2BCGWBS1200Smart Wi-Fi Light Switch

Quick Start Guide 7106511303 REV1.0.0 *Images may differ from actual products. Wiring guide: Scan QR code or visit https://www.tp-link.com/support/faq/3999/ Smart Wi-Fi Light Switch Wiring Diagram Wire Your Switch Turn off the circuit breaker. Remove the wallplate of the old switch in one of your 3-way wall boxes and pull the switch out. 1 Get to know the wires. 2 1/ Pull Out the Old Switch & Get to Know the Wires OFF 2/ Identify the Line Wire and Other Wires Turn on the circuit breaker and turn off the switch. Put the voltage detector on the terminal screw of the Line/Load wire. The energized wire is the Line wire. The switch in this wall box will be the one to be replaced with Tapo smart switch. 1 Turn off the circuit breaker. Label the Ground, Neutral, Traveler, and Line wires. 2 Line wireLoad wire 3/ Remove Old Switch and Connect the Wires 4/ Install the Smart Switch For scenarios where 1 light is controlled by 1switch. You can connect the Load wire to either Traveler terminal on your Tapo smart switch. Option 1: Single Pole Connection Connect the smart switch to your 3-way circuit together with your existing traditional 3-way switch. Option 2: 3-Way Connection Neutral Ground Line Load Neutral Traveler Ground Line Load Connect the smart switch to your 4-way circuit together with your existing traditional 4-way and 3-way switches. Option 3: 4-Way Connection Neutral Ground Line Traveler Traveler Traveler Load Disconnect wires from the old switch and connect them to the smart switch as below. No need to distinguish between the two Traveler wires. Before You Start Tools You’ll Need • Electrical Detector • Philips or Slotted Screwdriver • Pliers • Electrical Insulated Gloves (Recommended) CAUTION ! 1. Risk of Electric Shock - The product should be installed by a qualified electrician. 2. High Voltage - Disconnect power supply at the circuit breaker before servicing. MISE EN GARDE - Haute tension : débranchez l'alimentation électrique au niveau du disjoncteur avant l'utiliser. 3. Use copper conductors only. Do Not use two Tapo smart switches together for 3-way or 4-way connection. You can always find detailed wiring instructions in the Tapo app. Line up the switch with the mounting holes. Secure it with screws. 1 Ensure the UP arrow on the back of the wallplate points up and attach the wallplate. Then turn on the circuit breaker 2 Your dumb switches might look like this. Two Traveler wires (Opposite each other with the same color screws.) Line/Load wire (Black. Line and Load wires are in different boxes.) Line (Live/Hot): Usually black. One end is connected to the circuit breaker, the other to your FIRST 3-Way switch. Load: Usually black. One end is connected to the light fixture, the other to your SECOND 3-Way switch. Travelers: Usually one is black and the other is red. The two terminals are opposite each other with the same color screws. Neutral: Usually a bundle of white wires and not connected to the dumb switch. They may be folded up in the very back. Ground: Usually green or copper. The wire colors used in this guide are recommended by the National Electric Code (NEC). Your actual wire colors may vary. To Next Wall Box Power Source For single-pole connection, connect the Load wire to either Traveler terminal on your Tapo smart switch. The other Traveler terminal will be left unuse. Buttons & LEDAppearance Buttons Press to turn on / off your switch. Restart Reset Switch Button Press and hold for about 5 seconds to reset Wi-Fi while keeping previous settings. Press to restart your switch. Press and hold for about 10 seconds to restore your switch to factory default settings. Starting up; Disconnected form the cloud Solid amber Blinking amber Blinking green Solid red Solid green for 30s Blinking amber & green Connecting to Wi-Fi Ready for setup Device resetting Solid white The switch is off. LED is on to indicate the switch location in the dark. Disconnected from Wi-Fi Connected to Wi-Fi LED Switch Button Restart LED Reset Blinking green slowly Firmware upgrading Download Tapo App Set Up Get the Tapo app from the App Store or Google Play. Detach the wallplate with force, and you’ll see the Matter numeric code. Your can find another Matter setup code label in the package and stick it anywhere you like as needed for Matter setup. Matter Setup Code Matter Numeric Code Third-Party Services If you set up the switch via Tapo, you can link Tapo to Alexa, Google Assistant, and other third-party services to for voice control. Go to Me > Third-Party Services in the Tapo app to integrate third-party services. For step-by-step setup instructions, please visit: • Google Home Assistant: https://www.tp-link.com/support/faq/2779/ • Amazon Alexa: https://www.tp-link.com/support/faq/2780/ Why Adding to Tapo? You can add the smart switch to other eco-systems through the Matter setup code. But Tapo can offer more than others. 1. Energy Monitoring. Track the energy usage and estimate the energy bills. Currently, this feature is only available in the Tapo app. 2. Latest firmware update. Third-party apps may not provide timely device firmware updates. 3. Detailed wiring guide and troubleshooting. Tapo provides step-by-step wiring instructions. Tap the button in the Tapo app. Select Switches/Buttons and then your model. Then follow the app instructions to set up your smart switch. Setup via Tapo Open your preferred smart home app and add the device via the Matter setup code on the device or in the package. Setup via Matter My Home OR Specifications Rating: 100-120 V~ 50/60 Hz Load: 15 A General Use, 600 W Incandescent Operation temperature: 0~40 °C Method of mounting included: Independently mounted (Vertically position only); Operating control, Type 1.C action Pollution Degree 2, Rated Impulse Voltage 2500 V Software Class A, NEMA Type 1 Safety Notice Before installing, servicing or removing the switch, read and follow all safety precautions including the following: • CAUTION – Risk of Electric Shock – More t…

