Deco XM73 (4-Pack) Outdoor/Indoor Mesh Wi-Fi User Guide AX5400 Indoor/ Outdoor Whole Home Mesh Wi-Fi 6 System 1910013725 REV1.26.0 © 2024 TP-Link Contents About This Guide ···················································· 1 Appearance(Deco XM73-Outdoor) ·············· 2 Appearance(Deco XM73) ·································· 3 Set Up Your Indoor Deco ···································· 4 Set Up Your Outdoor Deco ································ 8 Troubleshooting ····················································11 Authentication ························································12 1 About This Guide This guide provides a brief introduction to Deco Indoor/Outdoor Whole Home Mesh Wi-Fi 6 System and regulatory information. Features available in Deco may vary by model and software version. Deco availability may also vary by region or ISP. All images, steps, and descriptions LQWKLVJXLGHDUHRQO\H[DPSOHVDQGPD\QRWUHưHFW\RXUDFWXDO'HFRH[SHULHQFH Conventions In this guide, the following conventions are used: Convention Description Deco S tands for Deco Whole Home Mesh Wi-Fi System/ Unit. Underline Hyperlinks are in teal and underlined. You can click to U HGLUHFWWRDZHEVLWHRUDVSHFLƮFVHFWLRQ Teal Key information appears in teal, including management page t ext such as menus, items, buttons and so on. Note: Ignoring this type of note might result in a malfunction or damage to the device. Tips: Indicates important information that helps you make better use of your device. More Info • 6SHFLƮFSURGXFWLQIRUPDWLRQFDQEHIRXQGRQWKHSURGXFWSDJHDW https://www.tp-link.com. • A Technical Community is provided for you to discuss our products at https://community.tp-link.com. • Our Technical Support contact information can be found at the Help center of the Deco app and the Contact Technical Support page at https://www.tp-link.com/support. Speed/ Coverage/Device Quantity Disclaimer Maximum wireless signal rates are the physical rates derived from IEEE 6WDQGDUGVSHFLƮFDWLRQV$FWXDOZLUHOHVVGDWDWKURXJKSXWDQG wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and GHQVLW\RIWUDƱFDQGFOLHQWORFDWLRQ MU-MIMO Disclaimer Use of MU-MIMO requires clients to also support MU-MIMO. IoT Compatibility Disclaimer IoT compatibility refers only to smart devices that can be controlled via the Deco app. Other wireless devices can still connect to Deco for normal Wi-Fi use. Seamless Roaming Disclaimer Clients need to support 802.11k/v/r and may require additional set up. Performance may vary depending on the client device. 2 Appearance(Deco XM73-Outdoor) Each Deco XM73-Outdoor has an LED that changes color according to its status, a mounting tab, two gigabit ports, a power slot, and a Reset button. See the explanation below: Yellow pulse: Deco is resetting. Yellow solid: Deco is starting up. Blue pulse: Deco is ready for setup or WPS in progress. Blue solid: Deco is setting up. Green pulse: 'HFRLVXSJUDGLQJƮUPZDUH Green solid: 'HFRLVUHJLVWHUHGDQGDOOLVZHOO Red pulse: 'HFRLVGLVFRQQHFWHGIURPPDLQ'HFR Red solid: Deco has an issue. Wall/Pole Mounting Tab )RUFRQQHFWLQJ'HFRWRDSROHRUZDOOZLWKWKH SURYLGHGPRXQWLQJNLWV Power Slot: )RUSRZHULQJXS'HFRYLDWKHSURYLGHGSRZHU cord. Reset Button: Press for 1 second and release to reset Deco to IDFWRU\GHIDXOWVHWWLQJV7KHOLJKWFKDQJLQJIURP SXOVLQJ\HOORZWRVROLG\HOORZLQGLFDWHVDVXFFHVVIXO reset. 2× Gigabit Ports with Power over Ethernet support: •As the PoE port:)RUSRZHULQJ'HFRXSYLDD36( GHYLFH VXFKDVD3R(VZLWFK  •As the WAN/LAN port: For connecting Deco to \RXUPRGHPWKH(WKHUQHWRXWOHWRURWKHU internet devices. 3 Appearance(Deco XM73) Each Deco XM73 has an LED that changes color according to its status, two Ethernet ports, a power slot, and a Reset button. See the explanation below: Pulse Yellow: Deco is resetting. Solid Yellow: Deco is starting up. Pulse Blue: Deco is ready for setup. Solid Blue: Deco is setting up. Pulse Green: 'HFRLVXSJUDGLQJƮUPZDUH Solid Green: Deco is all set up and connected. Pulse Red: The satellite Deco is disconnected IURPWKHPDLQ'HFR Solid Red: Deco has an issue. Ethernet Ports: )RUFRQQHFWLQJ'HFRWR\RXUPRGHPWKH(WKHUQHWRXWOHW RUIRURWKHULQWHUQHWVHUYLFHVLQ:LUHOHVV5RXWHUPRGH Reset Button: Press for 1 second and release to reset Deco to factory GHIDXOWVHWWLQJV7KHOLJKWFKDQJLQJIURPSXOVLQJ\HOORZWR VROLG\HOORZLQGLFDWHVDVXFFHVVIXOUHVHW Power Slot: )RUFRQQHFWLQJ'HFRWRWKHSRZHUVRFNHWYLDWKHSURYLGHG SRZHUDGDSWHU 4 Set Up Your Indoor Deco First let's start by setting up the indoor Deco network. Get the TP-Link Deco app for iOS or Android, then follow the app to walk through the setup. 1. Get the Deco app Download and install the Deco app from Google Play or App Store, or by scanning the QR code below. 2. Log in with TP-Link ID Open the app and log in with your TP-Link ID. If \RXGRQoWKDYHD73/LQN,'FUHDWHRQHƮUVW Tip: If you forgot your login password, tap Forgot Password. The app will help you reset your password. 3. Select your indoor Deco model Search for and select your indoor Deco model. If you have multiple indoor Decos, set up only RQHRIWKHPƮUVW or 5 4. Scan your indoor Deco's product label Scan the QR code on the product label at the bottom of your indoor Deco for a quicker setup. You can also set it up manually. 4. Plug in your indoor Deco 3RZHURƬ\RXUPRGHP&RQQHFW\RXULQGRRU Deco to the modem and power them both on. If you don't have a modem, connect your indoor Deco directly to the Ethernet outlet. 6. Wait until indoor Deco's LED pulses blue Wait until your indoor Deco's LED pulses blue, then your phone/tablet will connect to the indoor Deco's default Wi-Fi automatically. 6 9. Create your Wi-Fi network Set a network name…

