2BCGWH500Smart HomeBase

*Images may differ from your actual product. ©2024 TP-Link 7106511055 REV1.0.0 Install an extra HDD/SSD drive (2.5“) to expand local storage. Install Hard Drive Connect HomeBase to Network Set Up HomeBase Build Your Smart Home Overview Smart HomeBase Tapo H500 Quick Start Guide Install Your Hard Drive to Expand Local Storage Connect the HomeBase to your router or switch using the Ethernet cable provided, and then connect the HomeBase to a power outlet using the provided power adapter. Connect the HomeBase to Home Network 1. Push down the cover to remove it. The sign shows the place where you should press. 3. Put in your hard drive and secure it with the provided screws. 4. Insert the bracket back into the HomeBase. Secure it with the screw. 5. Replace the cover. 2. Loosen the screw and pull out the hard drive bracket. The HomeBase must be powered off when you install or remove a hard drive. Option 1: Wired Connection (Ethernet) You can connect your HomeBase to a 5 GHz Wi-Fi network. After connecting the HomeBase to a power outlet, refer to the Set Up the HomeBasesection to connect your HomeBase to Wi-Fi. Option 2: Wireless Connection Note: Initialize the hard drive in the Tapo app. 1. Get the Tapo app from the App Store or Google Play. 2. Tap the button in the app and select Hubs. Follow app instructions to complete setup. You can also connect it to a 5 GHz Wi-Fi network. OR Set Up the HomeBaseBuild Your Smart Home Build your smart home ecosystem by adding smart sensors, buttons, switches, cameras or doorbells to the Homebase. Smart sensors Doorbells Cameras Light switches (Sub-1G) Smart buttons Compatibility: Check compatible accessories at https://www.tp-link.com/tapo-h500/product-list/ For technical support, the user guide, warranty, and more, please scan the QR code or visit https://www.tapo.com/support/. Contents Overview Front Back 1 Type-C Port 2 USB 2.0 Port 5V/1.5A type-C port for charging your connected devices (e.g., cameras) or providing continuous power supply to your Pad. This port can not transfer any data. Export data to another device. 3 HDMI Port Output port for high-definition audio and video signals. You can connect it to a TV or monitor to project camera videos. Connect to a router or a switch using an Ethernet cable. 4 LAN Port 5 RESET Use a pin to press and hold for at least 5 seconds until the LED quickly blinks red to reset the hub. 7 Speaker 6 Power Port 9 Answer/SYNC Button 10 Decline/Mute Button Decline the video call, or silence the doorbell alarm. Switch to the previous or next channel when using HDMI output. 11 911 Volume Button Volume up or down. 13 Status LED 12 Pad Holder Easily place your pad here. 14 LAN LED 15 Disk LED Press once: Answer the video call. Long press: Enter pairing mode. 8 Microphone • Do not use damaged charger or USB cable to charge the device. • Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us. • Do not use any other chargers than those recommended. • Do not use the device where wireless devices are not allowed. • Adapter shall be easily accessible. • Use only power supplies which are provided by manufacturer and in the original packing of this product. If you have any questions, please don't hesitate to contact us. • Keep the device away from water, fire, humidity or hot environments. • Do not place near automatically controlled devices such as fire alarms. Radio waves emitted from this product may cause such devices to malfunction resulting in an accident. • Observe restrictions on using wireless products in fuel depots, chemical plants or when blasting operations are in progress. • Never put metal objects inside the product. If a metal object enters the product turn off the circuit breaker and contact an authorised electrician. • This product is not intended to be used when providing medical care. Consult the manufacturer of any personal medical devices, such as pacemakers or hearing aids to determine if they are adequality shielded from external RF (radio frequency) energy. • Do not use this product in health care facilities. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy. • When you leave the product unused for a long time unplug the product from the power outlet. • This product may interfere with other electronic products such as TV, radios, personal computers, phones or other wireless devices. Operating Temperature: 0 °C ~ 40°C (32°F ~ 104°F) Please read and follow the above safety information when operating the device. We cannot guarantee that no accidents or damage will occur due to improper use of the device. Please use this product with care and operate at your own risk. Safety Information Status LED Indications Blinking red and green Blinking red quickly Solid red Blinking green quickly Off Starting up Connecting to Wi-Fi Hub resetting Hub updating; Hub powered off Blinking red slowlyReady for setup Blinking green slowly Connected to Wi-Fi (Wireless) Connected to router (Ethernet) Pairing with Tapo accessory Solid greenConnected to the cloud Ethernet network is working properly. LAN LED Indications On OffEthernet cable not connected. CAUTION! Avoid replacement of a battery with an incorrect type that can defeat a safeguard. Avoid disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion. Do not leave a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas. Do not leave a battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas. a) Remove and immediately recycle or dispose of used batteries according to local regulations and keep away from children. Do NOT dispose of batteries in household trash or incinerate. b) Even used batteries may cause severe injury or death. c) Call a local poison control cen…

Text truncated - open the document above for the full version.

