H6E Diagnosis System User Manual H6E -Intelligent Diagnosis System 1 Declaration 1. This manual is designed for the usage of H6E, applying to H6E automotive diagnosis platform. No part of this manual can be reproduced, stored in a retrieval system or transmitted, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the prior written permission of Xtool. 2. This electronic control system diagnostic unit is designed for professional vehicle maintenance technicians. It has a certain reliability, however, it can not exclude vehicle damage and loss caused by customer technical problems, vehicle problems or other factors, so users need to take risks. 3. Use the device only as described in this manual. The user will be responsible solely for the after-effects of violating the laws and regulations caused by wrongly using the product or its data information, Xtool will not bear legal responsibility for that. 4. Xtool shall not be liable for any incidental or consequential damages neither for any economic consequential damages arising from the accidents of individual users and the third parties, misusing or abusing of the device, unauthorized changing or repairing of the device, or the failure made by the user not to use the product according to the manual. 5. All information, specifications and illustrations in this manual are based on the latest configurations and functions available at the time of printing. Xtool reserves the right to make changes at any time without notice. 6. is the registered trademark of Shenzhen Xtooltech Co., Ltd. 7.In countries that the trademarks, service marks, domain names, logos and the name of the company are not registered, Xtool claims that it still reserves the ownership of the unregistered trademarks, service marks, domain names, logos and the company name. All other marks for the other products and the company’s name mentioned in the manual still belong to the original registered company. You may not use the trademarks, service marks, domain names, logos and company name of Xtool or other companies mentioned without written permission from the trademark holder. 8. Please visit http://www.xtooltech.com for more information about H6E. 9. Xtool reserves the right for the final interpretation of this manual content. H6E -Intelligent Diagnosis System 2 Contents Chapter I．About H6E ...................................................................................................... 3 1.1 Appearance .......................................................................................................... 3 1.1.1 Front view ................................................................................................. 3 1.1.2 Back view ................................................................................................. 3 1.2 Interface of tablet ................................................................................................ 4 1.2.1 Top View ................................................................................................... 4 1.2.2 Bottom View ............................................................................................. 4 1.2.3 H6E Technical Parameters ........................................................................ 4 Chapter II. How to use H6E .............................................................................................. 6 2.1 Main Interface ..................................................................................................... 6 2.1.1 Main Interface ........................................................................................... 6 2.1.2 Interface Icon ............................................................................................ 6 2.1.3 Interface Taskbar ....................................................................................... 7 2.2 Connection Diagnosis ......................................................................................... 8 2.2.1 Vehicle Connection ................................................................................... 8 2.2.2 Precautions Before Use ............................................................................. 9 2.3 Diagnosis ........................................................................................................... 11 2.3.1 Menu selection ........................................................................................ 11 2.3.2 Diagnostic Function ................................................................................ 12 2.3.3 Read ECU ............................................................................................... 13 2.3.4 Read DTCs .............................................................................................. 14 2.3.5 Clear DTCs ............................................................................................. 14 2.3.6 Read live Data ......................................................................................... 15 2.3.7 Special functionss ................................................................................... 15 2.3.8 Actuating components test ...................................................................... 15 2.4 Setting ............................................................................................................... 16 2.5 Diagnose report ................................................................................................. 17 2.5.1 Diagnose report ....................................................................................... 17 2.5.2 Data playback ......................................................................................... 18 2.6 One-click upgrade ............................................................................................. 18 2.7 Xtool Cloud System .......................................................................................... 19 2.8 Remote control ......…

Text truncated - open the document above for the full version.

Shenzhen XTOOLTECH CO., LTD 2nd Floor, Building No.2, Block 1, Excellence City, Shangmeilin, Futian District, Shenzhen 518000, China Product Similarity Declaration Date: December 06, 2019 FCC ID: 2AVEM-H6 Model Number: H6 Elite, NITRO LT To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Shenzhen XTOOLTECH CO., LTD hereby declare that our product (Bluetooth Tower Stereo) Model Number: H6 Elite, NITRO LT board, Schematic, Hardware version, Software version, structure and internal photos are same, named differently due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name/Title: Darby Tan / CEO/General Manager Company: Shenzhen XTOOLTECH CO., LTD Address: 2nd Floor, Building No.2, Block 1, Excellence City, Shangmeilin, Futian District, Shenzhen 518000, China Tel: 86-755-21670995 Fax: 86-755-83461644 E-Mail: [email protected]

