2AWAA-RS5Thermal Imager

RS5 series infrared thermal imaging riflescope Quick Guide Product buttons introduction Eyepiece adjust Lens adjust Photo/ video Type‐C port Battery com partment Zoom in/ correct Color code/ menu Power /hibernate Power  Long press to turn on/off the thermal imager.  After power on, short press to make the eyepiece hibernate, and press any key to wake it up.  When setting calibrating data , short press to turn on/unfreeze the image function. Colour code  Short press to switch colour scale. WHot (white-hot), BHot (black hot), IHot (iron red), Roth (red hot), Forest (forest mode), the factory default is WHot (white hot).  Long press to enter the user menu, and long press again to exit the current menu. Menu location Horizontal tilt angle value Camera recording status Calibration Parameter Values Remaining storage capacity Color code status E zoom status WIFI statu Battery status Azimuth display Zoom in  Short press for electronic zoom, 1X, 2X, 4X cycle zoom.  Long press to enable manual image uniformity correction. Photo  Short press to take pictures.  Long press to start the recording function, and short press again to end the recording. Function key combination  Press and hold the "Zoom in" key and the "Photo" key at the same time to enable or disable the horizontal tilt angle value. Diopter adjustment  According to the individual degree of far and nearsightedness, adjust the eyepiece knob to adjust the diopter until the image and text are clear. Menu  Press and hold the “Color code” key to enter or exit the menu mode.  In the menu mode, press the "Zoom in" key or the "Photo" key to select a function, and press the "Color mode" key to select a function.  *Ranging function setting: Laser ranging can be performed on targets within 1000m. Press the "Zoom in" key or the "Photo" key to turn this function on or off, and the factory default is turned off. (*Requires optional laser ranging module)  Zero setting: can turn on or off automatic zero. Press the "Zoom in" key or the "Photo" key to turn this function on or off, and it is turned on by default.  Picture-in-picture function: the centre area is enlarged by 2 times by default. When the electronic zoom is activated at the same time, the picture-in-picture image is enlarged cyclically by 2X, 4X, and 8X. Press the "Zoom in" key or the "Photo" key to turn this function on or off, and it is turned off by default.  WIFI function: Android system can enter the official website to download the mobile client program "IR-TRACKER ", after installing and V running the mobile client program, in the first use state, find the instrument hotspot "RS5_xxxxxxxx" in the mobile phone WIFI, the initial password "12345678", the connection is successful After that, open the "IR-TRACKER V" software of the mobile phone, click the software "connect" to see the image, and realize the functions of taking pictures, video recording, playback and storage of the images through the mobile phone client software. The WiFi name and password can be customized by the client after connecting. Press the "Zoom in" key or the "Photo" key to turn this function on or off, and it is turned off by default. NOTE: Turning on WIFI for a long time will increase the power consumption of the instrument and shorten the standby time of the instrument. Please turn off this function when not in use.  Enhanced function: When enabled, it will display an enhanced image to increase image details. Press the "Zoom in" key or the "Photo" key to turn this function on or off, and it is turned on by default.  Hot spot tracking function: After it is turned on, it will take effect after exiting the menu, which can assist in tracking the highest temperature target on the screen. Press the "Zoom in" key or the "Photo" key to turn this function on or off, and it is turned off by default. Note: When the hot spot tracking function is turned on, the electronic zoom operation cannot be performed at the same time.  Cursor typesetting: ten cursor types can be selected (1~10), and no cursor mode (0) can be selected. Press the "Zoom in" key or the "Photo" key to switch the cursor type, and press the "Color mode" key to select the cursor And save, the factory default is "0".  Calibration data set: 5 sets of calibration data can be saved, press the "Zoom" key or the "Photo" key to switch the custom calibration data set, and press the "Color mode" key to select the custom set for setting. Note: After entering the calibration data setting menu, perform aiming and calibration shooting. When the target heat appears on the screen, short press the "Power" button to freeze the image, and then do the following operations. If you need to unfreeze, you can also short press the "power" button again, or long-press the "colour mode" button to exit the current menu and automatically unfreeze. Magnification: Selectable calibration electron magnification, 1x/2x/4x. Press the "Zoom in" key or the "Photo" key to change the parameters, and press the "Color mode" key to select and return. Calibre: You can select the calibration calibre size (Imperial), the range is 0.20~1.80. Press the "Zoom in" key or the "Photo" key to change the parameters, and press the "Color mode" key to select and return. Distance: Selectable calibration distance, 25/50/100. Press the "Zoom in" key or the "Photo" key to change the parameters, and press the "Color mode" key to select and return. Cross reticle: You can move the red cross reticle to the target point. Short press the "colour mode" button to switch between horizontal (X-axis) and vertical (Y-axis); press the "zoom in" button or "photo" button to change the coordinate value; after reaching the target position, long-press the "colour mode" button to save the score. Swipe the position and return to the previous menu. Modify: Modify and save the current group setting parameters. Press the "colour mode" key to save the modified parameters. Return: return to the previous menu, and press the …

