2BMXI-CMPT2WUOutdoor Wi-Fi Camera

Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0006-62 Page: 28 of 72 FCC ID:2BMXI-CMPT2WU TB-RF-073-3.1 11AX40SISO-Ant1-5190 11AX40SISO-Ant1-5230 11AX40SISO-Ant1-5270 11AX40SISO-Ant1-5310 11AX40SISO-Ant1-5510 11AX40SISO-Ant1-5550 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0006-62 Page: 29 of 72 FCC ID:2BMXI-CMPT2WU TB-RF-073-3.1 11AX40SISO-Ant1-5670 11AX40SISO-Ant1-5755 11AX40SISO-Ant1-5795 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0006-62 Page: 30 of 72 FCC ID:2BMXI-CMPT2WU TB-RF-073-3.1 3: Min emission bandwidth 3.1 Test Result-B4 TestMode Antenna Frequency[MHz] 6dB EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5745 16.56 5736.72 5753.28 0.5 PASS 11A Ant1 5785 16.32 5776.84 5793.16 0.5 PASS 11A Ant1 5825 16.52 5816.72 5833.24 0.5 PASS 11N20SISO Ant1 5745 17.84 5736.08 5753.92 0.5 PASS 11N20SISO Ant1 5785 17.72 5776.12 5793.84 0.5 PASS 11N20SISO Ant1 5825 17.84 5816.08 5833.92 0.5 PASS 11N40SISO Ant1 5755 36.48 5736.68 5773.16 0.5 PASS 11N40SISO Ant1 5795 36.48 5776.76 5813.24 0.5 PASS 11AC20SISO Ant1 5745 17.84 5736.04 5753.88 0.5 PASS 11AC20SISO Ant1 5785 17.88 5776.04 5793.92 0.5 PASS 11AC20SISO Ant1 5825 17.80 5816.08 5833.88 0.5 PASS 11AC40SISO Ant1 5755 36.48 5736.76 5773.24 0.5 PASS 11AC40SISO Ant1 5795 36.56 5776.68 5813.24 0.5 PASS 11AX20SISO Ant1 5745 19.08 5735.44 5754.52 0.5 PASS 11AX20SISO Ant1 5785 19.12 5775.40 5794.52 0.5 PASS 11AX20SISO Ant1 5825 19.16 5815.44 5834.60 0.5 PASS 11AX40SISO Ant1 5755 38.24 5735.88 5774.12 0.5 PASS 11AX40SISO Ant1 5795 38.16 5775.88 5814.04 0.5 PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0006-62 Page: 31 of 72 FCC ID:2BMXI-CMPT2WU TB-RF-073-3.1 3.2 Test Graphs-B4 11A-Ant1-5745-PASS 11A-Ant1-5785-PASS 11A-Ant1-5825-PASS 11N20SISO-Ant1-5745-PASS 11N20SISO-Ant1-5785-PASS 11N20SISO-Ant1-5825-PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0006-62 Page: 32 of 72 FCC ID:2BMXI-CMPT2WU TB-RF-073-3.1 11N40SISO-Ant1-5755-PASS 11N40SISO-Ant1-5795-PASS 11AC20SISO-Ant1-5745-PASS 11AC20SISO-Ant1-5785-PASS 11AC20SISO-Ant1-5825-PASS 11AC40SISO-Ant1-5755-PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0006-62 Page: 33 of 72 FCC ID:2BMXI-CMPT2WU TB-RF-073-3.1 11AC40SISO-Ant1-5795-PASS 11AX20SISO-Ant1-5745-PASS 11AX20SISO-Ant1-5785-PASS 11AX20SISO-Ant1-5825-PASS 11AX40SISO-Ant1-5755-PASS 11AX40SISO-Ant1-5795-PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0006-62 Page: 34 of 72 FCC ID:2BMXI-CMPT2WU TB-RF-073-3.1 4: Duty Cycle 4.1 Test Result TestMode Antenna Frequency [MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] DC Factor 1/T [kHz] 11A Ant1 5180 1.41 11.43 12.34 9.09 0.71 11A Ant1 5260 1.35 11.40 11.84 9.27 0.74 11A Ant1 5500 1.35 11.40 11.84 9.27 0.74 11A Ant1 5745 1.40 11.45 12.23 9.13 0.71 11N20SISO Ant1 5180 5.10 15.15 33.66 4.73 0.20 11N20SISO Ant1 5260 4.55 14.60 31.16 5.06 0.22 11N20SISO Ant1 5500 4.60 14.65 31.40 5.03 0.22 11N20SISO Ant1 5745 4.55 14.60 31.16 5.06 0.22 11N40SISO Ant1 5190 4.40 14.40 30.56 5.15 0.23 11N40SISO Ant1 5270 4.40 14.45 30.45 5.16 0.23 11N40SISO Ant1 5510 4.40 14.45 30.45 5.16 0.23 11N40SISO Ant1 5755 4.45 14.45 30.80 5.11 0.22 11AC20SISO Ant1 5180 4.60 14.65 31.40 5.03 0.22 11AC20SISO Ant1 5260 4.60 14.65 31.40 5.03 0.22 11AC20SISO Ant1 5500 4.55 14.60 31.16 5.06 0.22 11AC20SISO Ant1 5745 4.60 14.65 31.40 5.03 0.22 11AC40SISO Ant1 5190 4.40 14.45 30.45 5.16 0.23 11AC40SISO Ant1 5270 4.40 14.45 30.45 5.16 0.23 11AC40SISO Ant1 5510 4.40 14.45 