2AUCU-50101ZZ-WAVE+ AUX SWITCH

SQR50101**Z Z-Wave TM Plus Auxiliary Switch ** = color code: WH (white), LA (light almond), BK (black), GY (gray) Features • Wireless Z-Wave technology creates a mesh network for command and control interoperability with other Z-Wave compliant controllers and devices. • Work with other Z-Wave switch or dimmer devices for 3-way (multi-location) control, provide manual and remote control. • The 3-way control can be achieved through below 2 methods. o Association group control or o Central scene control • Configurable child lockout feature which disables the manual control. NOTE: • This auxiliary switch is only a wireless controller, it cannot be used by itself for single-pole control. Specification of SQR50101**Z Z-Wave Plus Auxiliary Switch Voltage 120 Vac, 60 Hz Operating temperature 32–104°F (0–40°C) Wireless type Z-Wave (Support S2 and SmartStart) Wireless frequency 908.40 MHz / 908.42 MHz / 916 MHz 1 Suitable for at least 90°C. Precautions CAUTION HAZARD OF UNINTENDED USE This device is intended to be used for non-critical automation activities. It is not intended to support life, safety, or medical equipment. Failure to follow these instructions can result in personal injury or equipment damage. DANGER Instruction Bulletin GDE77963_Eng, HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH • Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See NFPA 70E, NOM-029-STPS or CSA Z462 or local equivalent. • This equipment must only be installed and serviced by qualified electrical personnel. • Turn off all power supplying this equipment before working on or inside equipment. • Always use a properly rated voltage sensing device to confirm power is off. • Use with copper wire only. • Indoor use only. • Replace all devices, doors, and covers before turning on power to this equipment. Failure to follow these instructions will result in death or serious injury. WARNING HAZARD OF HEAT AND FIRE DAMAGE Read all instructions before installation. The manufacturer will not be held responsible for product damage resulting from not following the instructions. • Wet hands are strictly prohibited. • Do not continue working after self-disassembly of any nature and damage of external forces. Failure to follow these instructions can result in death, injury or equipment damage. WARNING: This product can expose you to chemicals including Carbon black, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. Notice Wireless Range Conditions The wireless range is the effective distance of remote control and it will be impacted by the following conditions: • Each wall or obstacle (e.g., refrigerator, TV, etc.) between the remote or Z- Wave device and the destination device will reduce the wireless range. • Brick, tile, or concrete walls block more of the wireless signal than walls made of wooden studs and plasterboard (drywall). • The angle of direction between the remote or Z-Wave device and the destination device will also impact the wireless range; normally, placing the Z- Wave devices face-to-face will get the best wireless range. • Wall-mounted Z-Wave devices installed in metal junction boxes may suffer a significant loss of range since the metal box blocks a large part of the wireless signal. Instruction Bulletin SQR50101**Z Z-Wave Plus Auxiliary Switch GDE97963_Eng © 2020 Schneider Electric All Rights Reserved 3 Installation 1. Turn the power OFF at circuit breaker or fuse and test that power is off before wiring. 2. Wire the device according to the wiring diagram. 3. Check that all connections are tight and no bare wires exposed. 4. Install the device into the standard outlet box using the screws provided. (update the wiring diagram for aux switch) 5. Install the plate (not included). 6. Restore power. Operation The auxiliary switch can only control other Z-Wave devices after it is added into a Z-Wave network. Instruction Bulletin SQR50101**Z Z-Wave Plus Auxiliary Switch GDE97963_Eng © 2020 Schneider Electric All Rights Reserved 4 (update the drawing: removing air gap switch) 1. Inclusion to a Z-Wave network: NOTE: The device supports up to S2-authenticated inclusion method, based on the gateway’s feature. It is highly recommended to only select S2-authenticated or the highest inclusion method, and deselect other methods. This ensures the highest security level during Z-Wave service. During S2-authenticated inclusion, users may be asked to scan the QR code or enter a 5-digit pin code attached on the device. A. SmartStart inclusion: The feature assumes the gateway has implemented SmartStart. Users could use the APP of the gateway or the gateway camera to scan the QR code on device or on device package before powering on the device, and then when the device is powered on, it shall be automatically added to the gateway. B. Manual inclusion: When the gateway is in adding mode (please refer to the instruction of the Z-Wave gateway for the operations on gateway itself), quick click the upper paddle or lower paddle 3 times within 1.5 seconds. 2. Exclusion from a Z-Wave network: When the gateway is in removing mode (please refer to the instruction of the Z-Wave gateway for the operations on gateway itself), quick click the upper paddle or lower paddle 3 times within 1.5 seconds. 3. Group control the nodes of association group 2: One short tap on upper paddle: turn on the grouped Z-Wave switch / dimmer devices One short tap on lower paddle: turn off the grouped Z-Wave switch / dimmer devices Instruction Bulletin SQR50101**Z Z-Wave Plus Auxiliary Switch GDE97963_Eng © 2020 Schneider Electric All Rights Reserved 5 （change the wire between two devices be Z-Wave pictograph） (replace the Z-Wave switch drawing with a symbol, and remove the CR No.) NOTE: - Please refer to association setting for nodes group 2 se…

