MobilePrinter HM-Z3 USERMANUAL Rev.1.1 XiamenHaninElectronicTechnologyCo.,Ltd. ADD:5F,8#,AideAirportIndustrialPark,HuliDistrict,Xiamen,China Tel.:+86-(0)592-5885993 Web:www.hprt.com CautionSymbol Nevertouchthethermalheadimmediatelyaftertheprinterhasbeenused.Letthethermal headcoolforafewminutesbeforetouchingit. Thissymbolisindicatethatitiseasilydamaged.Observetheprecautionsforhandling electrostaticsensitivedevices. SafetyPrecautions Tousethisproductinsafety,pleasefollowtheprecautionsgivenbelow. WARNING Ifyounoticesmoke,astrangesmell,orastrangesound,turnoffthepowerimmediately,and removetheUSBcableand/orbatterypack.Thencontactthedealer. Ifanyforeignmaterial(metalscraps,water,orotherfluid)enterstheprinter,immediatelyturnoff theprinterandremovetheUSBcableand/orbatterypack.Then,contactyourdealerforadvice. Continueduseoftheprintercouldresultinafire. Neverattempttorepairtheprinteryourself.Alsodonotdisassembleormodifytheproduct.Doing socouldleadtoinjury,fire,orelectricshock. Donottouchthetearbar. Thereisatearbarinsidethepaperoutletslot.Neitherputyourhandinthepaperoutletslot whileprintingisinprogress,orputyourhandintotheoutletevenwhenprintingisnotinprogress. Theprintercovercanbeopenedwhenreplacingthepaper.However,sincethetearbarisonthe insideoftheprintercover,becarefulnottoplaceyourfaceorhandstooclosetothetearbar. Duringandimmediatelyafterprinting,theareaaroundthethermalheadisveryhot.Donottouchit, asyoucouldbeburned. Ifanybatteryfluidgetsonyourskinorclothing,immediatelywashtheaffectedareawithfresh water.Otherwise,skindamagemayresult. Thebatterypackmaybehotimmediatelyaftertheproducthasbeenused. Pleasebesuretoread UsingthePrinter Somesemiconductorscanbedamagedbystaticelectricity.Besuretoturnofftheprinterwhen insertingorremovingthebatterypack. Donotdroptheprinterorhititagainstahardobject. Donotopentheprintercoverwhiletheprinterisprinting. Beforeyouopentheprintercover,makesurethatprintingdataisnotbeingsenttotheprinter. DonotunplugorpluginaUSBcablewhiletheprinterisprintingorduringcommunication. DonottouchaUSBconnectorwhiletheprinterisprinting. Turnofftheprinterwhenyouarenotusingit. Whentheprinterisusedinalowtemperatureenvironment,thebattery'sperformancewillbe diminished,andtheamountoftimethatyoucanusetheprinterformaybereduced. Donotpulloutpaperwhiletheprintercoverisclosed. TheheatingelementandthedriverICofthethermalheadareeasilydamaged.Donottouchthem withmetalobjects,sandpaper,etc. Printingqualitymaysufferifthethermalheadheatingelementbecomessoiledbybeingtouched withyourhands.Donottouchthethermalheadheatingelement. ThereisariskofdamagetothedriverICofthethermalheadfromstaticelectricity.Neverdirectly touchtheIC. Donotoperatetheprinterifthereismoistureonthefrontsurfaceoftheheadfromcondensation, etc. ThermalPaperHandling Onlyusethermalpaperwiththedesignatedspecifications.Theprintingqualityandworkinglifeof thethermalheadcannotbeguaranteedifanypaperotherthanthatrecommendedisused.In particular,ifionconcentrationof[Na+,K+,Cl-]ishigh,itmaydrasticallyreducetheworkinglifeof thethermalhead.Pleaseexercisecaution. Storethethermalpaperinacool,dry,darklocation. Donotrubthethermalpaperwithahardobject. Donotleavethethermalpaperincontactwithplasticfilm,aneraser,oradhesivetapeforalong periodoftime. Donotstackthethermalpaperonfreshdiazocopiesorwet-typecopies. Donotusechemicalglueonthethermalpaper. Donotusethermalpaperthathasbeenstoredforalongperiod. OperatingEnvironmentforthePrinter Beforeactuallyunpackingtheprinter,rememberthefollowingpointswhendoingthis. Donotusetheprinterinanenvironmentinwhichitwillbesubjecttostrongshakingwhileitis printing. Becarefultoensurethattheprinterisnotexposedtodirectsunlight. Theappropriateenvironmentforusingtheprinterisdescribedbelow. Temperature:-10°Cto52°C Humidity:10%RHto85%RH(nocondensation) Donotplacetheprinternearacopyingmachineorotherdevicethatproducesastrong electromagneticfield. Keeptheprintersufficientlyremovedfromheatersandothersourcesofheat. Usetheprinterinaclean,low-humidityenvironmentthatisfreefromdust. Avoidusingtheprinterinhigh-humidityrooms.  PrinterMaintenance Pleaseperformthefollowingmaintenanceevery6months. Thermalhead Dipacottonswabinanalcoholsolvent(ethanol,methanol,orisopropylalcohol),andcleanthe heatingareaofthehead. Platen Whileturningtheplaten,useasoftdryclothtolightlyrubtheentiresurfaceoftheplatenand removeanyforeignobjects. Paperstorageunitandthesurroundingarea Removeanydirt,dust,piecesofpaper,etc.,fromthepaperstorageunit. Contents 1.ProductOverview ....................................................................................................................................... 1 1.1Printer&Accessories ....................................................................................................................... 2 1.2AppearanceandComponents .......................................................................................................... 3 2.Setup ........................................................................................................................................................... 4 2.1BatteryPack ...................................................................................................................................... 4 2.1.1InsertingintothePrinter ....................................................................................................... 4 2.1.2ChargingtheBattery ............................................................................................................. 5 2.2Bluetooth .......................................................................................................................................... 8 2.3LoadingPaper ................................................................................................................................... 9 2.4MenuSettings ................................................................................................................................ 11 2.5BeltClip ................................…
