2BCGWTX10UBNANOAX900 Nano Wi-Fi6 Bluetooth USB Adapter

TP-Link Wi-Fi Bluetooth USB Adapter Images are for demonstration only. 7106511051 REV1.0.0 1 Disable Bluetooth Insert the adapter into a USB port on your computer directly. a. Right-click My Computer, select Manage, go to Device Manager. b. Expand the Bluetooth node to find your existing Bluetooth device. c. Right-click the existing Bluetooth device and select Disable. Note: Make sure you have disabled all existing Bluetooth devices (both built-in and third party). 2 Connect to a Computer 3 Install the Drivers Bluetooth Device Manager Disable Existing Bluetooth Adapter Before You Start: If you plan on using Bluetooth and already have connected Bluetooth devices, proceed with Step 1. Otherwise, skip to Step 2. . Go to My Computer or This PC. c. Follow the on-screen instructions to complete the Wi-Fi and Bluetooth drivers installation. Once finished, restart your computer. Note: • Your Wi-Fi Bluetooth USB adapter will be listed in the Device Manager when the driver is installed correctly. • If the driver installation fails, disable the antivirus software and firewall, then try again. Note: • If you cannot find the setup program, please download the driver at www.tp-link.com/support. • If an unknown publisher message pops up, select Ye s to continue. • If Windows User Account Control requires admin credentials, type user name and password of your Windows administrator account. SetupInstall.exe b. Double-click the TP-Link CD-ROM then run SetupInstall.exe to install the drivers. Frequently Asked Questions(FAQ) Q1. What should I do if I cannot find or connect to my wireless network? A1. Refer to https://www.tp-link.com/faq-2253.html. Q2. What should I do if the Bluetooth icon doesn’t appear? A1. Make sure you have turned on the Bluetooth in Windows settings. A2. If there are other Bluetooth devices on the computer, disable them in Device Manager, then insert the adapter and try again. Q3. Why the adapter is not working with my Bluetooth device? A1. Make sure your device has Bluetooth function. A2. Make sure you have installed the latest Bluetooth driver on the computer. You can check the published driver versions from https://www.tp-link.com/download-center. A3. For devices with non-standard Bluetooth protocols, such as Logitech Mouse, there may be some compatibility problems. ©2024 TP-Link For technical support, the user guide and other information, please visit https://www.tp-link.com/support, or simply scan the QR code. Support · Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us. · Do not use the device where wireless devices are not allowed. · Keep the device away from water, fire, humidity or hot environments. · This product can be powered only by power supplies that comply with Power Source Class 2 (PS2) or Limited Power Source(LPS) of IEC 62368-1. c. Select your Bluetooth device from the list and follow the on-screen instructions to complete pairing. Note: Make sure your device’s Bluetooth is enabled and discoverable. b. Select Add a Bluetooth Device or Add a Device to scan for available devices. a. Right-click the (Bluetooth) icon on the taskbar. Note: If the Bluetooth icon is not displayed, refer to FAQ > Q2. 3 Pair with Bluetooth Devices Add a device Mouse Pair Headset b. Select your Wi-Fi network, click Connect, and enter the password when prompted. 4 Join a Wireless Network Note: If you cannot find or connect to the wireless network, refer to FAQ > Q1. Network 6 Connected Network settings Connect automatically Connect √ TP-Link_XXXX TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2011 /65/EU and (EU) 2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca a. Click the network icon on the taskbar (the icon might look like one of these: , , , or ).

