2BQVD-RY-F84G LTE POC RADIO

User Manual Introductions Thank you for choosing our company’s 4G LTE POC RADIO products. In order for you to quickly enjoy the convenient brought by this terminal product, please read the User Manual carefully before use. The pictures in this manual are for reference only. If there is any discrepancy between the pictures and the actual product, please refer to the actual product. If there is any discrepancy between the function described and the actual function of the product, please refer to the actual function of the product. In accordance with the principle of continuous improvement and sustainable development, our company reserves the right to modify the contents of this manual without any prior notice .We apologize for any inconvenience caused. I . Instructions 1. Preparation Before Use a . Check if all accessories are complete and undamaged. b . If the accessories are normal, before use, please install the SIM card provided by the operator and insert the battery . c .If you cannot log in successfully after the starting up, please check if the account is registered properly. If not, please register the terminal account on the management platform. You can use the IMEI/ICCID number as the account for registration. After registration, join the group, and then restart the terminal to use it . 1.1 Installing SIM Card Open the card slot cover, insert the SIM card into the slot (Pay attention to the direction of the card ) and then lock the card cover. Note: After insert SIMcards successfully, the SIM card and the device will be locked after starting up. If replaced to another device , the SIM card cannot be used normally, you need to contact the card supplier to unbind the SIM card. Pls do not insert the SIM card into other devices. 1.2 Installation/Removal of Back Clip Intercom terminal back clip use removable design, in a variety of special environment, the user can install or remove the back clip according to needs. Installation: a.One way : Align the back clip with the slot on the back of the battery,insert it from top to bottom,and you will hear a “click”sound. b.Two way : Align the screw holes on the metal bottom plate with the screw holes on the back of device,and tighten the screws clockwise with a screwdriver . Remove: a. One way : Pull the clip outward,and then mover the back clip upwards to remove it. b.Two way : Use a screwdriver to unscrew the screw connecting back clip and device counter clockwise . During installation and removal ,please do not apply excessive force to avoid damaging the intercom and back clip. 1.3 Intercom Wearing Way It is better to wear in the chest, belt, shoulder belt, etc. It is recommended not to put in pockets of garments ! 2. Basic Operations 2.1 Basic operations Log in successfully ,enter into the home page of the device l. Intercom PTT: Press and hold on the PTT button to start speaking in the current group;release the PTT button to end the speaking. When a user speaking ,the indicator light turns red. When receiving communication ,the indicator light turns green. Menu item: On the home page, press the menu key to enter the menu page. Menu items include: group, members, Settings, and so on. Power switch: Turn on/off . 2.2 Groups Press the Menu key to enter the menu list, use direction keys to select up or down, View the group list: Select “Group”,enter to the group list page to display all groups . The current group is highlighted. Switching a group: On the Group list page, select the group you need,press the OK button . 2.3 Member List Press the menu key ,Scroll up and down to select “member”, Then press OK button enter to the member list that is the current group. View Member list : View all members of the group and their status: .: Online Online in same group. .: Online but in different group . .: Off-line 2.4 Call type 2.4.1 Single call: Select a member on line ,press PTT, and then release,this is created a single called. 2.4.2 Temporary group call : Select 2 or more members on line, press PTT, and then release , this is created a temporary group. Temporary group can last 30 seconds speaking maximum. If no one speaking for more than a minute ,the temporary Group will automatic disband . 2.4.3 All call : Press PTT speaking , all members in the same group all can receive voice . 2.5. Setting Before starting used , please select “ setting”and “confirmed , and select “POC Change” and confirmed ,to check whether is the correct platform or not ! 2.6 Account (About) Enter to “Account”can see the device inforamtion . IMEI : This number is the device’s identity ICCID: This number is SIM card No. 3. Platform If user use POC Global platform ,The software function see the POC Global Platform instruction book . 3.1 If user is Agent account , pls see Agent user instruction book. 3.2 If user is “unit user” , pls see the unit user instruction book. II.Product list Name Quantity Unit Remark POC Intercom (include back splint) 1 piece Charge Adapter 1 piece Type-C Charging Cable 1 piece Product Qualification Certificate 1 piece User Manual 1 piece Pay attention: The product list is for reference only, if there is any change without notice , please refer to the actural products . III. Conservation and Cleaning In order to ensure the good performance of this product and extend its service life, please be familiar with thecontent as fllowing 1. Conservation Do not use hard objects to punctured or scratched . When not used external headset or not charging, please closed the jack cover. When move the intercom,please handle with care, Do not grab the antenna directly, 2. Cleaning Before cleaning, please turn off the terminal device . After cleaning, Please not used untill dry complete . Please clean the surface of machine by clean and dry lint-free cloth or brush at regularly . When the keys and surfaces of machine are dirty, it can be cleaned with special cleaning agents and non-woven fabrics (Do not use strong corrosive chemicals). IV.Warranty If the terminal devi…

Text truncated - open the document above for the full version.