Text truncated - open the document above for the full version.

TP-LINK CORPORATION PTE.LTD. CERTIFICATIONS CONCERNING “COVERED” EQUIPMENT Date: 2024-08-15 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2BCGWBS1200 To Whom It May Concern: As required by section 2.911(d)(5)(i), [TP-LINK CORPORATION PTE.LTD.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. As required by section 2.911(d)(5)(ii), [TP-LINK CORPORATION PTE.LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Thank you for your attention to this matter. Sincerely yours, Signature Printed Name: Sarah Wang Company: TP-LINK CORPORATION PTE.LTD. Job Title: Regulatory Compliance Manager Email: [email protected] Telephone: +86 755 21534921

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO:AmericanCertificationBody,Inc. 313ParkAvenue Suite300 FallsChurch, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name:VISHTEC LLC Contact Name:Alan Graham Street Address:9888 W Belleview Ave Ste 2142 Denver CO 80123 City/Province/Zip:80123 Telephone No:（571）4007350 Email:[email protected] FRN #: 0033407131 This letter is to confirm that we (“the Designated U.S. Agent”) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process for the limited purpose of compliance with section 47 CFR 2.911(d)(7) only and not for any other purpose, on behalf of theApplicantnoted below. U.S. Agent Signature: Date:2023/8/28 Signed by (Printed Name/Title): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: TP-LINK CORPORATION PTE. LTD. Grantee Code: 2BCGW FRN #: 0034122556 Contact Name: Sarah Wang Street Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 City/Province/Zip: Singapore Telephone No: +65-97538388 Email: [email protected] Applicant Signature 1 : Date: 2023/8/28 Signed by (Printed Name/Title) S arah W ang 1 - Lettersshouldbeplacedonappropriateletterhead.

TP-LINK CORPORATION PTE.LTD. 030122-15 Authority to Act as Agent Date: August 15, 2024 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: BTL Inc./Rose Liu is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: 2025-08-15 By: __________________________ Sarah Wang (Signature 1 ) (Print name) Title: Regulatory Compliance Manager On behalf of: TP-LINK CORPORATION PTE.LTD. (Company Name) Telephone: +86 755 21534921 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-LINK CORPORATION PTE.LTD. 030122-15 Request for Confidentiality Date: August 15, 2024 Subject: Confidentiality Request for: 2BCGWBS1200 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term ☐ Permanent * 3 User’s Manual TP-LINK CORPORATION PTE.LTD. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Regulatory Compliance Manager Sarah Wang (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-LINK CORPORATION PTE.LTD. Wi-Fi Channel 12 and 13 Declaration Letter Date: 2024-08-15 We, the undersigned company Company Name: TP-LINK CORPORATION PTE. LTD. Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Declare that: Product description: Smart Wi-Fi Light Switch Type designation: BS1200 Brand: tp-link FCC ID: 2BCGWBS1200 Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: Sarah Wang Tel: +86 755 21534921 Email: [email protected]