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO:AmericanCertificationBody,Inc. 313ParkAvenue Suite300 FallsChurch, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name:VISHTEC LLC Contact Name:Alan Graham Street Address:9888 W Belleview Ave Ste 2142 Denver CO 80123 City/Province/Zip:80123 Telephone No:（571）4007350 Email:[email protected] FRN #: 0033407131 This letter is to confirm that we (“the Designated U.S. Agent”) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process for the limited purpose of compliance with section 47 CFR 2.911(d)(7) only and not for any other purpose, on behalf of theApplicantnoted below. U.S. Agent Signature: Date:2023/8/28 Signed by (Printed Name/Title): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: TP-LINK CORPORATION PTE. LTD. Grantee Code: 2BCGW FRN #: 0034122556 Contact Name: Sarah Wang Street Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 City/Province/Zip: Singapore Telephone No: +65-97538388 Email: [email protected] Applicant Signature 1 : Date: 2023/8/28 Signed by (Printed Name/Title) S arah W ang 1 - Lettersshouldbeplacedonappropriateletterhead.

TP-LINK CORPORATION PTE.LTD. CERTIFICATIONS CONCERNING “COVERED” EQUIPMENT Date:2024-09-14 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2BCGWH500 To Whom It May Concern: As required by section 2.911(d)(5)(i), [TP-LINK CORPORATION PTE.LTD.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. As required by section 2.911(d)(5)(ii), [TP-LINK CORPORATION PTE.LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Thank you for your attention to this matter. Sincerely yours, Signature Printed Name: Sarah Wang Company: TP-LINK CORPORATION PTE.LTD. Job Title: Regulatory Compliance Manager Email: [email protected] Telephone: 00852-37585503

TP-LINK CORPORATION PTE.LTD. 030122-15 Authority to Act as Agent Date: September 18, 2024 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: BTL Inc./Rose Liu is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: 2025-09-14 By: __________________________ Sarah Wang (Signature 1 ) (Print name) Title: Regulatory Compliance Manager On behalf of: TP-LINK CORPORATION PTE.LTD. (Company Name) Telephone: 00852-37585503 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-LINK CORPORATION PTE.LTD. 030122-15 Request for Confidentiality Date: September 18, 2024 Subject: Confidentiality Request for: 2BCGWH500 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term ☐ Permanent * 3 User’s Manual TP-LINK CORPORATION PTE.LTD. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Regulatory Compliance Manager Sarah Wang (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Declaration of Conformity We Name: TP-LINK CORPORATION PTE.LTD. Address: 7 Temasek Boulevard #29-03, Suntec Tower One, Singapore 038987 Declare that: Product: Smart HomeBase FCC ID: 2BCGWH500 Model: Tapo H500 Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2024-09-14

Declaration of Frequency Stability Date: 2024-09-14 We TP-LINK CORPORATION PTE.LTD. ensure that the product (FCC ID: 2BCGWH500 IC: 31152-H500) meets e-CFR Title 47 section 15.407(g) & RSS GEN Section 8.11 and KDB 789033 D02v02r01 frequency stability such that the emissions are maintained within the band of operation under all conditions of normal operation as specified in the user's manual. Name: Sarah Wang Position: Regulatory Compliance Manager TP-LINK CORPORATION PTE.LTD.