30.45 5.16 0.23 11AC40SISO Ant1 5755 4.40 14.45 30.45 5.16 0.23 11AX20SISO Ant1 5180 4.10 14.15 28.98 5.38 0.24 11AX20SISO Ant1 5260 4.10 14.15 28.98 5.38 0.24 11AX20SISO Ant1 5500 4.10 14.10 29.08 5.36 0.24 11AX20SISO Ant1 5745 4.10 14.15 28.98 5.38 0.24 11AX40SISO Ant1 5190 4.10 14.15 28.98 5.38 0.24 11AX40SISO Ant1 5270 4.10 14.15 28.98 5.38 0.24 11AX40SISO Ant1 5510 4.10 14.15 28.98 5.38 0.24 11AX40SISO Ant1 5755 4.10 14.15 28.98 5.38 0.24 Note: 1, Duty Cycle= Transmission Duration/ Transmission Period 2, DC Factor=10*Log 10 (1/Duty Cycle) 3, 1/T=1/ Transmission Duration Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0006-62 Page: 35 of 72 FCC ID:2BMXI-CMPT2WU TB-RF-073-3.1 4.2 Test Graphs NTNV-11A-Ant1-5180 NTNV-11A-Ant1-5260 NTNV-11A-Ant1-5500 NTNV-11A-Ant1-5745 NTNV-11N20SISO-Ant1-5180 NTNV-11N20SISO-Ant1-5260 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0006-62 Page: 36 of 72 FCC ID:2BMXI-CMPT2WU TB-RF-073-3.1 NTNV-11N20SISO-Ant1-5500 NTNV-11N20SISO-Ant1-5745 NTNV-11N40SISO-Ant1-5190 NTNV-11N40SISO-Ant1-5270 NTNV-11N40SISO-Ant1-5510 NTNV-11N40SISO-Ant1-5755

FCC ID:2BMXI-CM-PT2WU TB-RF-073-3.1 Appendix V EUT Test Photographs Conducted Emission Test Setup Radiated Emission Test Setup-Below 1G FCC ID:2BMXI-CM-PT2WU TB-RF-073-3.1 Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Conducted Measurements FCC ID:2BMXI-CM-PT2WU TB-RF-073-3.1 Photo of Setup for DFS Measurements -----END OF REPORT-----

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202603-0006-63 Page: 1 of 21 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com DFS Test Report FCC ID: 2BMXI-CMPT2WU Original Grant Report No. : TBR-C-202603-0006-63 Applicant : Hangzhou SuperAcme Electronics Technology Co., Ltd. Equipment Under Test (EUT) EUT Name : Outdoor Wi-Fi Camera Model No. : CM-PT2WU Series Model No. : Please Refer To Page 5 Brand Name : CINMOORE Sample ID : HC-C-202603-0006-01-01# & HC-C-202603-0006-01-02# Receipt Date : 2026-03-04 Test Date : 2026-03-04 to 2026-04-03 Issue Date : 2026-04-03 Standards : FCC Part 15 Subpart E 15.407 KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02 KDB 905462 D03 UNII Clients Without Radar Detection New Rules v01r02 Test Method : ANSI C63.10: 2020+Cor.1:2023+C63.10a: 2024+Errata to C63.10a: 2024 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above Test By : Lily Zhang Reviewed By : Camille Li Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202603-0006-63 Page: 2 of 21 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ...................................................................................................................................... 2 1. GENERAL INFORMATION ABOUT EUT....................................................................... 4 1.1 Client Information .......................................................................................................... 4 1.2 General Description of EUT (Equipment Under Test) ............................................ 4 1.3 Test Facility .................................................................................................................... 6 2. TEST SOFTWARE .............................................................................................................. 7 3. TEST EQUIPMENT AND TEST SITE .............................................................................. 7 4. U-NII DFS RULE REQUIREMENTS ................................................................................ 