A3LSMH204VIndoor CPE

Printed in Korea Verizon Wireless 5G CPE Product Safety and Warranty Please read this manual before operating your device and keep it for future reference. This document contains important terms and conditions with respect to your device. By using this device, you accept those terms and conditions. 5G CPE PSW - Outdoor.indd 11/19/2018 1:40:53 PM FC C ID: A3LSMH204V Important legal information Arbitration Agreement - This Product is subject to a binding arbitration agreement between you and SAMSUNG ELECTRONICS AMERICA, INC. (“Samsung”). You can opt out of the agreement within 30 calendar days of the first consumer purchase by emailing [email protected] or calling 1-800-SAMSUNG (726-7864) and providing the applicable information. The full Arbitration Agreement, Standard One-year Limited Warranty, End User License Agreement (EULA), and Health & Safety Information for your device are available online: • English: www.samsung.com/us/Legal/Tablet-HSGuide • Spanish: www.samsung.com/us/Legal/ Tablet-HSGuide-SP Terms and Conditions Read this document before operating the mobile device, accessories, or software (defined collectively and individually as the “Product”) and keep it for future reference. This document contains impor- tant Terms and Conditions. Electronic acceptance, opening the packaging, use, or retention of the Product constitutes acceptance of these Terms and Conditions. Revised 06/2019 Samsung Electronics America, Inc. 85 Challenger Road Ridgefield Park, NJ 07660 Phone: 1-800-SAMSUNG (726-7864) Internet: www.samsung.com Health and Safety WARNING! To avoid electric shock and damage to your device, do not charge device while it is wet or in an area where it could get wet. Do not handle device, charger or cords with wet hands while charging. Samsung mobile products and recycling WARNING! Never dispose of batteries in a fire because they may explode. Do not disassemble, crush, puncture, heat, burn or reuse. For battery and cell phone recycling, go to call2recycle.org or call 1-800-822-8837. For more recycling information, go to our website: www.samsung.com/recycling or call 1-800-SAMSUNG. FCC Part 15 Information and Notices This device complies with part 15 of the FCC Rules. Operation is subject to conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Device temperature Caution! Some applications or prolonged usage may increase device temperature. If the device feels hot to the touch, discontinue use and close all applications or turn off the device until it cools. Always ensure that the device has adequate ventilation and air flow. Covering the device can trap any dissipating heat and redirect it back to the device while it is active. ©2020 Samsung Electronics America, Inc. Samsung is a registered trademark of Samsung Electronics Co., Ltd. You have to keep more than 20 cm away from the installed the device to use it. Open Source Software Some software components of this product, including but not limited to ‘PowerTOP’ and ‘e2fsprogs’, incorporate source code covered under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered under the open source licenses, please visit: http://opensource.samsung.com. Disclaimer of Warranties; Exclusion of Liability EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT “AS IS”, AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS. Modification of Software SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS, OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE. USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY. YOUR CARRIER MAY NOT PERMIT USERS TO DOWNLOAD CERTAIN SOFTWARE, SUCH AS CUSTOM OS. Legal Information READ THIS INFORMATION BEFORE USING YOUR DEVICE. Samsung Limited Warranty - This product is covered under the applicable Samsung Limited Warranty INCLUDING ITS DISPUTE RESOLUTION PROCEDURE and your right to opt out of arbitration within 30 calendar days of the first consumer purchase. You may opt out by either sending an email to [email protected] with the subject line “Arbitration Opt- Out” or by calling 1-800-SAMSUNG (726-7864). For more detailed procedures, please refer to the “Dispute Resolution Procedures and Arbitration OptOut” section of the Limited Warranty. WARNING! This product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. For more information, please call 1-800-SAMSUNG (726-7864). Intellectual Property All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG Device, including but not limited to, accessories, parts, or software relating thereto (the “5G CPE”), is proprietary to Samsung and protected under federal laws…

Text truncated - open the document above for the full version.

