2AQ7B-IPC302Smart Outdoor Camera

Shenzhen Interthings Technology Co., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 12, 2024
Application Purpose: Original Equipment
Date of Application: Mar 12, 2024
Equipment Note: Smart Outdoor Camera
Frequency Range: 2412.00000000 - 2462.00000000
Company: Shenzhen Interthings Technology Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Model: IPC302 420x128MM power adaptercamerascrew package eset slot R SD Card Status light Microphone RESET Speaker DESCRIPTION: Power DC 5V +/- 5% Status lights: Blue light solid on: system setup Blue light blinking fast: waiting for the pairing Blue light blinking slowly: waiting for the WiFi connection Microphone Capture sound for your video SD Card slot Support local micro SD Card storage (Max. 128GB) Reset Press and hold the reset button for 5 seconds to reset the camera (if you have modied the settings, they will return to factory defaults) Before you start write down your network name & password. Note: this item only works on a 2.4GHz Wi-Fi network, not on a 5GHz network. Please consult your router manual for settings. Please follow the instructions and make sure the passwords are correctly inputted. One device can only be paired with one App account at a time, if the device has already been paired with another account, then it can’t be paired to another account. The device can be removed from the app account by being deleted from the app. The device will be reset automatically once the blue light changes to a solid on.

Attestation Statements

C5266091_X24_Ed.2 1/1 Shenzhen Interthings Technology Co., Ltd. “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Interthings Technology Co., Ltd. Grantee code: 2AQ7B FCC ID: 2AQ7B-IPC302 Contact Name: Lucy Fang Address: 701, Building 1, Lechuanghui Building, No.1211 Guanguang Road, Longhua District, Shenzhen,China Telephone No: +86-755-28177055 Fax No: / Email: [email protected] FRN: 0027836717 i. [Shenzhen Interthings Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Interthings Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Interthings Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2024/03/07 Applicant’s Name: Lucy Fang Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Attestation Statements

ShenzhenInterthingsTechnologyCo.,Ltd. DeclarationonModelDifferences We, ShenzhenInterthingsTechnologyCo.,Ltd. 701,Building1,LechuanghuiBuilding,No.1211GuanguangRoad,LonghuaDistrict, Shenzhen,China Declarethatthefollowingproduct(s): FCCID:2AQ7B-IPC302 ProductName:SmartOutdoorCamera ModelNo.:IPC302,CAM/WM//WIFI Utilizetheidenticalcircuitdesign,PCBlayout,shieldingandinterfacewith(IPC302),only modelnameandpackageboxdifferent.Thereforethisapplicationcanberegardedas identicalinperformancetothesubmittedtestsample. Themanufacturerwouldtakealltheresponsibilitiesfortheaboveproduct(s). Forandonbehalfof Sincerely, Signature LucyFang Manager ShenzhenInterthingsTechnologyCo.,Ltd. *IherebydeclarethatIamentitledtosignonbehalfoftheapplicantandthattheinformationsuppliediscorrectandcomplete.

Cover Letter(s)

C5266091_X10_Ed.2 1/1 Shenzhen Interthings Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024.03.07 Subject: Request for Confidentiality FCC ID: 2AQ7B-IPC302 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Lucy Fang Title: Manager

External Photos

ProjectNo.:18220WC400229Page 1 of 4 AppendixII--ExternalPhotograph ProjectNo.:18220WC400229Page 2 of 4 ProjectNo.:18220WC400229Page 3 of 4 ProjectNo.:18220WC400229Page 4 of 4

Internal Photos

ProjectNo.:18220WC400229Page 1 of 4 AppendixIII--InternalPhotograph ProjectNo.:18220WC400229Page 2 of 4 ProjectNo.:18220WC400229Page 3 of 4 ProjectNo.:18220WC400229Page 4 of 4 BLE&WiFiANT

