2BCGWC200V5Pan/Tilt Home Security Wi-Fi Camera

User Guide Pan/Tilt Home Security Wi-Fi Camera ©2024 TP-Link 1910013568 REV1.1.0 Contents About This Guide ···········································································1 Introduction ······················································································2 Appearance ······················································································3 Set Up Your Camera ·····································································4 Set Up Using Amazon Frustration-Free Setup ··············5 Install a microSD Card ·································································9 Mount Your Camera···································································10 Reset Your Camera ····································································11 Authentication ··············································································12 1 About This Guide This guide provides a brief introduction to the Pan/Tilt Home Security Wi-Fi Camera and regulatory information. Please note that features available in Tapo may vary by model and software version. Tapo availability may also vary by region. All images, steps, and descriptions in this guide are only examples and may not reflect your actual Tapo Camera experience. Conventions In this guide, the following convention is used: Convention Description Blue Key information appears in blue, including management page text such as menus, items, buttons and so on. Underline Hyperlinks are in blue and underlined. You can click to redirect to a website. Note: Ignoring this type of note might result in a malfunction or damage to the device. More Info • Specifications can be found on the product page at https://www.tapo.com. • Our Technical Support and troubleshooting information can be found at https://www.tapo.com/support/. • A Technical Community is provided for you to discuss our products at https://community.tp-link.com. • The setup video can be found at https://www.tp-link.com/support/setup-video/#cloud-cameras. 2 Introduction When you are away from home, there is always something you care about. This is where the smart camera functions. No matter whether your child is climbing the kitchen cabinet, or the pet is stealing snacks, the Pan/Tilt Home Security Wi-Fi Camera helps you stay with them anytime, anywhere. Receive a notification whenever your camera detects motion and see a video clip of this motion to check everything. • Motion Detection and Tracking – Automatically follow the subject and keeps it within the camera’s field of view whenever motion is detected. • Person Detection – Notify you when a person is detected. • Baby Crying Detection – Notify you when your baby cries. • 1080p Full High-Definition Video – Provide greater sharpness and clarity. • Night Vision up to 30 ft – Provide a visual distance of up to 30 ft in total darkness. • Two-Way Audio – Communicate in real time through a built-in microphone and speaker. • Field of View – A 360º horizontal range to get a detailed look at your room and capture every moment. • Customizable Block Zones – Set customizable block zones to keep private areas from being monitored. • Cloud Storage Supported – Store videos by using cloud storage services. *Subscribe for cloud storage at https://www.tapo.com/tapocare/. • Local microSD Storage – Store up to 512 GB of video on a microSD card. *microSD card needs to be purchased separately. 3 Appearance The Pan/Tilt Home Security Wi-Fi Camera has a system LED that changes color according to its status, a lens, microphone, speaker, DC power port, RESET button and a microSD card slot. Please refer below for details. Micro SDRESET microSD Card Slot System LED • Solid red: Starting up • Blinking red and green: Ready for setup • Blinking red slowly: Connecting to Wi-Fi • Solid amber: Connected to Wi-Fi • Solid green: Connected to the cloud • Blinking red quickly: Camera resetting • Blinking green quickly: Camera updating Speaker Built-in speaker. Microphone Built-in microphone. Note: Do NOT insert objects into the hole. DC Power Port Connect the power cord provided. Lens Reset Button 4 Set Up Your Camera Follow the steps below to get started with your new camera. Step 1. Download Tapo App Get the Tapo app from the App Store or Google Play, or by scanning the QR code below. Step 2. Log In Open the app, and log in with your TP-Link ID. If you don't have an account, create one first. Step 3. Add Your Camera Tap the button > Add Device in the app and search for your model. Follow the app instructions to complete the setup. OR 5 Set Up Using Amazon Frustration-Free Setup What is Amazon Frustration-Free Setup? Amazon Frustration-Free Setup can help connect and set up Tapo smart devices in fewer steps, without having to remember and re-enter your Wi-Fi password on each device. To use this feature, confirm the following: ● The new Tapo device supports Amazon FFS. ● The new Tapo device is purchased from Amazon. ● You have an Amazon FFS enabled Alexa device or router. ● You have saved your Wi-Fi information to Amazon by using Alexa echo. ● Your Tapo device and router are on the same network as your Alexa echo. LED Indications during Amazon Frustration-Free Setup LEDStatus Blinking red and greenReady for setup Blinking amberFFS setup in progress Solid greenWorking properly If the LED does not turn solid green after a long time, you can try to add the Tapo device manually. (Press the Reset button on your Tapo device once. Then open the Tapo app, tap the + button on the page, select your device model, and follow the app instructions. ) 6 1. Open the Amazon Alexa app. Then tap More and select Skills & Games. How to use Amazon Frustration-Free Setup with Tapo devices 2. Enter Tapo in the search bar and choose Tapo. 7 3. Tap the ENABLE TO USE button. 4. Log in with your TP-Link ID that has bound to your Tapo device, and tap Authorize. After authorized successfully, the message Tapo has been successfully linked will come up. 8 5. Pl…

