2BCGWTBE552EBE9300 Wi-Fi 7 Bluetooth PCIe Adapter

© 2024 TP-Link REV1.0.0 1910013664 User Guide BE9300 Wi-Fi 7 Bluetooth PCIe Adapter Archer TBE552E Contents About This Guide 01 Chapter 1 Get to Know About Your Adapter 03 Chapter 2 Connect to a Computer 05 Chapter 3 Use Your Adapter 10 3. 1. Install Drivers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 3. 2. Join a Wireless Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 3. 3. Pair with Bluetooth Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 3. 4. Uninstall Drivers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Appendix: Troubleshooting 14 01 About This Guide This guide is a complement to Quick Installation Guide. The Quick Installation Guide instructs you on quick installation, and this guide provides the product overview and more detailed instructions for each steps. When using this guide, please notice that features available of the adapter may vary by model and software version. It may also vary by region or ISP. All images, steps, and descriptions in this guide are only examples and may not reflect your actual experience. Conventions In this guide, the following conventions are used: Convention Description Underlined Underlined words or phrases are hyperlinks. You can click to redirect to a website or a specific section. Teal Contents to be emphasized and texts on the web page are in teal, including the menus, items, buttons, etc. Note: Ignoring this type of note might result in a malfunction or damage to the device. Tips: Indicates important information that helps you make better use of your device. Specifications are subject to change without notice. TP-Link is a registered trademark of TP-LINK CORPORATION PTE. LTD. † Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of network conditions, AP limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and AP location. ‡ Use of Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax), Wi-Fi 6 (802.11ax), and other features including 320 MHz Bandwidth, 4K-QAM, Multi-RUs, OFDMA, MU-MIMO, and BSS Color requires the AP and PC OS to also support the corresponding features. § Certain features of Archer TBE552E, such as Bluetooth 5.4, may be restricted on some computing systems and platforms. Please try to update the device’s driver for feature compatibility. △ The 320 MHz bandwidth is only available on the 6 GHz band. The 320 MHz bandwidth on the 6 GHz band and 160 MHz bandwidth on the 5 GHz band may be unavailable in some regions/countries due to regulatory restrictions. Double channel width and speed refer to 320 MHz compared to 160 MHz for Wi-Fi 6 adapters. *Actual network speed may be limited by the rate of the product’s PCI Express Interface, Ethernet WAN or LAN port, the rate supported by the network cable, internet service provider factors, operating system factors, and other environmental conditions. **Use of WPA3 requires APs to also support the corresponding feature. 02 More Info • The latest driver can be found at Download Center at https://www.tp-link.com/support. • The Quick Installation Guide (QIG) can be found where you find this guide or inside the package of the product. • Specifications can be found on the product page at https://www.tp-link.com. • A TP-Link Community is provided for you to discuss our products at https://community.tp-link.com. Chapter 1 Get to Know About Your Adapter This chapter introduces the detail of the adapter. 05 Chapter 1 Get to Know about Your Adapter Archer TBE552E Wi-Fi 7 unlocks the full potential of the 6 GHz band, providing exceptional bandwidth and congestion-free channels exclusive to your desktop. Enhanced by 4K-QAM and 320 MHz, TBE552E delivers astonishing wireless speeds, facilitating instant multi-stream media playback. ‡ Two powerful signal-boosting, high-performance antennas ensure stronger signal transmissions and reception to greatly extend existing Wi-Fi coverage, offering a fast, smooth online experience from farther away. • Wireless Standards: 5760 Mbps on 6 GHz + 2880 Mbps on 5 GHz + 688 Mbps on 2.4 GHz, compatible with IEEE 802.11a/b/g/n/ac/ax/be standard. • Antennas: 2× High-Performance Tri-Band Antennas • Wireless Security: WPA/WPA2/WPA3, WPA-PSK/WPA2-PSK* • Dimensions: 4.8x3.09x0.85 in (120.8*78.5*21.5 mm) • System Requirements: Windows 11(64-bit) only § • Environment: Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing Chapter 2 Connect to a Computer This chapter introduces how to connect the adapter to your computer. Please note that images are for demonstration only. 06 Chapter 2 Connect to a Computer 1. Turn off your computer, unplug the power cable then remove the case panel. 2. Connect the provided Bluetooth USB cable to the adapter. Bluetooth USB Cable Adapter 3. Locate an available PCIE slot ( X1, X4, X8, or X16) and carefully insert the adapter. Tip: If the bracket is not suitable for your computer, detach it from the adapter’s board and replace it with the low-profile bracket. 07 Chapter 2 Connect to a Computer 4. Locate an available F_USB connector and carefully plug the Bluetooth USB cable into it. USB USB Note: If the Bluetooth USB cable is not correctly connected to the motherboard, Bluetooth function won’t work even after driver installation. 5. Install the antennas to the adapter. Tip: • To maximize performance, make sure the path between the antenna and your router is clear. • DO NOT connect one SMA male connector directly to another with wires or other con-ductors to prevent short circuits or adapter damage. 6. Replace t…