8 4.1. Applicability of DFS requirements ....................................................................... 8 4.2. Test Limits and Radar Signal Parameters ......................................................... 9 5. CALIBRATION OF RADAR WAVEFORM ................................................................... 14 5.1. Test Procedure ..................................................................................................... 14 5.2. Conducted Calibration Test Setup .................................................................... 15 5.3. Deviation from Test Standard ............................................................................ 15 5.4. Radar Waveform Calibration Result ................................................................. 15 6. U-NII DFS TESTING ......................................................................................................... 16 6.1. Test Procedure ..................................................................................................... 16 6.2. Test Setup ............................................................................................................. 16 7. TESTING RESULTS ......................................................................................................... 17 7.1. Summary of Test Results ................................................................................... 17 7.2. DFS Detection Threshold ................................................................................... 17 7.3. Channel Closing Transmission Time ................................................................ 18 7.4. Non-occupancy Period ....................................................................................... 21 Report No.: TBR-C-202603-0006-63 Page: 3 of 21 www.cotecna-toby.com TB-RF-073-3.1 Revision History Report No. Version Description Issued Date TBR-C-202603-0006-63 Rev.01 Initial issue of report 2026-04-03 Report No.: TBR-C-202603-0006-63 Page: 4 of 21 www.cotecna-toby.com TB-RF-073-3.1 1. General Information about EUT 1. 1 Client Information Applicant : Hangzhou SuperAcme Electronics Technology Co., Ltd. Address : 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Zhejiang Province China 310000 Manufacturer : Hangzhou SuperAcme Electronics Technology Co., Ltd. Address : 14th Floor, Building 2, Silergy Plaza, 6 Lianhui St., Binjiang District, Hangzhou, Zhejiang Province China 310000 1.2 General Description of EUT (Equipment Under Test) EUT Name : Outdoor Wi-Fi Camera Models No. : CM-PT2WU, CM-PT3WU, CM-PT4WU, CM-PT5WU, CM-PT6WU, CM-PT7WU, CM-PT8WU, CM-PT9WU Model Different : All these models are identical in the same PCB, layout and elect rical circuit, The only difference is model name. Operating Frequency Band : 5250-5350MHz 5470-5725MHz TPC : No Ye s Power Rating : Input: 5V, 2A DC 3.6V by 9000mAh Rechargeable Li-ion battery Software Version : ---- Hardware Version : ---- Note : This device was functioned as a Master Slave device with radar detection Slave device without radar detection Note: (1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Report No.: TBR-C-202603-0006-63 Page: 5 of 21 www.cotecna-toby.com TB-RF-073-3.1 (2) Antenna information provided by the manufacturer. Antenna FPC Antenna Model: / Max. Gain: U-NII-1:5.58dBi U-NII-2A: 5.58dBi U-NII-2C: 5.58dBi U-NII-3: 5.58dBi (3) Channel List: Frequency Band Ch…

Text truncated - open the document above for the full version.

