series series NO. ButtonsFunction Power Photo · Short press: manual image correction · Long press: power on/off · Short press: capture picture, and exit video recording · Long press: turn on the video recording · Short press: color palette switching In menu mode: function conrmation · Long press: enter/exit user menu · Rotate:zoom in In menu mode: left/right switching and value addition/subtraction Manually adjusting image clarity Lens protection For use with optical riescope Can be powered by external battery, battery type CR123A Type-C interface, used for charging, external power supply, data transmission, system upgrade, and analog video output For use with other accessories For use with Picatinny rail 1 2 3 4 5 6 7 8 9 10 Knob Operation Focus Ring Lens cap Adapter ring External Battery Compartment Interface Extended Dovetail Groove Rail Interface Capacity Palette Group Zoom WiFi System time Battery series Power ·Short press: manual image uniformity correction, can be performed manually to refresh a clear image. ·Long press: on/off device. Photo ·Short press: take photos and exit the video recording. ·Long press: turn on the video recording. Knob ·Short press: color palette switching among White hot, Black hot, Emerald, Iron hot, Red hot and Green. ·Long press: enter/exit user menu. ·Rotate: 1.0~8.0x zoom in. Single step 0.1x zoom for ne on target image. Combination Button function : Power + Knob Simultaneously press and hold the “Power+Knob” button to switch between front/observation mode. Horizontal angle value Azimuth Pitch angle value series Knob Instruction ·Short press: function conrmation. ·Long press: return. ·Left/right switching and value addition/subtraction. series 4.1 Functions menu WiFi:off/AP/STA AP mode: Download the client program "IR-TRACKER V", install and run the mobile client program, and for the rst time in use, nd the instrument hot-spot "XXX_XXXXX" (WiFi name is "model serial number") in the mobile WiFi, with an initial password of "12345678". After successful connection, open the mobile "IR-TRACKER V" software, click on the software "Connect" to see the image, and use the mobile client software to achieve functions such as taking photos, recording, playback, and storage of the image. After connecting, the WiFi name and password can be customized on the client side. Click "Setting" on the homepage to enter the settings, select "WIFI settings", enter the desired WiFi name and password, click "Conrm the changes", and the STA mode setting is completed. STA mode: You need to rst connect to the client in AP mode. Click "Setting" on the homepage to enter the settings, select "Router settings", enter the WiFi name and password you want to connect to, click "Conrm the changes", and the STA mode setting is completed. Select STA mode for local WiFi to automatically connect to the network. Note: Turning on WIFI for a long time will increase the power consumption of the device, resulting in shorter standby time, please turn off this function when not in use. series OSD:on/off Display and Hidden of Status Bar. RAV:on/off Enable RAV function. When the impact occurs, the local recording will automatically start, and a pre-recorded video of 10 seconds before the impact will be synthesized into the recording le. Screen Brightness:1/2/3/4/5 Support 5-level eyepiece display screen brightness adjustment. Distance estimate Automatically displays the estimated distance to a specic target size object on the scale. Hot-spot tracking:on/off When turned on, the main interface will appear to automatically track the cursor to display the highest temperature point on the screen. Picture in Picture:off/Top/Bottom It can be displayed in two xed positions, top and bottom, and the center area will be enlarged twice. Enhance:0~15 Enhance the clarity of the image by up to 15 levels, the factory default is 5 level. Auto NUC:on/off When turned on, the device automatically zeroing for image refresh; When turned off, the device will no longer automatically refresh images. You can manually refresh images by short pressing the button "Power”. th series 4.2 System setting Language:English/Russian/German Three languages are optional. System information Displays information such as device model/software version. Formatting The built-in memory card can be formatted, and a prompt will appear at the top after successful formatting. Please operate with caution. Upgrade Version upgrades are available. The operation of version upgrade is as follows: Preparation: Download the version upgrade program le through PC (for details, please contact the manufacturer's after-sales technical support), and copy the ".upp" upgrade program to the root directory of the local storage space of the device. Device upgrade: Click the function in the device and select upgrade. After the upgrade is completed, press and hold the button"power " to turn off the device, and then turn on the device again to restart, the upgrade will be completed. Save:on/off When turned on, the recording will save the audio. Compass calibration After entering the compass calibration, rotate the device according to the prompts to correct the electronic compass. Sleep:0/5/30/60 The optional automatic sleep time is 0min/5min/30min/60min. If there is no operation during this time period, the eyepiece will be automatically turned off. The device will be in low-power standby mode, and press any button to restore. 4.3 Zeroing (Calibration) Knob ·Short press: function conrmation. ·Rotate: Left/right switching and value addition/subtraction. series series Group:1/2/3/4/5 Five sets of user-dened parameters for riescope calibration. Cursor Type:0~10 Ten cursor types are available, default "0" off. Color: White/Red/Green/Yellow Four cursor colors are available. Freeze: on/off Freeze the image. Zoom in:1X/2X/4X/8X 1x/2x/4x/8x centered on the cursors. Left/Right:[-360,360] Moves the cursor left/right on the X-axis. Up/Down:[-270,270] Moves the cursor …
