2BNNE-BQ-2784G LTE POC RADIO

1 User Manual Introductions Thank you for choosing our company’s 4G LTE POC RADIO products. In order for you to quickly enjoy the convenient brought by this terminal product, please read the User Manual carefully before use. The pictures in this manual are for reference only. If there is any discrepancy between the pictures and the actual product, please refer to the actual product. If there is any discrepancy between the function described and the actual function of the product, please refer to the actual function of the product. In accordance with the principle of continuous improvement and sustainable development, our company reserves the right to modify the contents of this manual without any prior notice .We apologize for any inconvenience caused. I . Instructions 1. Preparation Before Use a . Check if all accessories are complete and undamaged. b . If the accessories are normal, before use, pls install the SIM card provided by the operator and insert the battery . c .If you cannot log in successfully after the starting up, please check if the account is registered properly. If not, please register the terminal account on the management platform. You can use the IMEI/ICCID number as the account for registration. After registration, join the group, and then restart the terminal to use it . 1.1 Installing SIM Card Open the card slot cover, insert the SIM card into the slot (Pay attention to the direction of the card ) and then lock the card cover. Note: After insert SIMcards successfully, the SIM card and the device will be locked after starting up. If replaced to another device , the SIM card cannot be used normally, you need to contact the card supplier to unbind the SIM card. Pls do not insert the SIM card into other devices. 1.2 Installation/Removal of Back Clip Intercom terminal back clip use removable design, in a variety of special environment, the user can install or remove the back clip according to needs. Installation: a.One way : Align the back clip with the slot on the back of the battery,insert it from top to bottom,and you will hear a “click”sound. b.Two way : Align the screw holes on the metal bottom plate with the screw holes on the back of device,and tighten the screws clockwise with a screwdriver . Remove: a. One way : Pull the clip outward,and then mover the back clip upwards to remove it. b.Two way : Use a screwdriver to unscrew the screw connecting back clip and device counter clockwise . 2 During installation and removal ,please do not apply excessive force to avoid damaging the intercom and back clip. 1.3 Intercom Wearing Way It is better to wear in the chest, belt, shoulder belt, etc. It is recommended not to put in pockets of garments ! 2. Basic Operations 2.1 Basic operations Log in successfully ,enter into the home page of the device l. Intercom PTT: Press and hold on the PTT button to start speaking in the current group;release the PTT button to end the speaking. When a user speaking ,the indicator light turns red. When receiving communication ,the indicator light turns green. Menu item: On the home page, press the menu key to enter the menu page. Menu items include: group, members, Settings, and so on. Power switch: Turn on/off . 2.2 Groups Press the Menu key to enter the menu list, use direction keys to select up or down, View the group list: Select “Group”,enter to the group list page to display all groups . The current group is highlighted. Switching a group: On the Group list page, select the group you need,press the OK button . 2.3 Member List Press the menu key ,Scroll up and down to select “member”, Then press OK button 3 enter to the member list that is the current group. View Member list : View all members of the group and their status: .: Online Online in same group. .: Online but in different group . .: Off-line 2.4 Call type 2.4.1 Single call: Select a member on line ,press PTT, and then release,this is created a single called. 2.4.2 Temporary group call : Select 2 or more members on line, press PTT, and then release , this is created a temporary group. Temporary group can last 30 seconds speaking maximum. If no one speaking for more than a minute ,the temporary Group will automatic disband . 2.4.3 All call : Press PTT speaking , all members in the same group all can receive voice . 2.5. Setting Before starting used , pls select “ setting”and “confirmed , and select “POC Change” and confirmed ,to check whether is the correct platform or not ! 2.6 Account (About) Enter to “Account”can see the device inforamtion . IMEI : This number is the device’s identity ICCID: This number is SIM card No. 4 3. Platform If user use POC Global platform ,The software function see the POC Global Platform instruction book . 3.1 If user is Agent account , pls see Agent user instruction book. 3.2 If user is “unit user” , pls see the unit user instruction book. 5 II.Product list Name Quantity Unit Remark POC Intercom (include back splint) 1 piece Charge Adapter 1 piece Type-C Charging Cable 1 piece Product Qualification Certificate 1 piece User Manual 1 piece Pay attention: The product list is for reference only, if there is any change without notice , please refer to the actural products . III. Conservation and Cleaning In order to ensure the good performance of this product and extend its service life, please be familiar with thecontent as fllowing 1. Conservation Do not use hard objects to punctured or scratched . When not used external headset or not charging, please closed the jack cover. When move the intercom,pls handle with care, Do not grab the antenna directly, 2. Cleaning Before cleaning, please turn off the terminal device . After cleaning, Please not used untill dry complete . Please clean the surface of machine by clean and dry lint-free cloth or brush at regularly . When the keys and surfaces of machine are dirty, it can be cleaned with special cleaning agents and non-woven fabrics (Do not use strong corrosive chemicals). IV.Warranty If the terminal dev…

Text truncated - open the document above for the full version.