FCC compliance information statement Product Name: AX900 Nano Wi-Fi6 Bluetooth USB Adapter Model Number: Archer TX10UB Nano Responsible party: TP-Link USA Corporation Address: 10 Mauchly, Irvine, CA 92618 Website: https://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: [email protected] This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1 ) This device may not cause harmful interference. 2 ) This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment has been SAR-evaluated for use in hand. SAR measurements are based on a 5mm spacing from the body and that compliance is achieved at that distance. We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated. Issue Date: 2024.07.05 CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. OPERATING FREQUENCY (the maximum transmitted power) 2412 MHz -2472 MHz(12.99dBm) 5150 MHz -5250 MHz(13.42dBm) 5250 MHz -5350 MHz (13.23dBm) 5470 MHz -5725 MHz (13.47dBm) EU declaration of conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2011/65/ EU and (EU)2015/863. The original EU declaration of conformity may be found at https://www.tp-link.com/en/ce TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. The original UK declaration of conformity may be found at https://www.tp-link. com/support/ukca/ RF Exposure Information This device meets the EU requirements (2014/53/EU Article 3.1a) on the limitation of exposure of the general public to electromagnetic fields by way of health protection. This device has been tested and meets the ICNIRP exposure guidelines and the European Standard EN 62209-2. SAR is measured with this device at a separation of 0.5 cm to the body, while transmitting at the highest certified output power level in all frequency bands of this device. Carry this device at least 0.5 cm away from your body to ensure exposure levels remain at or below the as-tested levels. National restrictions Frequency band: 5150 - 5250 MHz: Indoor use: Inside buildings only. Installations and use inside road vehicles and train carriages are not permitted. Limited outdoor use: If used outdoors, equipment shall not be attached to a fixed installation or to the external body of road vehicles, a fixed infrastructure or a fixed outdoor antenna. Use by unmanned aircraft systems (UAS) is limited to within the 5170 - 5250 MHz band. Frequency band: 5250 - 5350 MHz: Indoor use: Inside buildings only. Installations and use in road vehicles, trains and aircraft are not permitted. Outdoor use is not permitted. Frequency band: 5470 - 5725 MHz: Installations and use in road vehicles, trains and aircraft and use for unmanned aircraft systems (UAS) are not permitted. ATBEBGCHCYCZDEDK EEELESFIFRHRHUIE ISITLILTLULVMTNL NOPLPTROSESISKUK(NI) Attention: This device may only be used indoors in Great Britain. UK Canadian Compliance Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1 ) This device may not cause interference. 2 ) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: 1 ) l’appareil ne doit pas produire de brouillage; 2 ) l’utilisateur de l’appareil doit accepter tout broui…

Text truncated - open the document above for the full version.

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO:AmericanCertificationBody,Inc. 313ParkAvenue Suite300 FallsChurch, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name:VISHTEC LLC Contact Name:Alan Graham Street Address:9888 W Belleview Ave Ste 2142 Denver CO 80123 City/Province/Zip:80123 Telephone No:（571）4007350 Email:[email protected] FRN #: 0033407131 This letter is to confirm that we (“the Designated U.S. Agent”) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process for the limited purpose of compliance with section 47 CFR 2.911(d)(7) only and not for any other purpose, on behalf of theApplicantnoted below. U.S. Agent Signature: Date:2023/8/28 Signed by (Printed Name/Title): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: TP-LINK CORPORATION PTE. LTD. Grantee Code: 2BCGW FRN #: 0034122556 Contact Name: Sarah Wang Street Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 City/Province/Zip: Singapore Telephone No: +65-97538388 Email: [email protected] Applicant Signature 1 : Date: 2023/8/28 Signed by (Printed Name/Title) S arah W ang 1 - Lettersshouldbeplacedonappropriateletterhead.

TP-LINK CORPORATION PTE.LTD. To: Federal Communications Commission Date: 2024/07/08 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section 2.911(d)(5)(i) and Section 2.911(d)(5)(ii) (KDB 986446 D01 Covered Equipment) Section 2.911(d)(5)(i) TP-LINK CORPORATION PTE.LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Section 2.911(d)(5)(ii) TP-LINK CORPORATION PTE.LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Type of Equipment subject to FCC Certification: DSS, DTS,NII FCC ID: 2BCGWTX10UBNANO If you have any questions, please feel free to contact me Contact Person: Sarah Wang Position in the Company: Regulatory Compliance Manager Date of Signature: 2024/07/08 ___________________________ Signatory (signature of the applicant)

TP-LINK CORPORATION PTE. LTD. 030122-15 Authority to Act as Agent Date: July 9, 2024 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: BTL Inc./Rose Liu is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: 2025-07-08 By: __________________________ Sarah Wang (Signature 1 ) (Print name) Title: Regulatory Compliance Manager On behalf of: TP-LINK CORPORATION PTE.LTD. (Company Name) Telephone: +86 755 21534921 1 - M ust be signed by ap p licant contact given for ap p licant on the FCC site, or by the authorized agent if an ap p rop riate authorized agent letter has been p rovided. Letters should be p laced on ap p rop riate letterhead.

TP-LINK CORPORATION PTE. LTD. 030122-15 Request for Confidentiality Date: July 9, 2024 Subject: Confidentiality Request for: 2BCGWTX10UBNANO Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term ☐ Permanent * 3 User’s Manual TP-LINK CORPORATION PTE. LTD. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Regulatory Compliance Manager Sarah Wang (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be p rovided to ACB before p ermanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the sp ecific Document link for D01 found at: http s://ap p s.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding sp ecific information that must accomp any these requests. 2 - Please refer to http s://acbcert.com/documents/misc-docs/M emo-Short-Term-Vs-Standard-Confidentiality .p df for comp lete details. 3 - M ust be signed by ap p licant contact given for ap p licant on the FCC site, or by the authorized agent if an ap p rop riate authorized agent letter has been p rovided. Letters should be p laced on ap p rop riate letterhead.