Samsung confidential Innovative Product Planning Group Samsung 5G Indoor CPE - Installation Process - July. 13. 2020 With 5G, The Future is Here Important legal information Arbitration Agreement - This Product is subject to a binding arbitration agreement between you and SAMSUNG ELECTRONICS AMERICA, INC. (“Samsung”). You can opt out of the agreement within 30 calendar days of the first consumer purchase by emailing [email protected] or calling 1-800-SAMSUNG (726-7864) and providing the applicable information. The full Arbitration Agreement, Standard One-year Limited Warranty, End User License Agreement (EULA), and Health & Safety Information for your device are available online: • English: www.samsung.com/us/Legal/Tablet-HSGuide • Spanish: www.samsung.com/us/Legal/ Tablet-HSGuide-SP Terms and Conditions Read this document before operating the mobile device, accessories, or software (defined collectively and individually as the “Product”) and keep it for future reference. This document contains impor- tant Terms and Conditions. Electronic acceptance, opening the packaging, use, or retention of the Product constitutes acceptance of these Terms and Conditions. Revised 06/2019 Samsung Electronics America, Inc. 85 Challenger Road Ridgefield Park, NJ 07660 Phone: 1-800-SAMSUNG (726-7864) Internet: www.samsung.com Health and Safety WARNING! To avoid electric shock and damage to your device, do not charge device while it is wet or in an area where it could get wet. Do not handle device, charger or cords with wet hands while charging. Samsung mobile products and recycling WARNING! Never dispose of batteries in a fire because they may explode. Do not disassemble, crush, puncture, heat, burn or reuse. For battery and cell phone recycling, go to call2recycle.org or call 1-800-822-8837. For more recycling information, go to our website: www.samsung.com/recycling or call 1-800-SAMSUNG. FCC Part 15 Information and Notices This device complies with part 15 of the FCC Rules. Operation is subject to conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Device temperature Caution! Some applications or prolonged usage may increase device temperature. If the device feels hot to the touch, discontinue use and close all applications or turn off the device until it cools. Always ensure that the device has adequate ventilation and air flow. Covering the device can trap any dissipating heat and redirect it back to the device while it is active. ©2020 Samsung Electronics America, Inc. Samsung is a registered trademark of Samsung Electronics Co., Ltd. You have to keep more than 20 cm away from the installed the device to use it. I nnovative Product Planning Group Mounting on Window I nnovative Product Planning Group 3 Guide from Verizon – Overall flow of installation I nnovative Product Planning Group 1- 4. Open box and understand how to install 4 How to Install TBD TBD I nnovative Product Planning Group 5- 7. Unbox device at setup location 5 Check the 5G coverage area Choosing a window consider •There must be an outlet nearby for a later step •The inside of the window cannot be near water •Do not attach to or block an emergency escape window •Window with sill is preferred •Window upstairs are preferred •User may need to remove the screen to attach the CPE to the window TBD I nnovative Product Planning Group 9. Power up the device 6 •Plug the USB C to CPE, and plug the adapter to outlet •Place the CPE where user wants to test 5G signal •When the power is connected, the CPE is automatically booted (This may take up to 2 min) <Bottom side of CPE> The step 8. “Attach the device to bracket” is not necessary •CPE enters to “installation mode” automatically after booting is finished •BLE pairing ready state in the installation mode (No Wi-Fi) •If the activation failed, user can re-connect the power plug I nnovative Product Planning Group 10. Pairing app to the device via Bluetooth 7 Find your CPE Connect using Bluetooth •After booted up, LED indicates “Cyan and green color switch every 200 ms” before BT pairing is completed •When BT pairing is completed, the LED indicates the signal strength of 5G. •If the activation failed, user can re-connect the power plug I nnovative Product Planning Group 11-13. Find the best place for 5G communication 8 •If there is window sill-Place the CPE on to the window sill. User can check the signal from both CPE LED indication and App •If there is no window sill-User holds the CPE by both hands, and check the signal quality through the CPE LED indication •The weight of CPE is only 1 kg, so it is possible to hold by one hand, but it is not recommended due to the safety reason. •LED indication for signal strength refreshes every 1 s •A pp also shows 5G signal strength Check the 5G signal Facethis inside (Towards you) 5G antenna TBD User marks the best signal spot using adhesive markers I nnovative Product Planning Group 14.Clean the window Preparation for installation 9 •User cleans the window with water and soft towels, then wipe with dry soft towels. Then dry the moisture on window thoroughly •Oily fingerprints, moisture, etccan weaken the adhesion of the mount to the window •The CPE can be installed by mount only, but mount stand helps more reliable installation •For reliable installation, the temperature of window should be at room temperature or higher (23-38 o C) •Cannot be attached to rough glass or surface with special coating •Please be careful not to momentary shock the mount. •Do not hang on to the mount. And don't put anything heavy other than the device. Mount stand Mount I nnovative Product Planning Group Installation on window with window sill I nnovative Product Planning Group 11 15. Mounting the CPE 15.1 Assemble the mount and the mount stand Mount stand Mount I nnovative Product Planning Group 15. Mounting the CPE 15.2 Check the exact position …

Text truncated - open the document above for the full version.

