Report No.: 2507V18169E-RF-01 Page 1 of 170 Appendix A Test Information: Sample No.: 3B0H-2 Te s t D a t e : 2025/11/10~2025/11/11 Te s t S i t e : RF Te s t M o d e : Transmitting Tester: Braylon Ma Test Result: Pass Environmental Conditions: Temperature: (°C) 23.5~24.6 Relative Humidity: (%) 48~59 ATM Pressure: (kPa) 100.2~100.3 Report No.: 2507V18169E-RF-01 Page 2 of 170 Frequency stability vs. temperature &Frequency stability vs. voltage Compliance FCC Part 22H Band 5, TN/VN Mode Test Channel (MHz) Frequency Error Limit (ppm) Verdict (Hz) (ppm) 10MHz_Middle_QPSK_50@0 836.5 -20.10 -0.0240 ±2.5 Pass 10MHz_Middle_16QAM_27@0 836.5 -13.13 -0.0157 ±2.5 Pass Band 5, T1/VN Mode Test Channel (MHz) Frequency Error Limit (ppm) Verdict (Hz) (ppm) 10MHz_Middle_QPSK_50@0 836.5 -19.93 -0.0238 ±2.5 Pass 10MHz_Middle_16QAM_27@0 836.5 -6.34 -0.0076 ±2.5 Pass Band 5, T2/VN Mode Test Channel (MHz) Frequency Error Limit (ppm) Verdict (Hz) (ppm) 10MHz_Middle_QPSK_50@0 836.5 -17.18 -0.0205 ±2.5 Pass 10MHz_Middle_16QAM_27@0 836.5 -14.63 -0.0175 ±2.5 Pass Band 5, T3/VN Mode Test Channel (MHz) Frequency Error Limit (ppm) Verdict (Hz) (ppm) 10MHz_Middle_QPSK_50@0 836.5 -19.07 -0.0228 ±2.5 Pass 10MHz_Middle_16QAM_27@0 836.5 -10.74 -0.0128 ±2.5 Pass Band 5, T4/VN Mode Test Channel (MHz) Frequency Error Limit (ppm) Verdict (Hz) (ppm) 10MHz_Middle_QPSK_50@0 836.5 -15.92 -0.0190 ±2.5 Pass 10MHz_Middle_16QAM_27@0 836.5 -16.52 -0.0197 ±2.5 Pass Band 5, T5/VN Mode Test Channel (MHz) Frequency Error Limit (ppm) Verdict (Hz) (ppm) 10MHz_Middle_QPSK_50@0 836.5 -16.91 -0.0202 ±2.5 Pass 10MHz_Middle_16QAM_27@0 836.5 -27.11 -0.0324 ±2.5 Pass Report No.: 2507V18169E-RF-01 Page 3 of 170 Band 5, T6/VN Mode Test Channel (MHz) Frequency Error Limit (ppm) Verdict (Hz) (ppm) 10MHz_Middle_QPSK_50@0 836.5 -17.27 -0.0206 ±2.5 Pass 10MHz_Middle_16QAM_27@0 836.5 -12.40 -0.0148 ±2.5 Pass Band 5, T7/VN Mode Test Channel (MHz) Frequency Error Limit (ppm) Verdict (Hz) (ppm) 10MHz_Middle_QPSK_50@0 836.5 -15.68 -0.0187 ±2.5 Pass 10MHz_Middle_16QAM_27@0 836.5 -22.10 -0.0264 ±2.5 Pass Band 5, T8/VN Mode Test Channel (MHz) Frequency Error Limit (ppm) Verdict (Hz) (ppm) 10MHz_Middle_QPSK_50@0 836.5 -16.32 -0.0195 ±2.5 Pass 10MHz_Middle_16QAM_27@0 836.5 -16.02 -0.0192 ±2.5 Pass Band 5, TN/VH Mode Test Channel (MHz) Frequency Error Limit (ppm) Verdict (Hz) (ppm) 10MHz_Middle_QPSK_50@0 836.5 -13.60 -0.0163 ±2.5 Pass 10MHz_Middle_16QAM_27@0 836.5 -15.32 -0.0183 ±2.5 Pass Band 5, TN/VL Mode Test Channel (MHz) Frequency Error Limit (ppm) Verdict (Hz) (ppm) 10MHz_Middle_QPSK_50@0 836.5 -18.01 -0.0215 ±2.5 Pass 10MHz_Middle_16QAM_27@0 836.5 -22.99 -0.0275 ±2.5 Pass Note: Frequency Error (ppm)=Frequency Error (MHz)/Test Channel(MHz)*10 6 TN: 20°C; T1: -30°C; T2: -20°C; T3: -10°C; T4: 0°C; T5: 10°C; T6: 30°C; T7: 40°C; T8: 50°C. VN: Normal Voltage; VL: Low Voltage; VH: High Voltage. Report No.: 2507V18169E-RF-01 Page 4 of 170 FCC Part 24E Band 2, TN/VN Mode F_L (MHz) F_H (MHz) Limit (MHz) Verdict 20MHz_Low_QPSK_100@0 1851.129 1868.991 1850 ~ 1910 Pass 20MHz_Low_16QAM_27@0 1850.949 1855.984 1850 ~ 1910 Pass 20MHz_High_QPSK_100@0 1891.069 1908.991 1850 ~ 1910 Pass 20MHz_High_16QAM_27@73 1904.136 1909.111 1850 ~ 1910 Pass Band 2, T1/VN Mode F_L (MHz) F_H (MHz) Limit (MHz) Verdict 20MHz_Low_QPSK_100@0 1851.129 1868.991 1850 ~ 1910 Pass 20MHz_Low_16QAM_27@0 1850.949 1855.984 