Declaration of Conformity We Name: TP-LINK CORPORATION PTE. LTD. Address: 7 Temasek Boulevard #29-03, Suntec Tower One, Singapore 038987, Singapore Declare that: Product: AX900 Nano Wi-Fi6 Bluetooth USB Adapter FCC ID: 2BCGWTX10UBNANO Model: Archer TX10UB Nano Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2024-07-08

Non-SDR (Software Defined Radio) Cover Letter Date: 2024-07-08 Refer to KDB 442812 D01 SDR apps Guide v02r03. The following six questions can be used for determining if a radio can elect to be, or must be an SDR. 1. Can the RF parameters of the device be altered through software? □Yes - go to 2. No, not an SDR 2. Can third parties not permitted by the Commission through specific filings modify, configure, or load different software, or make configuration settings to operate the device or host hardware radio frequency parameters (frequency range, modulation type, maximum output power or other radio parameters) in any other way than granted (or expected to be granted)? □Yes, must be an SDR. □No - go to 3. 3. Is the device capable of operating in any other way than granted, or will be, granted? □Yes, - go to 4. □No - go to 5. 4. Is this a Part 15 client Device as defined in Section 15.202 (as opposed to a master device)? □Yes, qualifies as a part 15 client devices - go to 5. □No, must be an SDR. 5. Does the manufacturer elect SDR? □Yes, elects to be an SDR. □No, Not an SDR Final conclusion: According to the above questions reply, we can confirm this AX900 Nano Wi-Fi6 Bluetooth USB Adapter (FCC ID: 2BCGWTX10UBNANO) must be a Non-SDR. Name: Sarah Wang Position: Regulatory Compliance Manager TP-LINK CORPORATION PTE.LTD.

Appendix No.: EP-2403G134-1 APPENDIX-EUT PHOTOS Project No.: 2403G134 Page 1 of 4 Appendix No.: EP-2403G134-1 APPENDIX-EUT PHOTOS Project No.: 2403G134 Page 2 of 4

Appendix No.: EP-2403G134-1 APPENDIX-EUT PHOTOS Project No.: 2403G134 Page 3 of 4 Antenna Appendix No.: EP-2403G134-1 APPENDIX-EUT PHOTOS Project No.: 2403G134 Page 4 of 4