Declaration of Conformity We Name: TP-LINK CORPORATION PTE.LTD. Address: 7 Temasek Boulevard #29-03, Suntec Tower One, Singapore 038987 Declare that: Product: Smart Wi-Fi Light Switch FCC ID: 2BCGWBS1200 Model: BS1200 Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2024-08-15

Project No.: 2404G013 Page 2 of 5

29.5 54.5 R3.5 C2 标贴尺寸：29.5*54.5mm ±0.2 实际粘贴效果图 注：序列号和产地由工厂直接打印在锡标上 （以上条码仅为示意）。 S/N:XXXXXXXXXXXXX US/1.6 MADE IN VIETNAMVN1 Rating: 100-120 V~ 50/60 Hz 15 A General Use 600 W Incandescent FCC ID: 2BCGWBS1200 UL1.0 Model: BS1200 Smart Wi-Fi Light Switch Use Copper Wires Only see installation instructions Label Location

Project No.: 2404G013 Page 3 of 5 Project No.: 2404G013 Page 4 of 5 Antenna Project No.: 2404G013 Page 5 of 5

Report No.: BTL-FCCP-3-2404G013 Page 1 of 4 FCC RF EXPOSURE REPORT FCC ID: 2BCGWBS1200 Project No. : 2404G013 Equipment : Smart Wi-Fi Light Switch Brand Name : tp-link Test Model : BS1200 Series Model : N/A Applicant : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Manufacturer : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Date of Receipt : Apr. 03, 2024 Date of Test : Apr. 06, 2024 ~ May 09, 2024 Issued Date : Aug. 16, 2024 Report Version : R00 Test Sample : Engineering Sample No.: SSL2024040320 for WiFi 2.4G, SSL2024040317 for LE. Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 & KDB 447498 D01 v06 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Nick Chen Approved by : Chay Cai Room 108, Building 2, No.1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong, People’s Republic of China Te l : + 8 6-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-3-2404G013 Page 2 of 4 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-3-2404G013 R00 Original Report. Aug. 16, 2024 Valid Report No.: BTL-FCCP-3-2404G013 Page 3 of 4 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 2. ANTENNA SPECIFICATION Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 TP-LINK CORPORATION PTE. LTD. 6035500141 PIFA N/A 3.18 Note: The antenna gain is provided by the manufacturer. Report No.: BTL-FCCP-3-2404G013 Page 4 of 4 3. CALCULATED RESULT For LE: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 3.18 2.0797 8.80 7.5858 0.00314 1 Complies For 2.4GHz: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 3.18 2.0797 20.65 116.1449 0.04808 1 Complies Note: The calculated distance is 20 cm. End of Test Report

