2BCGWBE700BE15000 Tri-Band Wi-Fi 7 Router, BE11000 Tri-Band Wi-Fi 7 Router

LED Explanation You can check the router’s working status by following the LED Explanation. Button Explanation 1. Connect your device to the router wirelessly or with an Ethernet cable. New Password: Let’s Get Started Confirm Password: http://tplinkwifi.net Method TWO: Via a Web Browser 2. Launch a web browser and enter http://tplinkwifi.net or http://192.168.0.1 in the address bar. Create a password to log in. 3. Follow the step-by-step instructions to set up the internet connection and register for the TP-Link Cloud service. Note: If the login window does not appear, please refer to Q1 of Need Help? in this guide. Method ONE: Via the TP-Link Tether App 1. Download the Tether app. Scan for Tether Tether or 3. Tap the button in the Tether app, select Wireless Router, and find your model. Follow the steps to complete the setup and connect to the internet. 2. Open the Tether app and log in with your TP-Link ID. Note: If you don’t have an account, create one first. To enjoy a more complete service from TP-Link, bind your TP-Link ID to the router. The default wireless network names (SSIDs) and password are printed on the label at the back of the router. Wireless Password/PIN: XXXXXXXX SSID:TP-Link_XXXX SSID:TP-Link_XXXX_5G SSID:TP-Link_XXXX_6G Set Up the Network 2 Three physical buttons are located on the front of the router. Press the WPS button, and immediately press the WPS button on your client device to start the WPS process. Press the LED button to turn on or off the LED of your router. Press and hold this button for about 2 seconds to turn on or off the wireless function of your router. LED ButtonWi-Fi ButtonWPS Button Wait until the LED is solid on (LED Exclamation Point or All LEDs). 4 Off Power is off or the LED is turned off. Blinking Wi-Fi is off. Blinking The router is disconnected from the internet, and Wi-Fi is off. Solid The router is disconnected from the internet. Blinking Establishing a WPS connection. Solid The router is working normally. Cycling The system is starting up or the router is being upgraded. Do not disconnect or power off your router. All LEDs Top 10 LEDs LED Exclamation Point LED Exclamation Point All LEDs Connect the powered-off modem to the router’s 10G Internet port with an Ethernet cable. 1 Power on the modem, and then wait about 2 minutes for it to restart. • Unplug the power to turn off your modem, if any, and remove the backup battery if it has one. • Keep the router vertical while working. Refer to Q5 of Need Help? to place the router for optimal Wi-Fi performance. Modem Unplug the power If your internet comes from an Ethernet outlet instead of a DSL / Cable / Satellite modem, connect the router’s 10G Internet port to it, and then follow steps 3 and 4 to complete the hardware connection. *Images may differ from your actual products. Internet 3 Connect the power adapter to the router. Then press the Power button to turn on the router. Choose Your Device Type Gaming Router Range Extender Wireless Router Note: Due to Tether app updates, your actual user interface and pathway may differ from those depicted here. 1 Connect the Hardware Or Q1. What should I do if I can’t access the web management page? • Reboot your router and try again. • If the computer is set to a static IP, change its settings to obtain an IP address automatically. • Verify that http://tplinkwifi.net is correctly entered in the web browser. Alternatively, enter http://192.168.0.1 or http://192.168.1.1 in the web browser. • Use another web browser and try again. • Disable and enable the network adapter in use. Q2. What should I do if I can’t access the internet? • Power off your modem for about 5 minutes, then power it on and check the internet. If your modem has more than one Ethernet port, keep the other ports unconnected. • Check if the internet is working normally by connecting a computer directly to the modem via an Ethernet cable. If it is not, contact your internet service provider. • Log in to the web management page, and go to the Network Map page to check whether the internet IP address is valid or not. If it’s valid, go to Advanced > Network > Internet, click Advanced Settings, select Use the Following DNS Addresses, set the primary DNS to 8.8.8.8, and set the secondary DNS to 8.8.4.4. If it is not, check the hardware connection or contact your internet service provider. • For cable modem users, log in to the web management page of the router and go to Advanced > Network > Internet > MAC Clone. Select Clone Current Device MAC and click SAVE. Then reboot both the modem and the router. Q3. What should I do if I forget my wireless password? • If you have not changed the default wireless password, it can be found on the label at the back of the router. • Connect a computer directly to the router using an Ethernet cable. Log in to the router’s web management page at http://tplinkwifi.net and go to With the USB port, it’s easy to share files and media with multiple devices. Visit https://www.tp-link.com/app/usb to learn more about the USB applications. EasyMesh-Compatible You can experience strong, stable, and seamless wireless connections throughout your home with EasyMesh. ©2024 TP-Link 7106510966 REV1.0.0 Need Help? Tri-Band Wi-Fi 7 Router Quick Installation Guide For technical support, replacement services, user guides, and other information, please visit https://www.tp-link.com/support. TP-Link HomeShield premium security services keep your home network safe with cutting-edge features. Download the Tether app to enjoy HomeShield features. For more details, visit https://www.tp-link.com/homeshield. Comprehensive Reports Gain full statistics and insights to help you know your home network better. Parental Controls Manage online time and block inappropriate content to maintain healthy online habits. Quality of Service (QoS) Prioritize your bandwidth needs for a better networking experience. Network Protection Detects cyber threats to keep your privacy and connected devices well p…

