2BMXI-CMBC7WUAll-in-One Solar AI Wi-Fi Security Camera

For any inquiries, don't hesitate to contact us at [email protected]. Thanks for Choosing CiNMOORE All-in-One Solar Al Wi-Fi Security Camera Quick Operation Guide CM-BC7WU * There may be slight differences between the pictures and the actual products. Please refer to the actual products. * Pay attention to waterproofing. Before use, the waterproof plug must be fully covered. * Please place the camera in a location with good electrical signal for binding. * The black surface area represents the built-in solar panel of the device. Please ensure that the sun shines on the solar panel as much as possible to avoid any part of the black solar panel being blocked. What' s in the BoxProduct OverviewConnect Camera Return Sleep ReturnShareMore Set up Full screen APP Function Introduction ISED Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1)This device may not cause interference. (2)This device must accept any interference, including interference that may cause undesired operation of the device. This device meets the exemption from the routine evaluation limits in section 5.3.2 of RSS 102 and compliance with RSS 102 RF exposure, users can obtain Canadian information on RF exposure and compliance. This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC Information Please take attention that changes or modification notexpressly approved by the party responsible for compliancecould void the user' s authority to operate the equipment.FCC compliance: This equipment has been tested and foundto comply with the limits for a Class B digital device,pursuant to part 15 of the FCC Rules. These limits aredesigned to provide reasonable protection against harmfulinterference in a residential installation. This equipmentgenerates, uses and can radiate radio frequency energy and,if not installed and used in accordance with the instructions,may cause harmful interference to radio communications.However, there is no guarantee that interference will notoccur in a particular installation. If this equipment doescause harmful interference to radio or television reception,which can be determined by turing the equipment off andon, the user is encouraged to try to correct the interferenceby one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment andreceiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technicianfor help To maintain compliance with FCC' s RF Exposure guidelines,This equipment should be installed and operated withminimum 20cm distance between the radiator and yourbody: Use only the supplied antenna. Company Statement 1.We have tried our best to ensure the complete-ness and accuracy of the materials.lf you haveany questions or disputes,please refer to thecompany' s final explanation. 2.we will update the information content in atimely manner according to the productfunction. And regularly modify and update theproducts or programs described in this informa-tion.Updates will be added to the new versionwithout notification. 3.The content of this material is for reference onlyfor customers.There is no guarantee that it isexactly the same as the product.Please focus onthe actual product. 4. The camera parts shown in this information arefor illustration only. It does not represent thepurchased configuration. Operating conditions: emperature: -20°Cto 45°C(-68 °F to113°F) Humidity 95% or less (non-condensing) FCC statements This device complies with part 15 of the FCCRules.Operation is subject to the following twoconditions:(1)this device may not cause harmfulinterface,and (2)this device must accept anyinterference received,including interference thatmay cause undesired operation. Power button 1. Long press can be used for turning on and off the device. 2. Press twice in succession to reset the machine. 3. When pressing the power button, please remove the waterproof cap to facilitate easy pressing of the power key; after turning on, please replace the waterproof cap. Charging port If you receive the machine for the first time, please charge it first. When the battery is low, the Shenmou APP will notify you to charge. Please use a charger for charging. Solar panel folding bracket microphone Indicator light Fill light Lens module 时间： 2026/03/03 图纸名称： BC7WU说明书 工艺说明： 风琴折页 50*100mm 单色印刷 The camera supports three mounting methods: tabletop placement, hole punching, and magnetic attachment. 1. Tabletop placement 2.Magnetic attraction Quick Installation SD Protective cap SD card slot Charging port Power button SD POWER SD What' s in the Box Product Overview Quick Start Connect Camera APP Registration APP Function Introduction Charge the Camera Quick Installation 01 02 03 04 06 07 08 09 13 14 15 16 18 19 20 21 25 26 27 28 30 31 31 33 ¡Qué hay en la caja Detalles del producto Comienza rápidamente Conectar la cámara Registro de la APP Presentación de la APP Cargar la cámara Instalación rápida Qu'est - ce que dans le boîte Présentation du produit Un démarrage rapide Connecter la caméra Enregistrement de l’application Introduction de fonction d’app Chargez la caméra Installation rapide Declaración de ISED Este dispositivo contiene transmisores/receptores exentos de licencia que cumplen con los RSS exentos de licencia de Innovación, Ciencia y Desarrollo Económico de Canadá. El funcionamiento está sujeto a las dos condiciones siguientes: (1) Este dispositivo no puede causar interferencias. (2) Este dispositivo debe aceptar cualquier interferencia, incluidas las interferencias que puedan causar un funcionamiento no de…