Product Model： BS1200 Manufacturer： TP-LINK CORPORATION PTE. LTD. Test Date： 2023.12.19 Tested By： Xuan Shan TP-Link Corporation Limited Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Konga TEL: 00852-37585503 http://www.tp-link.com/en Index 1. Antenna Distribution ........................................................................................ 3 2. Electrical Characteristics ................................................................................ 3 3. Gain and Radiation Pattern ............................................................................. 3 3.1 Measurement Procedure ........................................................................................... 3 3.2 Test Setup ................................................................................................................. 5 3.3 S Parameter Test Data ............................................................................................. 6 3.4 Antenna Peak Gain ................................................................................................... 6 3.5 Antenna Radiation Pattern ........................................................................................ 6 Page 3 1. Antenna Distribution BS1200 2. Electrical Characteristics Ant1 Frequency 2400~2500MHz Impedance 50Ohm Antenna Type PIFA Antenna Gain 3.18dBi@2400~2500MHz Radiation pattern Omni-Directional tp-link P/N 6035500141 3. Gain and Radiation Pattern 3.1 Measurement Procedure This measurement experiment adopted an antenna near-field measurement system, and the diagram of the measurement system was shown in Figure 3-1. The excitation signal was generated by the Keysight E5071C (300kHz-20GHz). Under the control of the central computer, the probe rotated in the θ direction, and the EUT rotated in the φ direction with the turntable. The probe sampling frame received and collected signals in the near-field range of the EUT. The software system which was controlled by the central computer completed the processing, output and display of the test data. Page 4 Figure 3-1 The test site was a full anechoic chamber with a size of 3.0m×3.1m×2.97m, which was built by GTS Rayzone2800. All six surfaces of the anechoic chamber were pasted with absorbing materials. And the chamber was calibrated by the authoritative third-party lab every year. The antenna anechoic chamber measurement system adopted a 13-probe multi-probe system. The probe antennas were evenly distributed on the spherical surface surrounding the EUT, and theirs operating frequency was 600MHz~8.5GHz. During the measurement, the probe antennas were rotated in the θ direction under the control of the probe holder to sample the near-field data at the θ angle. At the same time, the EUT rotated with the turntable in the φ direction to sample the near field data at the φ angle. The sampling accuracy was 15°. The system diagram was shown in Figure 3-2. From the sampling results, the EUT's near-field test data of θ component, φ component and total component could be obtained. Figure 3-2 Before the measurement, calibrated the vector network analyzer, and then connected the input end of each antenna to the output end of the vector network analyzer, and evenly the antennas to be measured. Test Equipment listed below: Equipments Model Manufacturer S/N Cali. Interval Cali. Due Date Chamber Rayzone2800 GTS(General Test System) MY5347043 5 12months 2024/01/15 Vector Network Analyzer E5071C Keysight MY46315238 24months 2024/03/13 Page 5 GTS MaxSign100 Software V2.1 GTS(General Test System) / / / 3.2 Test Setup The test setup was shown in Figure 3-3, 3-4: Figure 3-3 Figure 3-4 Page 6 3.3 S Parameter Test Data Ant1 3.4 Antenna Peak Gain Frequency(GHz) 2.45 Ant1 MaxGain(dBi) 3.18 Ant1 Polarization/Φ (°)/θ(°) Linear/165/135 Max Gain(dBi) 3.18 3.5 Antenna Radiation Pattern Ant1 Page 7