Text truncated - open the document above for the full version.

© 2024 TP-Link User Guide BE15000 Tri-Band Wi-Fi 7 Router Archer BE700 142 FCC compliance information statement Product Name: BE15000 Tri-Band Wi-Fi 7 Router Model Number: Archer BE700 Component NameModel I.T.E. Power Supply T120330-2B4 Responsible party: TP-Link USA Corporation Address: 10 Mauchly, Irvine, CA 92618 Website: http://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: [email protected] This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 143 Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this transmitter must be installed to provide a separation distance of at least 41 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. • FCC regulations restrict the operation of this device to indoor use only. • The operation of this device is prohibited on oil platforms, cars, trains, boats, and aircraft, except that operation of this device is permitted in large aircraft while flying above 10,000 feet in the 5.925-6.425 GHz band. • Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or communications with unmanned aircraft systems. FCC compliance information statement Product Name: I.T.E. Power Supply Model Number: T120330-2B4 Responsible party: TP-Link USA Corporation Address: 10 Mauchly, Irvine, CA 92618 Website: http://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: [email protected] This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 144 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated. Issue Date: 2024-02-29 145 CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. OPERATING FREQUENCY(the maximum transmitted power) 2400 MHz -2483.5 MHz (20dBm) 5150 MHz -5250 MHz (23dBm) 5250 MHz -5350 MHz (23dBm) 5470 MHz -5725 MHz (30dBm) 5945MHz -6425 MHz (23dBm) EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce/ RF Exposure Information This device meets the EU requirements (2014/53/EU Article 3.…

Text truncated - open the document above for the full version.

TP-LINK CORPORATION PTE.LTD. 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 012423-17 rev2 Statement for 47 CFR section 2.911(d)(5)(i) TP-LINK CORPORATION PTE.LTD. certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) TP-LINK CORPORATION PTE.LTD. certifies that, as of the date of the filing of this application, the applicant ☐ - is /- is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: ____Sarah Wang__ (Signature 2 ) (Print name) Title: Compliance manager Company: TP-LINK CORPORATION PTE.LTD. PTE.LTD.) Telephone: +86 755 21534921 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters should be placed on appropriate letterhead.