Non-SDR (Software Defined Radio) Cover Letter Date: 2024-09-14 Refer to KDB 442812 D01 SDR apps Guide v02r03. The following six questions can be used for determining if a radio can elect to be, or must be an SDR. 1. Can the RF parameters of the device be altered through software? □Yes - go to 2. No, not an SDR 2. Can third parties not permitted by the Commission through specific filings modify, configure, or load different software, or make configuration settings to operate the device or host hardware radio frequency parameters (frequency range, modulation type, maximum output power or other radio parameters) in any other way than granted (or expected to be granted)? □Yes, must be an SDR. □No - go to 3. 3. Is the device capable of operating in any other way than granted, or will be, granted? □Yes, - go to 4. □No - go to 5. 4. Is this a Part 15 client Device as defined in Section 15.202 (as opposed to a master device)? □Yes, qualifies as a part 15 client devices - go to 5. □No, must be an SDR. 5. Does the manufacturer elect SDR? □Yes, elects to be an SDR. □No, Not an SDR Final conclusion: According to the above questions reply, we can confirm this Smart HomeBase (FCC ID: 2BCGWH500) must be a Non-SDR. Name: Sarah Wang Position: Regulatory Compliance Manager TP-LINK CORPORATION PTE. LTD.

Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 1 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 2 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 3 of 19 Project No.: 2404G123

尺寸图来料效果图 备注： 1）S/N码由工厂打印在20*5(7210500365)的空白标贴上贴于标贴指定位置。 2）图示条码均为示意，具体请以生产实际为准。 标贴尺寸：45*26mm ±0.2；R1,C2 7202510262 卷装供货 跳距：3mm 边距：3mm Model: Tapo H500 26 45 TP-LINK CORPORATION PTE. LTD. 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Power: 12V 2A FCC ID: 2BCGWH500 IC: 31152-H500 MAC: XX-XX-XX-XX-XX-XX S/N:XXXXXXXXXXXXX EU/1.0 Smart HomeBase

Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 4 of 19 Project No.: 2404G123 WIFI Ant. 1 WIFI Ant. 2 Sub 1G (915MHz) Ant. Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 5 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 6 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 7 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 8 of 19 Project No.: 2404G123

Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 9 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 10 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 11 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 12 of 19 Project No.: 2404G123

Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 13 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 14 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 15 of 19 Project No.: 2404G123

Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 16 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 17 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 18 of 19 Project No.: 2404G123 Appendix No.: EP-2404G123-1 APPENDIX-EUT PHOTOS Page 19 of 19 Project No.: 2404G123