Report No.: BTL-FCC SAR-1-2403G134 Page 1 of 38 FCC SAR Test Report FCC ID: 2BCGWTX10UBNANO Project No. : 2403G134 Equipment : AX900 Nano Wi-Fi6 Bluetooth USB Adapter Brand Name : tp-link Test Model : Archer TX10UB Nano Series Model : N/A Date of Receipt : Mar. 27, 2024 Date of Test : May 07, 2024 ~ Jun. 03, 2024 Issued Date : Jul. 03, 2024 Report Version : R00 Test Sample : Engineering Sample No.: SSL2024032762 Standard(s) : Please refer to page 2. Applicant : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Manufacturer : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Factory : TP-LINK International Shenzhen Co. Ltd. Guangming Branch Address : Room 101,1F-8F,C901,C1001,C1101,C1201,TP-LINK Export factory,No.198, Kelian Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen City, Guangdong Province, P.R.China The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Justin Huang Approved by : Herbort Liu Room 108, Building 2, No.1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong, People’s Republic of China Te l : + 8 6-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCC SAR-1-2403G134 Page 2 of 38 Standard(s) : IEEE Std C95.1:2019 IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 kHz to 300 GHz EN IEC/IEEE 62209-1528:2021 Measurement procedure for the assessment of specific absorption rate of human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices - Part 1528: Human models, instrumentation, and procedures (Frequency range of 4 MHz to 10 GHz) KDB447498 D04 Interim General RF Exposure Guidance v01 KDB447498 D02 SAR Procedures for Dongle Xmtr v02 KDB865664 D01 SAR measurement 100 MHz to 6 GHz v01r04 KDB865664 D02 SAR Reporting v01r02 Report No.: BTL-FCC SAR-1-2403G134 Page 3 of 38 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025: 2017 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCC SAR-1-2403G134 Page 4 of 38 Table of Contents Page REPORT ISSUED HISTORY 6 1 . GENERAL INFORMATION 7 1.1 STATEMENT OF COMPLIANCE 7 1.2 LABORATORY ENVIRONMENT 7 1.3 GENERAL DESCRIPTION OF EUT 8 1.4 MAIN TEST INSTRUMENTS 9 2 . RF EMISSIONS MEASUREMENT 10 2.1 TEST FACILITY 10 2.2 MEASUREMENT UNCERTAINTY 10 3 . SAR MEASUREMENTS SYSTEM CONFIGURATION 11 3.1 SAR MEASUREMENT SET-UP 11 3.1.1 TEST SETUP LAYOUT 11 3.2 DASY5 E-FIELD PROBE SYSTEM 12 3.2.1 PROBE SPECIFICATION 12 3.2.2 E-FIELD PROBE CALIBRATION 13 3.2.3 OTHER TEST EQUIPMENT 14 3.2.4 SCANNING PROCEDURE 15 3.2.5 SPATIAL PEAK SAR EVALUATION 16 3.2.6 DATA STORAGE AND EVALUATION 17 3.2.7 DATA EVALUATION BY SEMCAD 18 4 . SYSTEM VERIFICATION PROCEDURE 20 4.1 TISSUE VERIFICATION 20 4.2 SYSTEM CHECK 21 4.3 SYSTEM CHECK PROCEDURE 21 5 . SAR MEASUREMENT VARIABILITY AND UNCERTAINTY 22 5.1 SAR MEASUREMENT VARIABILITY 22 6 . OPERATIONAL CONDITIONS DURING TEST 23 6.1 TEST POSITION 23 6.2 TEST CONFIGURATION 24 6.2.1 WIFI TEST CONFIGURATION 24 7 . TEST RESULT 27 7.1 CONDUCTED POWER RESULTS 27 7.1.1 CONDUCTED POWER MEASUREMENTS OF BT 27 7.1.2 CONDUCTED POWER MEASUREMENTS OF WIFI 28 7.2 SAR TEST RESULTS 33 7.2.1 SAR MEASUREMENT RESULT 34 Report No.: BTL-FCC SAR-1-2403G134 Page 5 of 38 Table of Contents Page 8 MULTIPLE TRANSMITTER EVALUATION 36 APPENDIX 37 1. TEST LAYOUT 37 Appendix A. SAR Plots of System Verification Appendix B. SAR Plots of SAR Measurement Appendix C. Calibration Certificate Appendix D. Photographs of the Test Set-Up Report No.: BTL-FCC SAR-1-2403G134 Page 6 of 38 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCC SAR-1-2403G134 R00 Original Report. Jul. 03, 2024 Valid Report No.: BTL-FCC SAR-1-2403G134 Page 7 of 38 1. GENERAL INFORMATION 1.1 STATEMENT OF COMPLIANCE Mode Highest Reported Body SAR-1g(W/kg) 2.4G WLAN 1.520 5.2G WLAN 1.378 5.3G WLAN 1.420 5.6G WLAN 1.309 5.8G WLAN 1.371 Bluetooth 0.357 Note: 1) The device is in compliance…

Text truncated - open the document above for the full version.