U.S. AgentDesignationfor Serviceof Process (Applicantand U.S. Agentare SeparateParties) TO:AmericanCertificationBody, Inc. 313 Park Avenue Suite 300 Falls Church,VA 22046 ATTENTION:FCC Certification– Section2.911(d)(7)Information DesignatedU.S. Agent CompanyName:VISHTECLLC ContactName:Alan Graham StreetAddress:9888 W BelleviewAve Ste 2142 DenverCO 80123 City/Province/Zip:80123 TelephoneNo:（571）4007350 Email: [email protected] FRN #: 0033407131 This letter is to confirmthat we (“the DesignatedU.S. Agent ”) have acceptedthe responsibilityto act as the DesignatedU.S. Agent for Serviceof Processfor the limited purposeof compliancewith section47 CFR 2.911(d)(7)only and not for any other purpose,on behalfof theApplicantnoted below. U.S. AgentSignature: Date: 2023/8/28 Signedby (PrintedName/Title): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: TP-LINK CORPORATION PTE. LTD. Grantee Code: 2BCGW FRN #: 0034122556 Contact Name: Sarah Wang Street Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 City/Province/Zip: Singapore Telephone No: +65-97538388 Email: [email protected] Applicant Signature 1 : Date: 2023/8/28 Signed by (Printed Name/Title) S arah W ang 1 - Lettersshouldbe placedon appropriateletterhead.

AttestationLetter FederalCommunicationsCommission AuthorizationandEvaluationDivision We Name:TP-LINKCORPORATIONPTE.LTD. Address:7TemasekBoulevard#29-03SuntecTowerOne,Singapore038987 Declarethatthedevicedoesnotsupportchannel12~13in2.4GHzbandandanynon-US channelsinalltheoperationalmode(s)forthefollowingproduct. Product:BE15000Tri-BandWi-Fi7Router BE11000Tri-BandWi-Fi7Router FCCID:2BCGWBE700 Model:ArcherBE700,ArcherBE700Pro,ArcherBE11000Pro Brand:tp-link Sincerely, _________________ Name:SarahWang Position:RegulatoryComplianceManager Date:2024-03-01

ConfidentialityRequestLetter FederalCommunicationsCommission AuthorizationandEvaluationDivision FCCID:2BCGWBE700 ConfidentialityRequest PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequest confidentialtreatmentofinformationaccompanyingthisapplicationasoutlinedbelow: 1.BlockDiagram 2.Schematics 3.OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarily releasedtothepublic.Thepublicdisclosureofthesemattersmightbeharmfultothe applicantandprovideunjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoRule0.457,disclosureofthisapplicationandall accompanyingdocumentationwillnotbemadebeforethedateoftheGrantforthis application. Sincerely, _________________ Name:SarahWang Position:RegulatoryComplianceManager Date:2024-03-01

DeclarationofAuthorization We Name:TP-LINKCORPORATIONPTE.LTD. Address:7TemasekBoulevard#29-03SuntecTowerOne,Singapore038987 Declarethat: NameRepresentativeofagent:MarlinChen AgentCompanyname:MRTTechnology(Suzhou)Co.,Ltd Address:D8Building,YouxinIndustrialPark,No.2Tian'edangRd., WuzhongEconomicDevelopmentZone City:Suzhou Country:China isauthorizedtoapplyforCertificationofthefollowingproduct(s): Product:BE15000Tri-BandWi-Fi7Router BE11000Tri-BandWi-Fi7Router FCCID:2BCGWBE700 Model:ArcherBE700,ArcherBE700Pro,ArcherBE11000Pro Brand:tp-link Sincerely, _________________ Name:SarahWang Position:RegulatoryComplianceManager Date:2024-03-01

DeclarationofConformity We Name:TP-LINKCORPORATIONPTE.LTD. Address:7TemasekBoulevard#29-03SuntecTowerOne,Singapore038987 Declarethat: Product:BE15000Tri-BandWi-Fi7Router BE11000Tri-BandWi-Fi7Router FCCID:2BCGWBE700 Model:ArcherBE700,ArcherBE700Pro,ArcherBE11000Pro Brand:tp-link ProductwhichbearstheaboveFCCIDisalsocompliantwiththeFCCrequirementsforsDOC. AndthesDOCprocedureshallbecarriedoutpriortomarketingthedeviceintheUS. Sincerely, _________________ Name:SarahWang Position:RegulatoryComplianceManager Date:2024-03-01

_____________________ Name:SarahWang Position:RegulatoryComplianceManager Date:2024-03-05 Declaration letter For our business issue and marketing requirement, we would like to list different model number as following: Model No.: Archer BE700, Archer BE700 Pro, Archer BE11000 Pro Model Difference: 1. The only difference between the models is in the design of the RJ45 port. Other designs (including hardware and software) are the same. Archer BE700 with 1Gbps ports and Archer BE700 Pro and Archer BE11000 Pro with 10G bps port. 2. Archer BE11000 Pro has the different model and product name from Archer BE700 Pro, others are exactly the same.

