2AP35SR51FB22C-08Solar LED Light

02/28/2020 E REPLACING THE BATTERY TROUBLE SHOOTING INSTRUCTIONS Tools Required Phillips-head Screwdriver Pencil Electric drill drill bit size: ø7.5mm (3/10 in.) INSTALLATION Drill two holes. 1 Marking the location Measure the width of two holes on the back of the solar fence light to align holes for the 2 screws (Part A) on the surface. The distance between the two holes is 2.36in. (60mm). Mark the location where you want to mount the light xture (Part C). 2 Mounting the light Insert the wall anchors (Part B) so they are ush with the surface. x x 2.36in. FOR FIRST TIME USE: SOLAR LIGHT NEEDS TO CHARGE IN FULL SUNLIGHT FOR 8 -12 HOURS WITH THE SWITCH IN THE “ON” POSITION TO ALLOW THE RECHARGEABLE BATTERIES TO REACH MAXIMUM CAPACITY. The intelligent solar LED motion activated light measures the corresponding available battery power through the current voltage point of the battery, adjusts the energy and lumen output, and maximizes the lighting time. Hardware Included Parts (B) Wall Anchor X 4(A) Screw X 4 (C) Light Fixture X 2(D) Mounting Plate X 2 Secure the mounting plate (Part D) in place with the screws (Part A). Mount the light on the mounting plate (Part D) by aligning the holes on the back of the light to the key on the front of the mounting plate. Slide and lock into place. B A D C Slide the power switch to the "OFF" position. Use a Phillips head screwdriver to remove the 6 screws holding the battery cover in place. Gently pull battery pack away from the light xture and disconnect the battery connector. Replace old battery pack with a new 3.7V, 2000 mAh lithium (18650) rechargeable battery pack. Connect the battery connector and insert battery pack into the light xture. Replace the battery cover by aligning it properly and replacing the 6 screws removed earlier. Slide the power switch to the “ON” position. For optimum performance, allow light xture to charge in full sunlight for 8-12 hours. ScrewsPower Switch Battery pack Battery Cover If the light does not turn on, remove the battery cover and check if the battery pack is connected to the battery connector. If the connection is ok, replace the battery with a new one. INTELLIGENT SOLAR LED MOTION ACTIVATED FENCE LIGHT ITEM: SR51FB22C-08 NOTE: Light will stay on 30 seconds when triggered by motion. Detection range is 26 feet, detection angle is 120°. Light use radio frequency technology to link, and should not be greater than 98 feet between the neighboring/adjacent lights. The package include 2 lights. These 2 lights is factory linked, and can not linked any other lights. 02/28/2020 2/2E For additional help and information regarding installation, contact customer service at 1-844-551-0680, 8am-5pm, CST Monday – Friday [email protected] , WESTINGHOUSE, are trademarks of Westinghouse Electric Corporation. Used under license by Sky Rich Star Limited. All Rights Reserved. FCC WARNING Warning: Changes or modications to this unit not expressly approved by the party responsible for compliance could void the user authority to operate the equipment. Notes: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency enerqy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no quarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio / TV technician for help. WARNING: Do not dispose of lithium batteries in municipal waste stream or by re as batteries may explode. Do not open, short circuit, or destroy batteries. Dispose of batteries in accordance with Local, State, and Federal regulations. Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel cadmium, nickel metal hydride or lithium ion) batteries . INTELLIGENT SOLAR LED MOTION ACTIVATED FENCE LIGHT ITEM: SR51FB22C-08 RF EXPOSURE: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 02/28/2020 S INSTRUCCIONES CAMBIANDO LA BATERÍA SOLUCIÓN DE PROBLEMAS INSTALACIÓN Cabeza de Phillips Destornillador Taladro eléctrico tamaño de la broca de taladro: ø7.5 mm (3/10 plg) Lápiz Herramientas NecesariasHerrajes Incluidos Partes (B) Anclajes de pared X 4(A) Tornillo X 4 PARA EL PRIMER USO: LA LUZ SOLAR NECESITA CARGARSE BA JO LUZ SOLAR DIRECTA POR UN PERIODO DE ENTRE 8 Y 12 HORAS CON EL INTERRUPTOR EN LA POSICIÓN "ON" (PRENDIDO) PARA PERMITIR QUE LAS BATERÍAS RECARGABLES ALCANCEN SU CAPACIDAD MÁXIMA. La luz inteligente activada por movimiento del LED solar mide la energía de la batería disponible correspondiente a través del punto de voltaje actual de la batería, ajusta la energía y la salida de luz y maximiza el tiempo de iluminación. x x 2.36in. Taladre dos oricios. 1 Cómo marcar el lugar de montaje Mide el ancho de los dos oricios que están en la parte posterior de la lámpara solar para cerca para alinearlos con 2 tornillos ( Parte A) en la supercie. La distancia entre los oricios es de 2.36in. (60mm). Marque el lugar en el que quiere montar…

Text truncated - open the document above for the full version.