Quanzhou Rongyaokesi Electronic Technology Co., LTD No. 68, Jinpu, Pudang Village, Xiamei Town, Nan 'an City, Quanzhou City, Fujian Province, China Model:SW-Q100 4GChannel TRP (dBm) TIS (dBm) GAIN (dBi) B2 L 21.5 1.1 M 21.6 H 21.8-93.4 B3 L 20.5 0.9 M 21.4-95.2 H 21.3 B4 L 20.5 1.0 M 21.3 H 21.5-94.2 B5 L 20.5 0.6 M 20.6 H 20.8-94.8 4GChannel TRP (dBm) TIS (dBm) GAIN (dBi) B 7 L 20.1 0.7 M 20.3 H 19.9-93.8 B 8 L 21.2 0.6 M 20.5 H 20.3-95.8 B 28 L 17.4 0.1 M 17.3 H 18.5-94.4 B 66 L 21.2 1.0 M 20.8 H 21.2-95.6 700M 800M 900M 1700M 1800M 1900M 2100M 2600M

Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z18185E-RF-TSP Page 1 / 3 EUT SETUP PHOTOS Radiation Emission - Front View (Below 1GHz) Radiation Emission - Back View (Below 1GHz) Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z18185E-RF-TSP Page 2 / 3 Radiation Emission - Front View (1GHz - 18GHz) Radiation Emission - Back View (1GHz - 18GHz) Bay Area Compliance Laboratories Corp. (Xiamen) Report No.: 2507Z18185E-RF-TSP Page 3 / 3 Radiation Emission - Front View (Above 18 GHz) Radiation Emission - Back View (Above 18 GHz)

Report No.: 2507Z18185E-RF-01 Page 160 of 165 15MHz_Low_QPSK_1@0(30MHz~18.55GHz) 15MHz_Middle_QPSK_1@0(30MHz~18.55GHz) 15MHz_High_QPSK_1@0(30MHz~18.55GHz) 20MHz_Low_QPSK_1@0(30MHz~18.55GHz) 20MHz_Middle_QPSK_1@0(30MHz~18.55GHz) 20MHz_High_QPSK_1@0(30MHz~18.55GHz) Report No.: 2507Z18185E-RF-01 Page 161 of 165 Band 7, Normal 1RB was the worst case 5MHz_Low_QPSK_1@0(30MHz~26.7GHz) 5MHz_Middle_QPSK_1@0(30MHz~26.7GHz) 5MHz_High_QPSK_1@0(30MHz~26.7GHz) 10MHz_Low_QPSK_1@0(30MHz~26.7GHz) 10MHz_Middle_QPSK_1@0(30MHz~26.7GHz) 10MHz_High_QPSK_1@0(30MHz~26.7GHz) Report No.: 2507Z18185E-RF-01 Page 162 of 165 15MHz_Low_QPSK_1@0(30MHz~26.7GHz) 15MHz_Middle_QPSK_1@0(30MHz~26.7GHz) 15MHz_High_QPSK_1@0(30MHz~26.7GHz) 20MHz_Low_QPSK_1@0(30MHz~26.7GHz) 20MHz_Middle_QPSK_1@0(30MHz~26.7GHz) 20MHz_High_QPSK_1@0(30MHz~26.7GHz) Report No.: 2507Z18185E-RF-01 Page 163 of 165 Band 66, Normal 1RB was the worst case 1.4MHz_Low_QPSK_1@0(30MHz~18.8GHz) 1.4MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 1.4MHz_High_QPSK_1@0(30MHz~18.8GHz) 3MHz_Low_QPSK_1@0(30MHz~18.8GHz) 3MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 3MHz_High_QPSK_1@0(30MHz~18.8GHz) Report No.: 2507Z18185E-RF-01 Page 164 of 165 5MHz_Low_QPSK_1@0(30MHz~18.8GHz) 5MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 5MHz_High_QPSK_1@0(30MHz~18.8GHz) 10MHz_Low_QPSK_1@0(30MHz~18.8GHz) 10MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 10MHz_High_QPSK_1@0(30MHz~18.8GHz) Report No.: 2507Z18185E-RF-01 Page 165 of 165 15MHz_Low_QPSK_1@0(30MHz~18.8GHz) 15MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 15MHz_High_QPSK_1@0(30MHz~18.8GHz) 20MHz_Low_QPSK_1@0(30MHz~18.8GHz) 20MHz_Middle_QPSK_1@0(30MHz~18.8GHz) 20MHz_High_QPSK_1@0(30MHz~18.8GHz)

Report No.: 2507Z18185E-RF-01 Page 140 of 165 20MHz_High_QPSK_1@99 20MHz_High_QPSK_100@0 20MHz_High_16QAM_1@99 20MHz_High_16QAM_27@73 Band 66, Normal 1.4MHz_Low_QPSK_1@0 1.4MHz_Low_QPSK_6@0 Report No.: 2507Z18185E-RF-01 Page 141 of 165 1.4MHz_Low_16QAM_1@0 1.4MHz_Low_16QAM_6@0 1.4MHz_High_QPSK_1@5 1.4MHz_High_QPSK_6@0 1.4MHz_High_16QAM_1@5 1.4MHz_High_16QAM_6@0 Report No.: 2507Z18185E-RF-01 Page 142 of 165 3MHz_Low_QPSK_1@0 3MHz_Low_QPSK_15@0 3MHz_Low_16QAM_1@0 3MHz_Low_16QAM_15@0 3MHz_High_QPSK_1@14 3MHz_High_QPSK_15@0 Report No.: 2507Z18185E-RF-01 Page 143 of 165 3MHz_High_16QAM_1@14 3MHz_High_16QAM_15@0 