2AQRPTJC120WCWireless Charging Stand

Wireless Charging Stand for Qi-enabled smartphones Quick Start Guide We’d love to hear from you. Scan with your Walmart app and let us know what you think. 2AQRPTJC120WC What’s in the Box? Plug in the wireless charging stand Place your smartphone onto the stand The Fine Print 1 2 1. Wireless Charging Stand 2. Charging Cable Check to make sure you have 01 02 Using the charging cable that came in the box, insert the micro USB plug into the micro USB port on the back of the wireless charging stand. Insert the USB plug into any USB power source, (for example: a wall charger, car charger or computer USB port.) Place your Qi-enabled smartphone onto the center of the stand. The charging icon will appear on your smartphone screen to indicate your phone is charging. This equipment has been tested and found to comply with the limits for a WPC device, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. NOTE: This equipment has been tested and found to comply with the limits for a wireless power charger, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the product. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

FCC ID: 2AQRPTJC120WC

Label Location On EUT Label Product Name: Wireless Charging Stand Model No.: C-120 FCC ID: 2AQRPTJC120WC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AQRPTJC120WC ANT

version01 Dongguan Tyjin Electronics Co., Ltd. Declaration concerning Antenna Specification It is hereby declared that the product Model No.: C-120, WIABLK100010767 FCC ID : 2AQRPTJC120WC fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: C-120 Type of antenna:Inductive loop coil Antenna Gain of the antenna: 0 dBi Frequency range:110.1-205KHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China City: Dongguan ZIP / Postal code: N/A Country:China Place:DongguanDate: 2020-01-09 Signature:

Report No.: SZAWW191206005-02FCC ID: 2AQRPTJC120WCPage 1 of 13 Code:AB-RF-05-a FCC TEST REPORT Client Name: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Product Name: Wireless Charging Stand Date: Jan. 09, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: SZAWW191206005-02FCC ID: 2AQRPTJC120WCPage 2 of 13 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 5 2. Measurement and Result ..................................................................................................................................... 6 2.1. Requirements .............................................................................................................................................. 6 2.2. Test Setup .................................................................................................................................................... 7 2.3. Test Procedure ............................................................................................................................................ 7 2.4. Test Result ................................................................................................................................................... 7 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 7 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 .................................................................................................................................................................. 9 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 11 Report No.: SZAWW191206005-02FCC ID: 2AQRPTJC120WCPage 3 of 13 Code:AB-RF-05-a TEST REPORT Applicant: Dongguan Tyjin Electronics Co., Ltd. Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Product Name: Wireless Charging Stand Model No.: C-120, WIABLK100010767 Trade Mark: N.A. Rating(s): Input: DC 5V, 2A Wireless output: 5W Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptDec. 06, 2019 Date of Test Dec. 06~27, 2019 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: SZAWW191206005-02FCC ID: 2AQRPTJC120WCPage 4 of 13 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Wireless Charging Stand Model No.: C-120, WIABLK100010767 (Note: All samples are the same except the model number & appearance, so we prepare “C-120” for test only.) Trade Mark: N.A. Test Power Supply: AC 120V, 60Hz for adapter Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency:110.1-205KHz Modulation Type:ASK Antenna Type:Inductive loop coil Antenna Antenna Gain(Peak):0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Address : Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Factory: Dongguan Tyjin Electronics Co., Ltd. Address : Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Report No.: SZAWW191206005-02FCC ID: 2AQRPTJC120WCPage 5 of 13 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test Adapter:Manufacturer: ZTE M/N: STC-A2050I1000USBA-C S/N: 201202102100876 Input: 100-240V~ 50/60Hz, 0.3A Output: DC 5V, 2000mA Mobile Phone: iPhone 1.4. Test Equipment List ItemEquipmentManufacturerModel No.Serial No.Last Cal.Cal. Interval 1 Magnetic field meter NARDAELT-400423623 Dec. 23, 2019 1 Year 2E-Field ProbeNardaEF0391Q15221 Nov.17, 2017 3 Year 3H-Field ProbeNardaHF3061Q15835 Nov.17, 2017 3 Year 1.5. Measurement Uncertainty Radiation Uncertainty: Ur = 3.9 dB (Horizontal) Ur = 3.8 dB (Vertical) Conduction Uncertainty: Uc = 3…

Text truncated - open the document above for the full version.

Report No.: SZAWW191206005-01FCC ID: 2AQRPTJC120WCPage 1 of 27 Code:AB-RF-05-a FCC TEST REPORT Client Name: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Product Name: Wireless Charging Stand Date: Jan. 09, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: SZAWW191206005-01FCC ID: 2AQRPTJC120WCPage 2 of 27 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 4 1.4. Description of Test Modes ........................................................................................................................ 5 1.5. Description Of Test Setup ......................................................................................................................... 6 1.6. Test Equipment List .................................................................................................................................... 7 1.7. Measurement Uncertainty ......................................................................................................................... 8 1.8. Description of Test Facility ........................................................................................................................ 8 2. Summary of Test Results ..................................................................................................................................... 9 3. Conducted Emission Test ................................................................................................................................... 10 3.1. Test Standard and Limit .......................................................................................................................... 10 3.2. Test Setup .................................................................................................................................................. 10 3.3. Test Procedure .......................................................................................................................................... 10 3.4. Test Data .................................................................................................................................................... 10 4. Radiation Spurious Emission and Band Edge ................................................................................................ 13 4.1. Test Standard and Limit .......................................................................................................................... 13 4.2. Test Setup .................................................................................................................................................. 13 4.3. Test Procedure .......................................................................................................................................... 14 4.4. Test Data .................................................................................................................................................... 15 5. Antenna Requirement ......................................................................................................................................... 19 5.1. Test Standard and Requirement ............................................................................................................ 19 5.2. Antenna Connected Construction .......................................................................................................... 19 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 20 APPENDIX II -- EXTERNAL PHOTOGRAPH ..................................................................................................... 22 APPENDIX III -- INTERNAL PHOTOGRAPH ..................................................................................................... 26 Report No.: SZAWW191206005-01FCC ID: 2AQRPTJC120WCPage 3 of 27 Code:AB-RF-05-a TEST REPORT Applicant: Dongguan Tyjin Electronics Co., Ltd. Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Product Name: Wireless Charging Stand Model No.: C-120, WIABLK100010767 Trade Mark: N.A. Rating(s): Input: DC 5V, 2A Wireless output: 5W Test Standard(s) : FCC Part15 Subpart C 2018, Paragraph 15.209 Test Method(s): ANSI C63.10: 2013 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 15 Subpart C requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptDec. 06, 2019 Date of TestDec. 06~27, 2019 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: SZAWW191206005-01FCC ID: 2AQRPTJC120WCPage 4 of 27 Code:AB-RF-05-a 1. General Information 1.1. Client Information Applicant: Dongguan Tyjin Electronics Co., Ltd. Address: Shitouling Industri…

Text truncated - open the document above for the full version.

FCC ID: 2AQRPTJC120WC Photo of Conducted Emission Measurement Photo of Radiation Emission Test Photo of MPE Measurement