1850 ~ 1910 Pass 20MHz_High_QPSK_100@0 1891.069 1908.931 1850 ~ 1910 Pass 20MHz_High_16QAM_27@73 1904.076 1909.051 1850 ~ 1910 Pass Band 2, T2/VN Mode F_L (MHz) F_H (MHz) Limit (MHz) Verdict 20MHz_Low_QPSK_100@0 1851.129 1868.931 1850 ~ 1910 Pass 20MHz_Low_16QAM_27@0 1850.949 1855.984 1850 ~ 1910 Pass 20MHz_High_QPSK_100@0 1891.129 1908.931 1850 ~ 1910 Pass 20MHz_High_16QAM_27@73 1904.076 1909.051 1850 ~ 1910 Pass Band 2, T3/VN Mode F_L (MHz) F_H (MHz) Limit (MHz) Verdict 20MHz_Low_QPSK_100@0 1851.069 1868.991 1850 ~ 1910 Pass 20MHz_Low_16QAM_27@0 1851.009 1855.984 1850 ~ 1910 Pass 20MHz_High_QPSK_100@0 1891.129 1908.931 1850 ~ 1910 Pass 20MHz_High_16QAM_27@73 1904.136 1909.051 1850 ~ 1910 Pass Band 2, T4/VN Mode F_L (MHz) F_H (MHz) Limit (MHz) Verdict 20MHz_Low_QPSK_100@0 1851.069 1868.991 1850 ~ 1910 Pass 20MHz_Low_16QAM_27@0 1850.949 1855.924 1850 ~ 1910 Pass 20MHz_High_QPSK_100@0 1891.129 1908.991 1850 ~ 1910 Pass 20MHz_High_16QAM_27@73 1904.076 1909.051 1850 ~ 1910 Pass Report No.: 2507V18169E-RF-01 Page 5 of 170 Band 2, T5/VN Mode F_L (MHz) F_H (MHz) Limit (MHz) Verdict 20MHz_Low_QPSK_100@0 1851.069 1868.991 1850 ~ 1910 Pass 20MHz_Low_16QAM_27@0 1851.009 1855.984 1850 ~ 1910 Pass 20MHz_High_QPSK_100@0 1891.129 1908.931 1850 ~ 1910 Pass 20MHz_High_16QAM_27@73 1904.076 1909.051 1850 ~ 1910 Pass Band 2, T6/VN Mode F_L (MHz) F_H (MHz) Limit (MHz) Verdict 20MHz_Low_QPSK_100@0 1851.129 1868.991 1850 ~ 1910 Pass 20MHz_Low_16QAM_27@0 1850.949 1855.984 1850 ~ 1910 Pass 20MHz_High_QPSK_100@0 1891.069 1908.931 1850 ~ 1910 Pass 20MHz_High_16QAM_27@73 1904.136 1909.051 1850 ~ 1910 Pass Band 2, T7/VN Mode F_L (MHz) F_H (MHz) Limit (MHz) Verdict 20MHz_Low_QPSK_100@0 1851.129 1869.051 1850 ~ 1910 Pass 20MHz_Low_16QAM_27@0 1851.009 1855.984 1850 ~ 1910 Pass 20MHz_High_QPSK_100@0 1891.129 1908.931 1850 ~ 1910 Pass 20MHz_High_16QAM_27@73 1904.076 1909.051 1850 ~ 1910 Pass Band 2, T8/VN Mode F_L (MHz) F_H (MHz) Limit (MHz) Verdict 20MHz_Low_QPSK_100@0 1851.129 1868.991 1850 ~ 1910 Pass 20MHz_Low_16QAM_27@0 1850.949 1855.984 1850 ~ 1910 Pass 20MHz_High_QPSK_100@0 1891.069 1908.931 1850 ~ 1910 Pass 20MHz_High_16QAM_27@73 1904.076 1909.051 1850 ~ 1910 Pass Band 2, TN/VH Mode F_L (MHz) F_H (MHz) Limit (MHz) Verdict 20MHz_Low_QPSK_100@0 1851.129 1868.991 1850 ~ 1910 Pass 20MHz_Low_16QAM_27@0 1851.009 1855.984 1850 ~ 1910 Pass 20MHz_High_QPSK_100@0 1891.129 1908.991 1850 ~ 1910 Pass 20MHz_High_16QAM_27@73 1904.136 1909.051 1850 ~ 1910 Pass Report No.: 2507V18169E-RF-01 Page 6 of 170 Band 2, TN/VL Mode F_L (MHz) F_H (MHz) Limit (MHz) Verdict 20MHz_Low_QPSK_100@0 1851.129 1868.991 1850 ~ 1910 Pass 20MHz_Low_16Q…

Text truncated - open the document above for the full version.

FCC Part 27, Part 22H, Part 24E Page 1 of 33 FCC PART 27 FCC P ART 22H, PART 24E TEST REPORT For Quanzhou Rongyaokesi Electronic Technology Co., LTD No. 68, Jinpu, Pudang Village, Xiamei Town, Nan 'an City, Quanzhou City, Fujian Province, China FCC ID: 2BQVD-TK-168 Report Type: Original Report Product Name: 4G LTE POC RADIO Report Number: 2507V18169E-RF-01 Report Date: 2025-11-13 Reviewed By: Ash Lin Approved By: Miles Chen Prepared By: Bay Area Compliance Laboratories Corp. (Xiamen) Unit 102, No. 902 Meifeng South Road, Binhai West Avenue, Science and Technology Innovation Park, Torch High tech Zone XiaMen Tel: +86-592-3200111 www.baclcorp.com.cn Bay Are…
