2AQRPTJC109WCWireless Charging Pad

C M Y CM MY CY CMY K WX-WirelessCharging-Manual-OL.pdf 1 12/31/18 1:37 PM FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

FCC ID: 2AQRPTJC109WC

Label Location On EUT Label Product Name: Wireless Charging Pad Model No.: C-109 FCC ID: 2AQRPTJC109WC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AQRPTJC109WC

version01 Dongguan Tyjin Electronics Co., Ltd. Declaration concerning Antenna Specification It is hereby declared that the product Model No.: C-109, WXQI1076N, WXQI1080B, WXQI1082Z FCC ID : 2AQRPTJC109WC fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: C-109 Type of antenna:Inductive loop coil Antenna Gain of the antenna: 0 dBi Frequency range:110.1-205KHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China City: Dongguan ZIP / Postal code: N/A Country:China Place:DongguanDate: 2020-04-08 Signature:

Report No.: 18220WC00020502FCC ID: 2AQRPTJC109WCPage 1 of 13 Code:AB-RF-05-a FCC TEST REPORT Client Name: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Product Name: Wireless Charging Pad Date: Apr. 08 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00020502FCC ID: 2AQRPTJC109WCPage 2 of 13 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 5 2. Measurement and Result ..................................................................................................................................... 6 2.1. Requirements .............................................................................................................................................. 6 2.2. Test Setup .................................................................................................................................................... 7 2.3. Test Procedure ............................................................................................................................................ 7 2.4. Test Result ................................................................................................................................................... 7 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 7 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 .................................................................................................................................................................. 9 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 11 Report No.: 18220WC00020502FCC ID: 2AQRPTJC109WCPage 3 of 13 Code:AB-RF-05-a TEST REPORT Applicant: Dongguan Tyjin Electronics Co., Ltd. Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Product Name: Wireless Charging Pad Model No.: C-109, WXQI1076N, WXQI1080B, WXQI1082Z Trade Mark: , Rating(s): Input: DC 5V, 2A Wireless output: 5W Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptMar. 17, 2020 Date of TestMar. 17~25, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00020502FCC ID: 2AQRPTJC109WCPage 4 of 13 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Wireless Charging Pad Model No.: C-109, WXQI1076N, WXQI1080B, WXQI1082Z (Note: All samples are the same except the model appearance, so we prepare "C-109" for test only.) Trade Mark: , Test Power Supply: AC 120V, 60Hz for adapter Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency:110.1-205KHz Modulation Type:ASK Antenna Type:Inductive loop coil Antenna Antenna Gain(Peak):0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Address : Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Factory: Dongguan Tyjin Electronics Co., Ltd. Address : Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Report No.: 18220WC00020502FCC ID: 2AQRPTJC109WCPage 5 of 13 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test Adapter: Model: A2013 Input: 100-240V~50/60Hz 0.7A Output: DC 3.6-6.5V, 3A/6.5-9V, 2A/9-12V, 1.5A 1.4. Test Equipment List ItemEquipmentManufacturerModel No.Serial No.Last Cal.Cal. Interval 1 Magnetic field meter NARDAELT-400423623 Dec. 23, 2019 1 Year 2E-Field ProbeNardaEF0391Q15221 Nov.17, 2017 3 Year 3H-Field ProbeNardaHF3061Q15835 Nov.17, 2017 3 Year 1.5. Measurement Uncertainty Radiation Uncertainty: Ur = 3.9 dB (Horizontal) Ur = 3.8 dB (Vertical) Conduction Uncertainty: Uc = 3.4 dB 1.6. Description of Test Facility The test f…

Text truncated - open the document above for the full version.

FCC ID: 2AQRPTJC109WC Photo of Conducted Emission Measurement Photo of Radiation Emission Test Photo of MPE Measurement