Text truncated - open the document above for the full version.

Schneider Electric (China) Co., Ltd., Shenzhen Branch Agent Authorization Company: Schneider Electric (China) Co., Ltd., Shenzhen Branch Address: Room 201, Building A, No. 1 Qianwanyi Road, Shengang Cooperation Zone, Qianhai, Shenzhen, China Product Name: Z-WAVE+ AUX SWITCH Model Number(s): SQR50101WHZ；SQR50101LAZ；SQR50101BKZ Product Description: Z-WAVE+ AUX SWITCH We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Dec 1 st , 2020 Name: Tony Huang Title: Manager Company: Schneider Electric (China) Co., Ltd., Shenzhen Branch

Schneider Electric (China) Co., Ltd., Shenzhen Branch Address: Room 201, Building A, No. 1 Qianwanyi Road, Shengang Cooperation Zone, Qianhai, Shenzhen, China Confirmation Letter We, Schneider Electric (China) Co., Ltd., Shenzhen Branch The product: Z-WAVE+ AUX SWITCH FCC ID: 2AUCU-50101Z IC: 25381-50101Z SQR50101LAZ and SQR50101BKZ have the same technical construction including circuit diagram, PCB Layout, components and component layout, all electrical construction and mechanical construction with SQR50101WHZ. The difference lies only model number and color. ______________________ Company Name: Schneider Electric (China) Co., Ltd., Shenzhen Branch Contact Name: Tony Huang Address: Room 201, Building A, No. 1 Qianwanyi Road, Shengang Cooperation Zone, Qianhai, Shenzhen Date:12/16/2020

Schneider Electric (China) Co., Ltd., Shenzhen Branch Dec 1 st , 2020 Federal Communications Commission Authorization and Evaluation Division FCC ID：2AUCU-50101Z Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Company Name: Schneider Electric (China) Co., Ltd., Shenzhen Branch Contact Name: Tony Huang Title of Person：Manager E-mail: [email protected] Address: Room 201, Building A, No. 1 Qianwanyi Road, Shengang Cooperation Zone, Qianhai, Shenzhen

Z-WAVE+ AUX SWITCH External Photo 1 External Photo 2 1 External Photo 3 External Photo 4 2 External Photo 5 External Photo 6 3