Report No.: BTL-FCCP-5-2404G123 Page 1 of 5 Report Version: R00 Project No.: 2404G123 FCC Radio Test Report FCC ID: 2BCGWH500 Report No. : BTL-FCCP-5-2404G123 Equipment : Smart HomeBase Model Name : Tapo H500 Brand Name : tp-link, tapo Applicant : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Radio Function : WLAN 2.4 GHz, RLAN 5 GHz (U-NII 1, U-NII 2A, U-NII 2C, U-NII 3), SRD (908 - 922MHz) FCC Rule Part(s) : FCC Guidelines for Human Exposure IEEE C95.1 & KDB 447498 D04 Date of Receipt : 2024/5/31 Date of Test : 2024/6/4 ~ 2024/6/26 Issued Date : 2024/9/14 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Poken Huang, Engineer Approved by : Peter Chen, Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-5-2404G123 Page 2 of 5 Report Version: R00 Project No.: 2404G123 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-5-2404G123 R00 Original Report. 2024/9/14 Valid Report No.: BTL-FCCP-5-2404G123 Page 3 of 5 Report Version: R00 Project No.: 2404G123 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 2. ANTENNA SPECIFICATION Antenna Specification: For 2.4GHz: Ant. Brand Name P/N Type Connector Gain (dBi) 1 TP-LINK CORPORATION PTE. LTD. 3101506738 Dipole N/A 2.00 2 TP-LINK CORPORATION PTE. LTD. 3101506739 Dipole N/A 2.00 NOTE: 1) The EUT incorporates a CDD function. Physically, the EUT provides two completed transmitters and receivers (2T2R). For Output Power For N ANT = 2 < 4, Direction gain = G ANT + 0 = 2.00 + 0 = 2.00 dBi. The Direction gain is less than 6 dBi, so output power limits will not be reduced. 2) The above Antenna information are derived from the antenna data sheet provided by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. For 5GHz: Ant. Brand Name P/N Type Connector Gain (dBi) 1 TP-LINK CORPORATION PTE. LTD. 3101506738 Dipole N/A 3.00 2 TP-LINK CORPORATION PTE. LTD. 3101506739 Dipole N/A 3.00 Note: 1) This EUT supports CDD, and all antennas have the same gain, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=3.00dB (N ANT ≤4), so the Directional gain=3.00. For power spectral density measurements, N ANT =4, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=3.00+10log(2/1)dBi=6.01. Then, the UNII-1 power spectral density limit is 17-(6.01-6)=16.99. the UNII-2A, UNII-2C power spectral density limit is 11-(6.01-6)=10.99, the UNII-3 power spectral density limit is 30-(6.01-6)=29.99. 2) Beamforming Gain: 3.00dB, so the Directional gain=3.00+3.00=6.00dB. 3) The above Antenna information are derived from the antenna data sheet provided by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. Report No.: BTL-FCCP-5-2404G123 Page 4 of 5 Report Version: R00 Project No.: 2404G123 For Sub 1G: Ant. Brand Name P/N Type Connector Gain (dBi) 1 TP-LINK CORPORATION PTE. LTD. 3101506737 Dipole N/A -6.10 Note: 1) The above Antenna information are derived from the antenna data sheet provided by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. 3. TABLE FOR ANTENNA CONFIGURATION For 2.4GHz: Operating Mode TX Mode 2TX IEEE 802.11b V (Ant. 1+Ant. 2) IEEE 802.11g V (Ant. 1+Ant. 2) IEEE 802.11n (HT20) V (Ant. 1+Ant. 2) IEEE 802.11n (HT40) V (Ant. 1+Ant. 2) For 5GHz Non Beamforming: Operating Mode TX Mode 2TX IEEE 802.11a V (Ant. 1+Ant. 2) IEEE 802.11ac (VHT20) V (Ant. 1+Ant. 2) IEEE 802.11ac (VHT40) V (Ant. 1+Ant. 2) IEEE 802.11ac (VHT80) V (Ant. 1+Ant. 2) For 5GHz Beamforming: Operating Mode TX Mode 2TX IEEE 802.11ac (VHT20) V (Ant. 1+Ant. 2) IEEE 802.11ac (VHT40) V (Ant. 1+Ant. 2) IEEE 802.11ac (VHT80) V (Ant. 1+Ant. 2) Report No.: BTL-FCCP-5-2404G123 Page 5 of 5 Report Version: R00 Project No.: 2404G123 4. CALCULATED RESULT For 2.4GHz: Direction Gain (dBi) Direction Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.00 1.5849 29.03 799.8343 0.25232 1 Complies For 5GHz Non Beamforming: Direction Gain (dBi) Direction Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 3.00 1.9953 23.97 249.4595 0.09907 1 Complies For 5GHz Beamforming: Direction Gain (dBi) Direction Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 6.00 3.9811 23.47 222.3310 0.17618 1 Complies For Sub 1G: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result -6.10 0.2455 15.21 33.1894 0.00162 1 Complies For the max simultaneous transmission MPE: Ratio Total Limit of Ratio Test Result Sub 1G 2.4GHz 5GHz 0.00162 0.25232 0.17618 0.43012 1 Complies Note: The calculated distance is 20 cm. Output power including tune up tolerance. End of Test Report