Text truncated - open the document above for the full version.

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO:AmericanCertificationBody,Inc. 313ParkAvenue Suite300 FallsChurch, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name:VISHTEC LLC Contact Name:Alan Graham Street Address:9888 W Belleview Ave Ste 2142 Denver CO 80123 City/Province/Zip:80123 Telephone No:（571）4007350 Email:[email protected] FRN #: 0033407131 This letter is to confirm that we (“the Designated U.S. Agent”) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process for the limited purpose of compliance with section 47 CFR 2.911(d)(7) only and not for any other purpose, on behalf of theApplicantnoted below. U.S. Agent Signature: Date:2023/8/28 Signed by (Printed Name/Title): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: TP-LINK CORPORATION PTE. LTD. Grantee Code: 2BCGW FRN #: 0034122556 Contact Name: Sarah Wang Street Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 City/Province/Zip: Singapore Telephone No: +65-97538388 Email: [email protected] Applicant Signature 1 : Date: 2023/8/28 Signed by (Printed Name/Title) S arah W ang 1 - Lettersshouldbeplacedonappropriateletterhead.

TP-LINK CORPORATION PTE.LTD. To: Federal Communications Commission Date: 2024/07/02 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section 2.911(d)(5)(i) and Section 2.911(d)(5)(ii) (KDB 986446 D01 Covered Equipment) Section 2.911(d)(5)(i) TP-LINK CORPORATION PTE.LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Section 2.911(d)(5)(ii) TP-LINK CORPORATION PTE.LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Type of Equipment subject to FCC Certification: DSS, DTS,NII,6XD FCC ID: 2BCGWTBE552E If you have any questions, please feel free to contact me Contact Person: Sarah Wang Position in the Company: Regulatory Compliance Manager Date of Signature: 2024/07/02 Signatory (signature of the applicant)

Letter of Declaration on Indoor Access Point (6XD) Operation Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BCGWTBE552E To Whom It May Concern We, TP-LINK CORPORATION PTE. LTD. (7 Temasek Boulevard #29-03, Suntec Tower One, Singapore 038987, Singapore), attest that this Indoor Access Point device complies with the following requirements of Part 15E of the FCC’s rules for 6G bands: Protocol attestation statement: FCC ID: 2BCGWTBE552E To Whom It May Concern: Indoor Access Point 6XD: a. The device will only associate and connect with a low-power indoor access point or subordinate device and never directly connect to other client devices. b. This device will always initiate transmission under the control of a low-power indoor AP or subordinate except for brief transmissions before joining a network. These short messages will only occur if the client has detected an indoor AP or subordinate operating on a channel. These brief messages will have a time-out mechanism such that if it does not receive a response from an AP it will not continually repeat the request. C. The transmissions will be lower or equal to the power advertised by the indoor low-power access point or subordinate and never above the maximum output power allowed by the FCC grant for equipment class 6XD. d. Prohibited for control of or communications with unmanned aircraft systems, including drones. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-07-10