Report No.: 2401TW0112-UE 1 of 11 External Photograph (1) EUT Photo – Archer BE700 (2) EUT Photo – Archer BE700 Report No.: 2401TW0112-UE 2 of 11 (3) EUT Photo – Archer BE700 (4) EUT Photo Report No.: 2401TW0112-UE 3 of 11 (5) EUT Photo – Archer BE700 (6) EUT Photo – Archer BE700 Report No.: 2401TW0112-UE 4 of 11 (7) EUT Photo – Archer BE700 Pro (8) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UE 5 of 11 (9) EUT Photo – Archer BE700 Pro (10) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UE 6 of 11 (11) EUT Photo – Archer BE700 Pro (12) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UE 7 of 11 (13) EUT Photo (Brand: tp-link, M/N: T120330-2B4) (14) EUT Photo (Brand: tp-link, M/N: T120330-2B4) Report No.: 2401TW0112-UE 8 of 11 (15) EUT Photo (Brand: tp-link, M/N: T120330-2B4) (16) EUT Photo (Brand: tp-link, M/N: T120330-2B4) Report No.: 2401TW0112-UE 9 of 11 (17) EUT Photo (Brand: tp-link, M/N: T120330-2B4) (18) EUT Photo (Brand: tp-link, M/N: T120330-2B4) Report No.: 2401TW0112-UE 10 of 11 (19) EUT Photo (Brand: tp-link, M/N: T120330-2B4) (20) EUT Photo (Brand: tp-link, M/N: T120330-2B4) Report No.: 2401TW0112-UE 11 of 11 (21) EUT Photo

深圳市联洲国际技术有限公司 尺寸：53.7*28.7 mm±0.2 mm, R3.5, C2 Archer BE700(US)_1.0产品规格标贴 A1 Archer BE700(US)_1.0 Pantone 877C 黑色 Pantone 877C 张乐怡 2024-01-17 80g艾利铜版纸+雾膜 *尺寸按标贴框尺寸-1.3mm的标准制作 7202510084 Model: Archer BE700 BE15000 Tri-Band Wi-Fi 7 Router Power: 12V 3.3A Default Access: http://tplinkwifi.net JOIN PRESET WI-FI Model:Archer BE700(US) Ver:1.0 S/N:XXXXXXXXXXXXX MAC: XX-XX-XX-XX-XX-XX Wireless Password/PIN : XXXXXXXX SSID:TP-Link_XXXX SSID:TP-Link_XXXX_5G SSID:TP-Link_XXXX_6G FCC ID: 2BCGWBE700 IC: 31152-BE700 MADE IN CHINA Indoor use only This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 5.7 mm 28.2 mm

