2AQ7B-IPC267Smart PTZ Camera

QUICK START GUIDE IPC267,HUVIPC213 Read me before use! Keep manual and all relevant information for future reference. Description of the camera 1. Microphone 2. Camera lens 3. Indicator LED light 4. Micro SD card slot (max. 128GB) 5. Reset button 6. USB-C power connector 7. 1/4” screw hole for mounting camera on the wall 1 2 3 4 5 6 7 About the camera 1. Power on the camera To power on the camera, use a 5V (1A~2A) adapter (not included) to connect camera with supplied power cable. The indicator will turn on in blue color with a voice prompt, which means camera is ready for connection. 2. Micro SD card To save the events into local storage, the camera needs a max. 8GB~128GB (Class 10 or higher) micro SD card. Please format the card before using. 3. Reset If the device is not able to be connected to the app, you may need to reset the camera. Hold and press the reset button for 5 seconds, the camera will be restarted and you will hear the “welcome” voice announcement, which means the reset is succeed and the camera is ready to connect. 4. Installation the camera Connect the camera with App to check the signal before mounting the camera. Installation the camera: Setup with the App 1. Download and Install the app: Download and install the HALOWatch app by scanning the QR code for the Apple Store or Google Play Store. HALOWATCH Check that you have a strong Wi-Fi signal (at least two bars) where the smart camera is to be installed. 2. Account Registration: Open the app and register a new account or log in to an existing account. 3. Add Camera: Navigate to the Home Page within the app. Locate and select "Add Camera" then go through preparation instructions to power on your camera properly. 4. Bluetooth Access: Follow the on-screen instructions to enable Bluetooth access, which is required for device discovery. Do not skip this step. Ensure Bluetooth access is enabled as instructed, allowing the app to discover the device via BLE. 5. Connect to Wi-Fi: The app will automatically scan for nearby 2.4GHz &5GHz Wi-Fi routers. The camera supports both 2.4GHz and 5GHz Wi-Fi. 6. Input Wi-Fi Credentials: Enter the password for your selected Wi-Fi network. Click "Next" to initiate connection. Wait a few seconds for the device to connect to the internet. You'll hear a notification sound from the device indicating successful progress. 7. Live view and app support Hear and talk to the camera with the app. If you have any questions or suggestions, find the support icon as following to chat or e-mail with us. FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD 102A,102B,Building2,ShanghenglangNewIndustrialZone,ShanghenglangCommunity, DalangStreet,LonghuaDistrict,Shenzhen,Guangdong,People’sRepublicofChina,518000 Telephone:+86-755-26648640 Fax:+86-755-26648637 Website:www.cqa-cert.com ReportTemplateVersion:V06 ReportTemplateRevisionDate:2026-01-30 RFExposureEvaluationReport Thetestreportiseffectiveonlywithbothsignatureandspecializedstamp,Theresult(s)showninthisreportreferonlyto thesample(s)tested.WithoutwrittenapprovalofCQA,thisreportcan’tbereproducedexceptinfull. ReportNo.:CQASZ20260300608E-04 Applicant:ShenzhenInterthingsTechnologyCo.,Ltd. AddressofApplicant:701,Building1,LechuanghuiBuilding,No.1211GuanguangRoad,Longhua District,Shenzhen,China EquipmentUnderTest(EUT): EUTName:SmartPTZCamera ModelNo.:IPC267,HUVIPC213 TestModelNo.:IPC267 BrandName:N/A FCCID:2AQ7B-IPC267 Standards: 47CFRPart1.1307 47CFRPart1.1310 447498D04InterimGeneralRFExposureGuidancev01 DateofReceipt:2026-03-26 DateofTest:2026-03-26to2026-07-23 DateofIssue:2026-07-23 TestResult:PASS* *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove TestedBy: (LewisZhou) ReviewedBy: (TimoLei) ApprovedBy: (JackAi) SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-04 Page:2of9 1Version RevisionHistoryOfReport ReportNo.Version Description IssueDate CQASZ20260300608E-04Rev.01 Initialreport 2026-07-23 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-04 Page:3of9 2Contents Page 1VERSION............................................................................................................................................................................2 