TP-LINK CORPORATION PTE. LTD. 030122-15 Authority to Act as Agent Date: June 27, 2024 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: BTL Inc./Rose Liu is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: 2025-06-25 By: Sarah Wang (Signature 1 ) (Print name) Title: Regulatory Compliance Manager On behalf of: TP-LINK CORPORATION PTE.LTD. (Company Name) Telephone: +86 755 21534921 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Declaration of Conformity We Name: TP-LINK CORPORATION PTE. LTD. Address: 7 Temasek Boulevard #29-03, Suntec Tower One, Singapore 038987, Singapore Declare that: Product: BE9300 Wi-Fi 7 Bluetooth PCIe Adapter FCC ID: 2BCGWTBE552E Model: Archer TBE552E Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2024-06-25

Non-SDR (Software Defined Radio) Cover Letter Date: 2024-06-25 Refer to KDB 442812 D01 SDR apps Guide v02r03. The following six questions can be used for determining if a radio can elect to be, or must be an SDR. 1. Can the RF parameters of the device be altered through software? □Yes - go to 2. No, not an SDR 2. Can third parties not permitted by the Commission through specific filings modify, configure, or load different software, or make configuration settings to operate the device or host hardware radio frequency parameters (frequency range, modulation type, maximum output power or other radio parameters) in any other way than granted (or expected to be granted)? □Yes, must be an SDR. □No - go to 3. 3. Is the device capable of operating in any other way than granted, or will be, granted? □Yes, - go to 4. □No - go to 5. 4. Is this a Part 15 client Device as defined in Section 15.202 (as opposed to a master device)? □Yes, qualifies as a part 15 client devices - go to 5. □No, must be an SDR. 5. Does the manufacturer elect SDR? □Yes, elects to be an SDR. □No, Not an SDR Final conclusion: According to the above questions reply, we can confirm this BE9300 Wi-Fi 7 Bluetooth PCIe Adapter (FCC ID: 2BCGWTBE552E) must be a Non-SDR. Name: Sarah Wang Position: Regulatory Compliance Manager TP-LINK CORPORATION PTE.LTD.

Letter of Declaration on Indoor Access Point (6XD) Operation Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BCGWTBE552E To Whom It May Concern We, TP-LINK CORPORATION PTE. LTD. (7 Temasek Boulevard #29-03, Suntec Tower One, Singapore 038987, Singapore), attest that this Indoor Access Point device complies with the following requirements of Part 15E of the FCC’s rules for 6G bands: Protocol attestation statement: FCC ID: 2BCGWTBE552E To Whom It May Concern: Indoor Access Point 6XD: a. The device will only associate and connect with a low-power indoor access point or subordinate device and never directly connect to other client devices. b. This device will always initiate transmission under the control of a low-power indoor AP or subordinate except for brief transmissions before joining a network. These short messages will only occur if the client has detected an indoor AP or subordinate operating on a channel. These brief messages will have a time-out mechanism such that if it does not receive a response from an AP it will not continually repeat the request. C. The transmissions will be lower or equal to the power advertised by the indoor low-power access point or subordinate and never above the maximum output power allowed by the FCC grant for equipment class 6XD. d. Prohibited for control of or communications with unmanned aircraft systems, including drones. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-07-10

Media Tek Inc. Date: 2024-07-25 Letter of authorization We, Media Tek Inc. Declare that: is authorized to Product Name : BE9300 Wi-Fi 7 Bluetooth PCIe Adapter Model: Archer TBE552E Brand: tp-link With this letter we are authorizing TP-LINK CORPORATION PTE. LTD. to duplicate the initial modular test report and the test report number: Note: The module of MT7927 with FCC ID which was granted on 01/18/2023 TP-LINK CORPORATION PTE. LTD. Project request of FCC ID: 2BCGWTBE552E If you should have any questions regarding this declaration, please do not hesitate to contact us, thank you! Sincerely yours, Siegfried Chang MediaTek Inc.