RF Exposure Info

MAXIMUMPERMISSIBLEEXPOSURE KDB447498D01MobileandPortableDevicesRFExposureProceduresand EquipmentAuthorizationPoliciesv06. AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeused toevaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF) Radiationasspecifiedin§1.1307(b) EUTSpecification FCCID 2AQ7B-IPC302 EUT SmartOutdoorCamera Frequencyband(Operating)BT:2.402GHz~2.480GH WLAN:2.412GHz~2.462GHz RLAN:5.180GHz~5.240GHz RLAN:5.260GHz~5.320GHz RLAN: 5.500 GHz~ 5.700 GHz RLAN:5.745GHz~5.825GHz Others:BLE:2.402GHz~2.480GH DevicecategoryPortable(<20cmseparation) Mobile(>20cmseparation) Others___ ExposureclassificationOccupational/Controlledexposure GeneralPopulation/Uncontrolledexposure AntennadiversitySingleantenna Multipleantennas Txdiversity Rxdiversity Tx/Rxdiversity Antennagain(Max)2.54dBi EvaluationappliedMPEEvaluation SAREvaluation LimitsforMaximumPermissibleExposure(MPE) Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) Power Density(mW/cm 2 ) AverageTime (A)LimitsforOccupational/ControlExposures 300-1500----F/3006 1500-100000----56 (B)LimitsforGeneralPopulation/UncontrolExposures 300-1500----F/150030 1500-100000----130 Friistransmissionformula:Pd=(Pout*G)\(4*pi*R2) Where Pd=PowerdensityinmW/cm 2 Pout=outputpowertoantennainMw G=gainofantennainlinearscale Pi=3.1416 R=distancebetweenobservationpointandcenteroftheradiatorincm PdthelimitofMPE.Ifweknowthemaximumgainoftheantennaandtotalpowerinputto theantenna,throughthecalculation,wewillknowthedistancewheretheMPElimitis reached. MeasurementResult OperatingMode Maximum output power (dBm) Tuneup tolerance (dBm) Max.Tuneup Power (dBm) Antenna Gain (dBi) Power densityat 20cm (mW/cm 2 ) Power density Limits (mW/cm 2 ) WiFi2.4G15.5715.57±1 16.572.540.0162 1 BLE3.633.63±1 4.632.540.0010 1 Note:BT&WiFicannotsupportsimultaneoustransmission. Result:NoStandaloneSARtestisrequired.

Test Report

DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 1/9 承认书 APPROVALSHEET 客户名称 CUSTOMERNAME: 产品名称 PRODUCTNAME:2.4GW86白色天线L=125mm+端子客户料号 CUSTOMERP/N: 优比电子料号 YoubiP/N:UB02C120W2D2338AREV:A MANUFACTURER SIGNATURE CUSTOMER SIGNATURE CHECKEDBY:Yongxin.lu APPROVEDBY:Changxing.Liu DATE:2022/04/12 DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 2/9 ModificationHistory VersionContentRevisionIssuedbyDate AOriginalversionYongxin.Lu2022-04-12 DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 3/9 Content ltemDescription 1.--------------------------------------------------------------------ElectricalSpecification 2.---------------------------------------------------------------TestItemsandEquipment 3.---------------------------------------------------------------------------------SParameter 4.------------------------------------------------------------------------EfficiencyandGain 5.---------------------------------------------------------------------------RadiationPattern 6.-----------------------------------------------------------------MechanicalSpecification 7.------------------------------------------------------------------------------------Packaging DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 4/9 1.ElectricalSpecification: 2.TestItemsandEquipment CharacteristicsSpecificationsUnit OutlineDimensions12x64.2,L=125mm Frequency 2400-2500 MHz Impedance50Ω VSWR≤ 2.0 PolarizationLinearPolarization Gain2REF dBi Efficiency>60 % ConnectorType1.13MHF-1-Plug Operatingtemperature -20 °C ~+60 °C StorageTemp -20 °C ~+50 °C TestitemsTestequipment SParameter 1.ReturnLoss 2.VSWR Networkanalyzer (AgilentE5071B) Thewholemachineof Passiveparameters 1.Frequency 2.Gain 3.RadiationPattern 1.3Dmicrowavedarkroom (5m*5m*5m) 2.Networkanalyzer (AgilentE5071B) Thewholemachineof Activeparameters 1.TRP 2.TIS 1.3Dmicrowavedarkroom (5m*5m*5m) 2.Comprehensivetestinstrument (CMW500) DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 5/9 3.SParameter *VoltageStandingWaveRatio(VSWR) ReturnLoss(RL) RL=20*log10[(VSWR+1)/(VSWR-1) 4.EfficiencyandGain Frequency (MHz) 240024502500 Efficiency (%) 74.9984.5384.14 Gain (dBi) 1.682.232.54 Frequency (MHz) Return Loss(dB) VSWR 2400-11.121.77 2450-15.161.42 2500-14.671.45 DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 6/9 5.RadiationPattern 5-1Antenna3DRadiationPattern 2400MHz 2450MHz 2500MHz DongguanYoubiElectronicsCo.,LTDHangzhouYoubige ElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106, BuildingA,XinzhengIndustrialPark, XinfaRoa d,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57 LiuxianRoad,Bao 'an District,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 7 / 9 5-2 Antenna2D RadiationPattern Phi 0 2D Phi 90 2D Theta90 2D Vertical Plane Horizontal Plane DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 8/9 6.MechanicalSpecification: DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 9/9 7.Packaging