2CONTENTS........................................................................................................................................................................3 3GENERALINFORMATION..............................................................................................................................................4 3.1CLIENTINFORMATION...................................................................................................................................................4 3.2GENERALDESCRIPTIONOFEUT...................................................................................................................................4 3.3GENERALDESCRIPTIONOFBLECLASSIC.....................................................................................................................4 3.4GENERALDESCRIPTIONOF2.4GWIFICLASSIC...........................................................................................................5 3.5GENERALDESCRIPTIONOF5GWIFICLASSIC..............................................................................................................5 4MPEEVALUATION...........................................................................................................................................................6 4.1RFEXPOSURECOMPLIANCEREQUIREMENT.................................................................................................................6 4.1.1Limits....................................................................................................................................................................6 4.1.2TestProcedure...................................................................................................................................................6 4.1.3EUTRFExposure..............................................................................................................................................7 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-04 Page:4of9 3GeneralInformation 3.1ClientInformation Applicant:ShenzhenInterthingsTechnologyCo.,Ltd. AddressofApplicant: 701,Building1,LechuanghuiBuilding,No.1211GuanguangRoad, LonghuaDistrict,Shenzhen,China Manufacturer: ShenzhenInterthingsTechnologyCo.,Ltd. AddressofManufacturer: 701,Building1,LechuanghuiBuilding,No.1211GuanguangRoad, LonghuaDistrict,Shenzhen,China Factory:ShenzhenInterthingsTechnologyCo.,Ltd. AddressofFactory:701,Building1,LechuanghuiBuilding,No.1211GuanguangRoad, LonghuaDistrict,Shenzhen,China 3.2GeneralDescriptionofEUT ProductName: SmartPTZCamera ModelNo.: IPC267,HUVIPC213 TestModelNo.: IPC267 TradeMark: N/A SoftwareVersion: V1.0 HardwareVersion: V1.0 EUTPowerSupply: PoweredbyDC5Vforadapter 3.3GeneralDescriptionofBLEClassic OperationFrequency: 2402MHz~2480MHz BluetoothVersion: BluetoothSpec5.4 ModulationType: GFSK NumberofChannel: 40 TransferRate:1Mbps SampleType: MobilePortableFixLocation AntennaType: PCBantenna AntennaGain: -0.19dBi SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-04 Page:5of9 3.4GeneralDescriptionof2.4GWIFIClassic OperationFrequency: 2412MHz~2462MHz TypeofModulation: IEEEfor802.11b:DSSS(CCK,DQPSK,DBPSK) IEEEfor802.11g:OFDM(64QAM,16QAM,QPSK,BPSK) IEEEfor802.11n(HT20andHT40):OFDM(64QAM,16QAM,QPSK,BPSK) NumberofChannel: IEEE802.11b/g,IEEE802.11nHT20:11Channels IEEE802.11nHT40:7Channels ChannelSeparation: 5MHz TransferRate: IEEEfor802.11b: 1Mbps/2Mbps/5.5Mbps/11Mbps IEEEfor802.11g: 6Mbps/9Mbps/12Mbps/18Mbps/24Mbps/36Mbps/48Mbps/54Mbps IEEEfor802.11n(HT20): 6.5Mbps/13Mbps/19.5Mbps/26Mbps/39Mbps/52Mbps/58.5Mbps/65Mbps IEEEfor802.11n(HT40): 13.5Mbps/27Mbps/40.5Mbps/54Mbps/81Mbps/108Mbps/121.5Mbps/135Mbps SampleType: MobilePortableFixLocation AntennaType:PCBantenna AntennaGain:-0.19dBi 3.5GeneralDescriptionof5GWIFIClassic OperationFrequency: IEEE802.11a/n/ac(20M):5150MHz~5250MHz IEEE802.11n/ac(40M):5150MHz~5250MHz IEEE802.11a/n/ac(20M):5725MHz~5850MHz IEEE802.11n/ac(40M):5725MHz~5850MHz TypeofModulation:IEEEfor802.11a/n/ac:OFDM(256QAM,64QAM,16QAM,QPSK,BPSK) NumberofChannel: IEEE802.11a/n/ac(20M):5150MHz~5250MHz/4channel IEEE802.11n/ac(40M):5150MHz~5250MHz/2channel IEEE802.11a/n/ac(20M):5725MHz~5850MHz/5channel IEEE802.11n/ac(40M):5725MHz~5850MHz/2channel ChannelSeparation:5MHz SampleType: MobilePortableFixLocation AntennaType:PCBa…

Text truncated - open the document above for the full version.