Report No.: TBR-C-202603-0006-62 Page: 238 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AC20 5825 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5850.00 44.23 16.10 60.33 122.30 61.97 PK Horizont al PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 239 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AC20 5825 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5850.00 44.16 16.10 60.26 122.30 62.04 PK Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 240 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AX20 5745 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5725.00 42.32 15.88 58.20 122.30 64.10 PK Horizont al PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 241 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AX20 5745 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5725.00 43.38 15.88 59.26 122.30 63.04 PK Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 242 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AX20 5825 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5850.00 45.06 16.10 61.16 122.30 61.14 PK Horizont al PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 243 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AX20 5825 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5850.00 43.11 16.10 59.21 122.30 63.09 PK Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 244 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: N40 5755 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5725.00 44.01 15.88 59.89 122.30 62.41 PK Horizont al PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 245 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: N40 5755 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5725.00 45.30 15.88 61.18 122.30 61.12 PK Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 246 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: N40 5795 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5850.00 42.14 16.10 58.24 122.30 64.06 PK Horizont al PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 247 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: N40 5795 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5850.00 43.52 16.10 59.62 122.30 62.68 PK Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 248 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AC40 5755 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5725.00 44.71 15.88 60.59 122.30 61.71 PK Horizont al PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 249 of …

Text truncated - open the document above for the full version.

Report No.: TBR-C-202603-0006-62 Page: 203 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: N20 5320 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5350.00 37.73 14.52 52.25 74.00 21.75 PK Vertical PASS 2 5351.68 41.49 14.51 56.00 74.00 18.00 PK Vertical PASS 3 5354.43 45.48 14.50 59.98 74.00 14.02 PK Vertical PASS 4 5350.00 25.76 14.52 40.28 54.00 13.72 AV Vertical PASS 5 5355.88 26.64 14.50 41.14 54.00 12.86 AV Vertical PASS 6 5364.68 26.31 14.47 40.78 54.00 13.22 AV Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 204 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AC20 5320 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5350.00 35.08 14.52 49.60 74.00 24.40 PK Horizont al PASS 2 5354.98 37.27 14.50 51.77 74.00 22.23 PK Horizont al PASS 3 5367.63 37.57 14.46 52.03 74.00 21.97 PK Horizont al PASS 4 5350.00 25.05 14.52 39.57 54.00 14.43 AV Horizont al PASS 5 5350.33 25.80 14.52 40.32 54.00 13.68 AV Horizont al PASS 6 5370.29 26.02 14.46 40.48 54.00 13.52 AV Horizont al PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 205 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AC20 5320 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5350.00 35.94 