http://www.tpmseuroshop.com/documents/declaration_conformities The device under test is manufactured by the grantee (Sensata Technologies) and sold as an OEM product. Per 47 CFR 2.909, 2.927, 2.931, 2.1033, 15.15(b) etc..., the grantee must ensure the end-user has all applicable / appropriate operating instructions. When end-user instructions are required, as in the case of this product, the grantee must notify the OEM to notify the end- user. Sensata Technologies will supply this document to the reseller/distributor dictating what must be included in the end user’s manual for the commercial product. INFORMATION TO BE INCLUDED IN THE END USER'S MANUAL The following information (in blue) must be included in the end product user’s manual to ensure continued FCC and Industry Canada regulatory compliance. The ID numbers must be included in the manual if the device label is not readily accessible to the end user. The compliance paragraphs below must be included in the user's manual. FCC ID: 2ATIMBREX IC: 25094-BREX This device complies with Part 15 of the FCC Rules and with Licence exempt RSS standards of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d'ISDE Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Note: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement This equipment should be installed and operated with a Minimum distance of 20cm Between the radiator and your body. This transmitter module must not be co-located or operating in conjunction with any other antenna or transmitter. Co-location with other transmitter antennas would require the use of FCC multi-transmitter product procedures. Cet équipement est conforme aux limites d'exposition aux radiations de la FCC et de l'ISDE établies pour un environnement non contrôlé. Ce module émetteur ne doit pas être co-localisé ou fonctionner en conjonction avec une autre antenne ou un autre émetteur. La co-localisation avec d’autres antennes d’émetteur nécessiterait l’utilisation des procédures FCC relatives aux produits multi-émetteurs. WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met.

Willow Run (WR) Test Labs, Inc. 7117 Fieldcrest Dr., Brighton, Michigan 48116 USA Tel: (734) 252-9785, Fax: (734) 926-9785, e-mail: [email protected] Re: Certification for Schrader Electronics FCC ID: 2ATIMBREX IC: 25094-BREX REQUEST FOR CONFIDENTIALITY Pursuant to USA FCC 47 CFR 0.457(d) and 0.459 and Canada IC RSP-100, Section 10, Schrader Electronics requests that a part of the subject application be held confidential. Schrader Electronics has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to ”competition” would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Exhibit Conf. TypeRational Exh 04 - Block DiagramPermanentIncludes proprietary internal oscillator frequency information. Exh 05 - SchematicsPermanentIncludes proprietary design information Exh 10 - BOM + PlacementPermanentIncludes proprietary design information Long Term Confidentiality (Permanent):Schrader Electronics requests that any exhibits listed above as permanently confidential be permanently withheld from public review. Wherein Long Term Confidentiality is not an option for specific exhibits with ISED, this request applies only to the FCC application for those exhibits. Short-Term Confidentiality (FCC Only):Schrader Electronics requests that any exhibits selected above as short term confidential be withheld from public view for a period of days (noted above) from the date of the Grant of Equipment Authorization and prior to marketing. If there are any questions regarding the application or testing performed, please contact us at the above address or call (734) 252-9785, or e-mail [email protected]. Sincerely, Joseph D. Brunett Willow Run (WR) Test Labs, Inc. 9

Willow Run (WR) Test Labs, Inc. 7117 Fieldcrest Dr., Brighton, Michigan 48116 USA Tel: (734) 252-9785, Fax: (734) 926-9785, e-mail: [email protected] Attn.:Certification and Engineering Bureau, Innovation, Science and Economic Development Canada 3701 Carling Avenue, Bldg. 94 Ottawa, Ontario K2H 8S2 Re: Certification for Sensata Technologies BReX IC: 25094-BREX If necessary, we have enclosed application materials for certification of Sensata Technologies BReX. It has been verified to comply with IC RSS-247/GENe. Current Variants: There is only a single variant of the EUT, as tested. If there are any questions regarding the application or testing performed, please contact us at the above address or call (734) 252-9785, or e-mail [email protected]. Sincerely, Joseph D. Brunett Willow Run (WR) Test Labs, Inc. 11 Willow Run (WR) Test Labs, Inc. 7117 Fieldcrest Dr., Brighton, Michigan 48116 USA Tel: (734) 252-9785, Fax: (734) 926-9785, e-mail: [email protected] Attn.:Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Re: Certification for Sensata Technologies BReX FCC ID: 2ATIMBREX If necessary, we have enclosed application materials for certification of Sensata Technologies BReX. It has been verified to comply with CFR Title 47, Part 15.247. Current Variants: There is only a single variant of the EUT, as tested. If there are any questions regarding the application or testing performed, please contact us at the above address or call (734) 252-9785, or e-mail [email protected]. Sincerely, Joseph D. Brunett Willow Run (WR) Test Labs, Inc. 10

Sensata Technologies Model: BREX Equipment Category: UHF to BLE Range Extender Intended Use: The Wireless Range Extender, also known as BREX, is a product installed in a motor vehicle which receives tire pressure sensor data at 433.92 MHz and sends that information to a proprietary BLE HUB via BLE protocols at 2.4 GHz. The 433.92 MHz UHF data is received by an NXP MANTRA IC and transferred over to the SiLabs EFR32MG21 SOC BLE radio ic for transmission. The BLE radio may use data rates of 125 kbps, 500 kbps, 1 Mbps, or 2 Mbps to transfer this data to the HUF.