Report No.: 2401TW0112-UI 1 of 29 Internal Photograph (1) EUT Photo – Archer BE700 (2) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 2 of 29 (3) EUT Photo – Archer BE700 (4) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 3 of 29 (5) EUT Photo – Archer BE700 (6) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 4 of 29 (7) EUT Photo – Archer BE700 (8) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 5 of 29 (9) EUT Photo – Archer BE700 (10) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 6 of 29 (11) EUT Photo – Archer BE700 (12) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 7 of 29 (13) EUT Photo – Archer BE700 (14) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 8 of 29 (15) EUT Photo – Archer BE700 (16) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 9 of 29 (17) EUT Photo – Archer BE700 (18) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 10 of 29 (19) EUT Photo – Archer BE700 (20) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 11 of 29 (21) EUT Photo – Archer BE700 (22) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 12 of 29 (23) EUT Photo – Archer BE700 (24) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 13 of 29 (25) EUT Photo – Archer BE700 (26) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 14 of 29 (27) EUT Photo – Archer BE700 (28) EUT Photo – Archer BE700 Report No.: 2401TW0112-UI 15 of 29 (29) EUT Photo – Archer BE700 (30) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 16 of 29 (31) EUT Photo – Archer BE700 Pro (32) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 17 of 29 (33) EUT Photo – Archer BE700 Pro (34) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 18 of 29 (35) EUT Photo – Archer BE700 Pro (36) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 19 of 29 (37) EUT Photo – Archer BE700 Pro (38) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 20 of 29 (39) EUT Photo – Archer BE700 Pro (40) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 21 of 29 (41) EUT Photo – Archer BE700 Pro (42) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 22 of 29 (43) EUT Photo – Archer BE700 Pro (44) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 23 of 29 (45) EUT Photo – Archer BE700 Pro (46) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 24 of 29 (47) EUT Photo – Archer BE700 Pro (48) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 25 of 29 (49) EUT Photo – Archer BE700 Pro (50) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 26 of 29 (51) EUT Photo – Archer BE700 Pro (52) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 27 of 29 (53) EUT Photo – Archer BE700 Pro (54) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 28 of 29 (55) EUT Photo – Archer BE700 Pro (56) EUT Photo – Archer BE700 Pro Report No.: 2401TW0112-UI 29 of 29 (57) EUT Photo – Archer BE700 Pro (58) EUT Photo – Archer BE700 Pro