5MHz_Low_QPSK_1@0 5MHz_Low_QPSK_25@0 5MHz_Low_16QAM_1@0 5MHz_Low_16QAM_25@0 Report No.: 2507Z18185E-RF-01 Page 144 of 165 5MHz_High_QPSK_1@24 5MHz_High_QPSK_25@0 5MHz_High_16QAM_1@24 5MHz_High_16QAM_25@0 10MHz_Low_QPSK_1@0 10MHz_Low_QPSK_50@0 Report No.: 2507Z18185E-RF-01 Page 145 of 165 10MHz_Low_16QAM_1@0 10MHz_Low_16QAM_27@0 10MHz_High_QPSK_1@49 10MHz_High_QPSK_50@0 10MHz_High_16QAM_1@49 10MHz_High_16QAM_27@23 Report No.: 2507Z18185E-RF-01 Page 146 of 165 15MHz_Low_QPSK_1@0 15MHz_Low_QPSK_75@0 15MHz_Low_16QAM_1@0 15MHz_Low_16QAM_27@0 15MHz_High_QPSK_1@74 15MHz_High_QPSK_75@0 Report No.: 2507Z18185E-RF-01 Page 147 of 165 15MHz_High_16QAM_1@74 15MHz_High_16QAM_27@48 20MHz_Low_QPSK_1@0 20MHz_Low_QPSK_100@0 20MHz_Low_16QAM_1@0 20MHz_Low_16QAM_27@0 Report No.: 2507Z18185E-RF-01 Page 148 of 165 20MHz_High_QPSK_1@99 20MHz_High_QPSK_100@0 20MHz_High_16QAM_1@99 20MHz_High_16QAM_27@73 Report No.: 2507Z18185E-RF-01 Page 149 of 165 Spurious Emissions at Antenna Terminal FCC Part 22H Band 5, Normal Mode Va l u e (dBm) Limit Verdict 1.4MHz_Low_QPSK_1@0(30MHz~9.49GHz) -33.03 See Graphs Pass 1.4MHz_Middle_QPSK_1@0(30MHz~9.49GHz) -33.05 See Graphs Pass 1.4MHz_High_QPSK_1@0(30MHz~9.49GHz) -32.73 See Graphs Pass 3MHz_Low_QPSK_1@0(30MHz~9.49GHz) -32.42 See Graphs Pass 3MHz_Middle_QPSK_1@0(30MHz~9.49GHz) -32.53 See Graphs Pass 3MHz_High_QPSK_1@0(30MHz~9.49GHz) -32.59 See Graphs Pass 5MHz_Low_QPSK_1@0(30MHz~9.49GHz) -32.84 See Graphs Pass 5MHz_Middle_QPSK_1@0(30MHz~9.49GHz) -32.98 See Graphs Pass 5MHz_High_QPSK_1@0(30MHz~9.49GHz) -33.00 See Graphs Pass 10MHz_Low_QPSK_1@0(30MHz~9.49GHz) -33.03 See Graphs Pass 10MHz_Middle_QPSK_1@0(30MHz~9.49GHz) -32.69 See Graphs Pass 10MHz_High_QPSK_1@0(30MHz~9.49GHz) -32.49 See Graphs Pass Note:1RB was the worst case. Report No.: 2507Z18185E-RF-01 Page 150 of 165 Band 5, Normal 1RB was the worst case 1.4MHz_Low_QPSK_1@0(30MHz~9.49GHz) 1.4MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 1.4MHz_High_QPSK_1@0(30MHz~9.49GHz) 3MHz_Low_QPSK_1@0(30MHz~9.49GHz) 3MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 3MHz_High_QPSK_1@0(30MHz~9.49GHz) Report No.: 2507Z18185E-RF-01 Page 151 of 165 5MHz_Low_QPSK_1@0(30MHz~9.49GHz) 5MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 5MHz_High_QPSK_1@0(30MHz~9.49GHz) 10MHz_Low_QPSK_1@0(30MHz~9.49GHz) 10MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 10MHz_High_QPSK_1@0(30MHz~9.49GHz) Report No.: 2507Z18185E-RF-01 Page 152 of 165 FCC Part 24E Band 2, Normal Mode Va l u e (dBm) Limit Verdict 1.4MHz_Low_QPSK_1@0(30MHz~20.1GHz) -30.87 See Graphs Pass 1.4MHz_Middle_QPSK_1@0(30MHz~20.1GHz) -30.98 See Graphs Pass 1.4MHz_High_QPSK_1@0(30MHz~20.1GHz) -30.47 See Graphs Pass 3MHz_Low_QPSK_1@0(30MHz~20.1GHz) -30.01 See Graphs Pass 3MHz_Middle_QPSK_1@0(30MHz~20.1GHz) -29.72 See Graphs Pass 3MHz_High_QPSK_1@0(30MHz~20.1GHz) -29.83 See Graphs Pass 5MHz_Low_QPSK_1@0(30MHz~20.1GHz) -30.66 See Graphs Pass 5MHz_Middle_QPSK_1@0(30MHz~20.1GHz) -30.97 See Graphs Pass 5MHz_High_QPSK_1@0(30MHz~20.1GHz) -30.63 See Graphs Pass 10MHz_Low_QPSK_1@0(30MHz~20.1GHz) -31.01 See Graphs Pass 10MHz_Middle_QPSK_1@0(30MHz~20.1GHz) -30.96 See Graphs Pass 10MHz_High_QPSK_1@0(30MHz~20.1GHz) -31.37 See Graphs Pass 15MHz_Low_QPSK_1@0(30MHz~20.1GHz) -30.56 See Graphs Pass 15MHz_Middle_QPSK_1@0(30MHz~20.1GHz) -30.47 See Graphs Pass 15MHz_High_QPSK_1@0(30MHz~20.1GHz) -30.95 See Graphs Pass 20MHz_Low_QPSK_1@0(30MHz~20.1GHz) -30.01 See Graphs Pass 