A3KM11517" Color Monitor

Product Information Product Features • LightFrame™ for Windows • Technical Specifications • Power Management • Automatic Power Saving • Physical Specification • Pin Assignment • Product Views Product Features 107P40:
17-inch (16.0" VIS) Real Flat color monitor featuring ICE technology for excellent front of screen performance for use with MACs, PCs .
Autoscan covers horizontal frequencies up to 92 kHz offering a maximum resolution of 1920 x 1440 with flicker free display of 1024 x 768 up to 115 Hz
Flat aperture grille CRT with high-resolution 0.25 mm stripe pitch.
LightFrame™ for brightest and sharpest display of movie and photo windows.
Multimedia Base and USB Hub option
sRGB for true on screen color representation.
FCC, CE (in selected countries only) and ISO9241, ISO14001 certified RETURN TO TOP OF THE PAGE LightFrame™ for Windows Introduction Philips LightFrame™ feature enriches the experience of pictures and video on a Philips CRT (picture tube) monitor. LightFrame™ will boost the brightness and sharpness of photos and videos on the monitor screen. To control the LightFrame™ feature in your monitor, you have to install the LightFrame™ application which you will find on this CD-ROM. Note Philips LightFrame™ will only work with monitors that have been built to use this software. Earlier Philips monitors or other manufacturers’ monitors will not work with this special software. It is recommended that you install this software only on a Philips monitor designed to use it. These monitors can be identified by the LightFrame™ logo on the front of the monitor. This software is not designed for use with LCD flat screen monitors. LightFrame™ will work with true Windows-based programs and DOS-based programs that operate in a Windows environment. It will not work with DOS-based programs operating only in a DOS environment. Language Selection While English is the default language of LightFrame™, the User Interface can be set up to Exhibit 3 Installstion and Operating Instructions A: All Philips LightFrame™ 3 monitors display this logo on their front bezel: Q: How do I use the LightFrame™ 3 control bar that appears at the top my screen? A: The control bar is another upgrade that helps you run all LightFrame™ 3’s neat, new features. The illustration below describes the tasks each button performs. Accustomed to working with the original LightFrame™ tray icon? No problem: It’s still there and can be used to turn LightFrame™ on or off and check LightFrame™ status. RETURN TO TOP OF THE PAGE Technical Specifications* CRT • Size and deflection 17 inch / 41 cm ; 90° deflection angle • Grille pitch0.25 mm • Tube type Aperture grille, flat, high contrast, high brightness,anti- glare, anti-static, anti reflection, light transmission 38% • PhosphorB22 • Recommended display area12.0" x 9.0" / 306 x 230 mm * These information are subject to change without notice. • Maximum display area12.8" x 9.6" / 325 x 244 mm SCANNING • Horizontal scanning30 - 92 KHz • Vertical scanning50-160 Hz VIDEO • Video dot rate234 MHz • Input impedance - Video75 ohm - Sync2.2 kOhm • Input signal levels0.7 Vpp • Sync input signal Separate sync Composite sync • Sync polaritiesPositive and negative WHITE COLOR TEMPERATURE Chromaticity CIE coordinates: • at 9300 K degreesx = 0.283 / y = 0.297 • at 6500 K degreesx = 0.313 / y = 0.329 • at 5500 K degreesx = 0.332 / y = 0.347 sRGB sRGB is a standard for ensuring correct exchange of colors between different devices (e.g. digital cameras, monitors, printers, scanners, etc.) Using a standard unified color space, sRGB will help represent pictures taken by an sRGB compatible device correctly on your sRGB enabled Philips monitors. In that way, the colors are calibrated and you can rely on the correctness of the colors shown on your screen. Important with the use of sRGB is that the brightness and contrast of your monitor is fixed to a predefined setting as well as the color gamut. Therefore it is important to select the sRGB setting in the monitor's OSD. To do so, open the OSD by pressing the OK button on the front of your monitor. Use the down button to go to Color temperature and press OK again. Then move the down button to go to sRGB and press OK again. Exit this OSD. After this, please don't change the brightness or contrast setting of your monitor. If you change either of these, the monitor will exit the sRGB mode and go to a color temperature setting of 6500K. For more information on sRGB, please visit: www.srgb.com RETURN TO TOP OF THE PAGE Power Management Complies with EPA Energy Star and NUTEK specifications Automatic Power Saving If you have VESA's DPMS compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. And if an input from a keyboard, mouse or other input device is detected, the monitor will automatically "wake up". The following table shows the power consumption and signaling of this automatic power saving features: RETURN TO TOP OF THE PAGE Physical Specifications • Typical operation :92W • Suspend / Standby Mode :< 15W • Off Mode :< 2W Power Management Definition VESA's Mode Video H-sync V-sync Power Used Power Saving (%) LED color ON ActiveYes Yes < 92W 0 %Green Stand-by BlankedNo Yes < 2W 97% Yellow Suspend BlankedYes No < 2W 97% Yellow OFF BlankedNo No < 2W 97% Yellow This monitor is ENERGY STAR® compliant. As an ENERGY STAR ® Partner, PHILIPS has determined that this product meets the ENERGY STAR ® guidelines for energy efficiency. • Dimensions 15.7" x 16.1" x 16.5" / 399 x 410 x 419 mm (including base) 15.7" x 14.7" x 16.5" / 399 x 373 x 419 mm (excluding base) • Weight17.5 kg • Power supply90 - 264 VAC, 50/60Hz • Power consumption92 Watt* • Temperature (operating)0° to 40°C / 32° to 104°F • Temperature (storage)-25° to +65°C / -13° to +149°F * These information are subject to change without notice. RETURN TO TOP OF THE PAGE Pin Assignment The 15-pin D-sub connector (male) of the s…