Samsung Electronics America, Inc 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: July 27, 2020 FCC ID: A3LSMH204V To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory LLC, to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, LLC on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to any application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S. C. 862. Sincerely, Jenni Chun General Manager Regulatory & Environmental Affairs Samsung Electronics CO. LTD TEL: +1-973-808-6375 Fax : 1-973-808-6361 E-mail: [email protected]

SAMSUNG ELECTRONICS CO., LTD 129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 443-742 Korea 2020.07.24 Federal Communications Commission 7435 Oakland Mills R oad Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LSMH204V To whom it may concern: The device is compliant in accordance to the FCC rules about identification of equipment, stated in 47 CFR Part 2.925(d) The label statement is as follows: The FCC ID label is located on rear side of the CPE. At this time the FCC ID is readily visible to the user without the aid of magnification. The label is permanently attached by acrylic glue and not easily removed from the device. This statement could not be included in the label. So we inform you or it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Jenni Chun / General Manager Samsung Electronics America, Inc. Address: 19 Chapin Rd., Building D Pine Brook, NJ 07058 Tel: 1-973-808-6375

SAMS UNG ELECTRONICS AMERICA, INC. American QA Lab 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: July 27, 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE:Request of Confidentiality for FCC ID: A3LSMH204V To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily re leased to th e public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 day s after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information pri or to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST ExhibitDescription PERMANENT 1 Block Diagram 2 Operational Description 3 Schematics SHORT-TERM 4 External Photos 5 Internal Photos 6 Test-Setup Photos 7 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jenni Chun General Manager Regulatory & Environmental Affairs Samsung Electronics CO. LTD TEL: +1-973-808-6375 Fax : 1-973-808-6361 E-mail: [email protected]

FCC ID: A3LSMH204VExternal Photos

Label and Location Model: FCC ID: SM-H204V A3LSMH204V Label: Location: Rear Side of device CPE: FCC ID is placed on rear side of the device. Label

