Quick Installation Guide Wireless Access Point Note: EAP650 is used as an example throughout the Guide. Images may differ from your actual product. Hardware Overview 1 RESET With the device powered on, press and hold the button for about 5 seconds until the LED flashes quickly. Then release the button. The device will restore to factory default settings. Ethernet Port: ETH (PoE) The port is used to connect to a router or a switch to transmit data, or to a PSE (Power Sourcing Equipment), such as a PoE switch, for both data transmission and Power over Ethernet (PoE) through Ethernet cable. Note: For EAPs with 10Gbps port, if you use a CAT5E cable, the 10Gbps link of the Ethernet port is less than 55m. To achieve a longer transmission distance, use a shielded CAT6A cable. Power Port Plug one end of the power adapter to this port and the other end to a standard electrical wall outlet to power the E A P. Note: Power adapter is not included in the package contents of certain models. For details, refer to the product specifications or datasheet. For power supply specifications, refer to the product label. Self-tapping Screws Plastic Wall Anchors 1 Remove the ceiling tile. Note: Make sure that the ceiling tile is larger than the EAP. Wing NutsWashersPan-head Screws The EAP can be mounted to the ceiling, the wall, or in a junction box, using the screws in the package. Choose the appropriate mounting and installation steps below. Note: This product requires heat dissipation through the metal bracket during use, please be careful not to touch the metal bracket in the heat dissipation. Hardware Installation 2 2 Insert the plastic wall anchors into the holes. Front Panel Rear Panel Option 1: Ceiling Mounting Option 2: Wall Mounting 5 Connect the Ethernet cable to the Ethernet port. Please pay attention to the triangle sign. Attach the EAP to the mounting bracket, then rotate it until it locks into place, as shown on the left. 2 Place the mounting bracket in the center of the ceiling tile. Mark positions for the screw holes and a location for the Ethernet cable hole. Drill holes for the screws and a hole for the Ethernet cable at the marked positions. 3 Secure the mounting bracket to the ceiling tile using pan-head screws, washers, and wing nuts, as shown on the left. 5 Attach the EAP to the mounting bracket by rotating it until it locks into place, as shown on the left. 2 Connect the Ethernet cable to the Ethernet port on the EAP. 3 Attach the EAP to the mounting bracket by rotating it until it locks into place, as shown on the left. 4 Feed the Ethernet cable through the hole and set the ceiling tile back into place. 3 Secure the mounting bracket to the wall by driving the self-tapping screws into the anchors. Make sure that the shoulders of the mounting bracket are on the outside. 1 If your Ethernet cable feeds through the wall, position the mounting bracket below the cable hole. Mark positions for the screw holes and drill holes at the marked positions. Φ 7.6 mm (19/64 in) Option 2: Wall MountingOption 1: Ceiling MountingOption 3: Junction Box Mounting Blue On: Working normally/Initializing. For EAPs with dual-color LED: Normal power supply Orange On: For EAPs with dual-color LED: Low power supply Flash:• Flash twice: Initialization is completed. • Flash quickly: The EAP is resetting, or the Omada controller is locating the device*. • Flash once per second: The EAP is upgrading. • Flash Slowly: The EAP is in the isolated state. LED Indicator Off: Working abnormally/Power off/LED is turned off. * When the Locate feature is activated in the Omada controller, the LED flashes quickly to locate and identify the device. The LED will flash for 10 minutes. You can disable the feature manually to stop it from flashing. Option 3: Junction Box Mounting Prepare the cables and the junction box in advance. Ensure that the mounting holes align to your junction box. Route the cables through the square cable hole on the mounting bracket, and secure the mounting bracket to the junction box using screws. 1 The EAP can be powered via a power adapter or a PSE device (such as a PoE switch) which complies with Power Source Class 2 ( PS2) or Limited Power Source (LPS) of IEC 62368-1. Option 1: Via PoE Switch Option 2: Via Power Adapter Plug one end of the power adapter into the power port of the EAP and the other end to a standard electrical wall outlet. Note: Power adapter is not included in the package contents of certain models. For details, refer to the product specifications or datasheet. For power supply specifications, refer to the product label. Power Supply 3 Switch Power Adapter PoE Switch Connect an Ethernet cable from the PoE switch to the Ethernet port. Note: For PoE power supply specifications, refer to the product label. *Compatible wall junctions: ©2024 TP-Link 7106511257 REV1.5.2 4 Connect the Ethernet cable to the Ethernet port on the EAP. Φ 25 mm (63/64 in) Φ 4 mm (5/32 in) Setup with videos Visit https://www.tp-link.com/support/setup-video/?type=smb or scan the QR code to search for the setup video of your product model. Method 2: Controller Mode Note: • Before you start, be sure to power up and connect your devices according to the topology figure. • A DHCP server (typically a router with DHCP function enabled) is required to assign IP addresses to the EAPs and clients in your local network. Choose a type of Omada Controller: Choose from the following methods to set up your EAPs: Method 1: Standalone Mode Via Omada App 1. Connect your device to the EAP by using the default SSIDs printed on the label at the bottom of the product. 2. Launch a web browser and enter http://tplinkeap.net in the address bar. Use admin for both Username and Password to log in. 3. Set up a new Username and Password for secure management purpose. Then you can configure the AP. To configure other EAPs, connect your device to each EAP by the corresponding default SSID and repeat the steps above. You can configure some basic func…