Report No.: BTL-FCC SAR-1-2403G134_Appendix A. Page 1 of 4 Test Laboratory: BTL Inc. Date: 2024/5/15 System Check_H2450_0515 DUT: Dipole 2450 MHz D2450V2;SN:919; Communication System: UID 0, CW (0); Frequency: 2450 MHz; Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2450 MHz; σ = 1.836 S/m; ε r = 39.639; ρ = 1000 kg/m 3 Ambient Temperature：23.1 °C; Liquid Temperature：22.3 °C DASY Configuration: • Probe: EX3DV4 - SN7515; ConvF(7.45, 7.45, 7.45) @ 2450 MHz; Calibrated: 2023/12/14 • Sensor-Surface: 1.4mm (Mechanical Surface Detection), z = 1.0, 31.0 • Electronics: DAE4 Sn1390; Calibrated: 2023/11/20 • Phantom: ELI v5.0_Left; Type: QDOVA002AA; Serial: TP:1222 • DASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Area Scan (6x7x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 22.334 W/kg Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 90.03 V/m; Power Drift = 0.04 dB Peak SAR (extrapolated) = 28.5 W/kg SAR(1 g) = 13.1 W/kg; SAR(10 g) = 5.94 W/kg Maximum value of SAR (measured) = 22.4 W/kg Report No.: BTL-FCC SAR-1-2403G134_Appendix A. Page 2 of 4 Test Laboratory: BTL Inc. Date: 2024/5/16 System Check_H5250_0516 DUT: Dipole D5GHzV2;SN:1160; Communication System: UID 0, CW (0); Frequency: 5250 MHz; Duty Cycle: 1:1 Medium parameters used (interpolated): f = 5250 MHz; σ = 4.778 S/m; ε r = 36.004; ρ = 1000 kg/m 3 Ambient Temperature：22.9 °C; Liquid Temperature：22.2 °C DASY Configuration: • Probe: EX3DV4 - SN7515; ConvF(5.46, 5.46, 5.46) @ 5250 MHz; Calibrated: 2023/12/14 • Sensor-Surface: 1.4mm (Mechanical Surface Detection), z = 1.0, 23.0 • Electronics: DAE4 Sn1390; Calibrated: 2023/11/20 • Phantom: ELI v5.0_Left; Type: QDOVA002AA; Serial: TP:1222 • DASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Area Scan (6x6x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 17.8 W/kg Zoom Scan (7x7x12)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 65.95 V/m; Power Drift = -0.08 dB Peak SAR (extrapolated) = 39.2 W/kg SAR(1 g) = 7.83 W/kg; SAR(10 g) = 2.22 W/kg Maximum value of SAR (measured) = 21.3 W/kg Report No.: BTL-FCC SAR-1-2403G134_Appendix A. Page 3 of 4 Test Laboratory: BTL Inc. Date: 2024/5/16 System Check_H5600_0516 DUT: Dipole D5GHzV2;SN:1160; Communication System: UID 0, CW (0); Frequency: 5600 MHz; Duty Cycle: 1:1 Medium parameters used: f = 5600 MHz; σ = 5.193 S/m; ε r = 35.155; ρ = 1000 kg/m 3 Ambient Temperature：22.9 °C; Liquid Temperature：22.2 °C DASY Configuration: • Probe: EX3DV4 - SN7515; ConvF(4.71, 4.71, 4.71) @ 5600 MHz; Calibrated: 2023/12/14 • Sensor-Surface: 1.4mm (Mechanical Surface Detection), z = 1.0, 23.0 • Electronics: DAE4 Sn1390; Calibrated: 2023/11/20 • Phantom: ELI v5.0_Left; Type: QDOVA002AA; Serial: TP:1222 • DASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Area Scan (6x6x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 18.2 W/kg Zoom Scan (7x7x12)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 56.22 V/m; Power Drift = 0.07 dB Peak SAR (extrapolated) = 45.4 W/kg SAR(1 g) = 8.12 W/kg; SAR(10 g) = 2.29 W/kg Maximum value of SAR (measured) = 22.6 W/kg Report No.: BTL-FCC SAR-1-2403G134_Appendix A. Page 4 of 4 Test Laboratory: BTL Inc. Date: 2024/5/16 System Check_H5750_0516 DUT: Dipole D5GHzV2;SN:1160; Communication System: UID 0, CW (0); Frequency: 5750 MHz; Duty Cycle: 1:1 Medium parameters used: f = 5750 MHz; σ = 5.372 S/m; ε r = 34.835; ρ = 1000 kg/m 3 Ambient Temperature：22.9 °C; Liquid Temperature：22.2 °C DASY Configuration: • Probe: EX3DV4 - SN7515; ConvF(4.89, 4.89, 4.89) @ 5750 MHz; Calibrated: 2023/12/14 • Sensor-Surface: 1.4mm (Mechanical Surface Detection), z = 1.0, 23.0 • Electronics: DAE4 Sn1390; Calibrated: 2023/11/2022 • Phantom: ELI v5.0_Left; Type: QDOVA002AA; Serial: TP:1222 • DASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Area Scan (6x6x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 18.0 W/kg Zoom Scan (7x7x12)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 54.54 V/m; Power Drift = 0.09 dB Peak SAR (extrapolated) = 46.0 W/kg SAR(1 g) = 7.85 W/kg; SAR(10 g) = 2.21 W/kg Maximum value of SAR (measured) = 22.0 W/kg

Report No.: BTL-FCC SAR-1-2403G134_Appendix B. Page 1 of 6 Test Laboratory: BTL Inc. Date: 2024/5/15 W06_802.11b_CH6_Horizontal Up_5mm DUT: Dongle; Communication System: UID 10012 - CAB, IEEE 802.11b WiFi 2.4 GHz (DSSS, 1 Mbp…