Text truncated - open the document above for the full version.

TP-LINK CORPORATION PTE.LTD. To: Federal Communications Commission Date: 2024/07/02 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section 2.911(d)(5)(i) and Section 2.911(d)(5)(ii) (KDB 986446 D01 Covered Equipment) Section 2.911(d)(5)(i) TP-LINK CORPORATION PTE.LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Section 2.911(d)(5)(ii) TP-LINK CORPORATION PTE.LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Type of E quipment subject to FCC Certification: DTS,NII FCC ID: 2BCGWXM73OD If you have any questions, please feel free to contact me Contact Person: Sarah Wang Position in the Company: Regulatory Compliance Manager Date of Signature: 2024/07/02 Signatory (signature of the applicant)

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO:AmericanCertificationBody,Inc. 313ParkAvenue Suite300 FallsChurch, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name:VISHTEC LLC Contact Name:Alan Graham Street Address:9888 W Belleview Ave Ste 2142 Denver CO 80123 City/Province/Zip:80123 Telephone No:（571）4007350 Email:[email protected] FRN #: 0033407131 This letter is to confirm that we (“the Designated U.S. Agent”) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process for the limited purpose of compliance with section 47 CFR 2.911(d)(7) only and not for any other purpose, on behalf of theApplicantnoted below. U.S. Agent Signature: Date:2023/8/28 Signed by (Printed Name/Title): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: TP-LINK CORPORATION PTE. LTD. Grantee Code: 2BCGW FRN #: 0034122556 Contact Name: Sarah Wang Street Address: 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 City/Province/Zip: Singapore Telephone No: +65-97538388 Email: [email protected] Applicant Signature 1 : Date: 2023/8/28 Signed by (Printed Name/Title) S arah W ang 1 - Lettersshouldbeplacedonappropriateletterhead.

TP-LINK CORPORATION PTE. LTD. 030122-15 Authority to Act as Agent Date: July 2, 2024 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: BTL Inc./Rose Liu is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: 2025-07-02 By: __________________________ Sarah Wang (Signature 1 ) (Print name) Title: Regulatory Compliance Manager On behalf of: TP-LINK CORPORATION PTE.LTD. (Company Name) Telephone: +86 755 21534921 1 - M ust be signed by ap p licant contact given for ap p licant on the FCC site, or by the authorized agent if an ap p rop riate authorized agent letter has been p rovided. Letters should be p laced on ap p rop riate letterhead.