20MHz_Middle_QPSK_1@0(30MHz~20.1GHz) -30.63 See Graphs Pass 20MHz_High_QPSK_1@0(30MHz~20.1GHz) -30.69 See Graphs Pass Note:1RB was the worst case. Report No.: 2507Z18185E-RF-01 Page 153 of 165 Band 2, Normal 1RB was the worst case 1.4MHz_Low_QPSK_1@0(30MHz~20.1GHz) 1.4MHz_Middle_QPSK_1@0(30MHz~20.1GHz) 1.4MHz_High_QPSK_1@0(30MHz~20.1GHz) 3MHz_Low_QPSK_1@0(30MHz~20.1GHz) 3MHz_Middle_QPSK_1@0(30MHz~20.1GHz) 3MHz_High_QPSK_1@0(30MHz~20.1GHz) Report No.: 2507Z18185E-RF-01 Page 154 of 165 5MHz_Low_QPSK_1@0(30MHz~20.1GHz) 5MHz_Middle_QPSK_1@0(30MHz~20.1GHz) 5MHz_High_QPSK_1@0(30MHz~20.1GHz) 10MHz_Low_QPSK_1@0(30MHz~20.1GHz) 10MHz_Middle_QPSK_1@0(30MHz~20.1GHz) 10MHz_High_QPSK_1@0(30MHz~20.1GHz) Report No.: 2507Z18185E-RF-01 Page 155 of 165 15MHz_Low_QPSK_1@0(30MHz~20.1GHz) 15MHz_Middle_QPSK_1@0(30MHz~20.1GHz) 15MHz_High_QPSK_1@0(30MHz~20.1GHz) 20MHz_Low_QPSK_1@0(30MHz~20.1GHz) 20MHz_Middle_QPSK_1@0(30MHz~20.1GHz) 20MHz_High_QPSK_1@0(30MHz~20.1GHz) Report No.: 2507Z18185E-RF-01 Page 156 of 165 FCC Part 27 Band 4, Normal Mode Va l u e (dBm) Limit Verdict 1.4MHz_Low_QPSK_1@0(30MHz~18.55GHz) -30.71 See Graphs Pass 1.4MHz_Middle_QPSK_1@0(30MHz~18.55GHz) -30.21 See Graphs Pass 1.4MHz_High_QPSK_1@0(30MHz~18.55GHz) -31.25 See Graphs Pass 3MHz_Low_QPSK_1@0(30MHz~18.55GHz) -30.62 See Graphs Pass 3MHz_Middle_QPSK_1@0(30MHz~18.55GHz) -30.88 See Graphs Pass 3MHz_High_QPSK_1@0(30MHz~18.55GHz) -31.04 See Graphs Pass 5MHz_Low_QPSK_1@0(30MHz~18.55GHz) -30.30 See Graphs Pass 5MHz_Middle_QPSK_1@0(30MHz~18.55GHz) -31.20 See Graphs Pass 5MHz_High_QPSK_1@0(30MHz~18.55GHz) -30.92 See Graphs Pass 10MHz_Low_QPSK_1@0(30MHz~18.55GHz) -30.57 See Graphs Pass 10MHz_Middle_QPSK_1@0(30MHz~18.55GHz) -30.78 See Graphs Pass 10MHz_High_QPSK_1@0(30MHz~18.55GHz) -31.53 See Graphs Pass 15MHz_Low_QPSK_1@0(30MHz~18.55GHz) -29.68 See Graphs Pass 15MHz_Middle_QPSK_1@0(30MHz~18.55GHz) -31.35 See Graphs Pass 15MHz_High_QPSK_1@0(30MHz~18.55GHz) -31.61 See Graphs Pass 20MHz_Low_QPSK_1@0(30MHz~18.55GHz) -30.72 See Graphs Pass 20MHz_Middle_QPSK_1@0(30MH…

Text truncated - open the document above for the full version.

Report No.: 2507Z18185E-RF-01 Page 126 of 165 20MHz_Low_QPSK_1@0 20MHz_Low_QPSK_100@0 20MHz_Low_16QAM_1@0 20MHz_Low_16QAM_27@0 20MHz_High_QPSK_1@99 20MHz_High_QPSK_100@0 Report No.: 2507Z18185E-RF-01 Page 127 of 165 20MHz_High_16QAM_1@99 20MHz_High_16QAM_27@73 FCC Part 27 Band 4, Normal 1.4MHz_Low_QPSK_1@0 1.4MHz_Low_QPSK_6@0 1.4MHz_Low_16QAM_1@0 1.4MHz_Low_16QAM_6@0 Report No.: 2507Z18185E-RF-01 Page 128 of 165 1.4MHz_High_QPSK_1@5 1.4MHz_High_QPSK_6@0 1.4MHz_High_16QAM_1@5 1.4MHz_High_16QAM_6@0 3MHz_Low_QPSK_1@0 3MHz_Low_QPSK_15@0 Report No.: 2507Z18185E-RF-01 Page 129 of 165 3MHz_Low_16QAM_1@0 3MHz_Low_16QAM_15@0 3MHz_High_QPSK_1@14 3MHz_High_QPSK_15@0 3MHz_High_16QAM_1@14 3MHz_High_16QAM_15@0 Report No.: 2507Z18185E-RF-01 Page 130 of 165 5MHz_Low_QPSK_1@0 5MHz_Low_QPSK_25@0 5MHz_Low_16QAM_1@0 5MHz_Low_16QAM_25@0 5MHz_High_QPSK_1@24 5MHz_High_QPSK_25@0 Report No.: 2507Z18185E-RF-01 Page 131 of 165 5MHz_High_16QAM_1@24 5MHz_High_16QAM_25@0 10MHz_Low_QPSK_1@0 10MHz_Low_QPSK_50@0 10MHz_Low_16QAM_1@0 10MHz_Low_16QAM_27@0 Report No.: 2507Z18185E-RF-01 Page 132 of 165 10MHz_High_QPSK_1@49 10MHz_High_QPSK_50@0 10MHz_High_16QAM_1@49 10MHz_High_16QAM_27@23 15MHz_Low_QPSK_1@0 15MHz_Low_QPSK_75@0 Report No.: 2507Z18185E-RF-01 Page 133 of 165 15MHz_Low_16QAM_1@0 15MHz_Low_16QAM_27@0 15MHz_High_QPSK_1@74 15MHz_High_QPSK_75@0 15MHz_High_16QAM_1@74 