C5266091_X8_Ed.1 1/1 Letter of Authorization Shenzhen XTOOLTECH CO., LTD Company: Shenzhen XTOOLTECH CO., LTD Address: 2nd Floor, Building No.2, Block 1, Excellence City, Shangmeilin, Futian District, Shenzhen 518000, China Product Name: Diagnosis System Model Number: H6 Elite, NITRO LT FCC Identifier: 2AVEM-H6 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Date: December 25, 2019 Title: CEO/General Manager Signature of applicant: Darby Tan

C5266091_X10_Ed.1 1/1 Shenzhen XTOOLTECH CO., LTD Office of Engineering Technology Federal Communications Commission 7075 Flying Cloud Dr. Eden Prairie, MN 55344 USA Date: December 25, 2019 Subject: Request for Confidentiality FCC ID: 2AVEM-H6 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Darby Tan Title: CEO/General Manager

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 1. EXTERIOR PHOTOGRAPHS Fig. 1 Fig. 2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 3 Fig. 4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 5 Fig. 6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 7 Fig. 8

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 Label and Location Size: L2.0cm*W1.5cm Label Location Diagnosis System Model No.: H6 Elite FCC ID: 2AVEM-H6

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 1. INTERIOR PHOTOGRAPHS Fig. 1 Fig. 2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 3 Fig. 4 Antenna SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 5 Fig. 6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 7 Fig. 8 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 9 Fig. 10 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 11 Fig. 12 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 13 Fig. 14 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 15 Fig. 16 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 17 Fig. 18 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 19 Fig. 20 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Fig. 21

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 8 Maximum Permissible Exposure Report 1. Product Information FCC ID: 2AVEM-H6 Product name Diagnosis System Model number H6 Elite, NITRO LT Model Declaration PCB board, structure and internal of these model(s) are the same, So no additional models were tested Test Model H6 Elite Power supply DC 7.4V By lithium ion polymer battery(10000mAh) Recharged by DC 12V/3A adapter Operation frequency 79 Channels for Bluetooth V4.2 (DSS) IEEE 802.11b: DSSS(CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM(64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM,QPSK, BPSK) 4 Channels for 802.11a, 802.11n(HT20), 802.11ac(VHT20) 2 Channels for 802.11n(HT40), 802.11ac(VHT40) 1 Channels for 802.11ac(VHT80) 5 channels for 20MHz bandwidth(5745-5825MHz) 2 channels for 40MHz bandwidth(5755~5795MHz) 1 channels for 80MHz bandwidth(5775MHz) Antenna Type Internal Antenna Antenna Gain 2dBi Hardware version V1.03 Software version / Channel Number 79 Channels for Bluetooth V4.2 (DSS) 11 Channels for 20MHz bandwidth(2412~2462MHz) 7 Channels for 40MHz bandwidth(2422~2452MHz) 4 Channels for 802.11a, 802.11n(HT20), 802.11ac(VHT20) 2 Channels for 802.11n(HT40), 802.11ac(VHT40) 1 Channels for 802.11ac(VHT80) 5 channels for 20MHz bandwidth(5745-5825MHz) 2 channels for 40MHz bandwidth(5755~5795MHz) 1 channels for 80MHz bandwidth(5775MHz) Channel Spacing 5MHz Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Portable Device 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 8 3. 1 Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information ES-D4 can only use antennas certificated as follows provided by manufacturer; Internal Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Notes Antenna 0 Internal Antenna 2000 MHz – 2500 MHz 2 dBi WiFi Antenna 6. Conducted Power SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 8 [BT Max Conducted Power] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 4.749 39 2441 4.784 78 2480 1.070 π/4DQPSK 0 2402 1.227 39 2441 1.153 78 2480 0.683 8DPSK 0 2402 1.607 19 2440 1.445 78 2480 1.023 [2.4GWIFI Max Conducted Power] Mode Channel Frequency(MHz) Max Conducted Power (dBm) 11B 1 2412 8.59 6 2437 8.44 11 2462 8.64 11G 1 2412 8.66 6 2437 8.14 11 2462 8.49 11N20SISO 3 2412 8.70 6 2437 8.29 …