14.52 50.46 74.00 23.54 PK Vertical PASS 2 5355.83 43.59 14.50 58.09 74.00 15.91 PK Vertical PASS 3 5357.13 43.80 14.49 58.29 74.00 15.71 PK Vertical PASS 4 5350.00 25.44 14.52 39.96 54.00 14.04 AV Vertical PASS 5 5352.83 26.10 14.51 40.61 54.00 13.39 AV Vertical PASS 6 5360.43 26.14 14.49 40.63 54.00 13.37 AV Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 206 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AX20 5320 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5350.00 34.11 14.52 48.63 74.00 25.37 PK Horizont al PASS 2 5351.18 39.89 14.52 54.41 74.00 19.59 PK Horizont al PASS 3 5360.88 37.09 14.49 51.58 74.00 22.42 PK Horizont al PASS 4 5350.00 25.44 14.52 39.96 54.00 14.04 AV Horizont al PASS 5 5355.33 26.22 14.50 40.72 54.00 13.28 AV Horizont al PASS 6 5363.78 26.07 14.47 40.54 54.00 13.46 AV Horizont al PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 207 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AX20 5320 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5350.00 37.64 14.52 52.16 74.00 21.84 PK Vertical PASS 2 5353.83 41.58 14.50 56.08 74.00 17.92 PK Vertical PASS 3 5359.23 45.11 14.48 59.59 74.00 14.41 PK Vertical PASS 4 5350.00 26.54 14.52 41.06 54.00 12.94 AV Vertical PASS 5 5352.58 26.69 14.51 41.20 54.00 12.80 AV Vertical PASS 6 5357.78 26.54 14.49 41.03 54.00 12.97 AV Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 208 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: N40 5310 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5350.00 35.16 14.52 49.68 74.00 24.32 PK Horizont al PASS 2 5358.28 40.31 14.49 54.80 74.00 19.20 PK Horizont al PASS 3 5361.04 39.33 14.49 53.82 74.00 20.18 PK Horizont al PASS 4 5350.00 25.51 14.52 40.03 54.00 13.97 AV Horizont al PASS 5 5353.30 25.89 14.51 40.40 54.00 13.60 AV Horizont al PASS 6 5358.34 25.90 14.49 40.39 54.00 13.61 AV Horizont al PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 209 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: N40 5310 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 5350.00 39.38 14.52 53.90 74.00 20.10 PK Vertical PASS 2 5359.42 47.71 14.49 62.20 74.00 11.80 PK Vertical PASS 3 5362.54 49.59 14.48 64.07 74.00 9.93 PK Vertical PASS 4 5350.00 26.08 14.52 40.60 54.00 13.40 AV Vertical PASS 5 5354.44 26.58 14.50 41.08 54.00 12.92 AV Vertical PASS 6 5362.54 26.64 14.48 41.12 54.00 12.88 AV Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) Report No.: TBR-C-202603-0006-62 Page: 210 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AC40 5310 Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. pr…

Text truncated - open the document above for the full version.

Report No.: TBR-C-202603-0006-62 Page: 169 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AX40 5190Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/ m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 11851.43 45.30 6.86 52.16 68.30 16.14 PK Vertical PASS 2 14853.43 44.37 8.84 53.21 68.30 15.09 PK Vertical PASS 3 17965.98 41.37 12.29 53.66 68.30 14.64 PK Vertical PASS 4 12072.54 33.27 7.21 40.48 54.00 13.52 AV Vertical PASS 5 14887.44 32.60 8.91 41.51 54.00 12.49 AV Vertical PASS 6 17778.89 30.31 12.04 42.35 54.00 11.65 AV Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) 3. The tests evaluated 1-40GHz,The testing has been conformed to the 10th harmonic of the highest fundamental frequency or 40GHz. Test with highpass filter (Pass Frequency:8-25G)., and 18GHz-40GHz is the noise, No other signals were detected. 