15MHz_High_16QAM_27@48 Report No.: 2507Z18185E-RF-01 Page 134 of 165 20MHz_Low_QPSK_1@0 20MHz_Low_QPSK_100@0 20MHz_Low_16QAM_1@0 20MHz_Low_16QAM_27@0 20MHz_High_QPSK_1@99 20MHz_High_QPSK_100@0 Report No.: 2507Z18185E-RF-01 Page 135 of 165 20MHz_High_16QAM_1@99 20MHz_High_16QAM_27@73 Band 7, Normal 5MHz_Low_QPSK_1@0 5MHz_Low_QPSK_25@0 5MHz_Low_16QAM_1@0 5MHz_Low_16QAM_25@0 Report No.: 2507Z18185E-RF-01 Page 136 of 165 5MHz_High_QPSK_1@24 5MHz_High_QPSK_25@0 5MHz_High_16QAM_1@24 5MHz_High_16QAM_25@0 10MHz_Low_QPSK_1@0 10MHz_Low_QPSK_50@0 Report No.: 2507Z18185E-RF-01 Page 137 of 165 10MHz_Low_16QAM_1@0 10MHz_Low_16QAM_27@0 10MHz_High_QPSK_1@49 10MHz_High_QPSK_50@0 10MHz_High_16QAM_1@49 10MHz_High_16QAM_27@23 Report No.: 2507Z18185E-RF-01 Page 138 of 165 15MHz_Low_QPSK_1@0 15MHz_Low_QPSK_75@0 15MHz_Low_16QAM_1@0 15MHz_Low_16QAM_27@0 15MHz_High_QPSK_1@74 15MHz_High_QPSK_75@0 Report No.: 2507Z18185E-RF-01 Page 139 of 165 15MHz_High_16QAM_1@74 15MHz_High_16QAM_27@48 20MHz_Low_QPSK_1@0 20MHz_Low_QPSK_100@0 20MHz_Low_16QAM_1@0 20MHz_Low_16QAM_27@0

Report No.: 2507Z18185E-RF-01 Page 72 of 165 20MHz_Middle_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 20MHz_High_QPSK_100@0 Occupied Bandwidth 26dB Bandwidth 20MHz_High_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 73 of 165 RF Output Power FCC Part 22H Band 5, Normal Mode Average Conducted Power(dBm) ERP (dBm) ERP (W) Limit (W) Verdict 1.4MHz_Low_QPSK_1@0 22.24 20.69 0.117 7 Pass 1.4MHz_Low_QPSK_1@3 22.23 20.68 0.117 7 Pass 1.4MHz_Low_QPSK_1@5 22.20 20.65 0.116 7 Pass 1.4MHz_Low_QPSK_3@0 22.20 20.65 0.116 7 Pass 1.4MHz_Low_QPSK_3@1 22.21 20.66 0.116 7 Pass 1.4MHz_Low_QPSK_3@3 22.40 20.85 0.122 7 Pass 1.4MHz_Low_QPSK_6@0 21.35 19.80 0.095 7 Pass 1.4MHz_Low_16QAM_1@0 21.89 20.34 0.108 7 Pass 1.4MHz_Low_16QAM_1@3 21.76 20.21 0.105 7 Pass 1.4MHz_Low_16QAM_1@5 21.73 20.18 0.104 7 Pass 1.4MHz_Low_16QAM_3@0 21.73 20.18 0.104 7 Pass 1.4MHz_Low_16QAM_3@1 21.73 20.18 0.104 7 Pass 1.4MHz_Low_16QAM_3@3 21.72 20.17 0.104 7 Pass 1.4MHz_Low_16QAM_6@0 20.39 18.84 0.077 7 Pass 1.4MHz_Middle_QPSK_1@0 21.87 20.32 0.108 7 Pass 1.4MHz_Middle_QPSK_1@3 21.80 20.25 0.106 7 Pass 1.4MHz_Middle_QPSK_1@5 22 20.45 0.111 7 Pass 1.4MHz_Middle_QPSK_3@0 21.88 20.33 0.108 7 Pass 1.4MHz_Middle_QPSK_3@1 21.92 20.37 0.109 7 Pass 1.4MHz_Middle_QPSK_3@3 22 20.45 0.111 7 Pass 1.4MHz_Middle_QPSK_6@0 20.88 19.33 0.086 7 Pass 1.4MHz_Middle_16QAM_1@0 20.67 19.12 0.082 7 Pass 1.4MHz_Middle_16QAM_1@3 20.67 19.12 0.082 7 Pass 1.4MHz_Middle_16QAM_1@5 20.84 19.29 0.085 7 Pass 1.4MHz_Middle_16QAM_3@0 21.02 19.47 0.089 7 Pass 1.4MHz_Middle_16QAM_3@1 21.09 19.54 0.090 7 Pass 1.4MHz_Middle_16QAM_3@3 21.11 19.56 0.090 7 Pass 1.4MHz_Middle_16QAM_6@0 20.30 18.75 0.075 7 Pass 1.4MHz_High_QPSK_1@0 21.98 20.43 0.110 7 Pass 1.4MHz_High_QPSK_1@3 21.91 20.36 0.109 7 Pass Report No.: 2507Z18185E-RF-01 Page 74 of 165 Mode Average Conducted Power(dBm) ERP (dBm) ERP (W) Limit (W) Verdict 1.4MHz_High_QPSK_1@5 21.91 20.36 0.109 7 Pass 1.4MHz_High_QPSK_3@0 21.93 20.38 0.109 7 Pass 1.4MHz_High_QPSK_3@1 21.91 20.36 0.109 7 Pass 1.4MHz_High_QPSK_3@3 21.95 20.40 0.110 7 Pass 1.4MHz_High_QPSK_6@0 20.81 19.26 0.084 7 Pass 1.4MHz_High_16QAM_1@0 20.68 19.13 0.082 7 Pass 1.4MHz_High_16QAM_1@3 20.69 19.14 0.082 7 Pass 1.4MHz_High_16QAM_1@5 20.73 19.18 0.083 7 Pass 1.4MHz_High_16QAM_3@0 21.05 19.50 0.089 7 Pass 1.4MHz_High_16QAM_3@1 21.06 19.51 0.089 7 Pass 1.4MHz_High_16QAM_3@3 21.10 19.55 0.090 7 Pass 