2BCGWUB500PLUSLong Range Bluetooth USB Adapter

© 2024 TP-Link REV1.0.0 1910013705 User Guide Long Range Bluetooth USB Adapter UB500 Plus Contents Chapter 1. About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Chapter 2. Get to Know About Your Adapter. . . . . . . . . . . . . . . . . . . . . . . 2 Chapter 3. Connect to a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Chapter 4. Install Bluetooth Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 3. 1. Install Bluetooth Adapter’s Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 3. 2. Pair With Your Bluetooth Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 3. 3. Uninstall Bluetooth Adapter’s Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Chapter 5. Appendix: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 1 About This Guide This guide is a complement to Quick Installation Guide. The Quick Installation Guide instructs you on quick installation, and this guide provides the product overview and detailed instructions for each steps. When using this guide, please notice that features available of the adapter may vary by model and software version. The adapter’s availability may also vary by region or ISP. All images, steps, and descriptions in this guide are only examples and may not reflect your actual experience. Conventions In this guide, the following conventions are used: Convention Description Teal Underline Hyper links are in teal italic. You can click to redirect to a website or a specific section. Teal Contents to be emphasized and texts on the web page are in teal, including the menus, items, buttons, etc. Note: Ignoring this type of note might result in a malfunction or damage to the device. Tips: Indicates important information that helps you make better use of your device. *For support and warranty, please visit: http://www.tp-link.com/support † To ensure compatibility, you may need to update the adapter’s drivers after an OS update. You can check full list of supported OS in the download center at tp-link.com/download-center. More Info • The latest software and utility can be found at https://www.tp-link.com/download-center. • The Quick Installation Guide (QIG) can be found where you find this guide or inside the package of the product. • Specifications can be found on the product page at https://www.tp-link.com. • Our Technical Support contact information can be found at the Contact Technical Support page at https://www.tp-link.com/support. • A TP-Link Community is provided for you to discuss our products at https://community.tp-link.com. Chapter 1 Get to Know About Your Adapter This chapter introduces what the adapter can do. 3 Chapter 1 Get to Know about Your Adapter TP-Link Long Range Bluetooth USB Adapter supports advanced Bluetooth 5.3 and enables wireless connectivity with a wide range of devices such as computers, printers, phones, headsets, speakers, keyboards, controllers, etc. Plug in Win 11/10/8.1/7 system to enjoy a wireless communication with Bluetooth-enabled devices. • Supports Windows 11/10/8.1/7 • Backward compatible with Bluetooth 5.2/5.0/4.0 devices • Bluetooth Low Energy technology for energy-saving wireless connectivity • Adjustable, Multi-Directional Antenna improve user experience and performance in different environments. Chapter 2 Connect to a Computer This chapter introduces how to connect the adapter to your computer. 5 Chapter 2 Connect to a Computer 1. Before you start using your adapter, disable all existing Bluetooth devices (both built-in and third party) from the Device Manager on Windows. Note: To go to Device Manager: Right-click This PC or My Computer, select Manage, go to Device Manager and disable all existing Bluetooth devices. 2. Insert the adapter into a USB port on your computer directly. * The image is for demonstration only. Note: you can try to adjust the direction of the antenna for a better performance. Chapter 3 Install Bluetooth Driver This chapter introduces how to install your adapter’s driver, pair with your Bluetooth devices and uninstall your driver. The adapter is equipped with a Driver Setup Wizard, which can guide you through the installation process. This chapter includes the following sections: • Install Bluetooth Adapter’s Driver • Pair With Your Bluetooth Devices • Uninstall Bluetooth Adapter’s Driver 7 Chapter 3 Install Bluetooth Driver 3. 1. Install Bluetooth Adapter’s Driver 1. Download the driver at https://www.tp-link.com/download-center Tip: For Windows 11/10/8.1 system, the driver installation will automatically start when connected to the internet. If not, please download the driver manually. 2. Extract the downloaded file and run the Setup.exe to start driver installation. 3. Follow the instructions to complete installation. 4. Once the process is finished, restart your computer. Notes: • Your TP-Link Bluetooth USB adapter will be listed in the Device Manager when the driver is installed correctly. • If the driver installation fails, disable the antivirus software and firewall, then try again. • In Windows 7, if a Windows Security message pops up, refer to https://www.tp-link.com/faq-2760.html 3. 2. Pair With Your Bluetooth Devices For Windows 7: 1. Open Start menu to access Devices and Printers. 2. Select Add Device to choose the device that you want to pair with your computer. 8 Chapter 3 Install Bluetooth Driver 3. Select the found-out device from the list and click Next. Note: Make sure your Bluetooth device is set to be discoverable. 4. Click Finish when completing the pairing. Note: During the pairing you may be prompted to enter the pairing code. You need to enter the identical code to both devices. 9 Chapter 3 Install Bluetooth Driver For Windows 8.1: 1. Open Start menu, type Bluetooth to access Bluetooth settings. 2. Toggle on Bluetooth. 3. Select yo…

Text truncated - open the document above for the full version.