Text truncated - open the document above for the full version.

ZHEJIANG DALI TECHNOLOGY CO., LTD Date: 2022.07.11 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:__ 2AWAA-RS5____ Product Name:__ Thermal Imager ________ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block Diagram • Operation Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name: Shi changbing Company: ZHEJIANG DALI TECHNOLOGY CO., LTD Address: NO639 Binkang Road, Hangzhou, P.R.CHINA 310053 Phone: 8657186483758 Fax: 8657186483758 E-Mail: [email protected]

ZHEJIANG DALI TECHNOLOGY CO., LTD Date: 2022.07.11 FCC ID: 2AWAA-RS5 Dear Sir/Madam, We, ZHEJIANG DALI TECHNOLOGY CO., LTD Hereby declares the following statement for Federal Communications Commission, All these models are identical in the same PCB, layout, electrical circuit and enclosure. The difference is the optical lens and whether there is a ranging module. Only the model RS550-640L removes the ranging module. Product name: Thermal Imager Model No.: RS535-640, RS519-384, RS535-384, RS550-640, RS535-640L, RS519-384L, RS535- 384L, RS550-640L Sincerely, Signature: Name: Shi changbing Company: ZHEJIANG DALI TECHNOLOGY CO., LTD Address: NO639 Binkang Road, Hangzhou, P.R.CHINA 310053 Phone: 8657186483758 Fax: 8657186483758 E-Mail: [email protected]

ZHEJIANG DALI TECHNOLOGY CO., LTD \\192.168.1.251\szctc\06 工程部\02 RF项目部\2022年案件\5月\CTC220429-029 通鉴 RS5 FCC ID & RED\1.资料\1.3 申请资料 \Letter\POA_Letter_140225.docx Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022.07.11 SUBJECT: FCC Application for FCC ID: 2AWAA-RS5 To Whom It May Concern: We, the undersigned, hereby authorize _ Titto Zhao _ at _CTC Laboratories, Inc. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by _ Titto Zhao _ on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Signature: Name: Shi changbing Company: ZHEJIANG DALI TECHNOLOGY CO., LTD Address: NO639 Binkang Road, Hangzhou, P.R.CHINA 310053 Phone: 8657186483758 Fax: 8657186483758 E-Mail: [email protected]

ZHEJIANG DALI TECHNOLOGY CO., LTD Date: 2022.07.11 FCC ID: 2AWAA-RS5 Dear Sir/Madam, We, ZHEJIANG DALI TECHNOLOGY CO., LTDHereby declares the Product name: Thermal Imager, Model no.: RS535-640, RS519-384, RS535-384, RS550-640, RS535-640L, RS519-384L, RS535-384L, RS550-640L, Have done SDOC certification. Sincerely, Signature: Name: Shi changbing Company: ZHEJIANG DALI TECHNOLOGY CO., LTD Address: NO639 Binkang Road, Hangzhou, P.R.CHINA 310053 Phone: 8657186483758 Fax: 8657186483758 E-Mail: [email protected]

CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel: +86-755- 27521059 Fax: +86-755- 27521011 Http://www.sz-ctc.org.cn Page 1 of 4 External Photographs Page 2 of 4 Page 3 of 4 Page 4 of 4

CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel: +86-755- 27521059 Fax: +86-755- 27521011 Http://www.sz-ctc.org.cn Page 1 of 1 Label 1. Label Location

CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel: +86-755- 27521059 Fax: +86-755- 27521011 Http://www.sz-ctc.org.cn Page 1 of 11 Internal Photographs Page 2 of 11 WIFI Antenna Page 3 of 11 Page 4 of 11 Page 5 of 11 Page 6 of 11 Page 7 of 11 Page 8 of 11 Page 9 of 11 Page 10 of 11 Page 11 of 11

Page 1 of 58 Report No.: S22051901602001 FCC SAR EVALUATION REPORT In accordance with the requirements of FCC 47 CFR Part 2(2.1093), ANSI/IEEE C95.1-1992 and IEEE Std 1528-2013 Product Name： Thermal Imager Trademark： N/A Model Name： RS535-640 Family Model： RS519-384, RS535-384, RS550-640, RS535-640L, RS519-384L, RS535-384L, RS550-640L Report No.： S22051901602001 FCC ID： 2AWAA-RS5 Prepared for ZHEJIANG DALI TECHNOLOGY CO.,LTD NO639 Binkang Road, Hangzhou, P.R.CHINA 310053 Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao'an District, Shenzhen 518126 P.R.China. Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Page 2 of 58 Report No.: S22051901602001 TEST RESULT CERTIFICATION Applicant’s name ................. : ZHEJIANG DALI TECHNOLOGY CO.,LTD Address .................................. : NO639 Binkang Road, Hangzhou, P.R.CHINA 310053 Manufacturer's Name ..................................... : ZHEJIANG DALI TECHNOLOGY CO.,LTD Address .................................. : NO639 Binkang Road, Hangzhou, P.R.CHINA 310053 Product description Product name ......................... : Thermal Imager Trademark ............................ : N/A Model Name ......................... : RS535-640 Family Model .......................... : RS519-384, RS535-384, RS550-640, RS535-640L, RS519-384L, RS535-384L, RS550-640L Standards .............................. : FCC 47 CFR Part 2(2.1093) ANSI/IEEE C95.1-1992 IEEE Std 1528-2013 Published RF exposure KDB procedures This device described above has been tested by Shenzhen NTEK. In accordance with the measurement methods and procedures specified in IEEE Std 1528-2013 and KDB 865664 D01. Testing has shown that this device is capable of compliance with localized specific absorption rate (SAR) specified in FCC 47 CFR Part 2(2.1093) and ANSI/IEEE C95.1-1992. The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK, this document may be altered or revised by Shenzhen NTEK, personal only, and shall be noted in the revision of the document. Test Sample Number .............................. S220519016001 Date of Test Date (s) of performance of tests ............. : Jul. 12, 2022 Date of Issue........................................... : Jul. 12, 2022 Test Result .............................................. : Pass Prepared By (Test Engineer) : (Jacob Chen) Approved By (Lab Manager) : (Alex Li) Page 3 of 58 Report No.: S22051901602001 ※ ※ Revision History ※ ※ REV. DESCRIPTION ISSUED DATE REMARK Rev.1.0 Initial Test Report Release Jul. 12, 2022 Jacob Chen Page 4 of 58 Report No.: S22051901602001 TABLE OF CONTENTS 1. General Information ............................................................................................ 6 1.1. RF exposure limits .................................................................................... 6 1.2. Statement of Compliance ........................................................................ 7 1.3. EUT Description ....................................................................................... 7 1.4. Test specification(s) .................................................................................. 8 1.5. Ambient Condition ................................................................................... 8 2. SAR Measurement System ................................................................................... 9 2.1. SATIMO SAR Measurement Set-up Diagram ............................................ 9 2.2. Robot ..................................................................................................... 10 2.3. E-Field Probe .......................................................................................... 11 2.3.1. E-Field Probe Calibration ................................................................. 11 2.4. SAM phantoms ...................................................................................... 12 2.4.1. Technical Data .................................................................................. 13 2.5. Device Holder ........................................................................................ 14 2.6. Test Equipment List ................................................................................ 15 3. SAR Measurement Procedures .......................................................................... 17 3.1. Power Reference ................................................................................... 17 3.2. Area scan & Zoom scan .......................................................................... 17 3.3. Description of interpolation/extrapolation scheme .............................. 19 3.4. Volumetric Scan ..................................................................................... 19 3.5. Power Drift ............................................................................................ 19 4. System Verification Procedure .......................................................................... 20 4.1. Tissue Verification ................................................................................. 20 4.1.1. Tissue Dielectric Parameter Check Results ...................................... 21 4.2. System Verification Procedure .............................................................. 22 4.2.1. System Verification Results .............................................................. 23 5. SAR Measurement variability and uncertainty .................................................. 24 5.1. SAR measurement variability ................................................................. 24 5.2. SAR measurement uncertainty ......................…

Text truncated - open the document above for the full version.