1.4MHz_High_16QAM_6@0 20.32 18.77 0.075 7 Pass 3MHz_Low_QPSK_1@0 22.90 21.35 0.136 7 Pass 3MHz_Low_QPSK_1@8 22.62 21.07 0.128 7 Pass 3MHz_Low_QPSK_1@14 22.62 21.07 0.128 7 Pass 3MHz_Low_QPSK_8@0 21.67 20.12 0.103 7 Pass 3MHz_Low_QPSK_8@4 21.61 20.06 0.101 7 Pass 3MHz_Low_QPSK_8@7 21.55 20.00 0.100 7 Pass 3MHz_Low_QPSK_15@0 21.57 20.02 0.100 7 Pass 3MHz_Low_16QAM_1@0 21.44 19.89 0.097 7 Pass 3MHz_Low_16QAM_1@8 21.36 19.81 0.096 7 Pass 3MHz_Low_16QAM_1@14 21.24 19.69 0.093 7 Pass 3MHz_Low_16QAM_8@0 20.65 19.10 0.081 7 Pass 3MHz_Low_16QAM_8@4 20.66 19.11 0.081 7 Pass 3MHz_Low_16QAM_8@7 20.63 19.08 0.081 7 Pass 3MHz_Low_16QAM_15@0 20.57 19.02 0.080 7 Pass 3MHz_Middle_QPSK_1@0 21.84 20.29 0.107 7 Pass 3MHz_Middle_QPSK_1@8 22.13 20.58 0.114 7 Pass 3MHz_Middle_QPSK_1@14 22.29 20.74 0.119 7 Pass 3MHz_Middle_QPSK_8@0 20.90 19.35 0.086 7 Pass 3MHz_Middle_QPSK_8@4 21.07 19.52 0.090 7 Pass 3MHz_Middle_QPSK_8@7 21.18 19.63 0.092 7 Pass 3MHz_Middle_QPSK_15@0 20.99 19.44 0.088 7 Pass 3MHz_Middle_16QAM_1@0 20.74 19.19 0.083 7 Pass Report No.: 2507Z18185E-RF-01 Page 75 of 165 Mode Average Conducted Power(dBm) ERP (dBm) ERP (W) Limit (W) Verdict 3MHz_Middle_16QAM_1@8 21.03 19.48 0.089 7 Pass 3MHz_Middle_16QAM_1@14 21.14 19.59 0.091 7 Pass 3MHz_Middle_16QAM_8@0 20.12 18.57 0.072 7 Pass 3MHz_Middle_16QAM_8@4 20.30 18.75 0.075 7 Pass 3MHz_Middle_16QAM_8@7 20.40 18.85 0.077 7 Pass 3MHz_Middle_16QAM_15@0 20.21 18.66 0.073 7 Pass 3MHz_High_QPSK_1@0 22.40 20.85 0.122 7 Pass 3MHz_High_QPSK_1@8 22.22 20.67 0.117 7 Pass 3MHz_High_QPSK_1@14 22.09 20.54 0.113 7 Pass 3MHz_High_QPSK_8@0 20.97 19.42 0.087 7 Pass 3MHz_High_QPSK_8@4 20.91 19.36 0.086 7 Pass 3MHz_High_QPSK_8@7 20.88 19.33 0.086 7 Pass 3MHz_High_QPSK_15@0 20.86 19.31 0.085 7 Pass 3MHz_High_16QAM_1@0 21.33 19.78 0.095 7 Pass 3MHz_High_16QAM_1@8 21.31 19.76 0.095 7 Pass 3MHz_High_16QAM_1@14 21.17 19.62 0.092 7 Pass 3MHz_High_16QAM_8@0 20.35 18.80 0.076 7 Pass 3MHz_High_16QAM_8@4 20.34 18.79 0.076 7 Pass 3MHz_High_16QAM_8@7 20.28 18.73 0.075 7 Pass 3MHz_High_16QAM_15@0 20.19 18.64 0.073 7 Pass 5MHz_Low_QPSK_1@0 23.04 21.49 0.141 7 Pass 5MHz_Low_QPSK_1@12 22.78 21.23 0.133 7 Pass 5MHz_Low_QPSK_1@24 22.35 20.80 0.120 7 Pass 5MHz_Low_QPSK_12@0 21.53 19.98 0.100 7 Pass 5MHz_Low_QPSK_12@7 21.54 19.99 0.100 7 Pass 5MHz_Low_QPSK_12@13 21.36 19.81 0.096 7 Pass 5MHz_Low_QPSK_25@0 21.41 19.86 0.097 7 Pass 5MHz_Low_16QAM_1@0 21.80 20.25 0.106 7 Pass 5MHz_Low_16QAM_1@12 21.57 20.02 0.100 7 Pass 5MHz_Low_16QAM_1@24 21.29 19.74 0.094 7 Pass 5MHz_Low_16QAM_12@0 20.60 19.05 0.080 7 Pass 5MHz_Low_16QAM_12@7 20.68 19.13 0.082 7 Pass 5MHz_Low_16QAM_12@13 20.47 18.92 0.078 7 Pass 5MHz_Low_16QAM_25@0 20.50 18.95 0.079 7 Pass Report No.: 2507Z18185E-RF-01 Page 76 of 165 Mode Average Conducted Power(dBm) ERP (dBm) ERP (W) Limit (W) Verdict 5MHz_Middle_QPSK_1@0 21.90 20.35 0.108 7 Pass 5MHz_Middle_QPSK_1@12 22.09 20.54 0.113 7 Pass 5MHz_Middle_QPSK_1@24 22.53 20.98 0.125 7 Pass 5MHz_Middle_QPSK_12@0 20.76 19.21 0.083 7 Pass 5MHz_Middle_QPSK_12@7 21.04 19.49 0.089 7 Pass 5MHz_Middle_QPSK_12@13 21.24 19.69 0.093 7 Pass 5MHz_Middle_QPSK_25@0 20.95 19.40 0.087 7 Pass 5MHz_Middle_16QAM_1@0 20.78 19.23 0.084 7 Pass 5MHz_Middle_16QAM_1@12 21.05 19.50 0.089 7 Pass 5MHz_Middle_16QAM_1@24 21.46 19.91 0.098 7 Pass 5MHz_Middle_16QAM_12@0 19.99 18.44 0.070 7 Pass 5MHz_Middle_16QAM_12@7 20.34 18.79 0.076 7 Pass 5MHz_Middle_16QAM_12@13 20.54 18.99 0.079 7 Pass 5MHz_Middle_16QAM_25@0 20.23 18.68 0.074 7 Pass 5MHz_High_QPSK_1@0 22.68 21.13 0.130 7 Pass 5MHz_High_QPSK_1@12 22.21 20.66 0.116 7 Pass 5MHz_High_QPSK_1@24 22.01 20.46 0.111 7 Pass 5MH…