QUANZHOU BINQI ELECTRONIC TECHNOLOGY CO.LTD ADD:No.132 Xiaguang Si, Xiamei Village, Xiamei Town, Nan'an city ,Quanzhou City ,Fujian ,China Model:168 4GChannel TRP(dBm)TIS(dBm) B-2 L 22.18 H 22.61 W 21.59-99.78 B-3 L 19.32 H 20.14 W 19.47-95.73 B-4 L 17.89 H 20.12 W 18.87-100.85 B-5 L 19.35 H 19.89 W 20.07-95.85 4GChannel TRP(dBm)TIS(dBm) B 7 L 21.98 H 21.84 W 21.52-98.74 B 8 L 21.67 H 21.3 W 20.8-96.46 B 28 L 15.92 H 20.51 W 19.1-96.52 B 66 L 17.62 H 18.38 W 17.91-99.3 StandardBand Gain(dBi) LTEB2 0.15 LTEB3 0.76 LTEB4 -1.02 LTEB5 0.10 LTEB7 -1.20 LTEB8 -0.21 LTEB28 -1.01 LTEB66 -0.96 Saiwei -Sai is far away, and Wei is eternal! 700M 800M 900M 1700M 1800M 1900M 2100M 2600M

Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2607P37970E-RF-TSP Page 1 / 3 EUT SETUP PHOTOS Radiation Emission - Front View (Below 1GHz) Radiation Emission - Back View (Below 1GHz) Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2607P37970E-RF-TSP Page 2 / 3 Radiation Emission - Front View (1GHz - 18GHz) Radiation Emission - Back View (1GHz - 18GHz) Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2607P37970E-RF-TSP Page 3 / 3 Radiation Emission - Front View (Above 18GHz) Radiation Emission - Back View (Above 18GHz)

FCC Part 27, Part 22H, Part 24E Page 1 of 32 FCC PART 27 FCC P ART 22H, PART 24E TEST REPORT For QUANZHOU BINQI ELECTRONIC TECHNOLOGY CO.LTD No.132 Xiaguang Si, Xiamei Village, Xiamei Town, Nan'an city ,Quanzhou City ,Fujian ,China FCC ID: 2BNNE-BQ-278 Report Type: Original Report Product Name: 4G LTE POC RADIO Report Number: 2607P37970E-RF-01 Report Date: 2026-05-14 Reviewed By: Ash Lin Approved By: Miles Chen Prepared By: Bay Area Compliance Laboratories Corp. (Xiamen) Unit 102, No. 902 Meifeng South Road, Binhai West Avenue, Science and Technology Innovation Park, Torch High tech Zone XiaMen, People's Republic of China Tel: +86-592-3200111 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2607P37970E-RF-01 FCC Part 27, Part 22H, Part 24E Page 2 of 32 TABLE OF CONTENTS REPORT REVISION HISTORY ................................................................................................................................ 3 1. GENERAL INFORMATION ................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 1.2 ★OPERATION VOLTAGE (VDC): ........................................................................................................................... 4 1.3 ★ANTENNA INFORMATION .................................................................................................................................... 5 1.4 OBJECTIVE ............................................................................................................................................................. 5 1.5 MEASUREMENT UNCERTAINTY .............................................................................................................................. 5 1.6 TEST FACILITY ....................................................................................................................................................... 5 2. SYSTEM TEST CONFIGURATION ...................................................................................................................... 6 2.1 JUSTIFICATION ....................................................................................................................................................... 6 2.2 CHANNEL LIST ....................................................................................................................................................... 6 2.3 EUT OPERATION CONDITION: ................................................................................................................................ 7 2.4 SUPPORT EQUIPMENT LIST AND DETAILS ............................................................................................................... 7 2.5 EXTERNAL I/O CABLE ............................................................................................................................................ 7 2.6 BLOCK DIAGRAM OF TEST SETUP .......................................................................................................................... 7 3. SUMMARY OF TEST RESULTS ........................................................................................................................... 9 4. TEST EQUIPMENT LIST ..................................................................................................................................... 10 5. REQUIREMENTS AND TEST PROCEDURES ................................................................................................. 11 5.1 APPLICABLE STANDARD FOR PART 22 SUBPART H: ............................................................................................. 11 5.1.1 RF Output Power ......................................................................................................................................... 11 5.1.2 Spurious Emissions ...................................................................................................................................... 11 5.1.3 Frequency stability....................................................................................................................................... 11 5.2 APPLICABLE STANDARD FOR PART 24 SUBPART E: .............................................................................................. 12 5.2.1 RF Output Power ......................................................................................................................................... 12 5.2.2 Spurious Emissions ...................................................................................................................................... 12 5.2.3 Frequency stability....................................................................................................................................... 12 5.3 APPLICABLE STANDARD FOR PART 27: ................................................................................................................ 13 5.3.1 RF Output Power ......................................................................................................................................... 13 5.3.2 Spurious Emissions ...................................................................................................................................... 14 5.3.3 Frequency stability....................................................................................................................................... 15 5.4 TEST METHOD: ..................................................................................................................................................... 16 5.4.1 Transmitter output power, e.r.p. and e.i.r.p ................................................................................................. 16 5.4.2 Occupied Bandwidth ..................................................................................…