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 36 FCC TEST REPORT For Shenzhen XTOOLTECH CO., LTD Diagnosis System Test Model: H6 Elite Additional Model No.: NITRO LT Prepared for : Shenzhen XTOOLTECH CO., LTD Address : 2nd Floor, Building No.2, Block 1, Excellence City, Shangmeilin, Futian District, Shenzhen 518000, China Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 1/F., Xingyuan Industrial Park, Tongda Road, Bao'an Avenue, Bao'an District, Shenzhen, Guangdong, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : November 20, 2019 Number of tested samples : 1 Serial number : Prototype Date of Test : November 20, 2019 ~ December 13, 2019 Date of Report : December 16, 2019 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 36 FCC TEST REPORT FCC CFR 47 PART 15 C(15.247) Report Reference No. ................. : LCS191022095AEB Date of Issue ................................... : December 16, 2019 Testing Laboratory Name ............. : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ........................................... : 1/F., Xingyuan Industrial Park, Tongda Road, Bao'an Avenue, Bao'an District, Shenzhen, Guangdong, China Testing Location/ Procedure ........... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .......................... : Shenzhen XTOOLTECH CO., LTD Address ........................................... : 2nd Floor, Building No.2, Block 1, Excellence City, Shangmeilin, Futian District, Shenzhen 518000, China Test Specification Standard .......................................... : FCC CFR 47 PART 15 C(15.247) Test Report Form No. ................... : LCSEMC-1.0 TRF Originator ................................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. ............................. : Diagnosis System Trade Mark ...................................... : XTOOL Model/ Type reference .................... : H6 Elite Ratings ............................................ : Recharged by adapter Input: AC 100-240V，50/60Hz,Max.1A Output: DC 12V,3A DC 3.7V By lithium ion polymer battery(10000mAh) Result ............................................ : Positive Compiled by: Supervised by: Approved by: Ray Yang/ File administrators Jin Wang/ Technique principal Gavin Liang/ Manager SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 36 FCC -- TEST REPORT EUT........................................ : Diagnosis System Type / Model........................... : H6 Elite Applicant............................... : Shenzhen XTOOLTECH CO., LTD Address.................................. : 2nd Floor, Building No.2, Block 1, Excellence City, Shangmeilin, Futian District, Shenzhen 518000, China Telephone.............................. : / Fax......................................... : / Manufacturer........................ : Shenzhen XTOOLTECH CO., LTD Address................................... : 2nd Floor, Building No.2, Block 1, Excellence City, Shangmeilin, Futian District, Shenzhen 518000, China Telephone.............................. : / Fax......................................... : / Factory.................................. : Shenzhen XTOOLTECH CO., LTD Address.................................. : 2nd Floor, Building No.2, Block 1, Excellence City, Shangmeilin, Futian District, Shenzhen 518000, China Telephone.............................. : / Fax......................................... : / Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCS191022095AEB December 16, 2019 Date of issue SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 36 Revision History Revision Issue Date Revisions Revised By 000 December 16, 2019 Initial Issue Gavin Liang SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 5 of 36 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 6 1.1. DESCRIPTION OF DEVICE (EUT) ........................................................................................................................ 6 1.2. HOST SYSTEM CONFIGURATION LIST AND DETAILS .................................................................................