INSTRUCTION MANUAL DVD & Hi-Fi VCR Home Theater 1AD6P1P1813-- DWM-3000, Issue Number 1 DWM-3000 English SANYO'S HELP-LINE Call the toll-free number below if you have any difficulties operating this product. 1-800-813-3435 (Weekdays: 7:30 AM - 4:00 PM Central Time) Before operating the unit, please read this manual thoroughly. Only cassettes marked can be used with this video cassette recorder. -E1- SAFETY PRECAUTIONS WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND. WARNING: Do not install this equipment in a confined space such as a book case or similar unit. NOTE TO CABLE/TV INSTALLER: This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as practical. CAUTION: This DVD/VCR employs a Laser System. To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference should the unit require maintenance, contact an authorized service location. Use of controls, adjustments, or the performance of procedures other than those specified herein may result in hazardous radiation exposure. To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser radiation when open. DO NOT STARE INTO BEAM. CAUTION: The apparatus should not be exposed to water (dripping or splashing)and no objects filled with liquids, such as vases, should be placed on the apparatus. FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. REGULATORY INFORMATION: FCC Part 15 This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the product is operated in a residential installation. This product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this product does cause harmful interference to radio or television reception, which can be determined by turning the product off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the product and receiver. •Connect the product into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. NOTES ON COPYRIGHTS: It is forbidden by law to copy, broadcast, show, broadcast via cable, play in public, or rent copyrighted material without permission. This product features the copy protection function developed by Macrovision. Copy protection signals are recorded on some discs. When recording and playing the pictures of these discs on a VCR, picture noise will appear. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. SERIAL NUMBER: The serial number is found on the back of this unit. This number is unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. Model No.___________________________________ Serial No.___________________________________ To operate the built-in TVGuardian ® This unit has the built-in TVGuardian ® Foul Language Filter (TVG ® ). When a disc supporting closed caption is played, it will mute the audio during the entire phrase containing offensive language. For more details, see page E52. Please Read This Manual. Because DVD is a new technology, we recommend that you read this manual carefully before connecting your DVD & VCR Home Theater System and operating it for the first time. Keep the manual in a safe place for future reference. -E2- CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper …

Text truncated - open the document above for the full version.