Setupphotos 1Photographs-EUTTestSetup 1.1RadiatedSpuriousEmission 9kHz~30MHz: 30MHz~1GHz: FCC ID: 2AQ7B-IPC267 Above1GHz: 1.2ConductedEmission

SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 30 of 58 BLE_2M_Ant1_2480 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 31 of 58 5.6Band-edgeforRFConductedEmissions TestRequirement:47CFRPart15CSection15.247(d) TestMethod:ANSI C63.10-2020+Cor.1-2023+C63.10a-2024+ErratatoC63.10a-2024 TestSetup: Remark:Offset=Cableloss+attenuationfactor. Limit:Inany100kHzbandwidthoutsidethefrequencybandinwhichthespread spectrumintentionalradiatorisoperating,theradiofrequencypowerthatis producedbytheintentionalradiatorshallbeatleast20dBbelowthatinthe 100kHzbandwidthwithinthebandthatcontainsthehighestlevelofthe desiredpower,basedoneitheranRFconductedoraradiatedmeasurement. TestMode:TransmittingwithGFSKmodulation. TestResults:Pass TestModeChNameFreq(MHz)RefLevel[dBm]Result[dBm]Limit[dBm]Verdict BLE_1M Low2402-1.96-44.39≤-21.96PASS High2480-0.25-42.57≤-20.25PASS BLE_2M Low2402-2.54-35.86≤-22.54PASS High2480-1.76-42.75≤-21.76PASS SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 32 of 58 Testplotasfollows: BLE_1M_Ant1_Low_2402 BLE_1M_Ant1_High_2480 BLE_2M_Ant1_Low_2402 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 33 of 58 BLE_2M_Ant1_High_2480 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 34 of 58 5.7SpuriousRFConductedEmissions TestRequirement:47CFRPart15CSection15.247(d) TestMethod:ANSI C63.10-2020+Cor.1-2023+C63.10a-2024+ErratatoC63.10a-2024 TestSetup: Remark:Offset=Cableloss+attenuationfactor. Limit:Inany100kHzbandwidthoutsidethefrequencybandinwhichthespread spectrumintentionalradiatorisoperating,theradiofrequencypowerthatis producedbytheintentionalradiatorshallbeatleast20dBbelowthatinthe 100kHzbandwidthwithinthebandthatcontainsthehighestlevelofthe desiredpower,basedoneitheranRFconductedoraradiated measurement. TestMode:TransmittingwithGFSKmodulation. TestResults:Pass SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 35 of 58 Testplotasfollows: BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 BLE_1M_Ant1_2402_1000~26500 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 36 of 58 BLE_1M_Ant1_2440_0~Reference BLE_1M_Ant1_2440_30~1000 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 37 of 58 BLE_1M_Ant1_2440_1000~26500 BLE_1M_Ant1_2480_0~Reference BLE_1M_Ant1_2480_30~1000 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 38 of 58 BLE_1M_Ant1_2480_1000~26500 BLE_2M_Ant1_2402_0~Reference SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 39 of 58 BLE_2M_Ant1_2402_30~1000 BLE_2M_Ant1_2402_1000~26500 BLE_2M_Ant1_2440_0~Reference SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 40 of 58 BLE_2M_Ant1_2440_30~1000 BLE_2M_Ant1_2440_1000~26500 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 41 of 58 BLE_2M_Ant1_2480_0~Reference BLE_2M_Ant1_2480_30~1000 BLE_2M_Ant1_2480_1000~26500 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 