Declaration Letter Date: 2024-08-02 To：Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia.MD 21046 Company Name: TP-LINK CORPORATION PTE. LTD. Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Hereby confirm that the following products: Product description: BE9300 Wi-Fi 7 Bluetooth PCIe Adapter Type designation: Archer TBE552E Trademark: tp-link Subject: Request permission to use WLAN 6G partial test results from model MT7927(FCC ID: RAS-MT7927) in our applications for the model Archer TBE552E(FCC ID: 2BCGWTBE552E) The detail information of changes as below: Archer TBE552E is that host integrator for the module MT7927, the power class of Archer TBE552E is not bigger than MT7927, The antenna gain is also smaller than that of the module, but the antenna type is different, so the radiation has been reevaluated. MT7927 6G supports 6XD and 6CD, while Archer TBE552E only supports 6XD function, which can be controlled through software, no other change for the module. For the above, 1. we performed full test for Radiated emissions and spot checked e.i.r.p power for 6GHz WIFI, re-used partial test results of 6GHz WIFI from module MT7927, 2. we performed full test for 2.4GHz/5GHz WIFI and BT/BLE. as below tables for details: Retest or not Comments 1、part 15E WIFI (6G) Spot check the e.i.r.p. Radiated emissions full test. Spot check e.i.r.p. is lower than module approval of MT7927(FCC ID: RAS-MT7927) 2、part 15C Full test WIFI (2.4G) and BT/LE 3、part 15E WIFI (5G) Full test Name: Sarah Wang Position: Regulatory Compliance Manager Signature: 2024-08-02

Project No.: 2403G002 Page 2 of 11 WIFI Ant. 1 WIFI Ant. 2 Project No.: 2403G002 Page 3 of 11 Project No.: 2403G002 Page 4 of 11 Project No.: 2403G002 Page 5 of 11

注： 1）SN码由工厂直接打印于锡标上指定位置。 2）图示条码均为示意，具体请以生产实际为准。 尺寸：37*30mm,0.5R，公差±0.2mm 文字转曲线（供应商来料效果图） Archer TBE552E(UN)1.0 _产品规格标贴 A1 80g艾利铜版纸+雾膜 Archer TBE552E(UN)1.0 曾明华 2024-01-15 白色 黑色 白色 白色 文字方向 文字方向 BE9300 Wi-Fi 7 Bluetooth PCIe Adapter Model: Archer TBE552E Model:Archer TBE552E(UN) Ver:1.0 S/N:XXXXXXXXXXXXX MADE IN CHINA Indoor use only FCC ID: 2BCGWTBE552E IC: 31152-TBE552E 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 TP-LINK CORPORATION PTE. LTD.

Project No.: 2403G002 Page 6 of 12 Project No.: 2403G002 Page 7 of 12 Project No.: 2403G002 Page 8 of 12 Project No.: 2403G002 Page 9 of 12 Project No.: 2403G002 Page 10 of 12 Project No.: 2403G002 Page 11 of 12 Project No.: 2403G002 Page 12 of 12