TP-LINK CORPORATION PTE.LTD. 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 012423-17 rev2 Statement for 47 CFR section 2.911(d)(5)(i) TP-LINK CORPORATION PTE.LTD. certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) TP-LINK CORPORATION PTE.LTD. certifies that, as of the date of the filing of this application, the applicant ☐ - is /- is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: ____Sarah Wang__ (Signature 2 ) (Print name) Title: Compliance manager Company: TP-LINK CORPORATION PTE.LTD. PTE.LTD.) Telephone: +86 755 21534921 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters should be placed on appropriate letterhead.

U.S. AgentDesignationfor Serviceof Process (Applicantand U.S. Agentare SeparateParties) TO:AmericanCertificationBody, Inc. 313 Park Avenue Suite 300 Falls Church,VA 22046 ATTENTION:FCC Certification– Section2.911(d)(7)Information DesignatedU.S. Agent CompanyName:VISHTECLLC ContactName:Alan Graham StreetAddress:9888 W BelleviewAve Ste 2142 DenverCO 80123 City/Province/Zip:80123 TelephoneNo:（571）4007350 Email: [email protected] FRN #: 0033407131 This letter is to confirmthat we (“the DesignatedU.S. Agent ”) have acceptedthe responsibilityto act as the DesignatedU.S. Agent for Serviceof Processfor the limited purposeof compliancewith section47 CFR 2.911(d)(7)only and not for any other purpose,on behalfof theApplicantnoted below. U.S. AgentSignature: Date: 2023/8/28 Signedby (PrintedName/Title): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: TP-LINK CORPORATION PTE. LTD. Grantee Code: 2BCGW FRN #: 0034122556 Contact Name: Sarah Wang Street Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 City/Province/Zip: Singapore Telephone No: +65-97538388 Email: [email protected] Applicant Signature 1 : Date: 2023/8/28 Signed by (Printed Name/Title) S arah W ang 1 - Lettersshouldbe placedon appropriateletterhead.

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: 2BCGWUB500PLUS Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2024-06-12

Declaration of Authorization We Name: TP-LINK CORPORATION PTE. LTD. Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: Long Range Bluetooth USB Adapter FCC ID: 2BCGWUB500PLUS Model: UB500 Plus Brand: tp-link Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2024-06-12

Declaration of Conformity We Name: TP-LINK CORPORATION PTE. LTD. Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Declare that: Product: Long Range Bluetooth USB Adapter FCC ID: 2BCGWUB500PLUS Model: UB500 Plus Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2024-06-12

Report No.: 2405TW0120-UE 1 of 3 External Photograph (1) EUT Photo (2) EUT Photo Report No.: 2405TW0120-UE 2 of 3 (3) EUT Photo (4) EUT Photo Report No.: 2405TW0120-UE 3 of 3 (5) EUT Photo (6) EUT Photo

Model: UB500 Plus RoHS FCC ID: 2BCGWUB500PLUSIC: 31152-UB500PLUS 201-240238 1.16±0.2mm 0.55±0.2mm 1.31±0.2mm 1.35±0.2mm