Willow Run (WR) Test Labs, Inc. 7117 Fieldcrest Drive Brighton, MI 48116 Phone: (734) 252-9785, Fax (734) 926-9785 e-mail:[email protected] RF EXPOSURE CALCULATIONS Requirement: According to USA CFR 15 §1.1307 (b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. For Canada, RSS-102 sets out the requirements and measurement techniques used to evaluate radio frequency (RF) exposure compliance of radiocommunication apparatus designed to be used within the vicinity of the human body. Maximum Permissible Exposure Calculations: Summary: The EUT with all transmitters is compliant with both the FCC power density limit and the ISED Exposure Evaluation limits. USA REF: 1.1310, 2.1091/1093, 447498 D01 General RF Exposure Guidance v06 Test Date: 11-Oct-22 IC REF: RSS-102 Issue 5, Safety Code 6 Test Engineer: John Nantz Min. Sep. Distance: 20 cm (Mobile) EUT: SCHR1 BREX EUT Mode: Worst Case Meas. Distance: Conducted R0 Mode Canada ISED RSS-102 MPEUSA FCC 1.1310 MPE SC6 Limit (S20cm)S LimitMPE Ratio W/m2 R1 BLE/BT2402 10.90.211.1129.80.002455.5 1.00000 0.0024475 R2 BLE/BT2440 10.90.211.1129.80.002455.5 1.00000 0.0024475 R3 BLE/BT2480 10.90.211.1129.80.002455.5 1.00000 0.0024475 R4 Complies? Yes MPE Total (<1):0.0024475 R5Complies? Yes #C1C2C3C4C5C6C7C8C9C10C11 (ROW)(COLUMN)NOTE R0C3As Measured / Computed from highest fundamental emission, see fundamental emission section of this report. Maximum of either EIRP or Pout as measured. R0C5 Freq. MHz Worst Case EIRP(Pk/Avg)** dBm Declared Tolerance (dB) Worst Case EIRP w/ Tolerance dBm E20cm(Avg) dBuV/m S20cm(Avg)**** mW/cm2 mW/cm2 EIRP (mW) = S (mW/cm^2) x 4 x PI x 20cm^2

Amber Helm Development L.C. 92723 Michigan Hwy-152 Sister Lakes, Michigan 49047 USA Tel: 888-847-8027 SENBREX-WR2229EM Issued:October 20, 2022 EMC Test Report regarding USA: CFR Title 47, Part 15.247(Emissions) Canada:IC RSS-247/GENe(Emissions) for BReX Category: Vehicular BLE Transceiver Judgments: FCC 15.247, ISED RSS-247v2 Compliant Testing Completed: October 19, 2022 TESTING NVLAP LAB CODE 200129-0 Prepared for: Sensata Technologies Unit 11, Antrim Technology Park, Antrim Northern Ireland BT41 1QS United Kingdom Phone: +44 28 9448 2181, Fax: +44 28 9446 8440 Contact: Michael Maingot, [email protected] Data Rec./Rev. by: Rpt. Auth. by: Mr. John NantzDr. Joseph Brunett, EMC-002790-NE Rpt. Prep./Rev. by:Date of Issue:October 20, 2022 Mr. John Nantz A copy of this report will remain on file until October 2032.Page 1 of 30 Date: October 20, 2022Prepared For: Sensata TechnologiesReport No.: SENBREX-WR2229EM Revision History Rev. No.DateDetailsRevised By r0October 20, 2022Initial Release.J. Brunett r1November 14, 2022Update Tables.J. Brunett r2November 22, 2022Reviewer Corrections.J. Brunett r3November 22, 2022Detail ant. meas.J. Brunett Contents Revision History2 Table of Contents2 1 Test Report Scope and Limitations5 1.1 Laboratory Authorization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 1.2 Report Retention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 1.3 Subcontracted Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 1.4 Test Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 1.5 Limitation of Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 1.6 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 1.7 Endorsements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 1.8 Test Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 1.9 Traceability and Equipment Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 2 Test Specifications and Procedures7 2.1 Test Specification and General Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 3 Configuration and Identification of the Equipment Under Test8 3.1 Description and Declarations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 3.1.1EUT Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 3.1.2Modes of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 3.1.3Variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 3.1.4Test Samples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 3.1.5Functional Exerciser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 3.1.6Modifications Made . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 3.1.7Production Intent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3.1.8Declared Exemptions and Additional Product Notes . . . . . . . . . . . . . . . . . . . . . . . . 10 4 Emissions11 4.1 General Test Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 4.1.1Radiated Test Setup and Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 4.1.2Conducted Emissions Test Setup and Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . 13 4.1.3Power Supply Variation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 4.2 Intentional Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 4.2.1Duty and Transmission Cycle, Pulsed Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 14 4.2.2Fundamental Emission Bandwidth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 4.2.3Effective Isotropic Radiated Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 4.2.4Power Spectral Density . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 4.3 Unintentional Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 4.3.1Transmit Chain Radiated Spurious Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 4.3.2Relative Transmit Chain Spurious Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USAPage 2 of 30 Date: October 20, 2022Prepared For: Sensata TechnologiesReport No.: SENBREX-WR2229EM 5 Measurement Uncertainty and Accreditation Documents30 Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USAPage 3 of 30 Date: October 20, 2022Prepared For: Sensata TechnologiesReport No.: SENBREX-WR2229EM List of Tables 1Test Site List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 2Equipment List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 3EUT Declarations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 4Pulsed Emission Characteristics (Duty Cycle). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 5Intentional Emission Bandwidth.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 6Radiated Power Results.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 7Power Spectral Densi…