Text truncated - open the document above for the full version.

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO:AmericanCertificationBody,Inc. 313ParkAvenue Suite300 FallsChurch, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name:VISHTEC LLC Contact Name:Alan Graham Street Address:9888 W Belleview Ave Ste 2142 Denver CO 80123 City/Province/Zip:80123 Telephone No:（571）4007350 Email:[email protected] FRN #: 0033407131 This letter is to confirm that we (“the Designated U.S. Agent”) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process for the limited purpose of compliance with section 47 CFR 2.911(d)(7) only and not for any other purpose, on behalf of theApplicantnoted below. U.S. Agent Signature: Date:2023/8/28 Signed by (Printed Name/Title): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: TP-LINK CORPORATION PTE. LTD. Grantee Code: 2BCGW FRN #: 0034122556 Contact Name: Sarah Wang Street Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 City/Province/Zip: Singapore Telephone No: +65-97538388 Email: [email protected] Applicant Signature 1 : Date: 2023/8/28 Signed by (Printed Name/Title) S arah W ang 1 - Lettersshouldbeplacedonappropriateletterhead.

TP-LINK CORPORATION PTE.LTD. CERTIFICATIONS CONCERNING “COVERED” EQUIPMENT Date:2024-07-04 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2BCGWC200V5 To Whom It May Concern: As required by section 2.911(d)(5)(i), [TP-LINK CORPORATION PTE.LTD.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. As required by section 2.911(d)(5)(ii), [TP-LINK CORPORATION PTE.LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Thank you for your attention to this matter. Sincerely yours, Signature Printed Name: Sarah Wang Company: TP-LINK CORPORATION PTE.LTD. Job Title: Regulatory Compliance Manager Email: [email protected] Telephone: +86 755 21534921

TP-LINK CORPORATION PTE.LTD. 030122-15 Authority to Act as Agent Date: July 4, 2024 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: BTL Inc./Rose Liu is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: 2025-07-04 By: __________________________ Sarah Wang (Signature 1 ) (Print name) Title: Regulatory Compliance Manager On behalf of: TP-LINK CORPORATION PTE.LTD. (Company Name) Telephone: +86 755 21534921 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-LINK CORPORATION PTE.LTD. 030122-15 Request for Confidentiality Date: July 4, 2024 Subject: Confidentiality Request for: 2BCGWC200V5 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term ☐ Permanent * 3 User’s Manual TP-LINK CORPORATION PTE.LTD. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Regulatory Compliance Manager Sarah Wang (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Declaration of Conformity We Name: TP-LINK CORPORATION PTE.LTD. Address: 7 Temasek Boulevard #29-03, Suntec Tower One, Singapore 038987 Declare that: Product: Pan/Tilt Home Security Wi-Fi Camera FCC ID: 2BCGWC200V5 Model: Tapo C200, TC70 Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2024-07-04

TP-LINK CORPORATION PTE.LTD. Wi-Fi Channel 12 and 13 Declaration Letter Date: 2024-07-04 We, the undersigned company Company Name: TP-LINK CORPORATION PTE. LTD. Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Declare that: Product description: Pan/Tilt Home Security Wi-Fi Camera Type designation: Tapo C200, TC70 Brand: tp-link FCC ID: 2BCGWC200V5 Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: Sarah Wang Tel: +86 755 21534921 Email: [email protected]

TP-LINK CORPORATION PTE. LTD. Model Declaration Letter We, the undersigning company Company Name: TP-LINK CORPORATION PTE. LTD. Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Hereby confirm that the following products: Product description: Pan/Tilt Home Security Wi-Fi Camera Type designation: Tapo C200, TC70 Trademark: tp-link That All versions of the Model Tapo C200 and TC70 are electrically equal except the following difference: 1. Only differ in model name. Contact Person: Sarah Wang Position in the Company: Regulatory Compliance Manager Date: 2024-07-04 Signature:

Project No.: 2404G033A Page 2 of 13 Project No.: 2404G033A Page 3 of 13 Project No.: 2404G033A Page 4 of 13 Project No.: 2404G033A Page 5 of 13

Lable Location

Project No.: 2404G033A Page 6 of 13 Project No.: 2404G033A Page 7 of 13 ANT1 Project No.: 2404G033A Page 8 of 13 Project No.: 2404G033A Page 9 of 13 Project No.: 2404G033A Page 10 of 13 Project No.: 2404G033A Page 11 of 13 Project No.: 2404G033A Page 12 of 13 Project No.: 2404G033A Page 13 of 13

Report No.: BTL-FCCP-2-2404G033A Project No.: 2404G033A Page 1 of 9 Report Version: R02 FCC RF Exposure Report FCC ID: 2BCGWC200V5 Report No. : BTL-FCCP-2-2404G033A Equipment : Pan/Tilt Home Security Wi-Fi Camera Model Name : Tapo C200, TC70 Brand Name : tp-link Applicant : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Standard(s) : 47 CFR § 2.1091 FCC Guidelines for Human Exposure IEEE C95.1 Date of Receipt : 2024/6/13 Date of Test : 2024/6/13 ~ 2024/6/14 Issued Date : 2024/7/12 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Poken Huang, Engineer Approved by : Peter Chen, Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-2-2404G033A Project No.: 2404G033A Page 2 of 9 Report Version: R02 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the Customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-2-2404G033A Project No.: 2404G033A Page 3 of 9 Report Version: R02 REVISION HISTORY Report No. Version Description Issued Date Note BTL-FCCP-2-2404G033A R00 Original Report. 2024/7/5 Invalid BTL-FCCP-2-2404G033A R01 Modified the comments. 2024/7/11 Invalid BTL-FCCP-2-2404G033A R02 Modified the comments. 2024/7/12 Valid Report No.: BTL-FCCP-2-2404G033A Project No.: 2404G033A Page 4 of 9 Report Version: R02 1. LIMITS According to § 1.1310 Radiofrequency radiation exposure limits. (a) Specific absorption rate (SAR) shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in § 1.1307(b) of this part within the frequency range of 100 kHz to 6 GHz (inclusive). (b) The SAR limits for occupational/controlled exposure are 0.4 W/kg, as averaged over the whole body, and a peak spatial-average SAR of 8 W/kg, averaged over any 1 gram of tissue (defined as a tissue volume in the shape of a cube). Exceptions are the parts of the human body treated as extremities, such as hands, wrists, feet, ankles, and pinnae, where the peak spatial-average SAR limit for occupational/controlled exposure is 20 W/kg, averaged over any 10 grams of tissue (defined as a tissue volume in the shape of a cube). Exposure may be averaged over a time period not to exceed 6 minutes to determine compliance with occupational/controlled SAR limits. (c) The SAR limits for general population/uncontrolled exposure are 0.08 W/kg, as averaged over the whole body, and a peak spatial-average SAR of 1.6 W/kg, averaged over any 1 gram of tissue (defined as a tissue volume in the shape of a cube). Exceptions are the parts of the human body treated as extremities, such as hands, wrists, feet, ankles, and pinnae, where the peak spatial-average SAR limit is 4 W/kg, averaged over any 10 grams of tissue (defined as a tissue volume in the shape of a cube). Exposure may be averaged over a time period not to exceed 30 minutes to determine compliance with general population/uncontrolled SAR limits. (e) Limits for Maximum Permissible Exposure (MPE) to radiofrequency electromagnetic fields (Table 1). Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (i) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 *(100) ≤6 3.0-30 1842/f 4.89/f *(900/f 2 ) <6 30-300 61.4 0.163 1.0 <6 300-1.500 f/300 <6 1.500-100.000 5 <6 (ii) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) <30 1.34-30 824/f 2.19/f *(180/f 2 ) <30 30-300 27.5 0.073 0.2 <30 300-1.500 f/1500 <30 1.500-100.000 1.0 <30 f = frequency in MHz. * = Plane-wave equivalent power density. Report No.: BTL-FCCP-2-2404G033A Project No.: 2404G033A Page 5 of 9 Report Version: R02 2. APPLIED EXEMPTION CRITERIA Refer to KDB 447498 D04, ticked item is applied: For RF Exposure Test Exemptions for Single Source: ☒ 1-mW Test Exemption Per § 1.1307(b)(3)(i)(A), a single RF source is exempt RF device (from the requirement to show data demonstrating compliance to RF exposure limits, as previously mentioned) if the available maximum time-averaged power is no more t…

Text truncated - open the document above for the full version.