Text truncated - open the document above for the full version.

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(S)(i)-(ii) of the Commission's Rules (47 C.F.R.) we attest as follows for the product listed below: FCCID Model name 2BMXI-CM BC7WU CM-BC?WU, CM-BC?WUP, CM-BC?WUS, CM-BC?WUU, CM- BC?WUJ W e, Applicant ····· Company Name:, Hangzhou SuperAcme Electronics i Technology Co., Ltd. ．． 口 ...........·-···- ·· -··.. -- .. .... _..俨． ．_......．·····、............ Address:'. 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Zhejiang, China --· .. .... -· . -···-..一........今.. Phone: l 18657152512 certify that the equipment for which authorization is sought is not "covered" equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. This includes the cybersecurity and anti-virus software produced or provided by Kaspersky Lab, Inc. or any of it's successors and assignees. We certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing "covered" equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerel y , Signature Date: 2026-04-24 Printed Name of Signee: Yongzhi Wang/Certified Engineer Company: Hangzhou SuperAcme Electronics Technology Co., Ltd. Address: 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Zhejiang, China Fax: N/A Phone:18657152512 Email: [email protected]

l ^,......I Qonrocont丁tiwol ottor Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(7), of the Commission's Rules (47 C.F.R.) we attest as follows for the product listed below: FCCID 2BMXI-CMBC7WU ModeI name CM-BC7WU, CM-BC7WUP, CM-BC7WUS, CM-BC7WUU, CM-BC7WU」 We hereby acknowledge as follows: i. both signees confirm that the point of contact accepts responsibility to act as a US­ American Representative on behalf of the applicant ii. the point of contact provides the physical U.S. address and email as listed below iii. both parties maintain the requirements of this agreement for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. iv. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. US-American Point of Contact Applicant/Approval Holder 夕 ｀ Signature Date:2026-04-03 Company Name: ACT Lab LLC FRN: 0033465568 Contact Name: Scott Huber Address: 3280 East 59th St「eetLong Beach, CA 90805 United States Phone: (562)470-7215 Email: [email protected] Signature 吵： 2026-04-03 Hangzhou H angzhou SuperAcme SuperAcme El Electronics Technology Co., Ltd. 0036433241 Yongzhi Wang 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Zhejiang, China 18657152512 [email protected]

Hangzhou SuperAcme Electronics Technology Co., Ltd. 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Zhejiang, China Date: 2026-04-24 FCC ID: 2BMXI-CMBC7WU Model Number: CM-BC?WU, CM-BC7WUP, CM-BC7WUS, CM-BC7WUU, CM- BC7WUJ To: Federal Communications Commission Authorization and Evaluation Division 7 435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Hangzhou SuperAcme Electronics Technology Co., Ltd., declare that this EUT FCC ID: 2BMXI-CMBC7WU doesn't have Ad Hoc mode function on "non-US/Canada frequencies". In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerel y , Name/Title: Company: Address: Phone: Fax: E- Mail: ％沪勹 Yongzhi Wang/ Certified Engineer Hangzhou Super A cme Electronics Technology Co., Ltd. 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Zhejiang, China 18657152512 N/ A wan gy [email protected] om