Report No.: 2405TW0120-UI 1 of 4 Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2405TW0120-UI 2 of 4 (3) EUT Photo (4) EUT Photo Report No.: 2405TW0120-UI 3 of 4 (5) EUT Photo (6) EUT Photo Report No.: 2405TW0120-UI 4 of 4 (7) EUT Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 2405RSU025-U1 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 2024-06-18 Template Version:0.0 1 of 43 SAR MEASUREMENT R EPORT FCC ID: 2BCGWUB500PLUS Applicant: TP-LINK CORPORATION PTE. LTD. Product: Long Range Bluetooth USB Adapter Model No.: UB500 Plus Brand Name: tp-link FCC Rule Part(s): FCC 47 CFR Part 2.1093 Result: Complies Received Date: 2024-05-22 Test Date: 2024-06-07 Reviewed By: Kevin Guo Approved By: Robin Wu The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in IEEE1528, KDB 447498 and KDB 865664. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2405RSU025- U1 2 of 43 Revision History Report No. Version Description Issue Date Note 2405RSU025-U1 V01 Initial Report 2024-06-18 Valid Report No.: 2405RSU025-U1 3 of 43 CONTENTS Description Page 1. General Information ............................................................................................................................... 5 1.1. Applicant ...................................................................................................................................... 5 1.2. Manufacturer ................................................................................................................................ 5 1.3. Testing Facility ............................................................................................................................. 5 1.4. Product Information ...................................................................................................................... 6 1.5. Radio Specification under Test .................................................................................................... 6 1.6. Antennas Details .......................................................................................................................... 6 2. Summary of Test Result ........................................................................................................................ 7 2.1. Test Standards ............................................................................................................................. 7 2.2. Environment Condition ................................................................................................................. 7 2.3. RF Exposure Limits ...................................................................................................................... 7 2.4. Test Result Summary .................................................................................................................. 8 3. Specific Absorption Rate (SAR) ............................................................................................................ 9 3.1. Introduction .................................................................................................................................. 9 3.2. Definition ...................................................................................................................................... 9 4. DASY6 Measurement System ............................................................................................................. 10 4.1. Introduction ................................................................................................................................ 10 4.2. DASY6 Measurement System Diagram .................................................................................... 10 4.3. System Components Details ...................................................................................................... 11 5. The SAR Measurement Procedure ..................................................................................................... 22 5.1. Measurement Process Diagram ................................................................................................ 22 5.2. Test Position Definition .............................................................................................................. 23 5.3. Test Procedure .......................................................................................................................... 26 6. System Verificaiton .............................................................................................................................. 29 6.1. SAR Tissue Check ..................................................................................................................... 29 6.2. SAR System Check ................................................................................................................... 32 7. Analysis and Results ........................................................................................................................... 34 7.1. Antenna Location ....................................................................................................................... 34 7.2. Conducted Power ...................................................................................................................... 34 7.3. SAR Test Results ....................................................................................................................... 35 8. Measuring Instrument .......................................................................................................................... 36 9. Measurement Uncertainty.................................................................................................................... 37 Annex A - System Check Result .................................................................................................................. 39 Annex B - Test…

Text truncated - open the document above for the full version.

MRT Technology (Taiwan) Co., Ltd Report No.: 2405TW0120-U2 Phone: +886-3-3288388 Report Version: 1.0 Fax: +886-3-3288918 Issue Date: 2024-06-18 Web: www.mrt-cert.com Page Number: 1 of 97 RF MEASUREMENT REPORT FCC ID : 2BCGWUB500PLUS APPLICANT : TP-LINK CORPORATION PTE. LTD. Application Type : Certification Product : Long Range Bluetooth USB Adapter Model No. : UB500 Plus Brand Name : tp-link FCC Classification : Digital Transmission System (DTS) FCC Rule Part(s) : Part 15.247 Test Procedure(s) : ANSI C63.10-2013 Received Date : May 28, 2024 Test Date : May 30, 2024~June 5, 2024 Tested By : ( Kaunaz Lee ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) The test results only relate to the tested sample. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2405TW0120-U2 Page Number: 2 of 97 Revision History Report No. Version Description Issue Date Note 2405TW0120-U2 1.0 Original Report 2024-06-18 Valid Report No.: 2405TW0120-U2 Page Number: 3 of 97 CONTENTS Description Page 1. INTRODUCTION ..................................................................................................................... 6 1.1. Scope .................................................................................................................................... 6 1.2. MRT Test Location ................................................................................................................ 6 2. PRODUCT INFORMATION ..................................................................................................... 7 2.1. Equipment Description .......................................................................................................... 7 2.2. Product Specification Subjective to this Standard .................................................................. 7 2.3. Test Mode ............................................................................................................................. 7 2.4. Operation Frequency / Channel List ...................................................................................... 8 2.5. Test Configuration ................................................................................................................. 9 2.6. Test System Details .............................................................................................................. 9 2.7. Test Software ........................................................................................................................ 9 2.8. Duty Cycle ........................................................................................................................... 10 2.9. EMI Suppression Device(s)/Modifications ........................................................................... 11 2.10. Labeling Requirements ....................................................................................................... 11 3. DESCRIPTION of TEST ........................................................................................................ 12 3.1. Evaluation Procedure .......................................................................................................... 12 3.2. AC Line Conducted Emissions ............................................................................................ 12 3.3. Radiated Emissions ............................................................................................................ 13 4. ANTENNA REQUIREMENTS ................................................................................................ 14 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................ 15 6. MEASUREMENT UNCERTAINTY ......................................................................................... 16 7. TEST RESULT ...................................................................................................................... 17 7.1. Summary ............................................................................................................................. 17 7.2. 6dB Bandwidth Measurement ............................................................................................. 18 7.2.1. Test Limit ......................................................................................................................... 18 7.2.2. Test Procedure used ....................................................................................................... 18 7.2.3. Test Setting ..................................................................................................................... 18 7.2.4. Test Setup ....................................................................................................................... 18 7.2.5. Test Result ...................................................................................................................... 19 7.3. Output Power Measurement ................................................................................................ 24 7.3.1. Test Limit ......................................................................................................................... 24 7.3.2. Test Procedure Used ....................................................................................................... 24 7.3.3. Test Setting ..................................................................................................................... 24 7.3.4. Test Setup ....................................................................................................................... 24 7.3.5. Test Result of Output Power ..............…