TP-LINK CORPORATION PTE. LTD. 030122-15 Request for Confidentiality Date: July 2, 2024 Subject: Confidentiality Request for: 2BCGWXM73OD Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term ☐ Permanent * 3 User’s Manual TP-LINK CORPORATION PTE. LTD. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Regulatory Compliance Manager Sarah Wang (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be p rovided to ACB before p ermanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the sp ecific Document link for D01 found at: http s://ap p s.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding sp ecific information that must accomp any these requests. 2 - Please refer to http s://acbcert.com/documents/misc-docs/M emo-Short-Term-Vs-Standard-Confidentiality .p df for comp lete details. 3 - M ust be signed by ap p licant contact given for ap p licant on the FCC site, or by the authorized agent if an ap p rop riate authorized agent letter has been p rovided. Letters should be p laced on ap p rop riate letterhead.

Declaration of Conformity We Name: TP-LINK CORPORATION PTE. LTD. Address: 7 Temasek Boulevard #29-03, Suntec Tower One, Singapore 038987, Singapore Declare that: Product: AX5400 Indoor/Outdoor Whole Home Mesh Wi-Fi 6 System FCC ID: 2BCGWXM73OD Model: Deco XM73-Outdoor Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2024-07-02

TP-LINK CORPORATION PTE. LTD. Wi-Fi Channel 12 and 13 Declaration Letter Date: 2024-07-02 We, the undersigned company Company Name: TP-LINK CORPORATION PTE. LTD. Address: 7 Temasek Boulevard #29-03, Suntec Tower One, Singapore 038987,Singapore Declare that: Product description: AX5400 Indoor/Outdoor Whole Home Mesh Wi-Fi 6 System Type designation: Deco XM73-Outdoor Brand: tp-link FCC ID: 2BCGWXM73OD Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us,thank you~ Sincerely, Signature: ________________________ Name : Sarah Wang Te l: +86 755 21534921 Email: ce [email protected]

Project No.: 2405G047 Page 2 of 20 Project No.: 2405G047 Page 3 of 20 Project No.: 2405G047 Page 4 of 20 Project No.: 2405G047 Page 5 of 20

C B A 12 C 345678 B E D A 9 123456789 A X5400 Indoor/Outdoor Whole Home Mesh Wi-Fi 6 System Model: Deco XM73-Outdoor Power: 100-240V~50/60Hz 0.5A 802.3at PoE: 42.5-57V 0.6A This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID: 2BCGWXM73OD Raintight CONFORMS TO UL STD. 62368-1 CERTIFIED TO CSA STD. 62368-1 For outdoor usage, use this product with ground fault circuit interrupter (GFCI) outlet. 22.5±0.8 121.3 39.9±0.8 21.4±0.8 22.5±0.8

Project No.: 2405G047 Page 6 of 20 2.4G&5G Ant. 1 2.4G&5G Ant. 2 2.4G Ant. 3 2.4G Ant. 4 5G Ant. 4 5G Ant. 3 Project No.: 2405G047 Page 7 of 20 Project No.: 2405G047 Page 8 of 20 Project No.: 2405G047 Page 9 of 20 Project No.: 2405G047 Page 10 of 20 Project No.: 2405G047 Page 11 of 20 Project No.: 2405G047 Page 12 of 20 Project No.: 2405G047 Page 13 of 20 Project No.: 2405G047 Page 14 of 20 Project No.: 2405G047 Page 15 of 20 Project No.: 2405G047 Page 16 of 20 Project No.: 2405G047 Page 17 of 20 Project No.: 2405G047 Page 18 of 20 Project No.: 2405G047 Page 19 of 20 Project No.: 2405G047 Page 20 of 20

