2BMXI-CMBC5Usmart battery camera

Hangzhou SuperAcme Electronics Technology Co., Ltd.

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Feb 12, 2026
Application Purpose: Original Equipment
Equipment Note: smart battery camera
Frequency Range: 5180.00000000 - 5240.00000000
Company: Hangzhou SuperAcme Electronics Technology Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

CM-BC5U 02 Connect Camera ( Compatible con Wi-Fi de doble banda (2,4 GHz y 5 GHz)) The cam- - era support both 2.4G & 5G HZ [email protected] FCC ID: 2BFCP-CMBC5U

Test Report

Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0209-22 Page: 1 of 111 FCC ID: 2BMXI-CMBC5U TB-RF-073-3.1 RF Test Data for 5G Wi-Fi (Conducted Measurements) General Description of EUT EUT Name: smart battery camera Model: CM-BC5U Sample ID: HC-C-202512-0209-01-01 Environmental Conditions Ambient Temperature: 25.6°C Ambient Humidity: 45.8%RH Test Power Supply: DC 3.6V Test Engineer: Kael Li Note: For a more detailed features description, please refer to the report TBR-C-202512-0209-22 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0209-22 Page: 2 of 111 FCC ID: 2BMXI-CMBC5U TB-RF-073-3.1 Contents 1: Emission Bandwidth ...................................................................................................................................... 3 1.1 Test Result ......................................................................................................................................... 3 1.2 Test Graphs ....................................................................................................................................... 5 2: Occupied channel bandwidth ...................................................................................................................... 18 2.1 Test Result ....................................................................................................................................... 18 2.2 Test Graphs ..................................................................................................................................... 20 3: Min emission bandwidth ............................................................................................................................. 33 3.1 Test Result-B4 ................................................................................................................................. 33 3.2 Test Graphs-B4 ............................................................................................................................... 34 4: Duty Cycle .................................................................................................................................................... 37 4.1 Test Result ....................................................................................................................................... 37 4.2 Test Graphs ..................................................................................................................................... 39 5: Maximum conducted output power ............................................................................................................ 52 5.1 Test Result ....................................................................................................................................... 52 6: Maximum power spectral density ............................................................................................................... 54 6.1 Test Result ....................................................................................................................................... 54 6.2 Test Graphs ..................................................................................................................................... 56 7: Band edge measurements ........................................................................................................................... 69 7.1 Test Result B1/2/3 .......................................................................................................................... 69 7.2 Test Result B4 ................................................................................................................................. 70 7.3 Test Graphs B1/2/3 ......................................................................................................................... 72 7.4 Test Graphs B4 ............................................................................................................................... 77 8: Frequency Stability ...................................................................................................................................... 80 8.1 Test Result ....................................................................................................................................... 80 9: Emissions in Restricted Bands ...................................................................................................................... 94 9.1 Test Result ....................................................................................................................................... 94 10.2 Test Graphs ................................................................................................................................. 100 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0209-22 Page: 3 of 111 FCC ID: 2BMXI-CMBC5U TB-RF-073-3.1 1: Emission Bandwidth 1.1 Test Result TestMode Antenna Frequency[MHz] 26dB EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5180 23.72 5167.88 5191.60 --- --- 11A Ant1 5200 18.84 5190.68 5209.52 --- --- 11A Ant1 5240 21.28 5230.00 5251.28 --- --- 11A Ant1 5260 22.08 5249.88 5271.96 --- --- 11A Ant1 5280 19.24 5270.80 5290.04 --- --- 11A Ant1 5320 19.52 5310.32 5329.84 --- --- 11A Ant1 5500 22.48 5487.92 5510.40 --- --- 11A Ant1 5580 22.12 5568.80 5590.92 --- --- 11A Ant1 5700 21.76 5690.24 5712.00 --- --- 11A Ant1 5745 22.80 5734.52 5757.32 --- --- 11A Ant1 5785 22.44 5773.96 5796.40 --- --- 11A Ant1 5825 19.88 5815.16 5835.04 --- --- 11N20SISO Ant1 5180 22.92 5168.56…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID:2BMXI-CMBC5U www.cotecna-toby.com TB-RF-073-3.1 Appendix V EUT Test Photographs Photo of Setup for Conducted Emission(AC POWER) Photo of Setup for Radiated Emission (30MHz~1GHz) FCC ID:2BMXI-CMBC5U www.cotecna-toby.com TB-RF-073-3.1 Photo of Setup for Radiated Emission (Above 1 GHz) Conducted Measurements Test FCC ID:2BMXI-CMBC5U www.cotecna-toby.com TB-RF-073-3.1 Conducted Measurements Test DFS -----END OF REPORT-----