｝ Original format A4 A B C D E F A B C D E F 1 2 34 State: 00 1/1 Document Number: Doc. Rev. Sheet: 1.000 mm Scale: Technical Specification: Units of measure : The information is highly confidential and is the exclusive property of Schneider Electric copyright reserved. This drawing must not be used for any purpose other than that expressly permitted in writing by the owners and must not be disclosed or reproduced in any way without permission from the owners in writing. This drawing must be returned to the owners when the purpose has ceased. Provisional NOTES: *** ARTWORK IS THE MASTER FOR COLOUR, FONT, SIZE & LOGO'S*** 1. TEST FOR MARKINGS: REFER TO CQCS 2. LOCATION OF MARKING: POSITION AS SHOWN 3. FONT: ARIAL ROUNDED 4. TEXT HEIGHT: AS INDICATED 5. SQUARE D LOGO SIZE: 2.73MM(H)*13.79MM(L)(Pantone Cool grey 6C) 6. MINIMUM SIZE: 0.5 inch (12.7mm) 1/2 inch (4 mm) (2.4 mm) SQR50101BKZ 120VAC, 60Hz INDOOR USE ONLY YYYYMMDD Reset Z-WAVE S2 PIN Code XXXXX E515069 Made in China STRIP GAUGE 1/2 inch NEUTRAL HOT FCC ID : 2AUCU-50101Z CAN ICES-003(B)/NMB-003(B) IC: 25381-50101Z Original format A4 A B C D E F A B C D E F 1 2 34 State: 00 1/1 Document Number: Doc. Rev. Sheet: 1.000 mm Scale: Technical Specification: Units of measure : The information is highly confidential and is the exclusive property of Schneider Electric copyright reserved. This drawing must not be used for any purpose other than that expressly permitted in writing by the owners and must not be disclosed or reproduced in any way without permission from the owners in writing. This drawing must be returned to the owners when the purpose has ceased. Provisional NOTES: *** ARTWORK IS THE MASTER FOR COLOUR, FONT, SIZE & LOGO'S*** 1. TEST FOR MARKINGS: REFER TO CQCS 2. LOCATION OF MARKING: POSITION AS SHOWN 3. FONT: ARIAL ROUNDED 4. TEXT HEIGHT: AS INDICATED UL Label (WIRELESS SWITCH) (11mm) 5. MINIMUM SIZE: (Z-WAVE Logo Color: Black)

｝ Original format A4 A B C D E F A B C D E F 1 2 34 State: 00 1/1 Document Number: Doc. Rev. Sheet: 1.000 mm Scale: Technical Specification: Units of measure : The information is highly confidential and is the exclusive property of Schneider Electric copyright reserved. This drawing must not be used for any purpose other than that expressly permitted in writing by the owners and must not be disclosed or reproduced in any way without permission from the owners in writing. This drawing must be returned to the owners when the purpose has ceased. Provisional NOTES: *** ARTWORK IS THE MASTER FOR COLOUR, FONT, SIZE & LOGO'S*** 1. TEST FOR MARKINGS: REFER TO CQCS 2. LOCATION OF MARKING: POSITION AS SHOWN 3. FONT: ARIAL ROUNDED 4. TEXT HEIGHT: AS INDICATED 5. SQUARE D LOGO SIZE: 2.73MM(H)*13.79MM(L)(Pantone Cool grey 6C) 6. MINIMUM SIZE: 0.5 inch (12.7mm) 1/2 inch (4 mm) (2.4 mm) SQR50101LAZ 120VAC, 60Hz INDOOR USE ONLY YYYYMMDD Reset Z-WAVE S2 PIN Code XXXXX E515069 Made in China STRIP GAUGE 1/2 inch NEUTRAL HOT FCC ID : 2AUCU-50101Z CAN ICES-003(B)/NMB-003(B) IC: 25381-50101Z Original format A4 A B C D E F A B C D E F 1 2 34 State: 00 1/1 Document Number: Doc. Rev. Sheet: 1.000 mm Scale: Technical Specification: Units of measure : The information is highly confidential and is the exclusive property of Schneider Electric copyright reserved. This drawing must not be used for any purpose other than that expressly permitted in writing by the owners and must not be disclosed or reproduced in any way without permission from the owners in writing. This drawing must be returned to the owners when the purpose has ceased. Provisional NOTES: *** ARTWORK IS THE MASTER FOR COLOUR, FONT, SIZE & LOGO'S*** 1. TEST FOR MARKINGS: REFER TO CQCS 2. LOCATION OF MARKING: POSITION AS SHOWN 3. FONT: ARIAL ROUNDED 4. TEXT HEIGHT: AS INDICATED UL Label (WIRELESS SWITCH) (11mm) 5. MINIMUM SIZE: (Z-WAVE Logo Color: Black)