Report No.: BTL-FCCP-7-2403G002 Page 1 of 7 FCC RF EXPOSURE REPORT FCC ID: 2BCGWTBE552E Project No. : 2403G002 Equipment : BE9300 Wi-Fi 7 Bluetooth PCIe Adapter Brand Name : tp-link Test Model : Archer TBE552E Series Model : N/A Applicant : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Manufacturer : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Date of Receipt : Mar. 01, 2024 Date of Test : Mar. 01, 2024 ~ Jun. 03, 2024 Issued Date : Jul. 17, 2024 Report Version : R01 Test Sample : Engineering Sample No.: SSL20240301184 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 & KDB 447498 D01 v06 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Grani Zhou Approved by : Chay Cai Room 108, Building 2, No.1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong, People’s Republic of China Tel: +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-7-2403G002 Page 2 of 7 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-7-2403G002 R00 Original Report. Jul. 01, 2024 Invalid BTL-FCCP-7-2403G002 R01 Revised report to address comments. Jul. 17, 2024 Val id Report No.: BTL-FCCP-7-2403G002 Page 3 of 7 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 2. ANTENNA SPECIFICATION Antenna Specification: For 6GHz Ant. Manufacturer P/N Antenna Type Connector Gain (dBi) 1 TP-LINK CORPORATION PTE. LTD. 3101504215 Dipole N/A 2.00 2 TP-LINK CORPORATION PTE. LTD. 3101504215 Dipole N/A 2.00 Note: a) The EUT incorporates a CDD function. Physically, the EUT provides two completed transmitters and receivers (2T2R). For Output Power, N ANT = 2 < 5; so Directional gain=2.00. The Direction gain is less than 6 dBi, so output power limits will not be reduced. b) The above Antenna information are derived from the antenna data sheet provided by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. For BT & BLE: Ant. Brand Name Model Name Type Connector Gain (dBi) 1 TP-LINK CORPORATION PTE. LTD. 3101504215 Dipole N/A 1.00 Note: c) The above Antenna information are derived from the antenna data sheet provided by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. For 2.4GHz: Ant. Brand Name Model Name Type Connector Gain (dBi) 1 TP-LINK CORPORATION PTE. LTD. 3101504215 Dipole N/A 1.00 2 TP-LINK CORPORATION PTE. LTD. 3101504215 Dipole N/A 1.00 NOTE: a) The EUT incorporates a CDD function. Physically, the EUT provides two completed transmitters and receivers (2T2R). b) For Output Power For N ANT = 2 < 5, Direction gain = G ANT + 0 = 1.00 + 0 = 1.00 dBi. The Direction gain is less than 6 dBi, so output power limits will not be reduced. d) The above Antenna information are derived from the antenna data sheet provided by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. Report No.: BTL-FCCP-7-2403G002 Page 4 of 7 For 5GHz: Ant. Brand Name Model Name Type Connector Gain (dBi) 1 TP-LINK CORPORATION PTE. LTD. 3101504215 Dipole N/A 2.00 2 TP-LINK CORPORATION PTE. LTD. 3101504215 Dipole N/A 2.00 Note: a) The EUT incorporates a CDD function. Physically, the EUT provides two completed transmitters and receivers (2T2R). b) For Output Power and Power Spectral Density For Non Beamforming, N ANT = 2 < 5; so Directional gain=2.00. The Direction gain is less than 6 dBi, so output power limits will not be reduced. 1) The above Antenna information are derived from the antenna data sheet provided by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. 3. TABLE FOR ANTENNA CONFIGURATION For 6GHz: Operating Mode TX Mode 2TX IEEE 802.11ax(HE20) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE40) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE80) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE160) V (Ant. 1 + Ant. 2)) IEEE 802.11be(EHT20) V (Ant. 1 + Ant. 2) IEEE 802.11be(EHT40) V (Ant. 1 + Ant. 2) IEEE 802.11be(EHT80) V (Ant. 1 + Ant. 2) IEEE 802.11be(EHT160) V (Ant. 1 + Ant. 2) IEEE 802.11be(EHT320) V (Ant. 1 + Ant. 2) For 2.4GHz: Operating Mode TX Mode 2TX IEEE 802.11b V (Ant. 1+Ant. 2) IEEE 802.11g V (Ant. 1+Ant. 2) IEEE 802.11n (HT20) V (Ant. 1+Ant. 2) IEEE 802.11n (HT40) V (Ant. 1+Ant. 2) IEEE 802.11ax (HE20) V (Ant. 1+Ant. 2) IEEE 802.11ax (HE40) V (Ant. 1+Ant. 2) IEEE 802.11be (EHT20) V (Ant. 1+Ant. 2) IEEE 802.11be (EHT40) V (Ant. 1+Ant. 2) Report No.: BTL-FCCP-7-2403G002 Page 5 of 7 For 5GHz: Operating Mode TX Mode 2TX IEEE 802.11a V (Ant. 1 + Ant. 2) IEEE 802.11ac (VHT20) V (Ant. 1 + Ant. 2) IEEE 802.11ac (VHT40) V (Ant. 1 + Ant. 2) IEEE 802.11ac (VHT80) V (Ant. 1 + Ant. 2)) IEEE 802.11ac (VHT160) V (Ant. 1 + Ant. 2) IEEE 802.11ax (HE20) V (Ant. 1 + Ant. 2) IEEE 802.11ax (HE40) V (Ant. 1 + Ant. 2) IEEE 802.11ax (HE80) V (Ant. 1 + Ant. 2) IEEE 802.11ax (HE160) V (Ant. 1 + Ant. 2) IEEE 802.11be (EHT20) V (Ant. 1 + Ant. 2) IEEE 802.11be (EHT40) V (Ant. 1 + Ant. 2) IEEE 802.11be (EHT80) V (Ant. 1 + Ant. 2) IEEE 802.11be (EHT160) V (Ant. 1 + Ant. 2) Report No.: BTL-FCCP-7-2403G002 Page 6 of 7 4. CALCULATED RESULT For 6GHz: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.00 1.5849 18.70 74.1310 0.02339 1 Complies For BT: Antenna Gain (dBi)…