Text truncated - open the document above for the full version.

Report No.: 2405TW0120-U2 Page Number: 38 of 97 LE Coded S=8 CH00 (2402MHz) LE(1Mbps) CH00 (2402MHz) LE(1Mbps) CH19 (2440MHz) LE(1Mbps) CH19 (2440MHz) LE(1Mbps) CH39 (2480MHz) LE(1Mbps) CH39 (2480MHz) LE(1Mbps) Report No.: 2405TW0120-U2 Page Number: 39 of 97 7.6. Radiated Spurious Emission Measurement 7.6.1. Test Limit All out of band emissions appearing in a restricted band as specified in Section 15.205 of the Title 47 CFR must not exceed the limits shown in Table per Section 15.209. FCC Part 15 Subpart C Paragraph 15.209 Frequency [MHz] Field Strength [V/m] Measured Distance [Meters] 0.009 - 0.490 2400/F (kHz) 300 0.490 - 1.705 24000/F (kHz) 30 1.705 - 30 30 30 30 - 88 100 3 88 - 216 150 3 216 - 960 200 3 Above 960 500 3 7.6.2. Test Procedure Used ANSI C63.10 - 2013 Section 6.3 (General Requirements) ANSI C63.10 - 2013 Section 6.4 (Standard test method below 30MHz) ANSI C63.10 - 2013 Section 6.5 (Standard test method above 30MHz to 1GHz) ANSI C63.10 - 2013 Section 6.6 (Standard test method above 1GHz) 7.6.3. Test Setting Peak Field Strength Measurements 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. RBW = as specified in Table 1 3. VBW = 3MHz 4. Detector = peak Report No.: 2405TW0120-U2 Page Number: 40 of 97 5. Sweep time = auto couple 6. Trace mode = max hold 7. Trace was allowed to stabilize Table 1 - RBW as a function of frequency Frequency RBW 9 ~ 150 kHz 200 ~ 300 Hz 0.15 ~ 30 MHz 9 ~ 10 kHz 30 ~ 1000 MHz 100 ~ 120 kHz > 1000 MHz 1 MHz Average Field Strength Measurements 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. RBW = 1MHz 3. VBW ≥ 1/T 4. De As an alternative, the instrument may be set to linear detector mode. Ensure that video filtering is applied in linear voltage domain (rather than in a log or dB domain). Some instruments require linear display mode in order to accomplish this. Others have a setting for Average-VBW Type, which can be set to “Voltage” regardless of the display mode 5. Detector = Peak 6. Sweep time = auto 7. Trace mode = max hold 8. Allow max hold to run for at least 50 times (1/duty cycle) traces Report No.: 2405TW0120-U2 Page Number: 41 of 97 7.6.4. Test Setup 9kHz ~ 30MHz Test Setup: 30MHz ~ 1GHz Test Setup: Report No.: 2405TW0120-U2 Page Number: 42 of 97 1GHz ~ 25GHz Test Setup: Report No.: 2405TW0120-U2 Page Number: 43 of 97 7.6.5. Test Result EUT Long Range Bluetooth USB Adapter Date of Test 2024-05-30 Factor VULB 9162 Temp. / Humidity 23C /64% Polarity Horizontal Site / Test Engineer AC1 / Todd Test Mode BLE_TX_1Mbps_CH 19 Test Voltage By Notebook PC No Frequency (MHz) Reading (dBuV) C.F (dB/m) Measurement (dBuV/m) Margin (dB) Limit (dBuV/m) Height (cm) Angle (deg) Remark (QP/PK/AV) 1 46.230 2.83 20.60 23.43 -16.57 40.00 150 335 QP 2 78.328 10.51 14.21 24.72 -15.28 40.00 150 145 QP 3 * 101.758 12.60 18.50 31.09 -12.41 43.50 150 295 QP 4 159.216 13.64 15.60 29.24 -14.26 43.50 150 170 QP 5 261.010 11.33 20.24 31.57 -14.43 46.00 100 245 QP 6 440.503 8.15 24.01 32.15 -13.85 46.00 150 260 QP Note: 1. " *", means this data is the worst emission level. 