Product Model： Tapo H500 Manufacturer： TP-LINK CORPORATION PTE. LTD. Test Date： 2024.04.26 Tested By： Yin shufen TP-LINK CORPORATION PTE. LTD. 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Index 1. Antenna Distribution ........................................................................................ 3 2. Electrical Characteristics ................................................................................ 3 3. Gain and Radiation Pattern ............................................................................. 5 3.1 Measurement Procedure ........................................................................................... 5 3.2 Test Setup ................................................................................................................. 6 3.3 S Parameter Test Data ............................................................................................. 7 3.4 Antenna Peak Gain ................................................................................................... 8 3.5 Antenna Radiation Pattern ........................................................................................ 9 Page 3 1. Antenna Distribution Tapo H500 2. Electrical Characteristics Ant1 Frequency 863 ~ 923MHz Impedance 50Ohm Antenna Type Dipole Antenna Gain -6.10dBi@863~923MHz Radiation pattern Omni-Directional P/N 3101506737 Ant2 Frequency 2400 ~ 2500&5150~5895MHz Impedance 50Ohm Antenna Type Dipole Antenna Gain 2.00dBi@2400~2500MHz 3.00dBi@5150~5250MHz 3.00dBi@5250~5350MHz 3.00dBi@5470~5725MHz 3.00dBi@5725~5895MHz Radiation pattern Omni-Directional P/N 3101506738 Ant3 Page 4 Frequency 2400 ~ 2500&5150~5895MHz Impedance 50Ohm Antenna Type Dipole Antenna Gain 2.00dBi@2400~2500MHz 3.00dBi@5150~5250MHz 3.00dBi@5250~5350MHz 3.00dBi@5470~5725MHz 3.00dBi@5725~5895MHz Radiation pattern Omni-Directional P/N 3101506739 Page 5 3. Gain and Radiation Pattern 3.1 Measurement Procedure This measurement experiment adopted an antenna near-field measurement system, and the diagram of the measurement system was shown in Figure 3-1. The excitation signal was generated by the Keysight E5071C (300kHz-20GHz). Under the control of the central computer, the probe rotated in the θ direction, and the EUT rotated in the φ direction with the turntable. The probe sampling frame received and collected signals in the near-field range of the EUT. The software system which was controlled by the central computer completed the processing, output and display of the test data. Figure 3-1 The test site was a full anechoic chamber with a size of 3.0m×3.1m×2.97m, which was built by GTS Rayzone2800. All six surfaces of the anechoic chamber were pasted with absorbing materials. And the chamber was calibrated by the authoritative third-party lab every year. The antenna anechoic chamber measurement system adopted a 13-probe multi-probe system. The probe antennas were evenly distributed on the spherical surface surrounding the EUT, and theirs operating frequency was 600MHz~8.5GHz. During the measurement, the probe antennas were rotated in the θ direction under the control of the probe holder to sample the near-field data at the θ angle. At the same time, the EUT rotated with the turntable in the φ direction to sample the near field data at the φ angle. The sampling accuracy was 15°. The system diagram was shown in Figure 3-2. From the sampling results, the EUT's near-field test data of θ component, φ component and total component could be obtained. Page 6 Figure 3-2 Before the measurement, calibrated the vector network analyzer, and then connected the input end of each antenna to the output end of the vector network analyzer, and evenly the antennas to be measured. Test Equipment listed below: Equipments Model ManufacturerS/N Cali. Interval Cali. Due Date Chamber Rayzone2800 GTS(General Test System) MY5347043 5 12months 2024/06/15 Vector Network Analyzer E5071C Keysight MY46315238 24months 2024/06/13 GTS MaxSign100 Software V2.1 GTS(General Test System) / / / 3.2 Test Setup The test setup was shown in Figure 3-3, 3-4: Figure 3-3 Page 7 Figure 3-4 3.3 S Parameter Test Data Ant1 Ant2 Page 8 Ant3 3.4 Antenna Peak Gain Frequency(GHz) 0.863 0.923 Ant1 MaxGain(dBi) -6.10 -6.25 Ant1 Polarization/Φ (°)/θ(°) Theta/345/75 Theta/225/75 Max Gain(dBi) -6.10 -6.25 Frequency(GHz) 2.45 5.2 5.3 5.6 Ant2 MaxGain(dBi) 2.00 2.88 2.62 3.00 Ant3 MaxGain(dBi) 2.00 2.93 3.00 2.90 Ant2 Polarization/Φ (°)/θ(°) Phi/195/45 Phi/270/30 Phi/270/30 Phi/255/30 Page 9 Ant3 Polarization/Φ (°)/θ(°) Theta/75/75 Theta/15/90 Theta/30/90 Theta/30/75 Max Gain(dBi) 2.00 2.93 3.00 3.00 Frequency(GHz) 5.8 Ant2 MaxGain(dBi) 3.00 Ant3 MaxGain(dBi) 3.00 Ant2 Polarization/Φ (°)/θ(°) Phi/270/30 Ant3 Polarization/Φ (°)/θ(°) Theta/30/90 Max Gain(dBi) 3.00 3.5 Antenna Radiation Pattern Ant1 Ant2 Ant3 Page 10

Report No.: BTL-FCCP-2-2404G123 Project No.: 2404G123 Page 1 of 222 Report Version: R01 FCC Radio Test Report FCC ID: 2BCGWH500 Report No. : BTL-FCCP-2-2404G123 Equipment : Smart HomeBase Model Name : Tapo H500 Brand Name : tp-link, tapo Applicant : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Radio Function : RLAN 5 GHz (U-NII 1, U-NII 2A, U-NII 2C, U-NII 3) FCC Rule Part(s) : FCC CFR Title 47, Part 15, Subpart E (15.407) Measurement Procedure(s) : ANSI C63.10-2013 Date of Receipt : 2024/5/31 Date of Test : 2024/6/4 ~ 2024/6/26 Issued Date : 2024/9/26 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Poken Huang, Engineer Approved by : Peter Chen, Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-2-2404G123 Project No.: 2404G123 Page 2 of 222 Report Version: R01 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the Customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities l…
