLICABLE ..................................................................................................................................... 21 5.2 TEST PROCEDURE .............................................................................................................................................. 21 5.3 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 21 6. EMISSION BANDWIDTH ...................................................................................................................................... 26 6.1 STANDARD APPLICABLE ..................................................................................................................................... 26 6.2 TEST PROCEDURE .............................................................................................................................................. 26 6.3 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 26 7. CONDUCTED EMISSIONS .................................................................................................................................. 28 7.1 TEST PROCEDURE .............................................................................................................................................. 28 7.2 BASIC TEST SETUP BLOCK…

Text truncated - open the document above for the full version.

Reference No.: WTH22X12242882W001 Page 9 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Radiation Emission Test Setup (Below 30MHz) Radiation Emission Test Setup (30MHz to 1GHz) Reference No.: WTH22X12242882W001 Page 10 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (1GHz to 18GHz) Radiation Emission Test Setup (Above 18GHz) ***** END OF REPORT *****