Text truncated - open the document above for the full version.

Report No.: 2507Z18185E-RF-01 Page 55 of 165 10MHz_Low_QPSK_50@0 Occupied Bandwidth 26dB Bandwidth 10MHz_Low_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 10MHz_Middle_QPSK_50@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 56 of 165 10MHz_Middle_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 10MHz_High_QPSK_50@0 Occupied Bandwidth 26dB Bandwidth 10MHz_High_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 57 of 165 15MHz_Low_QPSK_75@0 Occupied Bandwidth 26dB Bandwidth 15MHz_Low_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 15MHz_Middle_QPSK_75@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 58 of 165 15MHz_Middle_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 15MHz_High_QPSK_75@0 Occupied Bandwidth 26dB Bandwidth 15MHz_High_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 59 of 165 20MHz_Low_QPSK_100@0 Occupied Bandwidth 26dB Bandwidth 20MHz_Low_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 20MHz_Middle_QPSK_100@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 60 of 165 20MHz_Middle_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 20MHz_High_QPSK_100@0 Occupied Bandwidth 26dB Bandwidth 20MHz_High_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 61 of 165 Band 66, Normal 1.4MHz_Low_QPSK_6@0 Occupied Bandwidth 26dB Bandwidth 1.4MHz_Low_16QAM_6@0 Occupied Bandwidth 26dB Bandwidth 1.4MHz_Middle_QPSK_6@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 62 of 165 1.4MHz_Middle_16QAM_6@0 Occupied Bandwidth 26dB Bandwidth 1.4MHz_High_QPSK_6@0 Occupied Bandwidth 26dB Bandwidth 1.4MHz_High_16QAM_6@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 63 of 165 3MHz_Low_QPSK_15@0 Occupied Bandwidth 26dB Bandwidth 3MHz_Low_16QAM_15@0 Occupied Bandwidth 26dB Bandwidth 3MHz_Middle_QPSK_15@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 64 of 165 3MHz_Middle_16QAM_15@0 Occupied Bandwidth 26dB Bandwidth 3MHz_High_QPSK_15@0 Occupied Bandwidth 26dB Bandwidth 3MHz_High_16QAM_15@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 65 of 165 5MHz_Low_QPSK_25@0 Occupied Bandwidth 26dB Bandwidth 5MHz_Low_16QAM_25@0 Occupied Bandwidth 26dB Bandwidth 5MHz_Middle_QPSK_25@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 66 of 165 5MHz_Middle_16QAM_25@0 Occupied Bandwidth 26dB Bandwidth 5MHz_High_QPSK_25@0 Occupied Bandwidth 26dB Bandwidth 5MHz_High_16QAM_25@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 67 of 165 10MHz_Low_QPSK_50@0 Occupied Bandwidth 26dB Bandwidth 10MHz_Low_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 10MHz_Middle_QPSK_50@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 68 of 165 10MHz_Middle_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 10MHz_High_QPSK_50@0 Occupied Bandwidth 26dB Bandwidth 10MHz_High_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 69 of 165 15MHz_Low_QPSK_75@0 Occupied Bandwidth 26dB Bandwidth 15MHz_Low_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 15MHz_Middle_QPSK_75@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 70 of 165 15MHz_Middle_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 15MHz_High_QPSK_75@0 Occupied Bandwidth 26dB Bandwidth 15MHz_High_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 71 of 165 20MHz_Low_QPSK_100@0 Occupied Bandwidth 26dB Bandwidth 20MHz_Low_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 20MHz_Middle_QPSK_100@0 Occupied Bandwidth 26dB Bandwidth