FCC ID: A3LSMH204VInternal Photos

FCC ID: A3LSMH204V MAXIMUM PERMISSIBLE EXPOSURE REPORT (Freq < 6 GHz) Approved by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 1 of 9 1M2004140062-01.A3L 7/30/2020 Indoor Customer Premises Equipment © 2020 PCTEST V 9.0 02/01/2019 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. Applicant Name: Samsung Electronics Co., Ltd. 129, Samsung-ro, Yeongtong-gu, Suwon-si Gyeonggi-do, 16677, Korea Date of Testing: 7/30/2020 Test Site/Location: PCTEST Lab. Columbia, MD, USA Test Report Serial No.: 1M2004140062-01.A3L FCC ID: A 3 L SM H2 0 4 V APPLICANT: Samsung Electronics Co., Ltd. EUT Type: Indoor Customer Premises Equipment FCC Classifications: PCB, 5GT, DTS, NII, DSS FCC Rule Part: FCC Part 1 (§1.1310) and Part 2 (§2.1091) Test Procedure(s): KDB 447498 D01 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in FCC KDB 447498 D01. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctest.com RF EXPOSURE EVALUATION Part 1 Maximum Permissible Exposure [MPE] for Frequencies < 6 GHz FCC ID: A3LSMH204V MAXIMUM PERMISSIBLE EXPOSURE REPORT (Freq < 6 GHz) Approved by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 2 of 9 1M2004140062-01.A3L 7/30/2020 Indoor Customer Premises Equipment © 2020 PCTEST V 9.0 02/01/2019 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. TABLE OF CONTENTS 1.0 RF EXPOSURE EVALUATION – MAXIMUM PERMISSIBLE EXPOSURE (MPE) ........................ 3 1.1 Introduction ............................................................................................................................................ 3 1.2 EUT Description ..................................................................................................................................... 3 1.3 Test Procedure ...................................................................................................................................... 4 2.0 CONCLUSION ................................................................................................................................. 9 FCC ID: A3LSMH204V MAXIMUM PERMISSIBLE EXPOSURE REPORT (Freq < 6 GHz) Approved by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 3 of 9 1M2004140062-01.A3L 7/30/2020 Indoor Customer Premises Equipment © 2020 PCTEST V 9.0 02/01/2019 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. 1.0 R F E X P O S U R E E V A L U A T I O N – MAXIMUM PERMISSIBLE EXPOSURE (MPE) 1.1 Introduction This document is prepared to show compliance with the RF Exposure requirements as required in §1.1310 of the FCC Rules. The limit for Maximum Permissible Exposure (MPE), specified in FCC §1.1310, is listed in Table 1-1. According to FCC §1.1310: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in §1.1307(b). Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits For Occupational / Control Exposures (f = frequency) 30-300 61.4 0.163 1.0 6 300-1500 ... ... f/300 6 1500-100,000 ... ... 5.0 6 (B) Limits For General Population / Uncontrolled Exposure (f = frequency) 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 Table 1-1. Limits for Maximum Permissible Exposure (MPE) 1.2 EUT Description The Samsung Indoor Customer Premises Equipment FCC ID: A 3 L S M H 2 0 4 V is a device that supports 5G NR (FR1/FR2), LTE, 2.4GHz/5GHz WiFi, and Bluetooth LE operation. The EUT uses 5G to provide coverage throughout an area indoors. The worst case transmission scenario is determined with the following condition: 5G NR (mmWave) + LTE + 2.4GHz WiFi x 2 + 5GHz WiFi x 4 + Bluetooth LE FCC ID: A3LSMH204V MAXIMUM PERMISSIBLE EXPOSURE REPORT (Freq < 6 GHz) Approved by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 4 of 9 1M2004140062-01.A3L 7/30/2020 Indoor Customer Premises Equipment © 2020 PCTEST V 9.0 02/01/2019 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this …

Text truncated - open the document above for the full version.