Confidentiality Request Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission's Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: ：比靡－CMBC7WU 1芒心？霖:$j,CM-BC7WUP, CM-BC?WUS, CM-BC?WUU, CM-BC?WUJ For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: •the Operational Description •the Block Diagram •the Schematics The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 归叩 Signature Date: 2026-04-24 Printed Name of Signee: Yongzhi Wang/Certified Engineer Company: Hangzhou SuperAcme Electronics Technology Co., Ltd. A ddress: 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Z hejiang, China Phone:18657152512 Fax: N/A Email: [email protected]

FCC ID: 2BMXI-CMBC7WU TB-RF-073-3.1 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID: 2BMXI-CMBC7WU TB-RF-073-3.1 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID: 2BMXI-CMBC7WU TB-RF-073-3.1 Photo 5 Appearance of EUT Photo 6 Appearance of EUT

FCC ID: 2BMXI-CMBC7WU TB-RF-073-3.1 Appendix I Label Appendix II Label Location All-in-One Solar AI Wi-Fi Security Camera FCC ID: 2BMXI-CMBC7WU Model: CM-BC7WU

FCC ID: 2BMXI-CMBC7WU TB-RF-073-3.1 Appendix IV EUT Internal Photographs Photo 7 Internal of EUT Photo 8 Internal of EUT FCC ID: 2BMXI-CMBC7WU TB-RF-073-3.1 Photo 9 Appearance of Antenna Photo 10 Appearance of PCB FCC ID: 2BMXI-CMBC7WU TB-RF-073-3.1 Photo 11 Appearance of PCB Photo 12 Appearance of PCB FCC ID: 2BMXI-CMBC7WU TB-RF-073-3.1 Photo 13 Appearance of PCB Photo 14 Appearance of PCB FCC ID: 2BMXI-CMBC7WU TB-RF-073-3.1 Photo 15 Appearance of PCB Photo 16 Appearance of Battery