42 of 58 Remark: Pretest9kHzto25GHz,findthehighestpointwhentesting,soonlytheworstdatawereshowninthetest report.PerFCCPart15.33(a)and15.31(o),Theamplitudeofspuriousemissionsfromintentionalradiators whichareattenuatedmorethan20dBbelowthepermissiblevalueneednotbereportedunlessspecifically requiredelsewhereinthispart. SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 43 of 58 5.8RadiatedSpuriousEmission&Restrictedbands 5.8.1SpuriousEmissions TestRequirement:47CFRPart15CSection15.209and15.205 TestMethod:ANSI C63.10-2020+Cor.1-2023+C63.10a-2024+ErratatoC63.10a-2024 TestSite:MeasurementDistance:3m(Semi-AnechoicChamber) ReceiverSetup: FrequencyDetectorRBWVBWRemark 0.009MHz-0.090MHzPeak10kHz30kHzPeak 0.009MHz-0.090MHzAverage10kHz30kHzAverage 0.090MHz-0.110MHzQuasi-peak10kHz30kHzQuasi-peak 0.110MHz-0.490MHzPeak10kHz30kHzPeak 0.110MHz-0.490MHzAverage10kHz30kHzAverage 0.490MHz-30MHzQuasi-peak10kHz30kHzQuasi-peak 30MHz-1GHzQuasi-peak100kHz300kHzQuasi-peak Above1GHz Peak1MHz3MHzPeak Peak1MHz10HzAverage Limit: Frequency Fieldstrength (microvolt/meter) Limit (dBuV/m) Remark Measurement distance(m) 0.009MHz-0.490MHz2400/F(kHz)--300 0.490MHz-1.705MHz24000/F(kHz)--30 1.705MHz-30MHz30--30 30MHz-88MHz10040.0Quasi-peak3 88MHz-216MHz15043.5Quasi-peak3 216MHz-960MHz20046.0Quasi-peak3 960MHz-1GHz50054.0Quasi-peak3 Above1GHz50054.0Average3 Note:15.35(b),Unlessotherwisespecified,thelimitonpeakradio frequencyemissionsis20dBabovethemaximumpermittedaverageemission limitapplicabletotheequipmentundertest.Thispeaklimitappliestothetotal peakemissionlevelradiatedbythedevice. SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 44 of 58 TestSetup: Figure1.Below30MHz Figure2.30MHzto1GHzFigure3.Above1GHz TestProcedure:a.1)Below1G:TheEUTwasplacedonthetopofarotatingtable0.8 metersabovethegroundata3metersemi-anechoiccamber.Thetable wasrotated360degreestodeterminethepositionofthehighest radiation. 2)Above1G:TheEUTwasplacedonthetopofarotatingtable1.5 metersabovethegroundata3metersemi-anechoiccamber.Thetable wasrotated360degreestodeterminethepositionofthehighest radiation. Note:Fortheradiatedemissiontestabove1GHz: PlacethemeasurementantennaawayfromeachareaoftheEUT determinedtobeasourceofemissionsatthespecifiedmeasurement distance,whilekeepingthemeasurementantennaaimedatthesource ofemissionsateachfrequencyofsignificantemissions,withpolarization orientedformaximumresponse.Themeasurementantennamayhave tobehigherorlowerthantheEUT,dependingontheradiationpatternof theemissionandstayingaimedattheemissionsourceforreceivingthe maximumsignal.Thefinalmeasurementantennaelevationshallbethat whichmaximizestheemissions.Themeasurementantennaelevation formaximumemissionsshallberestrictedtoarangeofheightsoffrom 1mto4mabovethegroundorreferencegroundplane. b.TheEUTwasset3metersawayfromtheinterference-receiving antenna,whichwasmountedonthetopofavariable-heigh…

Text truncated - open the document above for the full version.

SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD 102A,102B,Building2,ShanghenglangNewIndustrialZone,ShanghenglangCommunity, DalangStreet,LonghuaDistrict,Shenzhen,Guangdong,People’sRepublicofChina,518000 Telephone:+86-755-26648640 Fax:+86-755-26648637 Website:www.cqa-cert.com ReportTemplateVersion:V06 ReportTemplateRevisionDate:2026-01-30 TestReport Thetestreportiseffectiveonlywithbothsignatureandspecializedstamp,Theresult(s)showninthisreportreferonly tothesample(s)tested.WithoutwrittenapprovalofCQA,thisreportcan’tbereproducedexceptinfull. ReportNo.:CQASZ20260300608E-01 Applicant:ShenzhenInterthingsTechnologyCo.,Ltd. AddressofApplicant:701,Building1,LechuanghuiBuilding,No.1211GuanguangRoad,Longhua District,Shenzhen,China EquipmentUnderTest(EUT): Product:SmartPTZCamera ModelNo.:IPC267,HUVIPC213 TestModelNo.:IPC267 BrandName:N/A FCCID:2AQ7B-IPC267 Standards:47CFRPart15,SubpartC KDB558074D0115.247MeasGuidancev05r02 ANSIC63.10:2020 DateofReceipt:2026-03-26 DateofTest:2026-03-26to2026-07-23 DateofIssue:2026-07-23 TestResult:PASS* *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove. TestedBy: (LewisZhou) ReviewedBy: (TimoLei) ApprovedBy: (JackAi) SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 2 of 58 1Version RevisionHistoryOfReport ReportNo.Version Description IssueDate CQASZ20260300608E-01Rev.01Initialreport2026-07-23 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 3 of 58 2TestSummary TestItemTestRequirementTestmethodResult AntennaRequirement 47CFRPart15,SubpartCSection 15.203/15.247(c) ANSI C63.10- 2020+Cor.1- 2023+C63.10a-2024+ ErratatoC63.10a-2024 PASS ACPowerLine Conducted Emission 47CFRPart15,SubpartCSection 15.207 ANSI C63.10- 2020+Cor.1- 2023+C63.10a-2024+ ErratatoC63.10a-2024 PASS ConductedPeakOutput Power 47CFRPart15,SubpartCSection 15.247(b)(3) ANSI C63.10- 2020+Cor.1- 2023+C63.10a-2024+ ErratatoC63.10a-2024 PASS 6dBOccupied Bandwidth 47CFRPart15,SubpartCSection 15.247(a)(2) ANSI C63.10- 2020+Cor.1- 2023+C63.10a-2024+ ErratatoC63.10a-2024 PASS PowerSpectralDensity 47CFRPart15,SubpartCSection 15.247(e) ANSI C63.10- 2020+Cor.1- 2023+C63.10a-2024+ ErratatoC63.10a-2024 PASS Band-edgeforRF ConductedEmissions 47CFRPart15,SubpartCSection 15.247(d) ANSI C63.10- 2020+Cor.1- 2023+C63.10a-2024+ ErratatoC63.10a-2024 PASS RFConductedSpurious Emissions 47CFRPart15,SubpartCSection 15.247(d) ANSI C63.10- 2020+Cor.1- 2023+C63.10a-2024+ ErratatoC63.10a-2024 PASS RadiatedSpurious Emissions 47CFRPart15,SubpartCSection 15.205/15.209 ANSI C63.10- 2020+Cor.1- 2023+C63.10a-2024+ ErratatoC63.10a-2024 PASS Restrictedbandsaround fundamentalfrequency (RadiatedEmission) 47CFRPart15,SubpartCSection 15.205/15.209 ANSI C63.10- 2020+Cor.1- 2023+C63.10a-2024+ ErratatoC63.10a-2024 PASS SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-01 Page: 4 of 58 3Contents Page 1VERSION..........................................................................................................................................................................2 2TESTSUMMARY............................................................................................................................................................3 3CONTENTS......................................................................................................................................................................4 4GENERALINFORMATION...........................................................................................................................................5 4.1CLIENTINFORMATION.................................................................................................................................................5 4.2GENERALDESCRIPTIONOFEUT.................................................................................................................................5 4.3ADDITIONALINSTRUCTIONS........................................................................................................................................7 4.4TESTENVIRONMENT...................................................................................................................................................8 4.5DESCRIPTIONOFSUPPORTUNITS...............................................................................................................................8 4.6TESTCONFIGURATION................................................................................................................................................8 4.7STATEMENTOFTHEMEASUREMENTUNCERTAINTY....................................................................................................9 4.8TESTLOCATION........................................................................................................................................................10 4.9TESTFACILITY..........................................................................................................................................................10 4.10DEVIATIONFROMSTANDARDS................................................................................................................................10 4.11OTHERINFORMATIONREQUESTEDBYTHECUSTOMER..........................................................................................10 4.12EQUIPMENTLIST.....................................................................................................................................................11 5TESTRESULTSANDMEASUREMENTDATA.....................................................................................................12 5.1ANTENNAREQUIREMENT..........................................................................................................................................12 5.2CONDUCTEDEMISSIONS............................................................................................................................................13 5.3CONDUCTEDPEAKOUTPUTPOWER..................................…

Text truncated - open the document above for the full version.

SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:63of95 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:64of95 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:65of95 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:66of95 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:67of95 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:68of95 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:69of95 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 11N40SISO_Ant1_2422_0~Reference SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:70of95 11N40SISO_Ant1_2422_30~1000 11N40SISO_Ant1_2422_1000~26500 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:71of95 11N40SISO_Ant1_2437_0~Reference 11N40SISO_Ant1_2437_30~1000 11N40SISO_Ant1_2437_1000~26500 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:72of95 11N40SISO_Ant1_2452_0~Reference 11N40SISO_Ant1_2452_30~1000 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:73of95 11N40SISO_Ant1_2452_1000~26500 Remark: Pretest9kHzto25GHz,findthehighestpointwhentesting,soonlytheworstdatawereshowninthetest report.PerFCCPart15.33(a)and15.31(o),Theamplitudeofspuriousemissionsfromintentional radiatorswhichareattenuatedmorethan20dBbelowthepermissiblevalueneednotbereportedunless specificallyrequiredelsewhereinthispart. SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:74of95 5.9RadiatedSpuriousEmissions TestRequirement:47CFRPart15CSection15.209and15.205 TestMethod:ANSIC63.102020 TestSite:MeasurementDistance:3m(Semi-AnechoicChamber) ReceiverSetup: FrequencyDetectorRBWVBWRemark 0.009MHz-0.090MHzPeak10kHz30kHzPeak 0.009MHz-0.090MHzAverage10kHz30kHzAverage 0.090MHz-0.110MHzQuasi-peak10kHz30kHzQuasi-peak 0.110MHz-0.490MHzPeak10kHz30kHzPeak 0.110MHz-0.490MHzAverage10kHz30kHzAverage 0.490MHz-30MHzQuasi-peak10kHz30kHzQuasi-peak 30MHz-1GHzQuasi-peak100kHz300kHzQuasi-peak Above1GHz Peak1MHz3MHzPeak Peak1MHz10HzAverage Limit: Frequency Fieldstrength (microvolt/meter) Limit (dBuV/m) Remark Measurement distance(m) 0.009MHz-0.490MHz2400/F(kHz)--300 0.490MHz-1.705MHz24000/F(kHz)--30 1.705MHz-30MHz30--30 30MHz-88MHz10040.0Quasi-peak3 88MHz-216MHz15043.5Quasi-peak3 216MHz-960MHz20046.0Quasi-peak3 960MHz-1GHz50054.0Quasi-peak3 Above1GHz50054.0Average3 Note:15.35(b),Unlessotherwisespecified,thelimitonpeakradiofrequency emissionsis20dBabovethemaximumpermittedaverageemissionlimit applicabletotheequipmentundertest.Thispeaklimitappliestothetotalpeak emissionlevelradiatedbythedevice. SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:75of95 TestSetup: Figure1.Below30MHz Figure2.30MHzto1GHzFigure3.Above1GHz TestProcedure: a.1)Below1G:TheEUTwasplacedonthetopofarotatingtable0.8 metersabovethegroundata3metersemi-anechoiccamber.Thetable wasrotated360degreestodeterminethepositionofthehighest radiation. 2)Above1G:TheEUTwasplacedonthetopofarotatingtable1.5 metersabovethegroundata3metersemi-anechoiccamber.Thetable wasrotated360degreestodeterminethepositionofthehighest radiation. Note:Fortheradiatedemissiontestabove1GHz: PlacethemeasurementantennaawayfromeachareaoftheEUT determinedtobeasourceofemissionsatthespecifiedmeasurement distance,whilekeepingthemeasurementantennaaimedatthesourceof emissionsateachfrequencyofsignificantemissions,withpolarization orientedformaximumresponse.Themeasurementantennamayhaveto