Differences Declaration To whom concern, We company INTERNATIONAL DEVELOPMENT COMPANY hereby declares: The product models SR51FB22*-##（Where "#" is used to denote numbers or blank for commercial purpose; Where “*” is used to denote letters or blank for commercial purpose.) are identical in the same PCB layout, interior structure and electrical circuits with the model SR51FB22C-08 which tested in Global United Technology Services Co., Ltd., The differences are colour and model name for commercial purpose. Authorized signature: Date: 2020-03-04

INTERNATIONAL DEVELOPMENT COMPANY DATE : 2020-03-04 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AP35SR51FB22C-08 Product Name: Solar LED Light Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name: zhiquan li Title: Manager Company: INTERNATIONAL DEVELOPMENT COMPANY

DATE:2020-03-04 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.andNo. 301- 309, 3/F., Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with INTERNATIONAL DEVELOPMENT COMPANY and 899 Henrietta Creek Road, Roanoke, Texas 76262, United States Signature: Name: zhiquan li Title: Manager Company: INTERNATIONAL DEVELOPMENT COMPANY

FCC Label and Location FCC Label: Label location:

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10- g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m Sopt = (EXd) 2 /30 x gt Ant gain= 3 dBi ; so Ant numeric gain= 2 Field strength =79.34dBuV/m @3m So Pt={ [10 (79.34 /20) /10 6 x3] 2 /30x2 }x1000 mW = 0.013 mW So (0.013 mW/5mm)x √2.420 GHz = 0.004 < 3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTS202003000002F01 Authorized Signature: Robinson Lo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 23 TEST REPORT Applicant: INTERNATIONAL DEVELOPMENT COMPANY Address of Applicant: 899 Henrietta Creek Road, Roanoke, Texas 76262, United States Manufacturer/Factory: Zhongshan Quanxin Lighting Electrical Co., Ltd. Address of Manufacturer/Factory: Hong Ji Street, Shalang, Long Ping Cun, West District, ZHONGSHAN Guangdong 528411 China Equipment Under Test (EUT) Product Name: Solar LED Light Model No.: SR51FB22C-08, SR51FB22*-##（Where "#" is used to denote numbers or blank for commercial purpose; Where “*” is used to denote letters or blank for commercial purpose.) FCC ID: 2AP35SR51FB22C-08 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 Date of sample receipt: March 02, 2020 Date of Test: March 02-04, 2020 Date of report issued: March 04, 2020 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS202003000002F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 23 2 Version Version No. Date Description 00 March 04, 2020 Original Prepared By: Date: March 04, 2020 Project Engineer Check By: Date: March 04, 2020 Reviewer Report No.: GTS202003000002F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 23 3 Contents Page 1 COVER PAGE .............................................................................................................................................1 2 VERSION ...................................................................................................................................................2 3 CONTENTS ...............................................................................................................................................3 4 TEST SUMMARY ......................................................................................................................................4 4.1 MEASUREMENT UNCERTAINTY .............................................................................................................4 5 GENERAL INFORMATION .......................................................................................................................5 5.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 5.2 TEST MODE .........................................................................................................................................6 5.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................6 5.4 DEVIATION FROM STANDARDS ..............................................................................................................6 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................6 5.6 TEST FACILITY ....................................................................................................................................6 5.7 TEST LOCATION ..................................................................................................................................6 6 TEST INSTRUMENTS LIST ......................................................................................................................7 7 TEST RESULTS AND MEASUREMENT DATA .......................................................................................9 7.1 ANTENNA REQUIREMENT ......................................................................................................................9 7.2 RADIATED EMISSION METHOD ............................................................................................................10 7.2.1 Field Strength of The Fundamental Signal ..................................................................................12 7.2.2 Spurious emissions .....................................................................................................................14 7.2.3 Bandedge emissions ...................................................................................................................19 7.3 20DB OCCUPY BANDWIDTH ...............................................................................................................21 8 TEST SETUP PHOTO .............................................................................................................................23 9 EUT CONSTRUCTIONAL DETAILS .......................................................................................................23 Report No.: GTS202003000002F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 23 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission 15.207 N/A Field strength of the fundamental signal 15.249 (a) Pass Spurious emissions 15.249 (a) (d)/15.209 Pass Band edge 15.249 (d)/15.205 Pass 20dB Occupied Bandwidth 15.215 (c) Pass Remarks： 1. Pass: The EUT complies …

Text truncated - open the document above for the full version.

Radiated Emission