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202603-0005-1 Page: 1 of 6 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Maximum Permissible Exposure Evaluation FCC ID: 2BMXI-CMBC7WU Original Grant Report No. : TBR-C-202603-0005-1 Applicant : Hangzhou SuperAcme Electronics Technology Co., Ltd. Equipment Under Test (EUT) EUT Name : All-in-One Solar AI Wi-Fi Security Camera Model No. : CM-BC7WU Series Model No. : CM-BC7WUP, CM-BC7WUS, CM-BC7WUU, CM-BC7WUJ Brand Name : CINMOORE Sample ID : HC-C-202603-0005-07-01# & HC-C-202603-0005-07-02# Receipt Date : 2026-03-04 Test Date : 2026-03-04 to 2026-04-23 Issue Date : 2026-04-24 Standards : FCC Part 2.1091 Test Method : KDB 447498 D01 General RF Exposure Guidance v06 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Lily Zhang Reviewed By : Henry Huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202603-0005-1 Page: 2 of 6 www.cotecna-toby.com TB-RF-073-3.1 CONTENTS CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 4 1.1 Client Information ................................................................................................................. 4 1.2 General Description of EUT (Equipment Under Test) ................................................... 4 1.3 Antenna Gain ........................................................................................................................ 4 2. MEASUREMENT UNCERTAINTY .......................................................................................... 5 3. TEST FACILITY.......................................................................................................................... 5 4. METHOD OF MEASUREMENT .............................................................................................. 6 5. TEST RESULT............................................................................................................................ 6 Report No.: TBR-C-202603-0005-1 Page: 3 of 6 www.cotecna-toby.com TB-RF-073-3.1 Revision History Report No. Version Description Issued Date TBR-C-202603-0005-1 Rev.01 Initial issue of report 2026-04-24 Report No.: TBR-C-202603-0005-1 Page: 4 of 6 www.cotecna-toby.com TB-RF-073-3.1 1. General Information about EUT 1.1 Client Information Applicant : Hangzhou SuperAcme Electronics Technology Co., Ltd. Address : 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Zhejiang Province China 310000 Manufacturer : Hangzhou SuperAcme Electronics Technology Co., Ltd. Address : 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Zhejiang Province China 310000 1.2 General Description of EUT (Equipment Under Test) EUT Name : All-in-One Solar AI Wi-Fi Security Camera Models No. : CM-BC7WU, CM-BC7WUP, CM-BC7WUS, CM-BC7WUU, CM-BC7WUJ Model Different : All these models are identical in the same PCB, layout and electrical circuit, The only difference is model name. Product Description : Operation Frequency: 802.11b/g/n(HT20)/ax(HE20): 2412MHz~2462MHz 802.11n(HT40)/ax(HE40): 2422MHz~2452MHz U-NII-1: 5180MHz~5240MHz U-NII-2A: 5260MHz~5320MHz U-NII-2C: 5500MHz~5700MHz U-NII-3: 5745MHz~5825MHz Bluetooth: 2402MHz~2480MHz Power Rating : USB/Solar panel Input: 5V, 2A DC 5V by 9000mAh Rechargeable Li-ion battery Software Version : ---- Hardware Version : ---- Remark: The above antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. 1.3 Antenna Gain Band Antenna Type Antenna Gain(dBi) Bluetooth FPC 2.56 2.4G Wi-Fi FPC 2.56 5G Wi-Fi U-NII-1 FPC 2.74 5G Wi-Fi U-NII-2A FPC 2.74 5G Wi-Fi U-NII-2C FPC 2.74 5G Wi-Fi U-NII-3 FPC 2.74 Report No.: TBR-C-202603-0005-1 Page: 5 of 6 www.cotecna-toby.com TB-RF-073-3.1 2. Measurement Uncertainty The reported uncertainty of measurement y±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. Test Item Parameters Expanded Uncertainty (ULab) Conducted Emission Level Accuracy: 9kHz~150kHz 150kHz to 30MHz ±3.50 dB ±3.10 dB Radiated Emission Level Accuracy: 9kHz to 30 MHz ±4.60 dB Radiated Emission Level Accuracy: 30MHz to 1000 MHz ±4.50 dB Radiated Emission Level Accuracy: Above 1000MHz ±4.20 dB Temperature / ±0.6°C Humidity / ±4% Supply voltages / ±2% Time / ±4% 3. Test Facility The testing report were performed by the Shenzhen Toby Technology Co., Ltd., in their facilities located at 1/F., Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. At the time of testing, the following bodies accredited the Laboratory: CNAS (L5813) The Laboratory has been accredited by CNAS to ISO/IEC 17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories for the competence in the field of testing. And the Registration No.: CNAS L5813. A2LA Certificate No.: 4750.01 The laboratory has been accredited by American Association for Laboratory Accreditation(A2LA) to ISO/IEC 17025：2017 General Requirements for the Competence of Testing and Calibration Laboratories for the technical competence in the field of Electrical Testing. And the A2LA Certificate No.: 4750.01.FCC Accredi…

Text truncated - open the document above for the full version.

