A3KM09614" LCD Monitor

Philips Electronics Industries (Taiwan) Ltd

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Apr 24, 2000
Application Purpose: Original Equipment
Date of Application: Mar 27, 2000
Equipment Note: 14" LCD Monitor
Company: Philips Electronics Industries (Taiwan) Ltd
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Block Diagram

Cover Letter(s)

Safety & Compliance Consulting 29 Sweetman Lane West Milford, NJ 07480-2932 Tel/Fax (973) 728-5141 April 24, 2000 PHI2000-F007A Attn:Diane Poole / FCC-OET Re:FCC ID: A3KM096 Applicant:Philips Electronics Industries (Taiwan) Ltd. Correspondence Ref No:13341 731 Confirmation Number:EA97177 Date of FCC E-Mail:04/07/2000 Type Product (EUT):14” LCD Monitor Dear Diane Poole: Please be advised, the subject monitor is provided with non-detachable shielded 15-Pin D-Sub connector signal cable with two external bonded ferrite cores and AC Adapter with one bonded ferrite core near its unshielded DC output cable jack. The test report and associated photographs show these two special cables were used during system tests. The other host peripheral devices were connected with typical shielded interface cables without any external ferrite cores. I trust this answers your inquiry. If not, please advise. Sincerely yours, Richard Mullen Manager Safety & Compliance Consulting
