Steps & Notes Take out one packet of photo paper (including 5pcs or 10pcs of photo paper and 1pc of blue smart sheet), and place them into the printer as shown on Figure 2. The photo paper should be placed a�er the blue smart sheet and its text side should face down. Please note that never place more than 10pcs of photo paper, and use the photo paper specially for the printer, use other brands of that may affect the print quality. Blue Smart Sheet Paper Loading Place your hands on both sides of the top cover, push it towards the direc�on as shown on Figure 1. Assemble the top cover. Precau�ons for Photo Paper The photo paper is easy to get damp, please use it as soon as possible a�er opening. Avoid excessive direct sunlight and over low temperature. Avoid device damage caused by using non-special paper. Do not fold or damage the paper. The blue smart sheet is used for color correc�on and TPH cleaning. When prin�ng a�er loading 1 packet of paper for the first �me, the blue smart sheet will be automa�cally out firstly, and then the photo will be printed out. The text side of all the photo paper should face down. Mini Photo Printer Packing List Note: The items in the package are actually based on the order. 1. When red LED stays on, you can check the detailed error condi�on on APP a�er connec�ng it to the printer. 2. When upda�ng the printer firmware, the blue LED will flash quickly. USB Type-C Cable Photo Paper (5pcs) Quick Start Guide LED Indicator Status Red LEDError Status OFF: Power off ON: Standby Slow Flash: Charging ON: Error (Paper jam/Out of paper /Cover opened) Slow Flash: Low power Blue LEDBasic Status USB InterfacePower Bu�on LED IndicatorPaper Outlet Hold down the power bu�on for 3 seconds, the printer will be turned on. How to Print Steps & Notes 1. If Bluetooth has been unconnected for 5 seconds, the printer will enter sleeping mode, press the power bu�on to awaken it. 2. In sleeping mode, if not awaken the printer within 5 minutes, it will be off automa�cally. 3. When using it for the second �me, just click the print icon that the printer will be connected automa�cally and send data to print. 4. Do not touch the photo paper during prin�ng, or else it may appear stripes. Turn on the Bluetooth on your mobile phone, then select “MT53_XXXXXX” in the Bluetooth list to connect. Remark: “XXXXXX” indicates last six digits of Bluetooth address. Open the photo printer APPchoose “MT53”, select the photos and enter the print preview. Click the print icon that it will show the device list, click the same model (“MT53_XXXXXX”) and confirm prin�ng. Then the printer will conduct prin�ng. Precau�ons for Prin�ng Before pu�ng the photo paper into the printer, do not touch the prin�ng surface of the photo paper with your hands to ensure that the prin�ng surface is free of dirt and dust par�cles, otherwise the prin�ng effect will be affected. It is not allowed to con�nuously print more than 10 sheets, or else the print head may accumulate dust, which needs to be cleaned by the blue smart sheet again. A�er prin�ng 3 sheets con�nuously, the printer may have overheat protec�on for the print head, and the prin�ng will be suspended forcibly, which is a normal phenomenon. It can be printed again a�er cooling the print head. Ba�ery Charging When the ba�ery power is low, the LED indicator will turn red and flash slowly. Please charge it by the supplied USB cable in �me. If you con�nue prin�ng, it may power off automa�cally. To charge, insert one end of the USB cable into the printer and the other end to the AC adapter or PC. When connected, the LED indicator will turn blue and flash slowly to indicate charging. It takes about 60 to 90 minutes for fully charge. A�er that, the blue LED indicator will be ligh�ng all the way. Charge via PC Charge via AC Adapter 1. The printer can be charged via computer USB port or AC adapter. Please note that the AC adapter is not supplied. 2. If charging via AC adapter, connect the USB cable to a power source of supplying DC 5V/2A. Manufacturer: Xiamen Hanin Electronic Technology Co., Ltd. Address: Room 305A, Angye Building, Pioneering Park, Torch High-tech, Zone, Xiamen, China E-mail: [email protected] Web: www.hprt.com Scan the QR code to download APP. APP Download This device complies with part 15 of the FCC Rules. Opera�on is subject to the following two condi�ons: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera�on. Any changes or modifica�ons not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec�on against harmful interference in a residen�al installa�on. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc�ons, may cause harmful interference to radio communica�ons. However, there is no guarantee that interference will not occur in a par�cular installa�on. If this equipment does cause harmful interference to radio or television recep�on, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separa�on between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condi�on without restric�on. FCC WARNING

Xiamen Hanin Electronic Technology Co., Ltd. Model difference statement Product Name: Mini Photo Printer Model N o.: MT53, CP53, T53, M53, COLOR53, Z53, ZK53, ZP200 We (Xiamen Hanin Electronic Technology Co., Ltd. Room 305A, Angye Building, Pioneering Park, Torch High-tech, Zone, Xiamen) hereby state that all the models are the same circuit and RF module, except the Naming method, resolution and model No.. Signature: Name / title: Qinqin Yu / Certified Engineer Tel: 15705965171 Email: [email protected] Date: 6.29.2021

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Xiamen Hanin Electronic Technology Co., Ltd. Address: Room 305A, Angye Building, Pioneering Park, Torch High-tech, Zone, Xiamen Product Name: Mini Photo Printer Model Number: MT53, CP53, T53, M53, COLOR53, Z53, ZK53, ZP200 FCC Identifier: 2AUTE-MT5321 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Qinqin Yu Date: 7/6/2021 Title: Certified Engineer Signature of applicant:

C5266091_X10_Ed.2 1/1 Xiamen Hanin Electronic Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 7/6/2021 Subject: Request for Confidentiality FCC ID: 2AUTE-MT5321 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Qinqin Yu Title: Certified Engineer
