2AUTE-ZEVA1966Photo printer

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Xiamen Hanin Electronic Technology Co.,Ltd. Address: Room 305A, Angye Building, Pioneering Park Torch High-tech, Zone Xiamen China Product Name: Photo Printer Model Number: Zeva 1966 FCC Identifier: 2AUTE-ZEVA1966 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Jeff Wang Date: 11/07/2022 Title: Certified Engineer Signature of applicant:

C5266091_X10_Ed.1 1/1 Xiamen Hanin Electronic Technology Co.,Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 11/07/2022 Subject: Request for Confidentiality FCC ID: 2AUTE-ZEVA1966 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jeff Wang Title: Certified Engineer

FCC ID: 2AUTE-HMDR22001 External photos FCC ID: 2AUTE-ZEVA1966 FCC ID: 2AUTE-ZEVA1966 FCC ID: 2AUTE-ZEVA1966 FCC ID: 2AUTE-ZEVA1966 FCC ID: 2AUTE-ZEVA1966 FCC ID: 2AUTE-ZEVA1966 FCC ID: 2AUTE-ZEVA1966

Laabel & Loccation

FCC ID: 2AUTE-ZEVA1966 Internal photos FCC ID: 2AUTE-ZEVA1966 RF Antenna RF chip FCC ID: 2AUTE-ZEVA1966 FCC ID: 2AUTE-ZEVA1966 FCC ID: 2AUTE-ZEVA1966 FCC ID: 2AUTE-ZEVA1966

Dongguan Nore Testing Center Co., Ltd. Report No.: NTC2210020F-1 FCC ID: 2AUTE-ZEVA1966 RF EXPOSURE EVALUATION EUT Specification EUT Photo printer Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others(Bluetooth: 2.402GHz ~ 2.480GHz) Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 24.462dBm(279.38mW) for WIFI 8.403dBm(6.92mW) for BLE 3.612dBm(2.30mW) for BDR+EDR Antenna gain 0dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) 300-1500 -- -- F/1500 1500-100000 -- -- 1 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC2210020F-1 FCC ID: 2AUTE-ZEVA1966 Friis transmission formula: Pd=(Pout*G)\(4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Channel Channel Frequency (MHz) Max Output power (dBm) Max Output power (mW) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) BT BLE Low 2402 8.403 6.92 0.001377 1 2.4G WIFI 802.11g Low 2412 24.462 279.38 0.055581 1 2.4G BT GFSK Low 2402 3.612 2.30 0.000458 1 When bluetooth and WiFi(2.4G) work together: Ratio BT Ratio 2.4G WIFI BT+2.4G WIFI Ratio Total Ratio Limits 0.001377 0.055581 0.056958 1 According to KDB447498 D01 V06, Compliance with RF Exposure requirement.