Test Report

ReportNo.:18220WC40022901FCCID:2AQ7B-IPC302Page1of31 FCCTestReport Applicant:ShenzhenInterthingsTechnologyCo.,Ltd. Address: 701,Building1,LechuanghuiBuilding,No.1211 GuanguangRoad,LonghuaDistrict, Shenzhen,China ProductName:SmartOutdoorCamera ReportDate:Mar.06,2024 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC40022901FCCID:2AQ7B-IPC302Page2of31 Contents 1.GeneralInformation.................................................................................................................................6 1.1.ClientInformation...........................................................................................................................6 1.2.DescriptionofDevice(EUT)..........................................................................................................6 1.3.AuxiliaryEquipmentUsedDuringTest..........................................................................................7 1.4.Operationchannellist....................................................................................................................7 1.5.DescriptionofTestModes.............................................................................................................7 1.6.MeasurementUncertainty.............................................................................................................8 1.7.TestSummary................................................................................................................................9 1.8.DescriptionofTestFacility...........................................................................................................10 1.9.Disclaimer....................................................................................................................................10 1.10.TestEquipmentList....................................................................................................................11 2.Antennarequirement..............................................................................................................................13 2.1.Conclusion...................................................................................................................................13 3.ConductedEmissionatACpowerline..................................................................................................14 3.1.EUTOperation.............................................................................................................................14 3.2.TestSetup....................................................................................................................................14 3.3.TestData......................................................................................................................................15 4.OccupiedBandwidth..............................................................................................................................17 4.1.EUTOperation.............................................................................................................................17 4.2.TestSetup....................................................................................................................................17 4.3.TestData......................................................................................................................................17 5.MaximumConductedOutputPower......................................................................................................18 5.1.EUTOperation.............................................................................................................................18 5.2.TestSetup....................................................................................................................................18 5.3.TestData......................................................................................................................................18 6.PowerSpectralDensity..........................................................................................................................19 6.1.EUTOperation.............................................................................................................................19 6.2.TestSetup....................................................................................................................................19 6.3.TestData......................................................................................................................................19 7.Emissionsinnon-restrictedfrequencybands.......................................................................................20 7.1.EUTOperation.............................................................................................................................20 7.2.TestSetup....................................................................................................................................20 7.3.TestData......................................................................................................................................20 8.Bandedgeemissions(Radiated)..........................................................................................................21 8.1.EUTOperation.............................................................................................................................21 8.2.TestSetup....................................................................................................................................21 8.3.TestData......................................................................................................................................22 9.Emissionsinfrequencybands(below1GHz).......................................................................................23 9.1.EUTOperation.............................................................................................................................23 9.2.TestSetup...................…

Text truncated - open the document above for the full version.