SPECIFICATION SPECIFICATION SHEETFORAPPROVAL （Revision：V1） CUSTOMERSIGNED QA CHECKED ME CHECKED RFCHECKED MANAGER CHECKED SHANGHAIDEEPFASTTECHNOLOGYCO.,LTD MANAGER CHECKED MANAGER CHECKED ME CHECKED RF CHECKED LISTER Address:No.2710FengxiangRoad,JiadingDistrict,ShanghaiPostalcode:201802 Phone:021-69986378Fax:021-69986369http://www.sh-shenxun.com CUSTOMER(客户名称) CSP/N(客户机种)BC7WU PARTNAME(品名)WIFIAntenna FREQUENCY(频率)2400-25005150-5850 MHz SUPPLIERPN.(供应商物料编号)17I017A DATE(日期)2026-1-23 Remark(备注)： Sign(客户确认签字盖章)： Catalogue SHEETFORAPPROVAL 1Summarize1 2TestEquipment1 3TestData1~4 4Match4 5EngineeringDrawing4~5 6TestReport6 7ProcessCapabilityIndexevaluationreport7 8SaltSprayReliabilityTestReport8 1 1.Summarize Type：WIFIAntenna Material：FPC 2.TestEquipment FranceSatimoSG24OTA E5071C 3．Testdata: Passive： H-Face 2 E1 E2 2400MHZ2450MHZ2500MHZ 3 5150MHZ5550MHZ5850MHZ FrequencyEfficiencyGain.dBFrequencyEfficiencyGain.dB 240048%2.63515034%1.42 241051%2.65517036%1.32 242051%2.64519037%1.27 243052%2.59521039%1.15 244053%2.60523040%1.55 245053%2.54525040%1.75 246053%2.37527041%1.89 247053%2.18529043%2.24 248053%1.94531044%2.45 249052%1.58533045%2.63 250051%1.20535045%2.53 537044%2.31 539045%2.46 541045%2.57 543046%2.74 545046%2.68 547044%2.30 549043%1.87 551042%1.80 553042%1.82 555043%1.97 557044%1.96 559042%1.59 561041%1.24 563039%0.86 565040%0.77 567041%0.74 569041%0.54 571041%0.10 573040%-0.07 575040%-0.13 577040%-0.07 579042%0.19 581041%0.20 583039%0.03 4 Active： BANDCHANNELTRPTIS 11b 118.29-83.99 618.23-84.31 1118.5-84.18 11a 3616.93-75.66 10015.5-74.57 16516.86-75.56 4.Match 5.EngineeringDrawing MatchWIFI E10Ω E2NC E3NC BC7WU Designed mm General Tolerance T1 1:1 ±0.20 5-10 ±0.30 10-20 ±0.40 20-40 ±0.50 40> 设计: 射频: Approval 批准: Date 日期: Scale 比例: Unit 单位: Rev 版本: 产品名称: Product Name Project Name 项目名称: Material 材料: Process 工艺: Third Angle 第三视角 Drawing Number Material Code 物料编码: 图纸编号: ±0.10 ±0.15 ±0.20 ±0.25 AB Dim Grade 2026.01.06 DP-QR-RD-013 镀金 铜 箔 产品外形 离型纸开槽位 备注： 1、图中所标注尺寸为IQC必测尺寸，加*尺寸为CPK管控尺寸。 2、线路采用丝印工艺。 3、字码采用丝印工艺，白色丝印。 4、包装方式（整版出货）。 5、外形需冲切光滑平顺、且不能冲切到内部线路。 6、产品表面不能有锡珠、脏污、露铜、气泡等不良问题。 7、要求过盐雾测试48小时不能出现氧化现象。 8、FPC天线成品未经过DEEPFAST公司确认，材料不能随意更改。 材质要求： 单面电解铜 表面涂哑光黑油 T=20um 优利 铜箔 T=18um 蔡伦格蒂 AD胶 T=13um PI层 T=12.5um 补强PET=200um 双面胶 3M9471 T=50um 镀金 ≥0.03um 离型纸 T=100um FPC 上海深迅通信技术有限公司 Shanghai DEEPFAST Commniunication Technology Co.,Ltd. 刘祥 17I017A JASON 版本 描述 制图 日期 T1 首次发行JASON2026.01.06 Rev Designed Date Description WIFI天线 PET加强板 1 0.20±0.05(PET补强板） 2 铜箔 AD胶 PI层 油层 3M胶 离型纸 PET补强 *22.70±0.30 *26.96±0.30 DP-WIFI-17I017A-T1.0 白色字符 Ø1.00±0.08 Ø1.00±0.08 Ø1.00±0.08 3M 300LSE 手撕位 蓝色区域铺补强 切刀 6 6.TestReport TestReport CustomerBC7WUPartName WIFI Antenna Quality10pcs MaterialFPCColorBlackDate2026.1.23 NO Required size MeasuredSizeResultRemark 12345678910OK 1 22.7±0.3 22.6622.6722.6222.6322.6822.7222.7122.7822.7422.76 OK 2 26.96±0.3 27.0326.9627.0426.9426.9826.892726.8827.0526.9 OK 3 0.2±0.05 0.200.200.200.210.200.200.200.190.200.20 