Report No.: BTL-FCCP-4-2405G047 Page 1 of 6 FCC RF EXPOSURE REPORT FCC ID: 2BCGWXM73OD Project No. : 2405G047 Equipment : AX5400 Indoor/Outdoor Whole Home Mesh Wi-Fi 6 System Brand Name : tp-link Test Model : Deco XM73-Outdoor Series Model : N/A Applicant : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Manufacturer : TP-LINK CORPORATION PTE. LTD. Address : 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987 Date of Receipt : May 22, 2024 Date of Test : May 23, 2024 ~ Jun. 24, 2024 Issued Date : Jul. 02, 2024 Report Version : R00 Test Sample : Engineering Sample No.: SSL2024052276 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 & KDB 447498 D01 v06 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Grani Zhou Approved by : Chay Cai Room 108, Building 2, No.1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong, People’s Republic of China. Tel: +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-4-2405G047 Page 2 of 6 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-4-2405G047 R00 Original Report. Jul. 02, 2024 Valid Report No.: BTL-FCCP-4-2405G047 Page 3 of 6 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 2. ANTENNA SPECIFICATION For 2.4GHz: Ant. Manufacturer P/N Antenna Type Connector Gain (dBi) Note 1 TP-LINK CORPORATION PTE. LTD. 3101505462 Dipole ipex 1.9 Horizontal 2 TP-LINK CORPORATION PTE. LTD. 3101506968 Dipole ipex 1.9 3 TP-LINK CORPORATION PTE. LTD. 3101505464 Dipole ipex 1.5 Vertical 4 TP-LINK CORPORATION PTE. LTD. 3101505465 Dipole ipex 1.5 Note: 1) This EUT supports CDD, the antennas Directional gain which declared by customer is 4.7dBi. 2) Beamforming Gain: 3 dB, that is Directional gain=1.9+3=4.9dBi. 3) All antennas had been pre-tested and found that Horizontal antennas were the worst case 4) The antenna gain and beamforming gain are provided by the manufacturer. For 5GHz: Ant. Brand P/N Antenna Type Connector Gain (dBi) 1 TP-LINK CORPORATION PTE. LTD. 3101505462 Dipole ipex 2 2 TP-LINK CORPORATION PTE. LTD. 3101506968 Dipole ipex 2 3 TP-LINK CORPORATION PTE. LTD. 3101506969 Dipole ipex 2 4 TP-LINK CORPORATION PTE. LTD. 3101506970 Dipole ipex 2 Note: 1) This EUT supports CDD, the antennas Directional gain which declared by customer is 7 dBi. 2) Beamforming Gain: 6 dB, that is Directional gain=2+6=8 dBi. 3) The antenna gain and beamforming gain are provided by the manufacturer. Report No.: BTL-FCCP-4-2405G047 Page 4 of 6 3. TABLE FOR ANTENNA CONFIGURATION For 2.4GHz_Non Beamforming: Operating Mode TX Mode 2TX IEEE 802.11b V(Ant. 1 + Ant. 2) IEEE 802.11g V(Ant. 1 + Ant. 2) IEEE 802.11n(HT20) V(Ant. 1 + Ant. 2) IEEE 802.11n(HT40) V(Ant. 1 + Ant. 2) IEEE 802.11ac(VHT20) V(Ant. 1 + Ant. 2) IEEE 802.11ac(VHT40) V(Ant. 1 + Ant. 2) IEEE 802.11ax(HE20) V(Ant. 1 + Ant. 2) IEEE 802.11ax(HE40) V(Ant. 1 + Ant. 2) For 2.4GHz_Beamforming: Operating Mode TX Mode 2TX IEEE 802.11n(HT20) V(Ant. 1 + Ant. 2) IEEE 802.11n(HT40) V(Ant. 1 + Ant. 2) IEEE 802.11ac(VHT20) V(Ant. 1 + Ant. 2) IEEE 802.11ac(VHT40) V(Ant. 1 + Ant. 2) IEEE 802.11ax(HE20) V(Ant. 1 + Ant. 2) IEEE 802.11ax(HE40) V(Ant. 1 + Ant. 2) Report No.: BTL-FCCP-4-2405G047 Page 5 of 6 For 5GHz_Non Beamforming: Operating Mode TX Mode 4TX IEEE 802.11a V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11n(HT20) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11n(HT40) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac(VHT20) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac(VHT40) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac(VHT80) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac(VHT160) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ax(HE20) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ax(HE40) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ax(HE80) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ax(HE160) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) For 5GHz_Beamforming: Operating Mode TX Mode 4TX IEEE 802.11n(HT20) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11n(HT40) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac(VHT20) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac(VHT40) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac(VHT80) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac(VHT160) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ax(HE20) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ax(HE40) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ax(HE80) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ax(HE160) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) Report No.: BTL-FCCP-4-2405G047 Page 6 of 6 4. CALCULATED RESULT For 2.4GHz_Non Beamforming: Directional gain (dBi) Directional gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 4.7 2.9512 29.75 944.0609 0.38511 1 Complies For 2.4GHz_Beamforming: Directional gain (dBi) Directional gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 4.9 3.0903 28.51 709.5778 0.30310 1 Complies For 5GHz_Non Beamforming: Directional gain (dBi) Directional gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 7 5.0119 28.96 787.0458 0.54524 1 Complies For 5GHz_Beamforming: Directional gain (dBi) Directional gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 8 6.3096 27.95 623.7348 0.54399 1 Complies For the max simultaneous transmission MPE: R…