ATTACHMENT J-1 FCC ID: A7RM2B8A FCC IDENTIFIER (♣2.926) LABELING REQUIREMENT(♣15.19) --- Labeling BACK VIEW

Test report No. : 23AE0029-YW-1 Page: 1 of 110 Date of issue: August 30, 2002 A-Pex International Co., Ltd. YOKOWA LAB. 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPAN Telephone: +81 596 39 1485 Facsimile: +81 596 39 0232MF060b(24.04.02) EMI TEST REPORT Test Report No. : 23AE0029-YW-1 Applicant :Orion Electric Co., Ltd. Type of equipment :DVD/VCR Receiver Model number :DWM-3000U Test standard :FCC Part 15 Subpart B Test result :Complied 1. This test report shall not be reproduced except in full or partial, without the written approval of A-Pex International Co., Ltd. 2. The results in this report apply only to the sample tested. 3. This equipment is in compliance with above regulation. We hereby certify that the data contain a true representation of the EMC profile. 4. The test results in this test report are traceable to the national or international standards. 5. This test report does not constitute an endorsement by NIST/NVLAP or U.S. Government. Date of test : August 19 to 23, 2002 Tested by: Hisayuki Kioka Hiroya Tabata Group Leader of EMC Seciton Group Leader of EMC Section Approve d by: Kazutoyo Nakanishi Site Operation Manager of EMC Section Test report No. : 23AE0029-YW-1 Page: 2 of 110 Date of issue: August 30, 2002 A-Pex International Co., Ltd. YOKOWA LAB. 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPAN Telephone: +81 596 39 1485 Facsimile: +81 596 39 0232MF060b(24.04.02) Contents Page Section 1 :Client information3 Section 2 :Equipment under test (E.U.T.)3 Section 3 :Test specification, procedures & results4 Section 4 :Operation of E.U.T. during tests6 Section 5 :Conducted emission8 Section 6 :Radiated emission11 Section 7 :Antenna terminal voltage15 Section 8 : RF output level / spurious emission16 Section 9 : Antenna transfer switch17 Section 10 : Picture sensitivity18 Section 11 :Noise figure19 Contents of Appendixes20 Appendix 1 :Photographs of test set up21 Appendix 2 :Data of EMI tests28 Appendix 3:Test instruments110 Test report No. : 23AE0029-YW-1 Page: 3 of 110 Date of issue: August 30, 2002 A-Pex International Co., Ltd. YOKOWA LAB. 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPAN Telephone: +81 596 39 1485 Facsimile: +81 596 39 0232MF060b(24.04.02) Section 1 : Client information Company name: Orion Electric Co., Ltd. Brand Name:ORION Address: 41-1 Iehisa-cho, Takefu-shi, Fukui-ken, 915-8555 JAPAN Telephone number: +81 778 23 0019 Facsimile number: +81 778 23 7799 Contact person: Hiroshi Tsujimoto Manufacture Company name:Orion Electric (U.K.) Ltd. World Electric (Thailand) Ltd. Korat Denki Ltd. Section 2 : Equipment under test (E.U.T.) 2.1Identification of E.U.T. Type of equipment: DVD/VCR Receiver Model number: DWM-3000U Rating:AC 120 V / 60 Hz Receipt Date of Sample:August 16, 2002 Condition of EUT:Production Prototype 2.2Product de scription Orion Electronics Co., Ltd. Model: DWM-3000U (referred to as the EUT in this report) is a DVD/VCR Receiver. The EUT specifications is as follows. Tuner type : Quartz PLL frequency synthesized I / F :45.75 MHz (Picture), 41.25 MHz (Sound) Receiving channel : VHF 2 – 13 ch / UHF 14 – 69 ch / CATV 1 – 125 ch Antenna input : 75 ohm Video signal : NTSC color Power source : AC 120 V / 60 Hz, 23 W I / O terminal (Video): RCA in 1Vp-p 75 ohm, RCA out 1 Vp-p 75 ohm I / O terminal (Audio): RCA in –8 dB 50 k ohm, RCA out –8 dB 1 k ohm 2.3Similar apparatus There are no similar apparatus. Test report No. : 23AE0029-YW-1 Page: 4 of 110 Date of issue: August 30, 2002 A-Pex International Co., Ltd. YOKOWA LAB. 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPAN Telephone: +81 596 39 1485 Facsimile: +81 596 39 0232MF060b(24.04.02) Section 3 : Test specification, procedures and results 3.1Test specification Test specification: FCC Part 15 Subpart B Title:FCC 47 CFR Part 15 Radio Frequency Device Subpart B Unintentional Radiators (Subpart C Intentional Radiators) 3.2Procedures & results No.Ite mTe st proce dureLimitsWorst marginRe sult 1 Conducted emission ANSI C63.4:1992 IEEE 213:1987 IEEE 187:1990 250 uV6.1 dB (28.6364 MHz)Complied 2 Radiated emission ANSI C63.4:1992 IEEE 213:1987 IEEE 187:1990 30–88 MH: 100 uV/m 88–216 MHz: 150 uV/m 216–960 MHz: 200 uV/m above 960 MHz: 500 uV/m 7.4 dB (1694.03 MHz)Complied 3 Antenna terminal voltage ANSI C63.4:1992 IEEE 213:1987 IEEE 187:1990 2 nW (at 75 ohm)11.8 dB (118 MHz)Complied RF output levelVideo signal: 3000 uV Aural signal: 671 uV 3.3 dB (61.25MHz)Complied4 Spurious emission ANSI C63.4:1992 IEEE 213:1987 IEEE 187:1990 94.8 uV14.8 dB (49.26 MHz) 5 Transfer switchANSI C63.4:1992 IEEE 213:1987 IEEE 187:1990 9.5 dB7.8 dB (61.25 MHz, 67.25 MHz) Complied 6 Picture sensitivity ANSI C63.4:1992 IEEE 213:1987 IEEE 187:1990 8 dB5.8 dBComplied 7 Noise figureFCC/OET MP:2:1986 14 dB7.4 dB (723.25 MHz) Complied 3.3Additions or deviations to standard No addition, deviation or exclusion has been made from standards. 3.4Confirmation A-Pex International Co., Ltd. hereby confirms that E.U.T., in the configuration tests, complies with the spe cifications FCC Part15 Subpart B. Test report No. : 23AE0029-YW-1 Page: 5 of 110 Date of issue: August 30, 2002 A-Pex International Co., Ltd. YOKOWA LAB. 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPAN Telephone: +81 596 39 1485 Facsimile: +81 596 39 0232MF060b(24.04.02) 3.5 • Uncertainty Conducte d e mission (450 kHz – 30 MHz) The measurement uncertainty (with a 95% confidence level) for this test was ± 1.74 dB. The data listed in this test report has enough margin, more than site margin. Radiated emission The measurement uncertainty (with a 95% confidence level) for this test using Biconical antenna is ±4.4 dB. The measurement uncertainty (with a 95% confidence level) for this test using Logperiodic antenna is ±4.8 dB. The data listed in this test report has enough margin, more than site margin. Antenna terminal voltage The measurement uncertainty (with a 95% confidence level) for this test was ± 3.48 dB. The data listed in this test report has enough margin, more than…