MRT Technology (Taiwan) Co., Ltd Report No.: 2401TW0112-U5 Phone: +886-3-3288388 Report Version 1.0 Web: www.mrt-cert.com Issue Date: 2024-03-07 Page Number: 1 of 13 RF Exposure Evaluation Declaration FCC ID : 2BCGWBE700 Applicant : TP-LINK CORPORATION PTE. LTD. Application Type : Certification Product : BE15000 Tri-Band Wi-Fi 7 Router BE11000 Tri-Band Wi-Fi 7 Router Model No. : Archer BE700 Series Model No. : Archer BE700 Pro, Archer BE11000 Pro Brand Name : tp-link FCC Classification : Digital Transmission System (DTS) Unlicensed National Information Infrastructure (NII) 15E 6GHz Low Power Indoor Access Point (6ID) 15E 6GHz Subordinate Indoor Device (6PP) Received Date : January 22, 2024 Test By : ( Owen Tsai ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2401TW0112-U5 Page Number: 2 of 13 Revision History Report No. Version Description Issue Date Note 2401TW0112-U5 1.0 Original Report 2024-03-07 Valid Report No.: 2401TW0112-U5 Page Number: 3 of 13 CONTENTS Description Page 1. INTRODUCTION .................................................................................................................... 5 1.1. Scope .......................................................................................................................... 5 1.2. MRT Test Location ...................................................................................................... 5 2. PRODUCT INFORMATION .................................................................................................... 6 2.1. Feature of Equipment under Test ................................................................................ 6 2.2. Description of Available Antennas ............................................................................... 6 2.3. Device Classification ................................................................................................... 8 2.4. Applied Standards ....................................................................................................... 8 3. RF Exposure Evaluation ...................................................................................................... 9 3.1. Limits........................................................................................................................... 9 3.2. MPE Exemptions ........................................................................................................10 3.3. Test Result of RF Exposure Evaluation ......................................................................13 Report No.: 2401TW0112-U5 Page Number: 4 of 13 General Information Applicant TP-LINK CORPORATION PTE. LTD. Applicant Address 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Manufacturer TP-LINK CORPORATION PTE. LTD. Manufacturer Address 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Test Site MRT Technology (Taiwan) Co., Ltd Test Site Address No. 38, Fuxing Second Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C) MRT FCC Registration No. 291082 Test Facility / Accreditations 1. MRT facility is a FCC registered (Reg. No. 291082) test facility with the site description report on file and is designated by the FCC as an Accredited Test Firm. 2. MRT facility is an IC registered (MRT Reg. No. 21723) test laboratory with the site description on file at Industry Canada. 3. MRT Lab is accredited to ISO 17025 by the Taiwan Accreditation Foundation (TAF Cert. No. 3261) in EMC, Telecommunications and Radio testing for FCC (Designation Number: TW3261), Industry Canada, EU and TELEC Rules. Report No.: 2401TW0112-U5 Page Number: 5 of 13 1. INTRODUCTION 1.1. Scope Measurement and determination of electromagnetic emissions (EMC) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission and the Innovation, Science and Economic Development Canada and Certification and Engineering Bureau. 1.2. MRT Test Location The map below shows the location of the MRT LABORATORY, its proximity to the Taoyuan City. These measurement tests were conducted at the MRT Technology (Taiwan) Co., Ltd. Facility located at No.38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 33377, Taiwan (R.O.C). Report No.: 2401TW0112-U5 Page Number: 6 of 13 2. PRODUCT INFORMATION 2.1. Feature of Equipment under Test Note 1: The only difference between the models is in the design of the RJ45 port. Other designs (including hardware and software) are the same. Archer BE700 with 1Gbps ports and Archer BE700 Pro and Archer BE11000 Pro with 10G bps port. Archer BE700 was selected for final tests in this report. Note 2: Archer BE11000 has the different model and product name from Archer BE700 Pro, others are exactly the same. 2.2. Description of Available Antennas Antenna Type Frequency Band (MHz) T X Paths Number of spatial streams Antenna Gain (dBi) Beamforming Directional Gain(dBi) CDD Directional Gain (dBi) Ant 0 Ant 1 For Power For PSD Wi-Fi 2.4G/5G Dipole 2412 ~ 2462 2 1 2.79 2.36 5.80 2.79 5.80 5150 ~ 5350 2 1 2.56 1.67 5.57 2.56 5.57 5470 ~ 5725 2 1 2.99 1.76 6.00 2.99 6.00 5725 ~ 5850 2 1 1.86 1.98 4.99 1.98 4.99 Remark: 1. The EUT supports Cyclic Delay Diversity (CDD) mode, and CDD signals are correlated. If all antennas have the same gain, G ANT , Directional gain = G ANT + Array Gain, where Array Gain is as follows. • For power spectral density (PSD) measurements on all devices, Product Name: BE15000 Tri-Band Wi-Fi 7 Router BE11000 Tri-Band Wi-Fi 7 Router Model No.: Archer BE700 Series Model No. Archer BE700 Pro, Archer BE11000 Pro Brand Name: tp…

Text truncated - open the document above for the full version.

Report No.: 2401TW0112-U2 Page Number: 40 of 221 802.11ax-HE20 AVGPSD – Ant 1 – CDD Mode Channel 01 (2412MHz) Channel 06 (2437MHz) Channel 11 (2462MHz) 802.11ax-HE40 AVGPSD – Ant 1 – CDD Mode Channel 03 (2422MHz) Channel 06 (2437MHz) Channel 09 (2452MHz) Report No.: 2401TW0112-U2 Page Number: 41 of 221 802.11be-EHT20 AVGPSD – Ant 1 – CDD Mode Channel 01 (2412MHz) Channel 06 (2437MHz) Channel 11 (2462MHz) 802.11be-EHT40 AVGPSD – Ant 1 – CDD Mode Channel 03 (2422MHz) Channel 06 (2437MHz) Channel 09 (2452MHz) Report No.: 2401TW0112-U2 Page Number: 42 of 221 7.5. Conducted Band Edge and Out-of-Band Emissions 7.5.1.Test Limit The limit for out-of-band spurious emissions at the band edge is 30dB below the fundamental emission level, as determined from the in-band power measurement of the DTS channel performed in a 100 kHz bandwidth per the PSD procedure. 7.5.2.Tes…