Test Report

Report No.: TBR-C-202512-0209-23 Page: 15 of 21 www.cotecna-toby.com TB-RF-073-3.1 5.2. Conducted Calibration Test Setup 5.3. Deviation from Test Standard No Deviation 5.4. Radar Waveform Calibration Result Report No.: TBR-C-202512-0209-23 Page: 16 of 21 www.cotecna-toby.com TB-RF-073-3.1 6. U-NII DFS Testing 6.1. Test Procedure 1. Master device and client device are set up by conduction method as the following configuration. 2. The client device is connected to notebook and to access a IP address on wireless connection with the master device. 3. Then the master device is connected to another notebook to access a IP address. 4. Finally, let the two IP addresses run traffic with each other through the Run flow software “Lan test” to reach 17% channel loading as below: 6.2. Test Setup Report No.: TBR-C-202512-0209-23 Page: 17 of 21 www.cotecna-toby.com TB-RF-073-3.1 7. Testing Results 7.1. Summary of Test Results Clause Test Parameter Remarks Pass/Fail 15.407 DFS Detection Threshold No Applicable N/A 15.407 Channel Availability Check Time Not Applicable N/A 15.407 Channel Move Time Applicable Pass 15.407 Channel Closing Transmission Time Applicable Pass 15.407 Non- Occupancy Period Applicable Pass 15.407 Uniform Spreading Not Applicable N/A 15.407 U-NII Detection Bandwidth Not Applicable N/A Test Mode The EUT is slave equipment, it need a master device when testing. Master with injection at the Master. (Radar Test Waveforms are injected into the Master) 7.2. DFS Detection Threshold Calibration: The EUT is slave equipment and it with a max gain is 3.91dBi. For a detection threshold level of -62dBm and the master (Brand: Altice Labs, Model: GR140IG, FCC ID: 2AW68-GR140IG) antenna gain is 5.98 dBi, required detection threshold is -56.02dBm= (-62+5.98)dBm. Note: Maximum Transmit Power is less than 200 milliwatt in this report, so detection threshold level is -62dBm. Report No.: TBR-C-202512-0209-23 Page: 18 of 21 www.cotecna-toby.com TB-RF-073-3.1 7.3. Channel Closing Transmission Time Channel Closing Transmission Time and Channel Move Time Result Test Mode Frequency[MHz] CCTT[ms] Limit[ms] CMT[ms] Limit[ms] Verdict 11AX40 5310 200+13 200+60 724.1 10000 PASS 5510 200+13 200+60 858 10000 PASS Report No.: TBR-C-202512-0209-23 Page: 19 of 21 www.cotecna-toby.com TB-RF-073-3.1 TX (11AX40 MHz Mode)_5310MHz Radar Signal 0 Cablibration Plots Report No.: TBR-C-202512-0209-23 Page: 20 of 21 www.cotecna-toby.com TB-RF-073-3.1 TX (11AX40 MHz Mode)_5510MHz Radar Signal 0 Cablibration Plots Report No.: TBR-C-202512-0209-23 Page: 21 of 21 www.cotecna-toby.com TB-RF-073-3.1 7.4. Non-occupancy Period During the 30 minutes observation time, UUT did not make any transmissions on a channel after a radar signal was detected on that channel by either the Channel Availability Check or the In-Service Monitoring. Non-Occupancy Period Result Modulation Mode Freq. (MHz) Non-Occupancy Period Measured Limit Result 11AX40 5310 >30min 30min Complied 5510 >30min 30min Complied TX (11AX40 MHz Mode)_5310MHz TX (11AX40 MHz Mode)_5510MHz -----END OF REPORT------