Text truncated - open the document above for the full version.

107P4 17" 92KHz BUS-DRIVER MONITOR H V V H HV H. freq. : 30 - 92KHzV. freq. : 50 - 160Hz S-Capacitor Switch Switching power fre q 30-80kHz CPU clock freq. : 12MHz H/O HV H/O V/O +190 90~264V +80 +13 47~63Hz +8 +5 -13 R B Pre -Amp TDA4886A Post-Amp LM2435T OSD NOV 68275-00031 Rotation CRT CPU WT62P1/ DDC2B Linearity Control DAF/ SLA5094 S-Capacitor Horizontal Deflection Vertical TDA8172 Muting CKT Sync Processor TDA 4841 XXX EHT/UC3843A X-RAY MHR Ckt Power Supply TEA1507 + Degussing ckt Video /B DAC SCL SD +6.3 DAC HUNLOCK Main /B SDA/SCL EEPROM EEPROMEEPROMEEPROM ST24C16 ST24C16ST24C16ST24C16 FunctionKey/Control Board& LED109B2 Flyingcable 15pin D-sub G Video-E TDA4823 Exhibit 5 Block Diagram

FCC ID: A3KM115 Exhibit 7 Photographs Front View FCC ID: A3KM115 Rear View FCC ID: A3KM115 Label

Exhibit 2 FCC ID Label

FCC ID: A3KM115 Side View Without Back Cover FCC ID: A3KM115 Side View Without Back Cover FCC ID: A3KM115 Shielding FCC ID: A3KM115 CRT Assembly FCC ID: A3KM115 PCB Layout FCC ID: A3KM115 PCB Layout FCC ID: A3KM115 PCB Layout FCC ID: A3KM115 PCB Layout FCC ID: A3KM115 Metal Plate FCC ID: A3KM115 Power Cord and I/F Cables

