在线微信客服 After-sales WeChat 产品介绍 装纸说明 产品介绍 外观与组件 开箱清单 入门指南 USB 数据线 指示灯状态 常亮：充电完成/打印机就绪 慢闪：充电中 固件升级中 常亮：异常（卡纸/缺纸/开盖） 慢闪：电量低 快闪：热写头过温 按图示箭头方向 滑动开盖推钮， 打开上盖 按图示方向放入纸卷， 热敏面朝下 热敏面 闭合上盖， 拉出一小段纸 根据需要编辑标签， 编辑完成后点击打印即可。 连接打印 先打开手机蓝牙，然后打开APP， 点击“设备连接”，选择“HPRT M11”。 选择“扫码取模”，对准纸卷管芯上的二维码 扫描，即可充值耗材里程，同时获取耗材模板。 保修条款 一、自出厂之日起，本产品保修12个月。 二、存在以下情况之一者，不属于保修范围之内： 未经我公司及授权维修人员许可，擅自对产品进行拆卸，或产品序 列号标贴被撕去及模糊不清，无法辨认； 由于固体颗粒刮伤热敏头片，引起的打印白线，则头片不属于保修 范围； 其他人为引起的故障。 三、保修期内，维修时所更换的产品零配件归我公司所有。 四、用户负责将产品寄送至我公司售后服务部或我公司授权的维修站点 进行保修服务。 五、厦门汉印电子技术有限公司拥有本保修条款的最终解释权。 制造商：厦门汉印电子技术有限公司 电话：400-766-7666 地址：福建省厦门市同安区榕源路96号 官网：www.hprt.com.cn 注意：若用户自行用错误型号电池更换会有爆炸危险，请务必按照说明 寄回维修站点处置用完的电池。 产品保修卡 尊敬的用户： 为了保障您的权益以及为您提供更优质的售 后服务，请您在购买产品时仔细填写并保留此卡， 进行保修服务时请与购买发票一同出示！ 用户名称： 联系地址： 联系电话： 产品型号（序列号）: 省市区（县） 经销商名称（盖章）： 联系地址： 联系电话： 购买日期： 年月日 当电池电量低时，指示灯会闪烁（红灯慢闪），请使用配套USB 线及时进行充电。 如果继续打印，打印机可能会自动关机。 电池充电 注意： 可以用电源适配器或电脑USB供电，出货时不配适配器。 消费者若使用电源适配器充电，则应购买使用获得CCC 认证且满足标准要求的电源适配器。 出现死机情况时，怎么办？ 打开打印机上盖，用回形针按一下Reset键，打印机将关闭， 重启打印机即可。 常见问题 Reset 重置键 通过PC端充电 通过电源适配器充电 APP下载 扫描二维码下载APP： 异常状态 基本状态 打印机 红灯 绿灯 红绿灯交替闪烁 长按电源键： 开/关机 短按电源键： 定位校准热敏标签纸和加热线位置 按键操作 出纸口 撕纸刀 开盖推钮 电源键& 指示灯 USB接口 HPRT M11 Product Introduction LED Indicator Status Red LED Error Status Basic Status ON: Charging finished/Printer is ready Slow Flash: Charging ON: Error (Paper jam/Paper end/Cover opened) Slow Flash: Low power Quick Flash: TPH is over temperature Green LED Red and green LED flash alternately Hold down the power button for a few seconds: Turn on/off the printer Press the power button: Position and calibrate the location of thermal label paper and heating line Button Operation Firmware updating Paper Loading Slide the cover-opening button as shown in the figure to open the upper cover. Load the paper as shown in the figure and make sure the thermosensitive layer faces down. Thermosensitive Layer Close the upper cover and pull some extra paper. Edit the label as need, and then click “Print” after editing. Connection and Printing Turn on Bluetooth on your mobile phone, then open App, click “Device Connection”, select “ HPRT M11”. Select “Scan to get the template”, then scan the QR code on the paper core to recharge consumables mileage and get the templates. App Download Scan the QR code to download App. Product Introduction Appearance and Components Cover-opening Button USB Interface Power Button & LED Indicator Packing List Quick Start Guide USB Cable Printer Paper Outlet Tear Bar When the battery power is low, the red LED indicator will flash slowly. Please charge it by the exclusive USB cable in time. If you continue printing， it may power off automatically. Battery Charging Note: The printer can be charged via computer USB port or AC adapter. Please note that the AC adapter is not supplied. Charge via PC Charge via AC Adapter When the printer crashes, how to deal with it? Open the upper cover, lightly hold down the [Reset] button with a pin so that the printer will be off, and then restart the printer. General Q&AFCC WARNING Reset Button This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. FCC ID：2AUTE-PLP

Xiamen Hanin Electronic Technology Co., Ltd. Model difference statement Product Name: Portable Lable Printer, Portable Pocket Printer Model N o.: HPRT M11, M11, HM-C120, M110, M10, HPRT M10, M61, M66, MU1, MU2, MU3, MU4, MU5, HPRT MU1, HPRT MU2, HPRT MU3, HPRT MU4, HPRT MU5 We (Xiamen Hanin Electronic Technology Co., Ltd. Room 305A, Angye Building, Pioneering Park, Torch High-tech, Zone, Xiamen) hereby state that all the model are the same circuit and RF module, except the model name, print resolution and program. Signature: Name: Qinqin Yu Title: Certified Engineer Tel: 15705965171 Email: [email protected] Date: 2.15.2022

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Xiamen Hanin Electronic Technology Co., Ltd. Address: Room 305A, Angye Building, Pioneering Park, Torch High-tech, Zone, Xiamen Product Name: Portable Lable Printer, Portable Pocket Printer Model Number: HPRT M11, M11, HM-C120, M110, M10, HPRT M10, M61, M66, MU1, MU2, MU3, MU4, MU5, HPRT MU1, HPRT MU2, HPRT MU3, HPRT MU4, HPRT MU5 FCC Identifier: 2AUTE-PLP We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Qinqin Yu Date: 2/15/2022 Title: Certified Engineer Signature of applicant:

C5266091_X10_Ed.2 1/1 Xiamen Hanin Electronic Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2/15/2022 Subject: Request for Confidentiality FCC ID: 2AUTE-PLP To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Qinqin Yu Title: Certified Engineer