Test Report

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202512-0209-23 Page: 1 of 21 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com DFS Test Report FCC ID: 2BMXI-CMBC5U Report No. : TBR-C-202512-0209-23 Applicant : Hangzhou SuperAcme Electronics Technology Co., Ltd. Equipment Under Test (EUT) EUT Name : smart battery camera Model No. : CM-BC5U Series Model No. : SC4U-BW2 Brand Name : CINMOORE Sample ID : HC-C-202512-0209-01-01&HC-C-202512-0209-02-01 Receipt Date : 2025-12-19 Test Date : 2025-12-19 to 2026-01-29 Issue Date : 2026-01-29 Standards : FCC Part 15 Subpart E 15.407 KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02 KDB 905462 D03 UNII Clients Without Radar Detection New Rules v01r02 Test Method : ANSI C63.10: 2013 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above Test By : Lily zhang Reviewed By : Henry Huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202512-0209-23 Page: 2 of 21 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ...................................................................................................................................... 2 1. GENERAL INFORMATION ABOUT EUT....................................................................... 4 1.1 Client Information .......................................................................................................... 4 1.2 General Description of EUT (Equipment Under Test) ............................................ 4 1.3 Test Facility .................................................................................................................... 6 2. TEST SOFTWARE .............................................................................................................. 7 3. TEST EQUIPMENT ............................................................................................................. 7 4. U-NII DFS RULE REQUIREMENTS ................................................................................ 8 4.1. Applicability of DFS requirements ....................................................................... 8 4.2. Test Limits and Radar Signal Parameters ......................................................... 9 5. CALIBRATION OF RADAR WAVEFORM ................................................................... 14 5.1. Test Procedure ..................................................................................................... 14 5.2. Conducted Calibration Test Setup .................................................................... 15 5.3. Deviation from Test Standard ............................................................................ 15 5.4. Radar Waveform Calibration Result ................................................................. 15 6. U-NII DFS TESTING ......................................................................................................... 16 6.1. Test Procedure ..................................................................................................... 16 6.2. Test Setup ............................................................................................................. 16 7. TESTING RESULTS ......................................................................................................... 17 7.1. Summary of Test Results ................................................................................... 17 7.2. DFS Detection Threshold ................................................................................... 17 7.3. Channel Closing Transmission Time ................................................................ 18 7.4. Non-occupancy Period ....................................................................................... 21 Report No.: TBR-C-202512-0209-23 Page: 3 of 21 www.cotecna-toby.com TB-RF-073-3.1 Revision History Report No. Version Description Issued Date TBR-C-202512-0209-23 Rev.01 Initial issue of report 2026-01-29 Report No.: TBR-C-202512-0209-23 Page: 4 of 21 www.cotecna-toby.com TB-RF-073-3.1 1. General Information about EUT 1.1 Client Information Applicant : Hangzhou SuperAcme Electronics Technology Co., Ltd. Address : 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Zhejiang Province, 310000 China Manufacturer : Hangzhou SuperAcme Electronics Technology Co., Ltd. Address : 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Zhejiang Province, 310000 China 1.2 General Description of EUT (Equipment Under Test) EUT Name : smart battery camera Models No./HVIN : CM-BC5U, SC4U-BW2 Model Different : All these models are the same in terms of the printed circuit board, layout and circuitry. The only difference lies in the different model names. Operating Frequency Band : 5250-5350MHz 5470-5725MHz TPC : No Yes Power Rating : USB Input:5V DC 3.6V 5200mAh Rechargeable Li-ion battery Software Version : N/A Hardware Version : N/A Note : This device was functioned as a Master Slave device with radar detection Slave device without radar detection Note: (1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Report No.: TBR-C-202512-0209-23 Page: 5 of 21 www.cotecna-toby.com TB-RF-073-3.1 (2) Antenna information provided by the manufacturer. Antenna Sheet Steel Antenna Model: / Max. Gain: U-NII-1: 3.97dBi U-NII-2A: 3.97dBi U-NII-2C: 3.97dBi U-NII-3: 3.97dBi (3) Channel List: Frequency Band Channel No. Frequency Channel No. Frequency 5260~5320 MHz (U-NII-2A) 52 5260 MHz 60 5300 M…

Text truncated - open the document above for the full version.

