2AUTE-NEW1Label Printer

Manufacturer: Xiamen Hanin Electronic Technology Co.,Ltd. TEL： 400-766-7666 Add: No.96, Rongyuan Road, Tong'an District, Xiamen, China, 361100 Web： cn.hprt.com Product Introduction Loading Paper Product Introduction Button Operation Appearance and ComponentsPacking List Quick Start Guide LED Indicator State on always：Charging is complete/ Charging Begins flashes slowly：Charging Long press the Power button： power-on/power-off Double-click the power button： Position and calibrate label paper and heating line positions. on always：Exception （paper jam/Out-of-paper/Cover Opening） flashes slowly：Low power flashes quickly：TPH is over temperature. Hold the fuselage with one hand，turn the cover opening knob clockwise with one hand,Implement cover opening. Load the roll in the direction shown and print face down. Push both sides of the paper roll baffle inward (arrow direction) until the paper roll is clamped. Exception status Basic status Printer Red Light White Light APP Download Scan the QR code below and download the APP: Click on“New Tab”, use the official supplies, the APP will automatically identify and guide the jump, to the corresponding template editing, in the template editing required content, and select print. Connection and Printing Long press the power button to boot, first open the phone Bluetooth, and then open the APP, click on“Connect devices”, select“New 1”. 1 1 2 2 3 Note: App operation shall be subject to the latest version. USB Cable(选配) Pull out a small piece of paper，Make sure that there is a paper section after closing, on the outside of the machine. 4 This position means that the working temperature is high, please do not touch it. This position is a sharp edge, do not touch. The thermosensitive layer faces down Cover Opening Button Tear Bar Paper Outlet power-on Power Button Type C Interface HCS-2LB23L FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Battery Charging Note: The printer can be charged via computer USB port or AC adapter. Please note that the AC adapter is not supplied. Charge via PC Charge via AC Adapter When the battery power is low, the red LED indicator will flash slowly. Please charge it by the exclusive USB cable in time. If you continue printing, it may power off automatically. New 1 Note: All the drawings of product and accessories in the manual are for reference only, please subject to the actual product. FCC-ID:2AUTE-NEW1

Xiamen Hanin Electronic Technology Co.,Ltd. Room 305A, Angye Building, Pioneering Park, Torch High-tech, Zone, Xiamen, China Date: 2024-01-04 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d) (5) (i) Filing SUBJECT: FCC Application for FCC ID: 2AUTE-NEW1 To Whom It May Concern: Xiamen Hanin Electronic Technology Co.,Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signatory [Jeff Wang, Certified Engineer]

Xiamen Hanin Electronic Technology Co.,Ltd. Room 305A, Angye Building, Pioneering Park, Torch High-tech, Zone, Xiamen, Chin Date: 2024-01-04 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d) (5) (ii) Filing SUBJECT: FCC Application for FCC ID: 2AUTE-NEW1 To Whom It May Concern: Xiamen Hanin Electronic Technology Co.,Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the CoveredList(as a specifically named entity or any of its subsidiaries or affiliates)as an entity producing “covered” equipment. Sincerely, Signatory [Jeff Wang, Certified Engineer]

Xiamen Hanin Electronic Technology Co.,Ltd. Room 305A, Angye Building, Pioneering Park, Torch High-tech, Zone, Xiamen, China Date: 2024-01-04 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AUTE-NEW1 Applicant FRN: 0028895233 US Agent – Attestation Statement / Part 2.911(d)(7) Xiamen Hanin Electronic Technology Co.,Ltd. certifies that, as of 2024-01-04, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2AUTE-NEW1. Xiamen Hanin Electronic Technology Co.,Ltd., accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicableequipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Xiamen Hanin Electronic Technology Co.,Ltd. for FCC ID:2AUTE-NEW1. Designated Agent Information: Company Name: FCC US Agent, LLC U.S. Agent FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company:Xiamen Hanin Electronic Technology Co.,Ltd. Designated Agent: FCC US Agent, LLC Company Representative: Jeff WangDesignated Agent Representative: Tim Payne Signature:Signature:

Xiamen Hanin Electronic Technology Co.,Ltd. Room 305A, Angye Building, Pioneering Park, Torch High-tech,Zone, Xiamen, China Date: 2024-01-04 FEDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 SUBJECT: FCC Application for FCC ID: 2AUTE-NEW1 Confidentiality Request To whom it may concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. ☒ Block Diagram ☐ Tune-Up Information ☒ Operational Description ☐ Security Information ☒ Schematics ☐ Software Defined Radio (SDR) Information ☐ Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentialityof the following attachment(s); ☐ External Photos ☐ Test Setup Photos ☐ Internal Photos ☐ User Manual ☐For 45 days, pursuant to Public Notice DA04-1705. or ☐For 180 days pursuant to KDB 726920 D01. The applicant understands that pursuant to Section 0.457 ofthe Rules, disclosure of this application and all accompanying documentation will not bemade before the date of the Grant for this application. Sincerely, Signatory [Jeff Wang, Certified Engineer]

Xiamen Hanin Electronic Technology Co.,Ltd. Room 305A, Angye Building, Pioneering Park, Torch High-tech,Zone, Xiamen, China Date: 2024-01-04 FEDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 SUBJECT: FCCID: 2AUTE-NEW1 Model Declaration Letter Dear Regulatory Authority, Model(s): New 1, Neo 1, Nova 1, HM-C221 are same to the model HCS-2LB23L,these models are same PCB Layout, Schematics, BOM.Only for different model name and appearances for different market require. Sincerely, Signatory [Jeff Wang, Certified Engineer]

Xiamen Hanin Electronic Technology Co.,Ltd. Room 305A, Angye Building, Pioneering Park, Torch High-tech,Zone, Xiamen, China Date: 2024-01-04 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for FCC ID: 2AUTE-NEW1 To Whom It May Concern: I, the undersigned, hereby states this equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 ofthe FCC Rules, and will apply the Supplier's Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. I understand the following FCC requirements: 1. Devices subject to the SDoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm (Select the "accredited" option to search for FCC recognized accredited test firms.) 2. Pt 2.1077 contains the list of information that must be included in the Supplier's Declaration of Conformity, which must be supplied with eachproduct sold. The SDoC compliance info shall be included in the User’s Manual or as aseparate sheet. The info must contain thename, address, and phone number of the responsible party, which must be located within the United States.According to 2.909(b), the responsible party is either the Manufactureror if the product is imported the Importer. Sincerely, Signatory [Jeff Wang, Certified Engineer]

Reference No.: WTX23X11255924W001/002/003 Page 2 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX23X11255924W001/002/003 Page 3 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX23X11255924W001/002/003 Page 4 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTX23X11255924W001/002/003 Page 5 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7

Reference No.: WTX23X11255924W001/002/003 Page 1 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTX23X11255924W001/002/003 Page 6 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 Reference No.: WTX23X11255924W001/002/003 Page 7 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Antenna View 1 BT Ant. Reference No.: WTX23X11255924W001/002/003 Page 8 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Antenna View 2 RFID Ant.