Report No.: BTL-FCCP-1-2404G013 Page 1 of 60 FCC Radio Test Report FCC ID: 2BCGWBS1200 This report concerns: Original Grant Project No. : 2404G013 Equipment : Smart Wi-Fi Light Switch Brand Name : tp-link Test Model : BS1200 Series Model : N/A Applicant : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Manufacturer : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Date of Receipt : Apr. 03, 2024 Date of Test : Apr. 06, 2024 ~ May 09, 2024 Issued Date : Aug. 15, 2024 Report Version : R00 Test Sample : Engineering Sample No.: SSL2024040318 for radiated and AC Power Line Conducted Emissions, SSL2024040317 for conducted. Standard(s) : FCC CFR Title 47, Part 15, Subpart C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Nick Chen Approved by : Chay Cai Room 108, Building 2, No.1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong, People’s Republic of China Te l : + 8 6-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-1-2404G013 Page 2 of 60 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025: 2017 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-2404G013 Page 3 of 60 Table of Contents Page REPORT ISSUED HISTORY 6 1 . APPLICABLE STANDARDS 7 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 2.3 TEST ENVIRONMENT CONDITIONS 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 11 3.3 PARAMETERS OF TEST SOFTWARE 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 SUPPORT UNITS 12 3.6 CUSTOMER INFORMATION DESCRIPTION 12 4 . AC POWER LINE CONDUCTED EMISSIONS 13 4.1 LIMIT 13 4.2 TEST PROCEDURE 13 4.3 DEVIATION FROM TEST STANDARD 13 4.4 TEST SETUP 14 4.5 EUT OPERATING CONDITIONS 14 4.6 TEST RESULTS 14 5 . RADIATED EMISSIONS 15 5.1 LIMIT 15 5.2 TEST PROCEDURE 16 5.3 DEVIATION FROM TEST STANDARD 17 5.4 TEST SETUP 17 5.5 EUT OPERATING CONDITIONS 19 5.6 TEST RESULT - 9 KHZ TO 30 MHZ 19 5.7 TEST RESULT - 30 MHZ TO 1000 MHZ 19 5.8 TEST RESULT - ABOVE 1000 MHZ 19 6 . BANDWIDTH 20 6.1 LIMIT 20 6.2 TEST PROCEDURE 20 Report No.: BTL-FCCP-1-2404G013 Page 4 of 60 Table of Contents Page 6.3 DEVIATION FROM STANDARD 20 6.4 TEST SETUP 20 6.5 EUT OPERATION CONDITIONS 20 6.6 TEST RESULTS 20 7 . MAXIMUM OUTPUT POWER 21 7.1 LIMIT 21 7.2 TEST PROCEDURE 21 7.3 DEVIATION FROM STANDARD 21 7.4 TEST SETUP 21 7.5 EUT OPERATION CONDITIONS 21 7.6 TEST RESULTS 21 8 . CONDUCTED SPURIOUS EMISSION 22 8.1 LIMIT 22 8.2 TEST PROCEDURE 22 8.3 DEVIATION FROM STANDARD 22 8.4 TEST SETUP 22 8.5 EUT OPERATION CONDITIONS 22 8.6 TEST RESULTS 22 9 . POWER SPECTRAL DENSITY 23 9.1 LIMIT 23 9.2 TEST PROCEDURE 23 9.3 DEVIATION FROM STANDARD 23 9.4 TEST SETUP 23 9.5 EUT OPERATION CONDITIONS 23 9.6 TEST RESULTS 23 10 . MEASUREMENT INSTRUMENTS LIST 24 11 . EUT TEST PHOTO 26 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 32 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 35 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 40 APPENDIX D - RADIATED EMISSION - ABOVE 1000 MHZ 43 APPENDIX E - BANDWIDTH 52 Report No.: BTL-FCCP-1-2404G013 Page 5 of 60 Table of Contents Page APPENDIX F - MAXIMUM OUTPUT POWER 54 APPENDIX G - CONDUCTED SPURIOUS EMISSION 56 APPENDIX H - POWER SPECTRAL DENSITY 59 Report No.: BTL-FCCP-1-2404G013 Page 6 of 60 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-1-2404G013 R00 Original Report. Aug. 15, 2024 Valid Report No.: BTL-FCCP-1-2404G013 Page 7 of 60 1. APPLICABLE STANDARDS According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ANSI C63.10-2013 The following reference test guidance is not within the scope of accreditation of A2LA: KDB 558074 D01 15.247 Meas Guidance v05r02 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC CFR Title 47, Part 15, Subpart C Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Powe…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-2404G013 Page 1 of 92 FCC Radio Test Report FCC ID: 2BCGWBS1200 This report concerns: Original Grant Project No. : 2404G013 Equipment : Smart Wi-Fi Light Switch Brand Name : tp-link Test Model : BS1200 Series Model : N/A Applicant : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Manufacturer : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Date of Receipt : Apr. 03, 2024 Date of Test : Apr. 06, 2024 ~ May 09, 2024 Issued Date : Aug. 15, 2024 Report Version : R00 Test Sample : Engineering Sample No.: SSL2024040318 for radiated and AC Power Line Conducted Emissions, SSL2024040320 for conducted. Standard(s) : FCC CFR Title 47, Part 15, Subpart C T he above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Nick Chen Approved by : Chay Cai Room 108, Building 2, No.1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong, People’s Republic of China Te l : + 8 6-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-2-2404G013 Page 2 of 92 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025: 2017 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessm…

Text truncated - open the document above for the full version.