Test Report

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202512-0209-22 Page: 1 of 60 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Radio Test Report FCC ID: 2BMXI-CMBC5U Report No. : TBR-C-202512-0209-22 Applicant : Hangzhou SuperAcme Electronics Technology Co., Ltd. Equipment Under Test (EUT) EUT Name : smart battery camera Model No. : CM-BC5U Series Model No. : SC4U-BW2 Brand Name : CINMOORE Sample ID : HC-C-202512-0209-01-01&HC-C-202512-0209-02-01 Receipt Date : 2025-12-19 Test Date : 2025-12-19 to 2026-01-29 Issue Date : 2026-01-29 Standards : FCC Part 15 Subpart E 15.407 Test Method : ANSI C63.10: 2020 KDB 789033 D02 General UNII Test Procedures New Rules v02r01 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Kael Li Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202512-0209-22 Page: 2 of 60 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ............................................................................................................................................ 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................ 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 7 1.4 Description of Support Units .............................................................................................. 7 1.5 Description of Test Mode ................................................................................................... 8 1.6 Description of Test Software Setting .............................................................................. 10 1.7 Measurement Uncertainty ................................................................................................ 13 1.8 Test Facility......................................................................................................................... 14 2. TEST SUMMARY..................................................................................................................... 15 3. TEST SOFTWARE .................................................................................................................. 15 4. TEST EQUIPMENT AND TEST SITE .................................................................................. 16 5. CONDUCTED EMISSION TEST ........................................................................................... 17 5.1 Test Standard and Limit ................................................................................................... 17 5.2 Test Setup........................................................................................................................... 17 5.3 Test Procedure .................................................................................................................. 17 5.4 Deviation From Test Standard......................................................................................... 17 5.5 EUT Operating Mode ........................................................................................................ 17 5.6 Test Data............................................................................................................................. 17 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 18 6.1 Test Standard and Limit ................................................................................................... 18 6.2 Test Setup........................................................................................................................... 19 6.3 Test Procedure .................................................................................................................. 20 6.4 Deviation From Test Standard......................................................................................... 21 6.5 EUT Operating Mode ........................................................................................................ 21 6.6 Test Data............................................................................................................................. 21 7. RESTRICTED BANDS REQUIREMENT ............................................................................. 22 7.1 Test Standard and Limit ................................................................................................... 22 7.2 Test Setup........................................................................................................................... 23 7.3 Test Procedure .................................................................................................................. 23 7.4 Deviation From Test Standard......................................................................................... 24 7.5 EUT Operating Mode ........................................................................................................ 24 7.6 Test Data............................................................................................................................. 24 8. BANDWIDTH TEST................................................................................................................. 25 8.1 Test Standard and Limit ........................................................…

Text truncated - open the document above for the full version.