Text truncated - open the document above for the full version.

Product Model： Archer TBE552E Manufacturer： TP-LINK CORPORATION PTE. LTD. Test Date： 2024.06.14 Tested By： Yu Sunli TP-LINK CORPORATION PTE. LTD. 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Index 1. Antenna Distribution ........................................................................................ 3 2. Electrical Characteristics ................................................................................ 3 3. Gain and Radiation Pattern ............................................................................. 4 3.1 Measurement Procedure ........................................................................................... 4 3.2 Test Setup ................................................................................................................. 5 3.3 S Parameter Test Data ............................................................................................. 6 3.4 Antenna Peak Gain ................................................................................................... 6 3.5 Antenna Radiation Pattern ........................................................................................ 7 Page 3 1. Antenna Distribution Archer TBE550E 2. Electrical Characteristics Ant1 Frequency 2400~2500 &5150~5895MHz&5925~7125MHz Impedance 50Ohm Antenna Type Dipole Antenna Gain 1.00dBi@2400~2500MHz 1.27dBi@5150~5250MHz 1.81dBi@5250~5350MHz 2.00dBi@5470~5725MHz 2.00dBi@5725~5895MHz 2.00dBi@5925~6425MHz 1.77dBi@6425~6525MHz 1.87dBi@6525~6875MHz 1.60dBi@6875~7125MHz Radiation pattern Omni-Directional P/N 3101504215 Ant2 Frequency 2400~2500 &5150~5895MHz&5925~7125MHz Impedance 50Ohm Antenna Type Dipole Antenna Gain 1.00dBi@2400~2500MHz 1.27dBi@5150~5250MHz 1.81dBi@5250~5350MHz Page 4 2.00dBi@5470~5725MHz 2.00dBi@5725~5895MHz 2.00dBi@5925~6425MHz 1.77dBi@6425~6525MHz 1.87dBi@6525~6875MHz 1.60dBi@6875~7125MHz Radiation pattern Omni-Directional P/N 3101504215 3. Gain and Radiation Pattern 3.1 Measurement Procedure This measurement experiment adopted an antenna near-field measurement system, and the diagram of the measurement system was shown in Figure 3-1. The excitation signal was generated by the Keysight E5071C (300kHz-20GHz). Under the control of the central computer, the probe rotated in the θ direction, and the EUT rotated in the φ direction with the turntable. The probe sampling frame received and collected signals in the near-field range of the EUT. The software system which was controlled by the central computer completed the processing, output and display of the test data. Figure 3-1 The test site was a full anechoic chamber with a size of 3.0m×3.1m×2.97m, which was built by GTS Rayzone2800. All six surfaces of the anechoic chamber were pasted with absorbing materials. And the chamber was calibrated by the authoritative third-party lab every year. The antenna anechoic chamber