2AQRPTJC05610WWireless Charging Stand

C M Y CM MY CY CMY K Wireless_Manual_252333_paths.pdf 1 11/18/19 7:40 PM FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

FCC ID: 2AQRPTJC05610W

Label Location On EUT Label Product Name: Wireless Charging Stand Model No.: C-056 FCC ID: 2AQRPTJC05610W This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AQRPTJC05610W ANT

version01 Dongguan Tyjin Electronics Co., Ltd. Declaration concerning Antenna Specification It is hereby declared that the product Model No.: C-056 FCC ID : 2AQRPTJC05610W fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: C-056 Type of antenna:Inductive loop coil Antenna Gain of the antenna: 0 dBi Frequency range:111-205KHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China City: Dongguan ZIP / Postal code: N/A Country:China Place:DongguanDate: 2020-05-14 Signature:

Report No.: SZAWW191216004-02FCC ID: 2AQRPTJC05610WPage 1 of 13 Code:AB-RF-05-a FCC TEST REPORT Client Name: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Product Name: Wireless Charging Stand Date: May 13, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: SZAWW191216004-02FCC ID: 2AQRPTJC05610WPage 2 of 13 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 5 2. Measurement and Result ..................................................................................................................................... 6 2.1. Requirements .............................................................................................................................................. 6 2.2. Test Setup .................................................................................................................................................... 7 2.3. Test Procedure ............................................................................................................................................ 7 2.4. Test Result ................................................................................................................................................... 7 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 7 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 .................................................................................................................................................................. 9 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 11 Report No.: SZAWW191216004-02FCC ID: 2AQRPTJC05610WPage 3 of 13 Code:AB-RF-05-a TEST REPORT Applicant: Dongguan Tyjin Electronics Co., Ltd. Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Product Name: Wireless Charging Stand Model No.: C-056 Trade Mark: N.A. Rating(s): Input: DC 5V, 2A/DC 9V, 1.67A Output: 5W/7.5W/10W Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptDec. 17, 2019 Date of TestDec. 17, 2019~Mar. 20, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: SZAWW191216004-02FCC ID: 2AQRPTJC05610WPage 4 of 13 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Wireless Charging Stand Model No.:C-056 Trade Mark: N.A. Test Power Supply: AC 120V, 60Hz for adapter Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency:111-205KHz Modulation Type:ASK Antenna Type:Inductive loop coil Antenna Antenna Gain(Peak):0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Address : Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Factory: Dongguan Tyjin Electronics Co., Ltd. Address : Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Report No.: SZAWW191216004-02FCC ID: 2AQRPTJC05610WPage 5 of 13 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test Adapter:Manufacturer: ZTE M/N: STC-A2050I1000USBA-C S/N: 201202102100876 Input: 100-240V~ 50/60Hz, 0.3A Output: DC 5V, 2000mA 1.4. Test Equipment List ItemEquipmentManufacturerModel No.Serial No.Last Cal.Cal. Interval 1 Magnetic field meter NARDAELT-400423623 Dec. 23, 2019 1 Year 2E-Field ProbeNardaEF0391Q15221 Nov.17, 2017 3 Year 3H-Field ProbeNardaHF3061Q15835 Nov.17, 2017 3 Year 1.5. Measurement Uncertainty Radiation Uncertainty: Ur = 3.9 dB (Horizontal) Ur = 3.8 dB (Vertical) Conduction Uncertainty: Uc = 3.4 dB 1.6. Description of Test Facility The test facility is recognized, certified, oraccredited by the following organizations: FCC-Regist…

Text truncated - open the document above for the full version.

Report No.: SZAWW191216004-01FCC ID: 2AQRPTJC05610WPage 1 of 27 Code:AB-RF-05-a FCC TEST REPORT Client Name: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Product Name: Wireless Charging Stand Date: May 13, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: SZAWW191216004-01FCC ID: 2AQRPTJC05610WPage 2 of 27 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 4 1.4. Description of Test Modes ........................................................................................................................ 5 1.5. Description Of Test Setup ......................................................................................................................... 6 1.6. Test Equipment List .................................................................................................................................... 7 1.7. Measurement Uncertainty ......................................................................................................................... 8 1.8. Description of Test Facility ........................................................................................................................ 8 2. Summary of Test Results ..................................................................................................................................... 9 3. Conducted Emission Test ................................................................................................................................... 10 3.1. Test Standard and Limit .......................................................................................................................... 10 3.2. Test Setup .................................................................................................................................................. 10 3.3. Test Procedure .......................................................................................................................................... 10 3.4. Test Data .................................................................................................................................................... 10 4. Radiation Spurious Emission and Band Edge ................................................................................................ 13 4.1. Test Standard and Limit .......................................................................................................................... 13 4.2. Test Setup .................................................................................................................................................. 13 4.3. Test Procedure .......................................................................................................................................... 14 4.4. Test Data .................................................................................................................................................... 15 5. Antenna Requirement ......................................................................................................................................... 19 5.1. Test Standard and Requirement ............................................................................................................ 19 5.2. Antenna Connected Construction .......................................................................................................... 19 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 20 APPENDIX II -- EXTERNAL PHOTOGRAPH ..................................................................................................... 22 APPENDIX III -- INTERNAL PHOTOGRAPH ..................................................................................................... 25 Report No.: SZAWW191216004-01FCC ID: 2AQRPTJC05610WPage 3 of 27 Code:AB-RF-05-a TEST REPORT Applicant: Dongguan Tyjin Electronics Co., Ltd. Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Product Name: Wireless Charging Stand Model No.: C-056 Trade Mark: N.A. Rating(s): Input: DC 5V, 2A/DC 9V, 1.67A Output: 5W/7.5W/10W Test Standard(s) : FCC Part15 Subpart C 2019, Paragraph 15.209 Test Method(s): ANSI C63.10: 2013 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 15 Subpart C requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptDec. 17, 2019 Date of TestDec. 17, 2019~Mar. 20, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: SZAWW191216004-01FCC ID: 2AQRPTJC05610WPage 4 of 27 Code:AB-RF-05-a 1. General Information 1.1. Client Information Applicant: Dongguan Tyjin Electronics Co., Ltd. Address: Shitoulin…

Text truncated - open the document above for the full version.