Test Report

Page1of33 AppendixTestData ReportNo.:18220WC40022901TestSampleNo.:1-2-2 StartTestDate:2023.2.24FinishTestDate:2023.2.24 TestEngineer:Auditor: Temperature:25.3 °C RelativeHumidity:48% Pressure:101kPa AppendixA:DTSBandwidth TestResult TestModeAntennaFrequency[MHz] DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict BLE_1MAnt1 24020.5082401.7002402.2080.5PASS 24400.5202439.6962440.2160.5PASS 24800.5282479.6882480.2160.5PASS BLE_2MAnt1 24020.8642401.4402402.3040.5PASS 24400.8362439.4402440.2760.5PASS 24800.8322479.4282480.2600.5PASS Page2of33 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page3of33 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 Page4of33 BLE_2M_Ant1_2480 Page5of33 AppendixB:OccupiedChannelBandwidth TestResult TestModeAntennaFrequency[MHz] OCB[MHz] FL[MHz]FH[MHz] BLE_1MAnt1 24021.07692401.48962402.5665 24401.09342439.47352440.5669 24801.12222479.44412480.5663 BLE_2MAnt1 24022.05512401.01842403.0735 24402.06222439.01212441.0743 24802.07782479.00282481.0806 Page6of33 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page7of33 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 Page8of33 BLE_2M_Ant1_2480 Page9of33 AppendixC:Maximumconductedoutputpower TestResultPeak TestModeAntennaFrequency[MHz] ConductedPeak Power[dBm] Conducted Limit[dBm] Verdict BLE_1MAnt1 24023.17≤30PASS 24403.52≤30PASS 24803.62≤30PASS BLE_2MAnt1 24023.15≤30PASS 24403.53≤30PASS 24803.63≤30PASS Page10of33 TestGraphsPeak BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page11of33 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 Page12of33 BLE_2M_Ant1_2480 Page13of33 AppendixD:Maximumpowerspectraldensity TestResult TestModeAntennaFrequency[MHz]Result[dBm/3kHz]Limit[dBm/3kHz]Verdict BLE_1MAnt1 2402-16.81≤8.00PASS 2440-16.87≤8.00PASS 2480-16.77≤8.00PASS BLE_2MAnt1 2402-19.36≤8.00PASS 2440-19≤8.00PASS 2480-18.77≤8.00PASS Page14of33 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page15of33 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 Page16of33 BLE_2M_Ant1_2480 Page17of33 AppendixE:Bandedgemeasurements TestResult TestMod e Antenn a ChNam e Frequency[MHz ] RefLevel[dBm ] Result[dBm ] Limit[dBm ] Verdic t BLE_1MAnt1 Low24022.82-49.8≤-17.18PASS High24803.56-52.37≤-16.44PASS BLE_2MAnt1 Low24022.54-31.06≤-17.46PASS High24802.36-46.14≤-17.65PASS Page18of33 TestGraphs BLE_1M_Ant1_Low_2402 BLE_1M_Ant1_High_2480 BLE_2M_Ant1_Low_2402 Page19of33 BLE_2M_Ant1_High_2480 Page20of33 AppendixF:ConductedSpuriousEmission TestResult TestMod e Antenn a Frequency[MHz ] FreqRange [MHz] RefLeve l [dBm] Result[dBm ] Limit[dBm ] Verdic t BLE_1MAnt1 2402 Reference2.982.98---PASS 30~10002.98-65.86≤-17.02PASS 1000~2650 0 2.98-47.44≤-17.02PASS 2440 Reference3.353.35---PASS 30~10003.35-69.1≤-16.65PASS 1000~2650 0 3.35-46.16≤-16.65PASS 2480 Reference3.463.46---PASS 30~10003.46-69.1≤-16.54PASS 1000~2650 0 3.46-48.22≤-16.54PASS BLE_2MAnt1 2402 Reference2.272.27---PASS 30~10002.27-49.04≤-17.73PASS 1000~2650 0 2.27-46.93≤-17.73PASS 2440 Reference2.632.63---PASS 30~10002.63-68.79≤-17.37PASS 1000~2650 0 2.63-51.45≤-17.37PASS 2480 Reference2.882.88---PASS 30~10002.88-68.85≤-17.12PASS 1000~2650 0 2.88-52.92≤-17.12PASS Page21of33 TestGraphs BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 BLE_1M_Ant1_2402_1000~26500 Page22of33 BLE_1M_Ant1_2440_0~Reference BLE_1M_Ant1_2440_30~1000 Page23of33 BLE_1M_Ant1_2440_1000~26500 BLE_1M_Ant1_2480_0~Reference Page24of33 BLE_1M_Ant1_2480_30~1000 BLE_1M_Ant1_2480_1000~26500 Page25of33 BLE_2M_Ant1_2402_0~Reference BLE_2M_Ant1_2402_30~1000 Page26of33 BLE_2M_Ant1_2402_1000~26500 BLE_2M_Ant1_2440_0~Reference Page27of33 BLE_2M_Ant1_2440_30~1000 BLE_2M_Ant1_2440_1000~26500 Page28of33 BLE_2M_Ant1_2480_0~Reference BLE_2M_Ant1_2480_30~1000 Page29of33 BLE_2M_Ant1_2480_1000~26500 Page30of33 AppendixG:DutyCycle TestResult TestModeAntennaFrequency[MHz] ONTime [ms] Period [ms] DutyCycle [%] DutyCycle Factor[dB] BLE_1MAnt1 24020.080.6212.908.89 24400.080.6212.908.89 24800.080.6212.908.89 BLE_2MAnt1 24020.050.628.0610.94 24400.060.629.6810.14 24800.060.639.5210.21 Page31of33 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page32of33 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 Page33of33 BLE_2M_Ant1_2480 ---END---