4. No report for the emission which below the prescribed limit. Report No.: TBR-C-202603-0006-62 Page: 170 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AX40 5230Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/ m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 12013.01 44.97 7.09 52.06 68.30 16.24 PK Horizont al PASS 2 14912.96 44.78 8.86 53.64 68.30 14.66 PK Horizont al PASS 3 17829.91 41.84 12.22 54.06 68.30 14.24 PK Horizont al PASS 4 12106.55 33.39 7.25 40.64 54.00 13.36 AV Horizont al PASS 5 14912.96 32.83 8.86 41.69 54.00 12.31 AV Horizont al PASS 6 17804.40 30.36 12.29 42.65 54.00 11.35 AV Horizont al PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) 3. The tests evaluated 1-40GHz,The testing has been conformed to the 10th harmonic of the highest fundamental frequency or 40GHz. Test with highpass filter (Pass Frequency:8-25G)., and 18GHz-40GHz is the noise, No other signals were detected. 4. No report for the emission which below the prescribed limit. Report No.: TBR-C-202603-0006-62 Page: 171 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AX40 5230Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/ m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 9521.26 47.57 4.45 52.02 68.30 16.28 PK Vertical PASS 2 14870.44 43.94 8.88 52.82 68.30 15.48 PK Vertical PASS 3 17931.97 41.48 12.16 53.64 68.30 14.66 PK Vertical PASS 4 9555.28 36.29 4.33 40.62 54.00 13.38 AV Vertical PASS 5 14904.45 32.41 8.91 41.32 54.00 12.68 AV Vertical PASS 6 17829.91 30.36 12.22 42.58 54.00 11.42 AV Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) 3. The tests evaluated 1-40GHz,The testing has been conformed to the 10th harmonic of the highest fundamental frequency or 40GHz. Test with highpass filter (Pass Frequency:8-25G)., and 18GHz-40GHz is the noise, No other signals were detected. 4. No report for the emission which below the prescribed limit. Report No.: TBR-C-202603-0006-62 Page: 172 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AX40 5270Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/ m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 12064.03 45.18 7.20 52.38 68.30 15.92 PK Horizont al PASS 2 14878.94 44.29 8.89 53.18 68.30 15.12 PK Horizont al PASS 3 17855.43 41.75 12.15 53.90 68.30 14.40 PK Horizont al PASS 4 9606.30 36.21 4.42 40.63 54.00 13.37 AV Horizont al PASS 5 14861.93 32.61 8.86 41.47 54.00 12.53 AV Horizont al PASS 6 17821.41 30.24 12.25 42.49 54.00 11.51 AV Horizont al PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) 3. The tests evaluated 1-40GHz,The testing has been conformed to the 10th harmonic of the highest fundamental frequency or 40GHz. Test with highpass filter (Pass Frequency:8-25G)., and 18GHz-40GHz is the noise, No other signals were detected. 4. No report for the emission which below the prescribed limit. Report No.: TBR-C-202603-0006-62 Page: 173 of 255 www.cotecna-toby.com TB-RF-073-3.1 Test Mode: AX40 5270Tx Mode Test Voltage: DC 5V Temperature: (°C): 23.4 Humidity (%): 53 Atm. press. (Mpa): 0.102 Remark: Only show the worst data. Test Graph Suspected Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/ m] Limit [dBμV/m] Margin [dB] Detector Polarity Verdict 1 9597.80 47.59 4.56 52.15 68.30 16.15 PK Vertical PASS 2 14785.39 44.32 8.62 52.94 68.30 15.36 PK Vertical PASS 3 17795.90 42.31 12.25 54.56 68.30 13.74 PK Vertical PASS 4 12089.54 33.28 7.25 40.53 54.00 13.47 AV Vertical PASS 5 14921.46 32.55 8.80 41.35 54.00 12.65 AV Vertical PASS 6 17829.91 30.42 12.22 42.64 54.00 11.36 AV Vertical PASS Remark: 1. Level (dBμV/m)= Factor (dB/m)+ Read Level (dBμV) 2. Margin (dB) =Limit(dBμV/m)-Level(dBμV/m) 3. The tests evaluated 1-40GHz,The testing has been conformed to the 10th harmonic of the highest fundamental frequency or 40GHz. Test with highpass filter (Pass Frequency:8-25G)., and 18GHz-40GHz is the noise, No other signals were detected. 4. No report for the emission which below the prescribed limit. Report No.: TBR-C-202603-0006-62 P…

Text truncated - open the document above for the full version.