CTC Laboratories, Inc. $CNAS$ 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel: +86-755- 27521059 Fax: +86-755- 27521011 Http://www.sz-ctc.org.cn TEST REPORT Report No. ··························: CTC20220914E01 FCC ID································: 2AWAA-RS5 Applicant····························: ZHEJIANG DALI TECHNOLOGY CO., LTD Address·······························: NO639 Binkang Road, Hangzhou, P.R.CHINA 310053 Manufacturer························: ZHEJIANG DALI TECHNOLOGY CO., LTD Address·······························: NO639 Binkang Road, Hangzhou, P.R.CHINA 310053 Product Name······················: Thermal Imager Trade Mark···························: / Model/Type reference·············: RS535-640 Listed Model(s) ····················: RS519-384, RS535-384, RS550-640, RS535-640L, RS519-384L, RS535-384L, RS550-640L Standard·····························: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of receipt of test sample...: May. 09, 2022 Date of testing.......................: May. 09, 2022 ~ May. 12, 2022 Date of issue.........................: May. 13, 2022 Result.................................: PASS Compiled by: (Printed name+signature) Terry Su Supervised by: (Printed name+signature) Eric Zhang Approved by: (Printed name+signature) Totti Zhao Testing Laboratory Name......: CTC Laboratories, Inc. Address...............................: 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China This test report may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CTC. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CTC within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. The test report merely correspond to the test sample. Page 2 of 80 Report No.: CTC20220914E01 CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel.: (86)755-27521059 Fax: (86)755-27521011 Http://www.sz-ctc.org.cn For anti-fake verification, please visit the official website of Certification and Accreditation Administration of the People’s Republic of China : yz.cnca.cn Table of Contents Page 1. TEST SUMMARY .................................................................................................................................................... 3 1.1. TEST STANDARDS .......................................................................................................................................................... 3 1.2. REPORT VERSION .......................................................................................................................................................... 3 1.3. TEST DESCRIPTION ........................................................................................................................................................ 4 1.4. TEST FACILITY .............................................................................................................................................................. 5 1.5. MEASUREMENT UNCERTAINTY ........................................................................................................................................ 5 1.6. ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 6 2. GENERAL INFORMATION ....................................................................................................................................... 7 2.1. CLIENT INFORMATION ................................................................................................................................................... 7 2.2. GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 7 2.3. ACCESSORY EQUIPMENT INFORMATION ............................................................................................................................ 8 2.4. OPERATION STATE ......................................................................................................................................................... 9 2.5. MEASUREMENT INSTRUMENTS LIST ............................................................................................................................... 10 3. TEST ITEM AND RESULTS ..................................................................................................................................... 11 3.1. CONDUCTED EMISSION ................................................................................................................................................ 11 3.2. RADIATED EMISSION ................................................................................................................................................... 14 3.3. BAND EDGE EMISSIONS (RADIATED) .............................................................................................................................. 36 3.4. BAND EDGE AND SPURIOUS EMISSIONS (CONDUCTED) ...................................................................................................... 49 3.5. DTS BANDWIDTH ....................................................................................................................................................... 63 3.6. PEAK OUTPUT POWER ................................................................................................................................................ 68 3.7. POWER SPECTRAL DENSITY ..................…

Text truncated - open the document above for the full version.

CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel: +86-755- 27521059 Fax: +86-755- 27521011 Http://www.sz-ctc.org.cn Page 1 of 2 Radiated Measurements Below 1GHz Above1GHz Page 2 of 2 Conducted Emissions

Test Positions Front Side (Separation distance of 0mm) Back Side (Separation distance of 0mm) Left side (Separation distance of 0mm) Right side (Separation distance of 0mm) Top side (Separation distance of 0mm) Bottom side (Separation distance of 0mm) Front Side (Separation distance of 5mm) Back Side (Separation distance of 5mm) Left side (Separation distance of 5mm) Right side (Separation distance of 5mm) Top side (Separation distance of 5mm) Bottom side (Separation distance of 5mm) END
