2BCGWBS2100Smart Wi-Fi Light Switch, Dimmer

Product IntroductionWire Your Switch Tapo smart dimmer switch turns on and dims the lights automatically, saving you effort and electricity bills. Connect the wires to the smart dimmer switch as shown below. 4 Disconnect the wires from the old switch. Ground: Usually green or copper. Neutral: Usually white and not connected to the dumb switch. Line: Usually black and coming from the circuit breaker. Load: Usually black. One end is connected to the light. If you are unsure, consult a qualified electrician. Turn off the circuit breaker. Then remove the old wallplate of the wall switch and label the Ground and Neutral wires. 1 2 Identify Line and Load wires. 3 Line up the switch with the mounting holes. Secure it with screws. 5 Attach the wallplate and turn on the circuit breaker. Then the wiring is finished. 6 Flip the page over to complete setup. 1) Turn on the circuit breaker. Use a voltage detector to identify the energized wire (Line wire). 2) Turn off the circuit breaker. Label the Line and Load wires. Take care to avoid electric shocks. Load wireLine wire Power Source To Light Button Explanations Smart Wi-Fi Light Switch, Dimmer BS2100 Quick Start Guide ©2022 TP-Link 7106509851 REV1.0.0 Specifications Rating: 120V~ 60Hz Load: 300W Incandescent, 150W LED Operation temperature: 0~40°C Method of mounting included: Independently mounted (Vertically position only); Operating control, Type 1 action Pollution Degree 2, Rated Impulse Voltage 2500 V Software Class A, NEMA Type 1.Y *Images may differ from your actual product. Restart Reset Press and hold for about 5s to reset Wi-Fi while keeping other settings. Press to restart your switch. Decrease or increase the brightness. Press and hold for about 10s to restore your switch to factory default settings. / Set Up Your Switch Appearance S T E P 2 SET UP Tap the button in the app. Select Switches and then your model. Follow the step-by-step app instructions to set up your smart switch. DOWNLOAD APP Get the Tapo app from the App Store or Google Play. S T EP 1 Before installing, servicing or removing the switch, read and follow all safety precautions including the following: • CAUTION – Risk of Electric Shock – More than one disconnect switch may be required to de-energize the equipment before servicing. A circuit breaker which disconnects the Line and Neutral conductor simultaneously is suitable. Ensure power is off at the circuit breaker before removing or installing any switch. Use a non-contact voltage tester to ensure the power is off. • The Smart Switch must be installed and used in accordance with the National Electric Code (NEC) or your local electrical code. If you are unfamiliar with these codes and requirements, or are uncomfortable performing the installation, consult a qualified electrician. • Do not install the Smart Switch with wet hands or when standing on wet or damp surfaces. • Install only in a suitable UL Listed outlet box (suitable dimensions: H > 2.95 in./75 mm, W > 1.81 in./46 mm, D > 2 in./51 mm). • Tighten terminal screws to 13 lbf-in. On/Off Button Decrease/Increase Brightness Restart LED Reset Brightness Indicators Need some help? ? Visit www.tp-link.com/support for technical support, user guides, FAQs, warranty and more information. Safety Notice OR Haute tension. Débrancher l'alimentation électrique avant d'utiliser High Voltage-Disconnect power supply before servicing CAUTION MISE EN GARDE LED Status Starting up; disconnected from cloud. Solid amber Blinking amber Blinking green White Solid red Stay green for 30s Blinking amber & green Connecting to Wi-Fi. Ready for setup. Device resetting. Light fixture is off. Disconnected from Wi-Fi. Connected to Wi-Fi. Blinking green slowly Firmware upgrading. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and consider removing the no-collocation statement. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:Th (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution! Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable tec…