2. C.F (Correction Factor) = Antenna Factor (dB/m) + Cable Loss (dB). 3. Measurement (dBuV/m) = Reading(dBuV) + C.F (Correction Factor). 4. The emission levels of other frequencies are very lower than the limit and not show in test report. 5. The amplitude of radiated emissions (frequency range from 9kHz to 30MHz) is that proximity to ambient noise, which also are attenuated more than 20dB below the permissible value. Therefore, the data is not presented in the report. Report No.: 2405TW0120-U2 Page Number: 44 of 97 EUT Long Range Bluetooth USB Adapter Date of Test 2024-05-30 Factor VULB 9162 Temp. / Humidity 23C /64% Polarity Vertical Site / Test Engineer AC1 / Todd Test Mode BLE_TX_1Mbps_CH 19 Test Voltage By Notebook PC No Frequency (MHz) Reading (dBuV) C.F (dB/m) Measurement (dBuV/m) Margin (dB) Limit (dBuV/m) Height (cm) Angle (deg) Remark (QP/PK/AV) 1 42.177 5.55 20.15 25.70 -14.30 40.00 100 105 QP 2 77.403 4.88 14.38 19.26 -20.74 40.00 100 310 QP 3 112.192 6.96 18.19 25.15 -18.35 43.50 100 260 QP 4 152.497 7.43 15.37 22.81 -20.69 43.50 150 235 QP 5 263.729 9.55 20.19 29.74 -16.26 46.00 150 315 QP 6 * 435.890 8.76 23.96 32.72 -13.28 46.00 100 325 QP Note: 1. " *", means this data is the worst emission level. 2. C.F (Correction Factor) = Antenna Factor (dB/m) + Cable Loss (dB). 3. Measurement (dBuV/m) = Reading(dBuV) + C.F (Correction Factor). 4. The emission levels of other frequencies are very lower than the limit and not show in test report. 5. The amplitude of radiated emissions (frequency range from 9kHz to 30MHz) is that proximity to ambient noise, which also are attenuated more than 20dB below the permissible value. Therefore, the data is not presented in the report. Report No.: 2405TW0120-U2 Page Number: 45 of 97 EUT Long Range Bluetooth USB Adapter Date of Test 2024-06-05 Factor BBHA 9120D Temp. / Humidity 25C /61% Polarity Horizontal Site / Test Engineer AC1 / Todd Test Mode BLE_TX_1Mbps_CH 0 Test Voltage By Notebook PC No Frequency (MHz) Reading (dBuV) C.F (dB/m) Measurement (dBuV/m) Margin (dB) Limit (dBuV/m) Height (cm) Angle (deg) Remark (QP/PK/AV) 1 4804.000 40.72 3.71 44.43 -29.57 74.00 100 309 Peak 2 7206.000 34.57 11.57 46.14 -27.86 74.00 100 115 Peak 3 * 9608.000 32.67 15.69 48.36 -25.64 74.00 100 105 Peak Note: 1. " *", means this data is the worst emission level. 2. C.F (Correction Factor) = Antenna Factor (dB/m) + Cable Loss (dB) – Preamplifier(dB). 3. Measurement (dBuV/m) = Reading(dBuV) + C.F (Correction Factor). 4. The emission levels of other frequencies are very lower than the limit and not show in test report. Report No.: 2405TW0120-U2 Page Number: 46 of 97 EUT Long Range Bluetooth USB Adapter Date of Test 2024-06-05 Factor BBHA 9120D Temp. / Humidity 25C /61% Polarity Vertical Site / Test Engineer AC1 / Todd Test Mode BLE_TX_1Mbps_CH 0 Test Voltage By Notebook …