behigherorlowerthantheEUT,dependingontheradiationpatternofthe emissionandstayingaimedattheemissionsourceforreceivingthe maximumsignal.Thefinalmeasurementantennaelevationshallbethat whichmaximizestheemissions.Themeasurementantennaelevationfor maximumemissionsshallberestrictedtoarangeofheightsoffrom1m to4mabovethegroundorreferencegroundplane. b.TheEUTwasset3metersawayfromtheinterference-receivingantenna, whichwasmountedonthetopofavariable-heightantennatower. c.Theantennaheightisvariedfromonemetertofourmetersabovethe groundtodeterminethemaximumvalueofthefieldstrength.Both horizontalandverticalpolarizationsoftheantennaaresettomakethe measurement. 1 5 0 c m SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:76of95 d.Foreachsuspectedemission,theEUTwasarrangedtoitsworstcase andthentheantennawastunedtoheightsfrom1meterto4meters(for thetestfrequencyofbelow30MHz,theantennawastunedtoheights1 meter)andtherotatabletablewasturnedfrom0degreesto360degrees tofindthemaximumreading. e.Thetest-receiversystemwassettoPeakDetectFunctionandSpecified BandwidthwithMaximumHoldMode. f.IftheemissionleveloftheEUTinpeakmodewas10dBlowerthanthe limitspecified,thentestingcouldbestoppedandthepeakvaluesofthe EUTwouldbereported.Otherwisetheemissionsthatdidnothave10dB marginwouldbere-testedonebyoneusingpeak,quasi-peakoraverage methodasspecifiedandthenreportedinadatasheet. g.TesttheEUTinthelowestchannel,themiddlechannel,theHighest channel. h.TheradiationmeasurementsareperformedinX,Y,Zaxispositioningfor Transmittingmode,AndfoundtheXaxispositioningwhichitisworse case. i.Repeataboveproceduresuntilallfrequenciesmeasuredwascomplete. ExploratoryTestMode:Transmittingwithallkindofmodulations,dataratesatlowest,middleand highestchannel. FinalTestMode:Onlytheworstcaseisrecordedinthereport. TestResults:Pass SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:77of95 5.9.1Radiatedemissionbelow1GHz 30MHz~1GHz Vertical Remark: ThefieldstrengthiscalculatedbyaddingtheAntennaFactor,Cab…

Text truncated - open the document above for the full version.

SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:32of95 11G_Ant1_2412 11G_Ant1_2437 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:33of95 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:34of95 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:35of95 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:36of95 5.56dBOccupiedBandwidth TestRequirement:47CFRPart15CSection15.247(a)(2) TestMethod:ANSIC63.10:2020 TestSetup: Offset=cableloss+attenuationfactor ExploratoryTestMode:Transmittingwithallkindofmodulations,datarates FinalTestMode:Onlytheworstcaseisrecordedinthereport. Limit:≥500kHz TestResults:Pass SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Page:37of95 TestResult TestModeFrequency[MHz] DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11B 24128.282407.842416.120.5PASS 24378.242432.842441.080.5PASS 24628.282457.842466.120.5PASS 11G 241216.082403.922420.000.5PASS 243716.082428.842444.920.5PASS 246216.162453.842470.000.5PASS 11N20SISO 241217.402403.282420.680.5PASS 243717.442428.202445.640.5PASS 246217.162453.482470.640.5PASS 11N40SISO 242233.522405.922439.440.5PASS 243735.922419.002454.920.5PASS 245236.002433.922469.920.5PASS SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260300608E-02 Pa…