FCC ID: A3LSMH204V COMPLIANCE SUMMARY REPORT Approved by: Quality Manager Document S/N: DUT Type: Page 1 of 10 1M2004140062-19.A3L Customer Premise Equipment (CPE) © 2020 PCTEST REV 1.0 06/01/2019 © 2020 PCTEST All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. PCTEST 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. +1.410.290.6652 / Fax +1.410.290.6654 http://www.pctest.com COMPLIANCE SUMMARY REPORT Applicant Name: Test Site/Location: Samsung Electronics Co., Ltd. PCTEST Lab, Columbia, MD, USA 129, Samsung-ro, Maetan dong, Document Serial No.: Yeongtong-gu, Suwon-si 1M2004140062-19.A3L Gyeonggi-do, 16677, Korea FCC ID: A3LSMH204V APPLICANT: SAMSUNG ELECTRONICS CO., LTD Report Type: DUT Type: Compliance Summary Customer Premise Equipment (CPE) Model: SM-H204V FCC ID: A3LSMH204V COMPLIANCE SUMMARY REPORT Approved by: Quality Manager Document S/N: DUT Type: Page 2 of 10 1M2004140062-19.A3L Customer Premise Equipment (CPE) © 2020 PCTEST REV 1.0 06/01/2019 © 2020 PCTEST All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. TABLE OF CONTENTS 1 STRATEGY FOR COMPLIANCE DEMONSTRATION 3 1.1 RF Exposure Evaluation Strategy 3 1.2 Nomenclature 4 1.3 Bibliography 4 2 TIME AVERAGING ALGORITHM 5 2.1 Algorithm Description 5 2.2 Basic concept of the algorithm 6 2.3 Configurable Parameters 8 3 DUT DESCRIPTION 9 3.1 Device Overview 9 4 COMPLIANCE SUMMARY 10 4.1 RF Exposure Compliance Summary 10 FCC ID: A3LSMH204V COMPLIANCE SUMMARY REPORT Approved by: Quality Manager Document S/N: DUT Type: Page 3 of 10 1M2004140062-19.A3L Customer Premise Equipment (CPE) © 2020 PCTEST REV 1.0 06/01/2019 © 2020 PCTEST All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. 1 STRATEGY FOR COMPLIANCE DEMONSTRATION 1.1 RF Exposure Evaluation Strategy The FCC RF exposure limits are defined based on time-averaged RF exposure. Therefore, to demonstrate the compliance, the maximum time-averaged exposure needs to be below the corresponding limits. Since Qualcomm CPE is under FCC “mobile” device category. The power density assessment is performed at 20 cm separation distance based on FCC 47 CFR 2.1091, and point PD should be applied throughout this RF exposure assessment package as the PD exposure for each radio is evaluated using Friis transmission equation regardless of operating frequency range (i.e., f > 6 GHz or f < 6 GHz). Demonstrating compliance of Qualcomm CPE with Qualcomm Smart Transmit feature is completed in three parts: Part 0. RF Exposure Compliance Test Report Part 0: PD Characterization Part 0 report determines device design related total uncertainty for each radio supported, and then derive the PD_design_target. The resulted PD_design_target is less than FCC regulatory PD limit after accounting for device design related uncertainty.The PD Characterization determines the input.power.limit corresponding to PD design target for each radio configuration and RF exposure usage scenario. The input.power.limit represents the maximum time-averaged power level for the corresponding radio/antenna configuration. The determined input power limits will be loaded and stored in a wireless device via the Embedded File System (EFS), and then used as inputs for Smart Transmit to operate. For f < 6 GHz radios, using Friis transmission equation to calculate the input.power.limit, denoted as Plimit for f < 6 GHz radios, per technology/band/antenna/exposure scenario for a given antenna gain. For mmW NR, demonstrate the compliance via the validated simulation approach. Using the validated simulation approach to obtain the simulated array gain (antenna array gain + power amplifier array gain) for each beam supported, then derive input power limit for each beam, denoted as input.power.limit for mmW NR, using Friis transmission equation. The simulation is validated and the resulted input.power.limit corresponds to mmW NR PD design target which is less than FCC PD limit, thus, all the supported beams are in compliance with FCC PD limit. Part 1. RF Exposure Compliance Test Report Part 1: Test in Static Transmission Scenario The purpose of Part 1 test is to demonstrate that the EUT meets FCC PD limits when transmitting in static transmission scenario at maximum allowable time-averaged power levels (i.e., Plimit for sub-6 radio, and input.power.limit for mmW NR), or maximum RF tune-up power levels if they are lower than maximum allowable time-averaged power levels. For f < 6 GHz radios, measure conducted power at each supported antenna port for all the radio configurations required in the existing FCC KDB procedures, determine PD characterization using Friis transmission equation based on measured conducted power and antenna gain. For mmW NR, the compliance demonstration is done in the Part 0 report. In Part 1 report, PD measurement on a few of selected beams is performed for further verification. NOTE: Note i…

Text truncated - open the document above for the full version.

FCC ID: A3LSMH204V MEASUREMENT REPORT (CERTIFICATION) Approved by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 1 of 171 1M2004140062-09.A3L 4/29 - 8/12/2020 Indoor Customer Premises Equipment (CPE) © 2020 PCTEST V 9.0 02/01/2019 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. Applicant Name: Samsung Electronics Co., Ltd. 129, Samsung-ro, Yeongtong-gu, Suwon-si Gyeonggi-do, 16677, Korea Date of Testing: 4/29 - 8/12/2020 Test Site/Location: PCTEST Lab. Columbia, MD, USA Test Report Serial No.: 1M2004140062-09.A3L FCC ID: A3LSMH204V APPLICANT: Samsung Electronics Co., Ltd. Application Type: Certification Model: SM-H204V EUT Type: Indoor Customer Premises Equipment (CPE) Frequency Range: 5180 – 5825MHz Modulation Type: OFDMA FCC Classification: Unlicensed National Information Infrastructure (UNII) FCC Rule Part(s): Part 15 Subpart E (15.407) Test Procedure(s): ANSI C63.10-2013, KDB 789033 D02 v02r01, KDB 662911 D01 v02r01 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2013 and KDB 789033 D02 v02r01. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctest.com MEASUREMENT REPORT FCC PART 15.407 UNII OFDMA FCC ID: A3LSMH204V MEASUREMENT REPORT (CERTIFICATION) A…

Text truncated - open the document above for the full version.