Report No.: NTC2210045FV00 Page 2 of 50 Table of Contents 1. Summary of Test Result ......................................................................................................................... 4 2. General Description of EUT .................................................................................................................... 5 3. Test Channels and Modes Detail ............................................................................................................ 8 4. Configuration of EUT .............................................................................................................................. 8 5. Modification of EUT................................................................................................................................. 8 6. Description of Support Device ................................................................................................................. 9 7. Test Facility and Location ..................................................................................................................... 10 8. Applicable Standards and References .................................................................................................. 11 9. Deviations and Abnormalities from Standard Conditions ....................................................................... 11 10. Test Conditions ................................................................................................................................... 12 11. Measurement Uncertainty ................................................................................................................... 13 12. Sample Calculations ........................................................................................................................... 14 13. Test Items and Results ....................................................................................................................... 15 13.1 Conducted Emissions Measurement ................................................................................................. 15 13.2 Radiated Spurious Emissions and Restricted Bands Measurement .................................................. 19 13.3 Channel Separation test .................................................................................................................... 26 13.4 20dB Bandwidth ................................................................................................................................ 30 13.5 Hopping Channel Number ................................................................................................................. 34 13.6 Time of Occupancy (Dwell Time) ...................................................................................................... 36 13.7 Maximum Peak Output Power........................................................................................................... 40 13.8 Band Edge Conducted Spurious Emission Measurement ................................................................. 44 13.9 Antenna Requirement ....................................................................................................................... 49 14. Test Equipment List ............................................................................................................................ 50 Report No.: NTC2210045FV00 Page 3 of 50 Revision History Report Number Description Issued Date NTC2210045FV00 Initial Issue 2022-12-08 Report No.: NTC2210045FV00 Page 4 of 50 1. Summary of Test Result FCC Rules Description of Test Result Remarks §15.247(a)(1) Channel Separation test PASS --- §15.247(a)(1) 20dB Bandwidth PASS --- §15.247(a)(1)(iii) Hopping Channel Number PASS --- §15.247(a)(1)(iii) Time of Occupancy (Dwell Time) PASS --- §15.247(b) Max Peak output Power test PASS --- §15.247(d) Band edge test PASS --- §15.207 (a) AC Power Conducted Emission PASS --- §15.247(d),§15.209, §15.205 Radiated Emission PASS --- §15.203 Antenna Requirement PASS --- §15.247(d) Conducted Spurious Emission PASS --- Report No.: NTC2210045FV00 Page 5 of 50 2. General Description of EUT Product Information Product name: Photo Printer Main Model Name: Zeva 1966 Additional Model Name: N/A Model Difference: N/A S/N: Zeva0223700001 Brand Name iDPRT Hardware version: CP4000LMB Software version: V1.0.X Rating: DC 24V from adapter Classification: Class B Typical arrangement: Table-top I/O Port: N/A Accessories Information Adapter: M/N: AP053U-24200 Input: AC 100-240V, 50/60Hz, 1.5A Output: DC 24V, 2A Cable: Power cord: 1.2m, unshielded, undetachable USB Line: 0.56m, unshielded Other: N/A Additional information Note: N/A Remark: All the information above are provided by the manufacturer. More detailed feature of the EUT please refers to the user manual. Report No.: NTC2210045FV00 Page 6 of 50 Technical Specification Bluetooth Version: V5.2 Frequency Range: 2402-2480MHz Modulation Type: GFSK, π/4-DQPSK, 8DPSK Number of Channel: 79 (refer to following channel list for details) Channel Space: 1MHz Antenna Type: PCB Antenna Antenna Gain: 0 dBi (Declared by manufacturer) Remark: This report only applies to BDR+EDR feature of the EUT. Report No.: NTC2210045FV00 Page 7 of 50 Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 0 2402 20 2422 40 2442 60 2462 1 2403 21 2423 41 2443 61 2463 2 2404 22 2424 42 2444 62 2464 3 2405 23 2425 43 2445 63 2465 4 2406 24 2426 44 2446 64 2466 5 2407 25 2427 45 2447 65 2467 6 2408 26 2428 46 2448 66 2468 7 2409 27 2429 47 2449 67 2469 8 2410 28 2430 48 2450 68 2470 9 2411 29 2431 49 2451 69 24721 10 2412 30 2432 50 2452 70 2472 11 2413 31 2433 51 2453 71 2473 12 2414 32 2434 52 2454 72 2474 13 2415 33 2435 53 2455 73 2475 14 2416 34 2436 54 2456 74 2476 15 2417 35 2437 55 2457 75 2477 16 2418 36 2438 56 2458 76 2478 17 2419 37 2439 57 2459 77 2479 18 2420 38 2440 58 2460 78 2480 19 2421 39 2441 59 …

Text truncated - open the document above for the full version.

Page 1 of 5 Xiamen Hanin Electronic Technology Co., Ltd. Specification for approval Customer: Xiamen Hanin Electronic Technology Co., Ltd. Antenna model number: Ant-1966 Antenna type: PCB Antenna Date: 2022.06.15 Page 2 of 5 1. Product Overview & Dimension Page 3 of 5 2. Test Result 2.1 VSWR Frequency (MHz) 2400 2450 2500 VSWR 1.542 1.027 1.415 Page 4 of 5 2. Test Result 2.2 Gain & Efficiency Frequency (MHz) Efficiency (%) Average Gain (dB) Peak Gain (dBi) 2400 4.97 -3.12 -0.13 2450 4.05 -3.53 0.00 2500 4.65 -3.70 -0.09 Page 5 of 5 2. Test Result Horizontal Vertical

FCC ID: 2AUTE-ZEVA1966 Test Photo Radiated emission (Below 30MHz) Radiated emission (30-1000MHz) FCC ID: 2AUTE-ZEVA1966 Radiated emission (Above 1000MHz) Conducted Emission