Test Report

ReportNo.:18220WC40022902FCCID:2AQ7B-IPC302Page1of32 FCCTestReport Applicant:ShenzhenInterthingsTechnologyCo.,Ltd. Address: 701,Building1,LechuanghuiBuilding,No.1211 GuanguangRoad,LonghuaDistrict, Shenzhen,China ProductName:SmartOutdoorCamera ReportDate:Mar.06,2024 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC40022902FCCID:2AQ7B-IPC302Page2of32 Contents 1.GeneralInformation.................................................................................................................................6 1.1.ClientInformation...........................................................................................................................6 1.2.DescriptionofDevice(EUT)..........................................................................................................6 1.3.AuxiliaryEquipmentUsedDuringTest..........................................................................................7 1.4.Operationchannellist....................................................................................................................7 1.5.DescriptionofTestModes.............................................................................................................7 1.6.MeasurementUncertainty.............................................................................................................7 1.7.TestSummary................................................................................................................................8 1.8.DescriptionofTestFacility.............................................................................................................9 1.9.Disclaimer......................................................................................................................................9 1.10.TestEquipmentList...................................................................................................................10 2.Antennarequirement..............................................................................................................................12 2.1.Conclusion...................................................................................................................................12 3.ConductedEmissionatACpowerline..................................................................................................13 3.1.EUTOperation.............................................................................................................................13 3.2.TestSetup....................................................................................................................................13 3.3.TestData......................................................................................................................................14 4.OccupiedBandwidth..............................................................................................................................16 4.1.EUTOperation.............................................................................................................................16 4.2.TestSetup....................................................................................................................................16 4.3.TestData......................................................................................................................................16 5.MaximumConductedOutputPower......................................................................................................17 5.1.EUTOperation.............................................................................................................................17 5.2.TestSetup....................................................................................................................................17 5.3.TestData......................................................................................................................................17 6.PowerSpectralDensity..........................................................................................................................18 6.1.EUTOperation.............................................................................................................................18 6.2.TestSetup....................................................................................................................................18 6.3.TestData......................................................................................................................................18 7.Emissionsinnon-restrictedfrequencybands.......................................................................................19 7.1.EUTOperation.............................................................................................................................19 7.2.TestSetup....................................................................................................................................19 7.3.TestData......................................................................................................................................19 8.Bandedgeemissions(Radiated)..........................................................................................................20 8.1.EUTOperation.............................................................................................................................20 8.2.TestSetup....................................................................................................................................20 8.3.TestData......................................................................................................................................21 9.Emissionsinfrequencybands(below1GHz).......................................................................................24 9.1.EUTOperation.............................................................................................................................24 9.2.TestSetup..................…

Text truncated - open the document above for the full version.

Test Report

Page1of49 AppendixTestData ReportNo.:18220WC40022902TestSampleNo.:1-2-2 StartTestDate:2024.2.23FinishTestDate:2024.2.24 TestEngineer:Auditor: Temperature:25.3°CRelativeHumidity:48% Pressure:101kPa AppendixA:DTSBandwidth TestResult TestModeAn…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Rongli Sun(Account Manager)

[email protected]86-755-21040734Fax: 86-755-21040734

Technical Contact

Shenzhen Anbotek Compliance Laboratory LimitedJeff Zhu

[email protected]13798230942

Shenzhen · China

Test Firm

Shenzhen Anbotek Compliance Laboratory LimitedJeff Zhu

[email protected]13798230942

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.41 GHz - 2.46 GHz	36.10 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons. End-users must be provided with operating procedures for satisfying RF exposure compliance.