Product Model： Tapo C200 Manufacturer： TP-LINK CORPORATION PTE. LTD. Test Date： 2023.12.14 Tested By： Chen Xuemeng TP-LINK CORPORATION PTE. LTD. 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Index 1. Antenna Distribution ........................................................................................ 3 2. Electrical Characteristics ................................................................................ 3 3. Gain and Radiation Pattern ............................................................................. 4 3.1 Measurement Procedure ........................................................................................... 4 3.2 Test Setup ................................................................................................................. 5 3.3 S Parameter Test Data ............................................................................................. 6 3.4 Antenna Peak Gain ................................................................................................... 7 3.5 Antenna Radiation Pattern ........................................................................................ 7 Page 3 1. Antenna Distribution Tapo C200 2. Electrical Characteristics Ant1 Frequency 2400~2500MHz Impedance 50Ohm Antenna Type IFA Antenna Gain 2.00 dBi@2400~2500MHz Radiation pattern Omni-Directional P/N Tapo C200+ANT Page 4 Gain and Radiation Pattern 2.1 Measurement Procedure This measurement experiment adopted an antenna near-field measurement system, and the diagram of the measurement system was shown in Figure 3-1. The excitation signal was generated by the Keysight E5071C (300kHz-20GHz). Under the control of the central computer, the probe rotated in the θ direction, and the EUT rotated in the φ direction with the turntable. The probe sampling frame received and collected signals in the near-field range of the EUT. The software system which was controlled by the central computer completed the processing, output and display of the test data. Figure 0-1 The test site was a full anechoic chamber with a size of 3.0m×3.1m×2.97m, which was built by GTS Rayzone2800. All six surfaces of the anechoic chamber were pasted with absorbing materials. And the chamber was calibrated by the authoritative third-party lab every year. The antenna anechoic chamber measurement system adopted a 13-probe multi-probe system. The probe antennas were evenly distributed on the spherical surface surrounding the EUT, and theirs operating frequency was 600MHz~8.5GHz. During the measurement, the probe antennas were rotated in the θ direction under the control of the probe holder to sample the near-field data at the θ angle. At the same time, the EUT rotated with the turntable in the φ direction to sample the near field data at the φ angle. The sampling accuracy was 15°. The system diagram was shown in Figure 3-2. From the sampling results, the EUT's near-field test data of θ component, φ component and total component could be obtained. Page 5 Figure 0-2 Before the measurement, calibrated the vector network analyzer, and then connected the input end of each antenna to the output end of the vector network analyzer, and evenly the antennas to be measured. Test Equipment listed below: Equipments Model Manufacturer S/N Cali. Interval Cali. Due Date Chamber Rayzone2800 GTS(General Test System) MY5347043 5 12months 2024/01/15 Vector Network Analyzer E5071C Keysight MY46315238 24months 2024/03/13 GTS MaxSign100 Software V2.1 GTS(General Test System) / / / 2.2 Test Setup The test setup was shown in Figure 3-3, 3-4: Figure 0-3 Page 6 Figure 0-4 2.3 S Parameter Test Data Ant1 Page 7 2.4 Antenna Peak Gain Frequency(GHz) 2.45 Ant1 MaxGain(dBi) 2.00 Ant1 Polarization/Φ (°)/θ(°) Theta/270/90 Max Gain(dBi) 2.00 2.5 Antenna Radiation Pattern Ant1

Appendix No.: TP-2404G033A-1 APPENDIX-TEST PHOTOS Project No.: 2404G033A Page 1 of 3 AC Power Line Conducted Emissions test photos Appendix No.: TP-2404G033A-1 APPENDIX-TEST PHOTOS Project No.: 2404G033A Page 2 of 3 Radiated emissions test photos 30 MHz to 1 GHz Appendix No.: TP-2404G033A-1 APPENDIX-TEST PHOTOS Project No.: 2404G033A Page 3 of 3 Radiated emissions test photos Above 1 GHz