Philips Electronics Industries (Taiwan) Ltd - EMC Lab. 5, Tze Chiang 1 Road, Chungli Industrial Park, Chungli, Taoyuan, Taiwan Tel.: +886-3-454-9862 Fax.: +886-3-454-9887 E-mail: [email protected] FCC Test Report Report No.: TYR87-2015 Date : 03 July, 2002 Page : Page 1 of 32 Customer : Philips Electronics Industries Name : Mr. S.T. Huang – EE LCD Address : 5, Tze Chiang 1 Road, Zip/City : Chungli Industrial Park, Country : Chungli, Taiwan, R.O.C. Equipment Under Test (including peripherals) : FCC ID. : A3KM115 Model Name : 107P40 Serial Number : TY0205343 Description : 17” XGA color monitor, Max. resolution 1280x1024/85Hz EMC Standards : FCC Part 15 of October 01,1999 Class B ANSI C63.4-1992 Result : PASSED the limits/test-levels in the standards. Note : The results in this report apply only to the sample(s) and mode(s) tested. It is the manufacturer’s responsibility to assume the continued EMC compliance of production models. Date of receipt of EUT : 28 Jun. 2002 Date of performance of test : 30 Jun., 2002 to 01 Jul., 2002 NVLAP Signatory Philips Electronics Industries (Taiwan) Ltd This report shall not be reproduce except in full, without written approval of the testing laboratory C.C. Wu - EMC Test Engineer Ronnie Yang - EMC Manager Reference: TYR87-2015 107P40 Date: 03 July 2002 Philips Electronics Industries (Taiwan) Ltd Page: 2 of 32 Table of contents 1. Summary of test results.............................................................................3 2. General information of EUT.......................................................................4 3. Test equipment.......................................................................................5 4. Test configuration of EUT and peripherals......................................................6 5. Test procedure.......................................................................................7 6. Measurement uncertainty...........................................................................9 7. Conducted emissions test..........................................................................10 8. Radiated emissions test............................................................................19 9. Photographs of test set-up.........................................................................28 10. References...........................................................................................32 Reference: TYR87-2015 107P40 Date: 03 July 2002 Philips Electronics Industries (Taiwan) Ltd Page: 3 of 32 1. Summary of test results Test Standard Result Note Emission, ANSI C63.4-1992 Conducted emission Radiated emission FCC Part 15 FCC Part 15 Passed Passed Remark: The test sample fully complies with the requirements set forth in : FCC Part 15 Class B. Reference: TYR87-2015 107P40 Date: 03 July 2002 Philips Electronics Industries (Taiwan) Ltd Page: 4 of 32 2. General Information of EUT The EUT, 17” color monitor : Model No. : 107P40 FCC ID : A3KM115 Brand : Philips The color monitor automatically scans horizontal frequencies between 30KHz and 92KHz , and vertical frequencies between 50Hz and 160Hz. This color monitor displays sharp and brilliant images of text and graphics with a maximum resolution up to 1280x1024 pixels. The monitor has 7 factory-preset modes as indicated in the following table: Item Resolution Freq. V x H Pixel rate(Mhz) Remark 1 640x480 75(37.500k) 31.500 VESA 2 800x600 75(46.875k) 49.500 VESA 3 800x600 85(53.674k) 56.250 VESA 4 1024x768 75(60.000k) 78.750 VESA 5 1024x768 85(68.677k) 94.500 VESA 6 1280x1024 75(79.976k) 135.000 VESA 7 1280x1024 85(91.146k) 157.500 VESA Reference: TYR87-2015 107P40 Date: 03 July 2002 Philips Electronics Industries (Taiwan) Ltd Page: 5 of 32 3. Test Equipment Test equipment used for line Conducted and Radiated emissions as following. All equipment were calibrated according to ANSI C63.4-1992 and ISO-9000 requirement unless otherwise specified. Traceability to R.O.C. and international standards is assured by using calibrated all equipment. - For Conducted Emissions Test: Test Equipment Model No. Serial No. Last Calibrate Next Calibrate Spectrum HP8568B 2415A00346 08/15/2001 08/15/2002 EMI Receiver R & S ESVS30 841977/006 06/13/2002 06/13/2003 LISN EMCO 3825/2 9311-2153 06/13/2002 06/13/2003 LISN EMCO 3825/2 9311-2154 06/13/2002 06/13/2003 RF Cable 8-meter N/A 05/29-2002 05/29/2003 - For Radiated Emissions Test: Test Equipment Model No. Serial No. Last Calibrate Next Calibrate Spectrum HP8568B 2415A00346 08/15/2001 08/15/2002 RF Preselector HP85685A 2901A00946 08/15/2001 08/15/2002 QP Adapter HP85650A 2043A00366 08/15/2001 08/15/2002 EMI Receiver HP85460A 3441A00199 09/11/2001 09/11/2002 RFI Filter Section HP85460A 3330A00177 09/11/2001 09/11/2002 EMI Receiver R & S ESVS30 841977/006 05/29/2002 05/29/2003 Biconical Antenna EMCO 3110B 3222 06/04/2002 06/04/2003 Biconical Antenna EMCO 3110B 3224 06/04/2002 06/04/2003 Log-Periodic Antenna EMCO 3146A 1424 06/04/2002 06/04/2003 Log-Periodic Antenna EMCO 3146A 1425 06/04/2002 06/04/2003 Turn Table EMCO 1060 1068 05/27/2002 05/27/2003 Antenna Tower EMCO 1050 1113 05/27/2002 05/27/2003 RF Cable M17/75-RG214-NE N/A 05/27/2002 05/27/2003 Reference: TYR87-2015 107P40 Date: 03 July 2002 Philips Electronics Industries (Taiwan) Ltd Page: 6 of 32 4. Test Configuration of EUT and Peripherals The system was configured for testing in a typical fashion ( as a customer would normally use it ) according to ANSI C63.4-1992, please see the photographs for detail. For system measurement, the EUT “107P40” were connected to: Description Brand/ Model No. Serial No. FCC ID Remark A Monitor Philips 107P40 TY0205343 A3KM115 EUT B PC Compaq ENC P866 5K15FXHZ2013 FCC Logo C Keyboard Compaq KB-9963 B26950GGALP13Q FCC Logo D Mouse Compaq M-S48a JNZ201213 E Modem USRobotics 268 2680559278575 CJE-0318 F Printer HP 2225C 3145S02419 DSI6XU2225 Connected Cables No. Description Manufacturer Length Shielded Remark 1 Power Cord Long Shine 1.8 me…

Text truncated - open the document above for the full version.

Reference: TYR87-2015 107P40 Date: 03 July 2002 Philips Electronics Industries (Taiwan) Ltd Page: 28 of 32 9. Photographs of Test Set-up Conducted Emissions Test Reference: TYR87-2015 107P40 Date: 03 July 2002 Philips Electronics Industries (Taiwan) Ltd Page: 29 of 32 Conducted Emissions Test Reference: TYR87-2015 107P40 Date: 03 July 2002 Philips Electronics Industries (Taiwan) Ltd Page: 30 of 32 Radiated Emissions Test Reference: TYR87-2015 107P40 Date: 03 July 2002 Philips Electronics Industries (Taiwan) Ltd Page: 31 of 32 Radiated Emissions Test