…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 1 of 40 Appendix C RF Test Data for 2.4G WIFI (Conducted Measurement) Product Name: Diagnosis System Trade Mark: XTOOL Test Model: H6 Elite Environmental Conditions Temperature: 24.3  C Relative Humidity: 53.1% ATM Pressure: 100.0 kPa Test Engineer: ZHUO ZHUO Supervised by: TOM LIU C.1 Duty Cycle Test Mode Test Channel Ant Duty Cycle[%] Verdict 11B 2437 Ant1 100 PASS 11G 2437 Ant1 100 PASS 11N20SISO 2437 Ant1 100 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 2 of 40 Duty Cycle_11B_2437_Ant1 Duty Cycle_11G_2437_Ant1 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 3 of 40 Duty Cycle_11N20SISO_2437_Ant1 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 4 of 40 C.2 Maximum Conducted Output Power Mode Channel Meas.Level [dBm] Limit [dBm] Verdict 11B LCH 8.59 30 PASS MCH 8.44 30 PASS HCH 8.64 30 PASS 11G LCH 8.66 30 PASS MCH 8.14 30 PASS HCH 8.49 30 PASS 11N20SISO LCH 8.7 30 PASS MCH 8.29 30 PASS HCH 8.63 30 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 5 of 40 Test Graphs 11B/LCH 11B/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 6 of 40 11B/HCH 11G/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 7 of 40 11G/MCH 11G/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 8 of 40 11N20SISO/LCH 11N20SISO/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 9 of 40 11N20SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 10 of 40 C.3 Maximum Power Spectral Density Mode Channel Meas.Level [dBm/30KHz] Limit [dBm/3KHz] Verdict 11B LCH -2.437 8 PASS MCH -1.416 8 PASS HCH -1.541 8 PASS 11G LCH -14.133 8 PASS MCH -14.808 8 PASS HCH -14.856 8 PASS 11N20SISO LCH -13.920 8 PASS MCH -14.285 8 PASS HCH -14.167 8 PASS Test Graphs 11B/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 11 of 40 11B/MCH 11B/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 12 of 40 11G/LCH 11G/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 13 of 40 11G/HCH 11N20SISO/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 14 of 40 11N20SISO/MCH 11N20SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 15 of 40 C.4 6dB Bandwidth Mode Channel 6dB Bandwidth [MHz] Limit [MHz] Verdict 11B LCH 8.571 ≥0.5 PASS MCH 9.053 ≥0.5 PASS HCH 9.050 ≥0.5 PASS 11G LCH 15.51 ≥0.5 PASS MCH 15.15 ≥0.5 PASS HCH 15.13 ≥0.5 PASS 11N20SISO LCH 15.99 ≥0.5 PASS MCH 15.99 ≥0.5 PASS HCH 16.11 ≥0.5 PASS Test Graphs 11B/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 16 of 40 11B/MCH 11B/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 17 of 40 11G/LCH 11G/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 18 of 40 11G/HCH 11N20SISO/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 19 of 40 11N20SISO/MCH 11N20SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 20 of 40 C.5 RF Conducted Spurious Emissions Mode Channel Pref [dBm] Max. Level [dBm] Limit [dBm] Verdic t 11B LCH -1.865 -37.832 -21.865 PASS MCH -1.41 -37.075 -21.410 PASS HCH -1.041 -37.255 -21.041 PASS 11G LCH -9.055 -37.141 -29.055 PASS MCH -8.969 -37.260 -28.969 PASS HCH -9.322 -38.013 -29.322 PASS 11N20 SISO LCH -9.682 -37.817 -29.682 PASS MCH -9.232 -37.163 -29.232 PASS HCH -9.434 -37.300 -29.434 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 21 of 40 11B_LCH_Graphs Pref/11B/LCH Puw/11B/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 22 of 40 11B_MCH_Graphs Pref/11B/MCH Puw/11B/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 23 of 40 11B_HCH_Graphs Pref/11B/HCH Puw/11B/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 24 of 40 11G_LCH_Graphs Pref/11G/LCH Puw/11G/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 25 of 40 11G_MCH_Graphs Pref/11G/MCH Puw/11G/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 26 of 40 11G_HCH_Graphs Pref/11G/HCH Puw/11G/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 27 of 40 11N20SISO_LCH_Graphs Pref/11N20SIS O/LCH Puw/11N20 SISO/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 28 of 40 11N20SISO_MCH_Graphs Pref/11N20 SISO/MCH Puw/11N20 SISO/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 29 of 40 11N20SISO_HCH_Graphs Pref/11N20 SISO/HCH Puw/11N20 SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 Report No.: LCS191022095AEB Page 30 of 40 C.6 Band-edge for RF Conducted Emissions Mode Channel Carrier Power[dBm] Max.Spurious Level [dBm] Limit [dBm] Verdict 11B LCH -2.061 -49.851 -22.06 PASS HCH -1.067 -49.209 -21.07 PASS 11G LCH -9.189 -49.849 -29.19 PASS HCH -9.188 -49.500 -29.19 PASS 11N20SISO LCH -9.607 -49.359 -29.61 PASS HCH -8.926 -48.998 -28.93 PASS Test Graphs 11B/LCH SHENZHEN LCS COMPLIANCE T…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 _______________________________________________________________________________________________ 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVEM-H6 _______________________________________________________________________________________________ 1.2. Photo of Conducted Emissions Measurement Fig. 3