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: Xiamen Hanin Electronic Technology Co.,Ltd. Address of applicant: Room 305A, Angye Building, Pioneering Park,Torch High-tech,Zone, Xiamen,China Manufacturer: Xiamen Hanin Electronic Technology Co.,Ltd. Address of manufacturer: No.96, Rongyuan Road, Tong'an District, Xiamen, China General Description of EUT: Product Name: Label Printer Trade Name / Model No.: New 1 Adding Model(s): HCS-2LB23L, Neo 1, Nova 1, HM-C221 Rated Voltage: DC3.7V Battery Capacity: 1000mAh Adapter Model: / FCC ID: 2AUTE-NEW1 Equipment Type: Mobile device Technical Characteristics of EUT: Bluetooth (BLE mode) Bluetooth Version: V4.0 (BLE mode) Frequency Range: 2402-2480MHz RF Output Power: 1.60dBm (Conducted) Data Rate: 1Mbps Modulation: GFSK Quantity of Channels: 40 Channel Separation: 2MHz Type of Antenna: PCB Antenna Antenna Gain: -2.2dBi Bluetooth (BR mode) Bluetooth Version: V4.0 (BR mode) Frequency Range: 2402-2480MHz RF Output Power: 1.87dBm (Conducted) Data Rate: 1Mbps Modulation: GFSK Quantity of Channels: 79 Channel Separation: 1MHz Type of Antenna: PCB Antenna Antenna Gain: -2.2dBi RFID Frequency Range: 13.56MHz Max. Field Strength: 77.06dBuV/m (at 3m) Antenna Type: Coil Antenna Antenna Gain 0dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and KDB 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-Averaged Power ERP (MHz) (dBm) (dBi) (%) (dBm) (dBm) Bluetooth 2402 1.87 -2.2 100 2.00 -2.35 RFID 13.56 -18.2 0 / -18.00 -20.15 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2402 B 0.5 2.00 1.58 2.788 0.57 Pass 13.56 B 0.5 -18.00 0.02 2997.21 0.01 Pass Note: 1. a. Time-Averaged Power=Output Power * Duty Cycle; ERP= Time-Averaged Power+ Antenna gain-2.15dB; b. EIRP= E-104.8+20logD; Output Power=EIRP- Antenna Gain; ERP=EIRP-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail Bluetooth+ RFID 0.57 0.01 0.58 1 Pass Result: Pass

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 11 TEST REPORT Reference No. .................... : WTX23X11255924W Applicant ........................... : Xiamen Hanin Electronic Technology Co.,Ltd. Address ............................. : Room 305A, Angye Building, Pioneering Park,Torch High-tech,Zone, Xiamen,China Manufacturer ..................... : Xiamen Hanin Electronic Technology Co.,Ltd. Address ............................. : No.96, Rongyuan Road, Tong'an District, Xiamen, China Product Name ................... : Label Printer Model No... ......................... : New 1 Standards .......................... : ANSI/ IEEE 149-2021 Date of Receipt sample .... : 2023-11-30 Date of Test........................ : 2023-11-30 to 2023-12-28 Date of Issue ..................... : 2023-12-28 Test Report Form No. ....... : WTX_IEEE 149 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Dashan Chen Silin Chen Reference No.: WTX23X11255924W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 11 TABLE OF CONTENTS 1.GENERAL INFORMATION .................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 2. SUMMARY OF TEST RESULTS ........................................................................................................................... 5 3. ANTENNA TEST CONFIGURATIONS ................................................................................................................ 6 3.1 TEST LOCATION ..................................................................................................................................................... 6 3.2 TEST ENVIRONMENTS............................................................................................................................................. 6 3.3 TEST EQUIPMENT LIST ........................................................................................................................................... 6 3.4 MEASUREMENT UNCERTAINTY .............................................................................................................................. 6 3.5 TEST SETUP ............................................................................................................................................................ 6 4. ANTENNA TEST RESULT ..................................................................................................................................... 7 4.1 GAIN AND EFFICIENCY ........................................................................................................................................... 7 4.2 RADIATION PATTERN 2D VIEW ............................................................................................................................... 8 4.3 RADIATION PATTERN 3D VIEW ............................................................................................................................... 9 EXHIBIT 1 - EUT PHOTOGRAPHS ........................................................................................................................ 10 EXHIBIT 2 - TEST SETUP PHOTOGRAPHS ........................................................................................................ 11 Reference No.: WTX23X11255924W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 3 of 11 Report version Version No. Date of issue Description Rev.00 2023-12-28 Original / / / Reference No.: WTX23X11255924W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 4 of 11 1.GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) General Description of EUT Product Name: Label Printer Trade Name: / Model No.: New 1 Adding Model(s): HCS-2LB23L, Neo 1, Nova 1, HM-C221 Note: The test data is gathered from a production sample, provided by the manufacturer. The appearance of others models listed in the report is different from main-test model New 1, but the circuit and the electronic construction do not change, declared by the manufacturer. Technical Characteristics of EUT Frequency Range: 2400-2500MHz Gain of Antenna: -2.2dBi (Max.) Type of Antenna: PCB Antenna Dimension: Reference No.: WTX23X11255924W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 5 of 11 2. SUMMARY OF TEST RESULTS Standards Description of Test Item Result ANSI/ IEEE 149-2021 IEEE Recommended Practice for Antenna Measurements Compliant N/A: not applicable Reference No.: WTX23X11255924W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 6 of 11 3. Antenna Test Configurations 3.1 Test Location Name: Shenzhen Morlab Communications Technology Co.,Ltd. Address: FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P.R. China 3.2 Test Environments Environments Parameter Temperature Voltage Humidit NTNV 25 C -- 50% 3.3 Test Equipment List Description Manufacturer Model Serial Number Cal. Date Due. Date Network Analyzer Agilent E5071C MY46110140 2023-06-21 2024-06-20 OTA Chamber ETS AMS-8923-150 TJ2235-Q1793 2022-11-30 2025-11-29 Antenna Measurement System ETS EMQuest EMQ-100 V1.13 Build 21267 1685 N/A N/A 3.4 Measurement Uncertainty The uncer…