｝ Original format A4 A B C D E F A B C D E F 1 2 34 State: 00 1/1 Document Number: Doc. Rev. Sheet: 1.000 mm Scale: Technical Specification: Units of measure : The information is highly confidential and is the exclusive property of Schneider Electric copyright reserved. This drawing must not be used for any purpose other than that expressly permitted in writing by the owners and must not be disclosed or reproduced in any way without permission from the owners in writing. This drawing must be returned to the owners when the purpose has ceased. Provisional NOTES: *** ARTWORK IS THE MASTER FOR COLOUR, FONT, SIZE & LOGO'S*** 1. TEST FOR MARKINGS: REFER TO CQCS 2. LOCATION OF MARKING: POSITION AS SHOWN 3. FONT: ARIAL ROUNDED 4. TEXT HEIGHT: AS INDICATED 5. SQUARE D LOGO SIZE: 2.73MM(H)*13.79MM(L)(Pantone Cool grey 6C) 6. MINIMUM SIZE: 0.5 inch (12.7mm) 1/2 inch (4 mm) (2.4 mm) SQR50101WHZ 120VAC, 60Hz INDOOR USE ONLY YYYYMMDD Reset Z-WAVE S2 PIN Code XXXXX E515069 Made in China STRIP GAUGE 1/2 inch NEUTRAL HOT FCC ID : 2AUCU-50101Z CAN ICES-003(B)/NMB-003(B) IC: 25381-50101Z Original format A4 A B C D E F A B C D E F 1 2 34 State: 00 1/1 Document Number: Doc. Rev. Sheet: 1.000 mm Scale: Technical Specification: Units of measure : The information is highly confidential and is the exclusive property of Schneider Electric copyright reserved. This drawing must not be used for any purpose other than that expressly permitted in writing by the owners and must not be disclosed or reproduced in any way without permission from the owners in writing. This drawing must be returned to the owners when the purpose has ceased. Provisional NOTES: *** ARTWORK IS THE MASTER FOR COLOUR, FONT, SIZE & LOGO'S*** 1. TEST FOR MARKINGS: REFER TO CQCS 2. LOCATION OF MARKING: POSITION AS SHOWN 3. FONT: ARIAL ROUNDED 4. TEXT HEIGHT: AS INDICATED UL Label (WIRELESS SWITCH) (11mm) 5. MINIMUM SIZE: (Z-WAVE Logo Color: Black)

