2AQRPTJC128WCWireless Charging Pad

MODEL: IHQI006 PLEASE MAKE SURE TO USE A WALL ADAPTER OR USB PORT THAT IS 1A - 2.4A 2.4A CHARGERS WILL ENABLE FAST CHARGE FUNCTION. DO NOT USE ANY USB PORTS BELOW 1A (EX: COMPUTERS OR USB PORTS THAT ARE BELOW 1A.) NORMAL & FAST WIRELESS CHARGING GET TO KNOW YOUR CHARGER TROUBLESHOOTING •SINGLE-COIL QI WIRELESS CHARGER •INDUCTIVE CHARGING •CHARGING INDICATOR LED •DESIGNED FOR QI COMPLIANCE INCORRECT PLACEMENT CORRECT PLACEMENT FAST CHARGE LED INDICATOR QI™ ENABLED ANTI-SLIP SURFACE AIRPAD ™ FOR iPHONE WIRELESS CHARGING ! This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: &KDQJHVRUPRGL ́FDWLRQVQRWH[SUHVVO\ approved by the party responsible for compliance could void the user's authority to operate this device. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. &RQVXOWWKHGHDOHURUDQH[SHULHQFHGUDGLR79WHFKQLFLDQ for help. DATE.2019 IF YOU HAVE PROBLEMS WITH WIRELESS CHARGING MAKE SURE YOUR PHONE IS CENTERED ON CHARGER. COMPATIBILITY: iPhone ® X, iPhone ® XR, iPhone ® XS, iPhone ® ;60D[L3KRQH ® 8 Plus, iPhone ® 8, 6DPVXQJ*DOD[\6 ® , S10 Plus ® , S8 ® , and any other wireless charging compatible device INPUT: 9$ OUTPUT: 7.5-10W FOR MAX CHARGING SPEED: Use a 2.4A AC Adapter PACKAGE INCLUDES: (1) Wireless Charging Mat, (1) Charging Cable QI™ WIRELESS COMPATIBLE SMARTPHONE SURFACE FOR WIRELESS CHARGING BACK FRONT This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC Radiation Exposure Statement: COMPATIBILITY: iPhone ® X, iPhone ® XS iPhone ® XS Max, iPhone ® XR, iPhone ® 8 Plus, iPhone ® 8 Samsung Galaxy S10 ® , Galaxy S10+ ® Galaxy S10e ® , Galaxy S9 ® , & Note 8 5V2A, 9V1.67A 5W/7.5W/10W Quick Charge adapter

FCC ID: 2AQRPTJC128WC

Label Location On EUT Label Product Name: Wireless Charging Pad Model No.: C-128 FCC ID: 2AQRPTJC128WC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AQRPTJC128WC ANT

version01 DongguanTyjinElectronicsCo.,Ltd. DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:C-128,IHQI1006J-WM,IHQI1006W-WM FCCID:2AQRPTJC128WC fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsforinternalantennatype(s) describedbelow: ModelNo.ofantenna:C-128 Typeofantenna:InductiveloopcoilAntenna Gainoftheantenna:0dBi Frequencyrange:110.1-205KHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname: DongguanTyjinElectronicsCo.,Ltd. Address:ShitoulingIndustrialZone,WulianVillage,FenggangTown,Dongguan,China City:Dongguan ZIP/Postalcode:N/A Country:China Place:DongguanDate: 2020-04-01 Signature:

Report No.: 18220WC00020402FCC ID: 2AQRPTJC128WCPage 1 of 13 Code:AB-RF-05-a FCC TEST REPORT Client Name: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Product Name: Wireless Charging Pad Date: Mar. 31, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00020402FCC ID: 2AQRPTJC128WCPage 2 of 13 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 5 2. Measurement and Result ..................................................................................................................................... 6 2.1. Requirements .............................................................................................................................................. 6 2.2. Test Setup .................................................................................................................................................... 7 2.3. Test Procedure ............................................................................................................................................ 7 2.4. Test Result ................................................................................................................................................... 7 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 7 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 .................................................................................................................................................................. 9 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 11 Report No.: 18220WC00020402FCC ID: 2AQRPTJC128WCPage 3 of 13 Code:AB-RF-05-a TEST REPORT Applicant: Dongguan Tyjin Electronics Co., Ltd. Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Product Name: Wireless Charging Pad Model No.: C-128, IHQI1006J-WM, IHQI1006W-WM Trade Mark: N.A. Rating(s): Input: DC 5V, 2A/DC 9V, 1.67A Wireless output: 5W/7.5W/10W Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptMar. 17, 2020 Date of TestMar. 17~25, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00020402FCC ID: 2AQRPTJC128WCPage 4 of 13 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Wireless Charging Pad Model No.: C-128, IHQI1006J-WM, IHQI1006W-WM (Note: All samples are the same except the model appearance, so we prepare "C-128" for test only.) Trade Mark: N.A. Test Power Supply: AC 120V, 60Hz for adapter Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency:110.1-205KHz Modulation Type:ASK Antenna Type:Inductive loop coil Antenna Antenna Gain(Peak):0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Address : Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Factory: Dongguan Tyjin Electronics Co., Ltd. Address : Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Report No.: 18220WC00020402FCC ID: 2AQRPTJC128WCPage 5 of 13 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test Adapter:Manufacturer: ZTE M/N: STC-A2050I1000USBA-C S/N: 201202102100876 Input: 100-240V~ 50/60Hz, 0.3A Output: DC 5V, 2000mA 1.4. Test Equipment List ItemEquipmentManufacturerModel No.Serial No.Last Cal.Cal. Interval 1 Magnetic field meter NARDAELT-400423623 Dec. 23, 2019 1 Year 2E-Field ProbeNardaEF0391Q15221 Nov.17, 2017 3 Year 3H-Field ProbeNardaHF3061Q15835 Nov.17, 2017 3 Year 1.5. Measurement Uncertainty Radiation Uncertainty: Ur = 3.9 dB (Horizontal) Ur = 3.8 dB (Vertical) Conduction Uncertainty: Uc = 3.4 …

Text truncated - open the document above for the full version.

Report No.: 18220WC00020401FCC ID: 2AQRPTJC128WCPage 1 of 28 Code:AB-RF-05-a FCC TEST REPORT Client Name: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Product Name: Wireless Charging Pad Date: Mar. 31, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00020401FCC ID: 2AQRPTJC128WCPage 2 of 28 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 4 1.4. Description of Test Modes ........................................................................................................................ 5 1.5. Description Of Test Setup ......................................................................................................................... 6 1.6. Test Equipment List .................................................................................................................................... 7 1.7. Measurement Uncertainty ......................................................................................................................... 8 1.8. Description of Test Facility ........................................................................................................................ 8 2. Summary of Test Results ..................................................................................................................................... 9 3. Conducted Emission Test ................................................................................................................................... 10 3.1. Test Standard and Limit .......................................................................................................................... 10 3.2. Test Setup .................................................................................................................................................. 10 3.3. Test Procedure .......................................................................................................................................... 10 3.4. Test Data .................................................................................................................................................... 10 4. Radiation Spurious Emission and Band Edge ................................................................................................ 13 4.1. Test Standard and Limit .......................................................................................................................... 13 4.2. Test Setup .................................................................................................................................................. 13 4.3. Test Procedure .......................................................................................................................................... 14 4.4. Test Data .................................................................................................................................................... 15 5. Antenna Requirement ......................................................................................................................................... 19 5.1. Test Standard and Requirement ............................................................................................................ 19 5.2. Antenna Connected Construction .......................................................................................................... 19 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 20 APPENDIX II -- EXTERNAL PHOTOGRAPH ..................................................................................................... 22 APPENDIX III -- INTERNAL PHOTOGRAPH ..................................................................................................... 26 Report No.: 18220WC00020401FCC ID: 2AQRPTJC128WCPage 3 of 28 Code:AB-RF-05-a TEST REPORT Applicant: Dongguan Tyjin Electronics Co., Ltd. Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Product Name: Wireless Charging Pad Model No.: C-128, IHQI1006J-WM, IHQI1006W-WM Trade Mark: N.A. Rating(s): Input: DC 5V, 2A/DC 9V, 1.67A Wireless output: 5W/7.5W/10W Test Standard(s) : FCC Part15 Subpart C 2019, Paragraph 15.209 Test Method(s): ANSI C63.10: 2013 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 15 Subpart C requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptMar. 17, 2020 Date of TestMar. 17~25, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00020401FCC ID: 2AQRPTJC128WCPage 4 of 28 Code:AB-RF-05-a 1. General Information 1.1. Client Information Applicant: Dongguan Tyjin Electronics Co., Ltd. Address…

Text truncated - open the document above for the full version.

FCC ID: 2AQRPTJC128WC Photo of Conducted Emission Measurement Photo of Radiation Emission Test Photo of MPE Measurement