Test Report

Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0209-22 Page: 69 of 111 FCC ID: 2BMXI-CMBC5U TB-RF-073-3.1 7: Band edge measurements 7.1 Test Result B1/2/3 TestMode Antenna ChName Frequency[MHz] Result[dBm] Limit[dBm] Verdict 11A Ant1 Low 5180 -34.33 ≤-27 PASS 11A Ant1 High 5320 -34.78 ≤-27 PASS 11A Ant1 Low 5500 -34.07 ≤-27 PASS 11A Ant1 High 5700 -34.79 ≤-27 PASS 11N20SISO Ant1 Low 5180 -34.56 ≤-27 PASS 11N20SISO Ant1 High 5320 -34.26 ≤-27 PASS 11N20SISO Ant1 Low 5500 -33.36 ≤-27 PASS 11N20SISO Ant1 High 5700 -33.86 ≤-27 PASS 11N40SISO Ant1 Low 5190 -34.3 ≤-27 PASS 11N40SISO Ant1 High 5310 -32 ≤-27 PASS 11N40SISO Ant1 Low 5510 -34.74 ≤-27 PASS 11N40SISO Ant1 High 5670 -33.81 ≤-27 PASS 11AC20SISO Ant1 Low 5180 -33.17 ≤-27 PASS 11AC20SISO Ant1 High 5320 -35.55 ≤-27 PASS 11AC20SISO Ant1 Low 5500 -33.54 ≤-27 PASS 11AC20SISO Ant1 High 5700 -33.93 ≤-27 PASS 11AC40SISO Ant1 Low 5190 -33.43 ≤-27 PASS 11AC40SISO Ant1 High 5310 -34.61 ≤-27 PASS 11AC40SISO Ant1 Low 5510 -34.99 ≤-27 PASS 11AC40SISO Ant1 High 5670 -33.76 ≤-27 PASS 11AX20SISO Ant1 Low 5180 -34.48 ≤-27 PASS 11AX20SISO Ant1 High 5320 -35.06 ≤-27 PASS 11AX20SISO Ant1 Low 5500 -34.12 ≤-27 PASS 11AX20SISO Ant1 High 5700 -32.8 ≤-27 PASS 11AX40SISO Ant1 Low 5190 -33.83 ≤-27 PASS 11AX40SISO Ant1 High 5310 -34.51 ≤-27 PASS 11AX40SISO Ant1 Low 5510 -33.97 ≤-27 PASS 11AX40SISO Ant1 High 5670 -34.33 ≤-27 PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0209-22 Page: 70 of 111 FCC ID: 2BMXI-CMBC5U TB-RF-073-3.1 7.2 Test Result B4 TestMode Antenna ChName Frequency[MHz] FreqRange [MHz] Result [dBm] Limit [dBm] Verdict 11A Ant1 Low 5745 5720~5725 -38.01 ≤15.98 PASS 11A Ant1 Low 5745 5700~5720 -35.17 ≤10.70 PASS 11A Ant1 Low 5745 5650~5700 -36.56 ≤-26.88 PASS 11A Ant1 Low 5745 5760~5650 -36.47 ≤-27 PASS 11A Ant1 High 5825 5850~5855 -35.01 ≤15.65 PASS 11A Ant1 High 5825 5855~5875 -34.53 ≤11.61 PASS 11A Ant1 High 5825 5875~5925 -34.87 ≤-25.28 PASS 11A Ant1 High 5825 5925~5935 -35.68 ≤-27 PASS 11N20SISO Ant1 Low 5745 5720~5725 -34.95 ≤17.12 PASS 11N20SISO Ant1 Low 5745 5700~5720 -35.62 ≤10.05 PASS 11N20SISO Ant1 Low 5745 5650~5700 -37.16 ≤-26.88 PASS 11N20SISO Ant1 Low 5745 5760~5650 -36.35 ≤-27 PASS 11N20SISO Ant1 High 5825 5850~5855 -36.14 ≤15.65 PASS 11N20SISO Ant1 High 5825 5855~5875 -35.43 ≤10.13 PASS 11N20SISO Ant1 High 5825 5875~5925 -35.21 ≤-26.58 PASS 11N20SISO Ant1 High 5825 5925~5935 -35.43 ≤-27 PASS 11N40SISO Ant1 Low 5755 5720~5725 -36.06 ≤16.34 PASS 11N40SISO Ant1 Low 5755 5700~5720 -32.92 ≤11.03 PASS 11N40SISO Ant1 Low 5755 5650~5700 -34.45 ≤-24.33 PASS 11N40SISO Ant1 Low 5755 5780~5650 -35.28 ≤-27 PASS 11N40SISO Ant1 High 5795 5850~5855 -34.56 ≤16.39 PASS 11N40SISO Ant1 High 5795 5855~5875 -32.49 ≤12.01 PASS 11N40SISO Ant1 High 5795 5875~5925 -35.35 ≤-26.97 PASS 11N40SISO Ant1 High 5795 5925~5935 -35.15 ≤-27 PASS 11AC20SISO Ant1 Low 5745 5720~5725 -36.81 ≤15.98 PASS 11AC20SISO Ant1 Low 5745 5700~5720 -34.55 ≤10.28 PASS 11AC20SISO Ant1 Low 5745 5650~5700 -36.48 ≤-26.88 PASS 11AC20SISO Ant1 Low 5745 5760~5650 -35.22 ≤-27 PASS 11AC20SISO Ant1 High 5825 5850~5855 -36.13 ≤15.65 PASS 11AC20SISO Ant1 High 5825 5855~5875 -34.98 ≤10.29 PASS 11AC20SISO Ant1 High 5825 5875~5925 -34.48 ≤-26.87 PASS 11AC20SISO Ant1 High 5825 5925~5935 -34.18 ≤-27 PASS 11AC40SISO Ant1 Low 5755 5720~5725 -36.31 ≤16.34 PASS 11AC40SISO Ant1 Low 5755 5700~5720 -36.63 ≤10.05 PASS 11AC40SISO Ant1 Low 5755 5650~5700 -34.82 ≤-26.94 PASS 11AC40SISO Ant1 Low 5755 5780~5650 -35.19 ≤-27 PASS 11AC40SISO Ant1 High 5795 5850~5855 -34.02 ≤16.39 PASS 11AC40SISO Ant1 High 5795 5855~5875 -32.67 ≤10.34 PASS 11AC40SISO Ant1 High 5795 5875~5925 -35.42 ≤-26.26 PASS 11AC40SISO Ant1 High 5795 5925~5935 -35.17 ≤-27 PASS 11AX20SISO Ant1 Low 5745 5720~5725 -33.54 ≤15.98 PASS 11AX20SISO Ant1 Low 5745 5700~5720 -35.41 ≤10.14 PASS 11AX20SISO Ant1 Low 5745 5650~5700 -36.72 ≤-26.14 PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0209-22 Page: 71 of 111 FCC ID: 2BMXI-CMBC5U TB-RF-073-3.1 11AX20SISO Ant1 Low 5745 5760~5650 -36.15 ≤-27 PASS 11AX20SISO Ant1 High 5825 5850~5855 -35.38 ≤15.65 PASS 11AX20SISO Ant1 High 5825 5855~5875 -31.61 ≤11.11 PASS 11AX20SISO Ant1 High 5825 5875~5925 -35.98 ≤-26.87 PASS 11AX20SISO Ant1 High 5825 5925~5935 -34.64 ≤-27 PASS 11AX40SISO Ant1 Low 5755 5720~5725 -34.59 ≤17.24 PASS 11AX40SISO Ant1 Low 5755 5700~5720 -33.24 ≤10.98 PASS 11AX40SISO Ant1 Low 5755 5650~5700 -35.43 ≤-25.63 PASS 11AX40SISO Ant1 Low 5755 5780~5650 -35.15 ≤-27 PASS 11AX40SISO Ant1 High 5795 5850~5855 -35.94 ≤15.85 PASS 11AX40SISO Ant1 High 5795 5855~5875 -33.83 ≤10.01 PASS 11AX40SISO Ant1 High 5795 5875~5925 -35.54 ≤-26.97 PASS 11AX40SISO Ant1 High 5795 5925~5935 -33.18 ≤-27 PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0209-22 Page: 72 of 111 FCC ID: 2BMXI-CMBC5U TB-RF-073-3.1 7.3 Test Graphs B1/2/3 11A-Ant1-5180-PASS 11A-Ant1-5320-PASS 11A-Ant1-5500-PASS 11A-Ant1-5700-PASS 11N20SISO-Ant1-5180-PASS 11N20SISO-Ant1-5320-PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0209-22 Page: 73 of 111 FCC ID: 2BMXI-CMBC5U TB-RF-073-3.1 11N20SISO-Ant1-5500-PASS 11N20SISO-Ant1-5700-PASS 11N40SISO-Ant1-5190-PASS 11N40SISO-Ant1-5310-PASS 11N40SISO-Ant1-5510-PASS 11N40SISO-Ant1-5670-PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-t…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Yongzhi Wang(manager)

[email protected]Fax: N/A

Technical Contact

ACT Lab LLCScott Huber

[email protected]

3280 East 59th Street,Long Beach, · United States

Test Firm

Shenzhen Toby Technology Co., Ltd.Ray Lai

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15E	5.18 GHz - 5.24 GHz	48.90 mW
2	15E	5.26 GHz - 5.32 GHz	41.10 mW
3	15E	5.50 GHz - 5.70 GHz	45.60 mW
4	15E	5.75 GHz - 5.83 GHz	37.50 mW

Confidentiality

Long Term

Grant Notes

Output power listed is average conducted. This device supports 802.11a, 802.11n, 802.11ac and 802.11ax with a 20 MHz, 40 MHz bandwidth mode. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This device complies with the Dynamic Frequency Selection (DFS) requirements of KDB 905462 D03 as a Client only without Radar Detection.