Report No.: 2507Z18185E-RF-01 Page 34 of 165 15MHz_Middle_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 15MHz_High_QPSK_75@0 Occupied Bandwidth 26dB Bandwidth 15MHz_High_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 35 of 165 20MHz_Low_QPSK_100@0 Occupied Bandwidth 26dB Bandwidth 20MHz_Low_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 20MHz_Middle_QPSK_100@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 36 of 165 20MHz_Middle_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth 20MHz_High_QPSK_100@0 Occupied Bandwidth 26dB Bandwidth 20MHz_High_16QAM_27@0 Occupied Bandwidth 26dB Bandwidth Report No.: 2507Z18185E-RF-01 Page 37 of 165 FCC Part 27 Band 4, Normal Mode 99% OBW (MHz) 26dB BW (MHz) 1.4MHz_Low_QPSK_6@0 1.084 1.273 1.4MHz_Low_16QAM_6@0 1.081 1.278 1.4MHz_Middle_QPSK_6@0 1.078 1.250 1.4MHz_Middle_16QAM_6@0 1.084 1.284 1.4MHz_High_QPSK_6@0 1.078 1.230 1.4MHz_High_16QAM_6@0 1.084 1.267 3MHz_Low_QPSK_15@0 2.682 2.925 3MHz_Low_16QAM_15@0 2.682 2.907 3MHz_Middle_QPSK_15@0 2.682 2.925 3MHz_Middle_16QAM_15@0 2.682 2.919 3MHz_High_QPSK_15@0 2.676 2.877 3MHz_High_16QAM_15@0 2.676 2.883 5MHz_Low_QPSK_25@0 4.470 4.845 5MHz_Low_16QAM_25@0 4.470 4.855 5MHz_Middle_QPSK_25@0 4.470 4.815 5MHz_Middle_16QAM_25@0 4.480 4.855 5MHz_High_QPSK_25@0 4.470 4.805 5MHz_High_16QAM_25@0 4.460 4.885 10MHz_Low_QPSK_50@0 8.940 9.470 10MHz_Low_16QAM_27@0 4.880 5.546 10MHz_Middle_QPSK_50@0 8.940 9.570 10MHz_Middle_16QAM_27@0 4.880 5.526 10MHz_High_QPSK_50@0 8.940 9.510 10MHz_High_16QAM_27@0 4.880 5.405 15MHz_Low_QPSK_75@0 13.440 14.384 15MHz_Low_16QAM_27@0 4.980 5.646 15MHz_Middle_QPSK_75@0 13.440 14.294 15MHz_Middle_16QAM_27@0 4.920 5.556 15MHz_High_QPSK_75@0 13.410 14.294 15MHz_High_16QAM_27@0 4.980 5.706 Report No.: 2507Z18185E-RF-01 Page 38 of 165 Mode 99% OBW (MHz) 26dB BW (MHz) 20MHz_Low_QPSK_100@0 17.840 18.819 20MHz_Low_16QAM_27@0 4.960 5.646 20MHz_Middle_QPSK_100@0 17.920 18.819 20MHz_Middle_16QAM_27@0 4.960 5.606 20MHz_High_QPSK_100@0 17.880 18.819 20MHz_High_16QAM_27@0 5 5.686 Band 7, Normal Mode 99% OBW (MHz) 26dB BW (MHz) 5MHz_Low_QPSK_25@0 4.470 4.865 5MHz_Low_16QAM_25@0 4.480 4.865 5MHz_Middle_QPSK_25@0 4.470 4.835 5MHz_Middle_16QAM_25@0 4.470 4.855 5MHz_High_QPSK_25@0 4.480 4.835 5MHz_High_16QAM_25@0 4.480 4.845 10MHz_Low_QPSK_50@0 8.900 9.510 10MHz_Low_16QAM_27@0 4.880 5.425 10MHz_Middle_QPSK_50@0 8.920 9.630 10MHz_Middle_16QAM_27@0 4.880 5.405 10MHz_High_QPSK_50@0 8.940 9.630 10MHz_High_16QAM_27@0 4.900 5.546 15MHz_Low_QPSK_75@0 13.380 14.324 15MHz_Low_16QAM_27@0 4.980 5.826 15MHz_Middle_QPSK_75@0 13.470 14.264 15MHz_Middle_16QAM_27@0 4.980 5.736 15MHz_High_QPSK_75@0 13.440 14.414 15MHz_High_16QAM_27@0 4.950 5.676 20MHz_Low_QPSK_100@0 17.800 18.859 20MHz_Low_16QAM_27@0 4.960 5.686 20MHz_Middle_QPSK_100@0 17.920 18.779 20MHz_Middle_16QAM_27@0 5 5.646 20MHz_High_QPSK_100@0 17.840 18.899 20MHz_High_16QAM_27@0 5 5.726 Report No.: 2507Z18185E-RF-01 Page 39 of 165 Band 66, Normal Mode 99% OBW (MHz) 26dB BW (MHz) 1.4MHz_Low_QPSK_6@0 1.084 1.253 1.4MHz_Low_16QAM_6@0 1.081 1.275 1.4MHz_Middle_QPSK_6@0 1.075 1.242 1.4MHz_Middle_16QAM_6@0 1.084 1.259 1.4MHz_High_QPSK_6@0 1.078 1.242 1.4MHz_High_16QAM_6@0 1.086 1.275 3MHz_Low_QPSK_15@0 2.682…

Text truncated - open the document above for the full version.