OK 4 5 6 7 8 9 10 Appearance:nobubbles,nodirt,noparticlesonthesurfaceOK.AdhesiontestOK. Other:100celltestOK Judge: □OK□NG Approval:王国均Audit:易爱玲Lister：韦金苏 7 7.ProcessCapabilityIndexEvaluationReport ProcessCapabilityIndexEvaluationReport Customer:BC7WU PartName:WIFIAntenna（17I017A）Date:2026.1.23 RecognizeAuditLister 胡春梅易爱玲韦金苏 NO. SPEC 22.7026.96Remark 0.300.300.300.30 Mass production canbecarried outunderthe condition thatCPK valuesare "satisfied", butthe inspection needstobe strengthened. 2.Underthe condition thatCPKvalue is"very satisfied", sampling inspection canbecarried outduring mass production. 3.Ifoneof theCPKvalues doesnotmeet the requirement of"meet",the reasons shouldbe analyzedand improved. 122.6627.03 222.6726.96 322.6227.04 422.6326.94 522.6826.98 622.7226.89 722.7127.00 822.7826.88 922.7427.05 1022.7626.90 1122.6927.03 1222.7326.88 1322.6726.96 1422.7226.89 1522.7926.99 1622.6526.92 1722.6426.93 1822.7726.88 1922.7026.89 2022.7826.94 2122.6826.98 2222.7226.97 2322.6327.04 2422.7427.00 2522.6227.02 2622.7926.95 2722.6426.99 2822.7726.93 2922.6226.98 3022.7027.05 3122.6326.90 3222.7326.90 MAX22.7927.05 MIN22.6226.88 X22.7026.96 M23.0027.26 CP1.7921.782 SN-10.0560.056 K0.00210.0031 CPK/Judg e 1.788 very satisf ied 1.776 very satisf ied Judge:TheCPKvalue"verywellmeets"theproductionconditionsandcanbeusedformassproduction. 8 8.SaltSprayReliabilityTestReport SaltSprayReliabilityTestReport CustomerBC7WUPartNameWIFIAntennaDate2026/1/23 MaterialFPCTime48HQuality3PCS TimeTestConditionTestStandardResultRemark 0-6hours Saltspray tester:salt solution:NaCl (anhydrous); Concentrationof 5%plusorminus 1%;PHvalue:6.5 ~7.2; Laboratory temperature: 32-38°C; Compressedair pressure:1.0± 0.01(KG/M2) spray volume:1.0~ 2.0ML/80CM2/H. Relative humidity:85%± 2%;Testproduct placement Angle:30 degrees+/-10 degrees; Durationofsalt spray:48h Productsurfacewithoutrust,oxidation, corrosion,plating(coating)layeroffand otheradversephenomena ok 2026.1.20 15：00 start 6-12 hours Productsurfacewithoutrust,oxidation, corrosion,plating(coating)layeroffand otheradversephenomena ok 12-18 hours Productsurfacewithoutrust,oxidation, corrosion,plating(coating)layeroffand otheradversephenomena ok 18-24 hours Productsurfacewithoutrust,oxidation, corrosion,plating(coating)layeroffand otheradversephenomena ok 24-30 hours Productsurfacewithoutrust,oxidation, corrosion,plating(coating)layeroffand otheradversephenomena ok 30-36 hours Productsurfacewithoutrust,oxidation, corrosion,plating(coating)layeroffand otheradversephenomena ok 36-42 hours Productsurfacewithoutrust,oxidation, corrosion,plating(coating)layeroffand otheradversephenomena ok 42-48 hours Productsurfacewithoutrust,oxidation, corrosion,plating(coating)layeroffand otheradversephenomena ok 2026.1.22 18：00end 48hours and more Productsurfacewithoutrust,oxidation, corrosion,plating(coating)layeroff≤ 1%productarea Judge OK Lister 韦金苏 Audit易爱玲Recognize胡春梅

Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0005-7 Page: 1 of 39 FCC ID:2BMXI-CMBC7WU TB-RF-073-3.1 RF Test Data for Bluetooth LE (Conducted Measurements) General Description of EUT Product Name: All-in-One Solar AI Wi-Fi Security Camera Test Model: CM-BC7WU Sample ID: HC-C-202603-0005-1-01 Environmental Conditions Temperature: 23.8°C Relative Humidity: 49% Test Voltage: DC 5V Test Engineer: Lily Zhang Note: For a more detailed features description, please refer to the report TBR-C-202603-0005-7. The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0005-7 Page: 2 of 39 FCC ID:2BMXI-CMBC7WU TB-RF-073-3.1 Contents 1. Duty Cycle ..................................................................................................................................................................................... 3 2. Maximum Conducted Output Power ............................................................................................................................................ 7 3. -6dB Bandwidth ........................................................................................................................................................................... 11 4. Occupied Channel Bandwidth .................................................................................................................................................... 15 5. Maximum Power Spectral Density Level ................................................................................................................................... 19 6. Band Edge ................................................................................................................................................................................... 23 7. Conducted RF Spurious Emission ............................................................................................................................................. 28 8. Restrict Band ............................................................................................................................................................................... 35 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0005-7 Page: 3 of 39 FCC ID:2BMXI-CMBC7WU TB-RF-073-3.1 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT BLE 1Mbps 2402 Ant1 84.92 0.71 0.47 NVNT BLE 1Mbps 2440 Ant1 84.92 0.71 0.47 NVNT BLE 1Mbps 2480 Ant1 84.92 0.71 0.47 NVNT BLE 2Mbps 2402 Ant1 56.8 2.46 0.94 NVNT BLE 2Mbps 2440 Ant1 56.85 2.45 0.94 NVNT BLE 2Mbps 2480 Ant1 56.85 2.45 0.94 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0005-7 Page: 4 of 39 FCC ID:2BMXI-CMBC7WU TB-RF-073-3.1 Test Graphs Duty Cycle NVNT BLE 1Mbps 2402MHz Ant1 Duty Cycle NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0005-7 Page: 5 of 39 FCC ID:2BMXI-CMBC7WU TB-RF-073-3.1 Duty Cycle NVNT BLE 1Mbps 2480MHz Ant1 Duty Cycle NVNT BLE 2Mbps 2402MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0005-7 Page: 6 of 39 FCC ID:2BMXI-CMBC7WU TB-RF-073-3.1 Duty Cycle NVNT BLE 2Mbps 2440MHz Ant1 Duty Cycle NVNT BLE 2Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0005-7 Page: 7 of 39 FCC ID:2BMXI-CMBC7WU TB-RF-073-3.1 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT BLE 1Mbps 2402 Ant1 6.955 0 6.955 30 Pass NVNT BLE 1Mbps 2440 Ant1 7.494 0 7.494 30 Pass NVNT BLE 1Mbps 2480 Ant1 7.912 0 7.912 30 Pass NVNT BLE 2Mbps 2402 Ant1 6.962 0 6.962 30 Pass NVNT BLE 2Mbps 2440 Ant1 7.415 0 7.415 30 Pass NVNT BLE 2Mbps 2480 Ant1 7.883 0 7.883 30 Pass Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0005-7 Page: 8 of 39 FCC ID:2BMXI-CMBC7WU TB-RF-073-3.1 Test Graphs Power NVNT BLE 1Mbps 2402MHz Ant1 Power NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0005-7 Page: 9 of 39 FCC ID:2BMXI-CMBC7WU TB-RF-073-3.1 Power NVNT BLE 1Mbps 2480MHz Ant1 Power NVNT BLE 2Mbps 2402MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Ad…