Internal Photo 1 Internal Photo 2 Internal Photo 3 Internal Photo 4

TEST REPORT Applicant : Schneider Electric (China) Co., Ltd., Shenzhen Branch Product Name : Z-WAVE+ AUX SWITCH Mode No. : SQR50101WHZ,SQR50101LAZ,SQ R50101BKZ Vkan Certification & Testing Co., Ltd. 威凯检测技术有限公司 Add.: No.3, Tiantaiyi Road, Kaitai Avenue, Science City, Guangzhou, 510663, P. R. China Telephone: +86-20-32293888 Fax : +86-20-32293889 E-mail: [email protected] Test Report No.: FCC2020-0027-1 Vkan Certification & Testing Co., Ltd. CVC Test Report No. FCC2020-0027-1 Page 2 of 28 LTC-R-7158-Part15B-A0 Applicant Name : Schneider Electric (China) Co., Ltd., Shenzhen Branch Address : Room 201, Building A, No. 1 Qianwanyi Road, Shengang Cooperation Zone, Qianhai, Shenzhen, China Manufacturer Name : Schneider Electric (China) Co., Ltd., Shenzhen Branch Address : Room 201, Building A, No. 1 Qianwanyi Road, Shengang Cooperation Zone, Qianhai, Shenzhen, China Equipment under Test Product Name : Z-WAVE+ AUX SWITCH Model No. : SQR50101WHZ,SQR50101LAZ,SQR50101BKZ Trade mark : Schneider Electric,Square D Serial no. : — Sampling : — Date of Receipt. 2020.12.01 Date of Testing 2020.12.01~2021.02.02 Test Specification Test Result FCC CFR47 Part 15B (2020) Radio Frequency Devices ANSI C63.4 (2014) PASS Evaluation of Test Result The equipment under test was found to comply with the requirements of the standards applied. Issue Date: 2021.02.03 Tested by: Xu Zhenfei  Name Signature Reviewed by: Liu Yonghai  Name Signature Approved by: Zeng Bo  Name Signature Other Aspects: NONE. Abbreviations:OK, Pass= passed Fail = failed N/A= not applicable EUT= equipment, sample(s) under tested This test report relates only to the EUT, and shall not be reproduced except in full, without written approval of CVC. Vkan Certification & Testing Co., Ltd. CVC Test Report No. FCC2020-0027-1 Page 3 of 28 LTC-R-7158-Part15B-A0 TABLE OF CONTENTS 1. GENERAL PRODUCT INFORMATION ................................................................................................... 4 1.1 GENERAL INFORMATION ............................................................................................................................. 4 2. TEST SITES................................................................................................................................................ 5 2.1 TEST FACILITIES......................................................................................................................................... 5 2.2 DESCRIPTION OF NON-STANDARD METHOD AND DEVIATIONS ................................................................. 5 2.3 LIST OF TEST AND MEASUREMENT INSTRUMENTS.................................................................................... 5 3. TEST CONFIGURATION ........................................................................................................................... 6 3.1 TEST MODE ................................................................................................................................................ 6 4. SUMMARY OF MEASUREMENT RESULTS .......................................................................................... 7 5. MEASUREMENT PROCEDURE ............................................................................................................. 8 5.1 CONDUCTED EMISSION .............................................................................................................................. 8 5.2 RADIATED EMISSION ................................................................................................................................ 12 6. TEST SETUP PHOTOGRAPH ................................................................................................................ 21 7. EUT PHOTOGRAPH ................................................................................................................................ 23 8. APPENDIX ................................................................................................................................................ 28 Vkan Certification & Testing Co., Ltd. CVC Test Report No. FCC2020-0027-1 Page 4 of 28 LTC-R-7158-Part15B-A0 1. General Product Information The model of this application: SQR50101WHZ,SQR50101LAZ,SQR50101BKZ. SQR50101LAZ and SQR50101BKZ have the same technical construction including circuit diagram, PCB Layout, components and component layout, all electrical construction and mechanical construction with SQR50101WHZ. The difference lies only model number and color. All the tests carried out on model SQR50101WHZ. 1.1 General information Product Name Z-WAVE+ AUX SWITCH Model No. SQR50101WHZ,SQR50101LAZ,SQR50101BKZ Power Supply 120 Vac,60Hz FCC ID 2AUCU-50101Z Note： 1. The information of the EUT is declared by the manufacturer. Vkan Certification & Testing Co., Ltd. CVC Test Report No. FCC2020-0027-1 Page 5 of 28 LTC-R-7158-Part15B-A0 2. Test Sites 2.1 Test Facilities The tests and measurements refer to this report were performed by EMC testing Lab. of Vkan Certification & Testing Co., Ltd. Add.: No.3, Tiantaiyi Road, Kaitai Avenue, Science City, Guangzhou, 510663, P. R. China Telephone : +86-20-32293888 Fax : +86-20-32293889 The EMC testing laboratory has been recognized by CNAS, and authorized by Nemko of Norway since 1997, and accredited by DAkkS of Germany since 2007, and assessed and found eligible to participated in the TDAP of VDE testing and certification Institute since 2004, and registered by FCC since 2001. 2.2 Description of Non-standard Method and Deviations The testing and measurement methods used in this report are applied by all standard methods. Not any non-standard method or deviation from the used standards was used. 2.3 List of Test and Measurement Instruments Refer to Appendix. Vkan Certification & Testing Co., Ltd. CVC Test Report No. FCC2020-0027-1 Page 6 of 28 LTC-R-7158-Part15B-A0 3. Test Configuration 3.1 Test Mode The EUT has been associated with peripherals and configuration operated in a manner tended to maximize …

Text truncated - open the document above for the full version.

Z-WAVE+ AUX SWITCH (1) Radiated spurious emission Test Setup(Below 1GHz) 1 (2) Radiated spurious emission Test Setup(Above 1GHz) 2 (3) Conducted Emission Test Setup 3