measurement system adopted a 13-probe multi-probe system. The probe antennas were evenly distributed on the spherical surface surrounding the EUT, and theirs operating frequency was 600MHz~8.5GHz. During the measurement, the probe antennas were rotated in the θ direction under the control of the probe holder to sample the near-field data at the θ angle. At the same time, the EUT rotated with the turntable in the φ direction to sample the near field data at the φ angle. The sampling accuracy was 15°. The system diagram was shown in Figure 3-2. From the sampling results, the EUT's near-field test data of θ component, φ component and total component could be obtained. Page 5 Figure 3-2 Before the measurement, calibrated the vector network analyzer, and then connected the input end of each antenna to the output end of the vector network analyzer, and evenly the antennas to be measured. Test Equipment listed below: Equipments Model Manufacturer S/N Cali. Interval Cali. Due Date Chamber Rayzone2800 GTS(General Test System) MY5347043 5 12months 2025/01/15 Vector Network Analyzer E5071C Keysight MY46315238 24months 2026/03/13 GTS MaxSign100 Software V2.1 GTS(General Test System) / / / 3.2 Test Setup The test setup was shown in Figure 3-3, 3-4: Figure 3-3 Figure 3-4 Page 6 3.3 S Parameter Test Data Ant1 Ant2 3.4 Antenna Peak Gain Frequency 2.45GHz 2400~2500MHz 5.2GHz 5150~5250MHz 5.3GHz 5250~5350MHz 5.6GHz 5470~5725MHz Ant1 MaxGain(dBi) 1.00 1.27 1.81 2.00 Ant2 MaxGain(dBi) 1.00 1.27 1.81 2.00 Ant1 Polarization/Φ(°)/θ(°) Theta/15/90 Theta/0/90 Theta/0/90 Theta/0/105 Ant2 Polarization/Φ(°)/θ(°) Theta/15/90 Theta/0/90 Theta/0/90 Theta/0/105 Max Gain(dBi) 1.00 1.27 1.81 2.00 Frequency 5.8GHz 5725~5895MHz 6.175GHz 5925~6425MHz 6.475GHz 6425~6525MHz Ant1 MaxGain(dBi) 2.00 2.00 1.77 Ant2 MaxGain(dBi) 2.00 2.00 1.77 Ant1 Polarization/Φ(°)/θ(°) Theta/0/105 Theta/0/105 Theta/15/105 Ant2 Polarization/Φ(°)/θ(°) Theta/0/105 Theta/0/105 Theta/15/105 Max Gain(dBi) 2.00 2.00 1.77 Frequency 6.725GHz 6525~6875MHz 7.025GHz 6875~7125MHz Ant1 MaxGain(dBi) 1.87 1.60 Ant2 MaxGain(dBi) 1.87 1.60 Ant1 Polarization/Φ(°)/θ(°) Theta/15/105 Theta/15/105 Ant2 Polarization/Φ(°)/θ(°) Theta/15/105 Theta/15/105 Max Gain(dBi) 1.87 1.60 Page 7 3.5 Antenna Radiation Pattern Ant1 Ant2

Report No.: BTL-FCCP-1-2403G002 Page 1 of 156 FCC Radio Test Report FCC ID: 2BCGWTBE552E This report concerns: Original Grant Project No. : 2403G002 Equipment : BE9300 Wi-Fi 7 Bluetooth PCIe Adapter Brand Name : tp-link Test Model : Archer TBE552E Series Model : N/A Applicant : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Manufacturer : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Date of Receipt : Mar. 01, 2024 Date of Test : Mar. 01, 2024 ~ Jul. 16, 2024 Issued Date : Jul. 24, 2024 Report Version : R02 Test Sample : Engineering Sample No.: SSL2024030118 4 Standard(s) : FCC CFR Title 47, Part 15, Subpart E The above equipme…