Text truncated - open the document above for the full version.

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 50 TEST REPORT Reference No. .................... : WTX23X11255924W001 FCC ID ................................ : 2AUTE-NEW1 Applicant ........................... : Xiamen Hanin Electronic Technology Co.,Ltd. Address ............................. : Room 305A, Angye Building, Pioneering Park,Torch High-tech,Zone, Xiamen,China Manufacturer ..................... : Xiamen Hanin Electronic Technology Co.,Ltd. Address ............................. : No.96, Rongyuan Road, Tong'an District, Xiamen, China Product Name ................... : Label Printer Model No... ......................... : New 1 Standards .......................... : FCC Part 15.247 Date of Receipt sample .... : 2023-11-30 Date of Test........................ : 2023-11-30 to 2023-12-26 Date of Issue ..................... : 2023-12-26 Test Report Form No. ....... : WTX_Part 15_247W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Dashan Chen Silin Chen Reference No.: WTX23X11255924W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 50 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ......................................................................... 5 1.2 TEST STANDARDS ................................................................................................................................................. 6 1.3 TEST METHODOLOGY ........................................................................................................................................... 6 1.4 TEST FACILITY ...................................................................................................................................................... 6 1.5 EUT SETUP AND TEST MODE .............................................................................................................................. 7 1.6 MEASUREMENT UNCERTAINTY ............................................................................................................................. 8 1.7 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................... 9 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 12 3. ANTENNA REQUIREMENT ................................................................................................................................. 13 3.1 STANDARD APPLICABLE ..................................................................................................................................... 13 3.2 EVALUATION INFORMATION ................................................................................................................................ 13 4. FREQUENCY HOPPING SYSTEM REQUIREMENTS .................................................................................... 14 4.1 STANDARD APPLICABLE ..................................................................................................................................... 14 4.2 FREQUENCY HOPPING SYSTEM ......................................................................................................................... 14 4.3 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ............................................................................... 15 5. QUANTITY OF HOPPING CHANNELS AND CHANNEL SEPARATION .................................................... 16 5.1 STANDARD APPLICABLE ..................................................................................................................................... 16 5.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 16 5.3 TEST PROCEDURE .............................................................................................................................................. 16 5.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 17 6. DWELL TIME OF HOPPING CHANNEL ........................................................................................................... 18 6.1 STANDARD APPLICABLE ..................................................................................................................................... 18 6.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 18 6.3 TEST PROCEDURE .............................................................................................................................................. 18 6.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 19 7. 20DB BANDWIDTH ............................................................................................................................................... 20 7.1 STANDARD APPLICABLE .................................................................................................................................…

Text truncated - open the document above for the full version.

Reference No.: WTX23X11255924W001/002/003 Page 9 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission Test Setup (Below 30MHz) Reference No.: WTX23X11255924W001/002/003 Page 10 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (30MHz to 1GHz) Radiation Emission Test Setup (1GHz to 18GHz) Reference No.: WTX23X11255924W001/002/003 Page 11 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (Above 18GHz) ***** END OF REPORT *****
