A7RM4C9FVCR

VIDEO CASSETTE RECORDER VIDEOGRABADOR DE CASSETTE OWNER'S MANUAL MANUAL DE INSTRUCCIONES Before operating the unit, please read this manual thoroughly. Antes de utilizar su aparato favor de leer las siguientes instrucciones. MVR4040A ATTENTION ATENCION For your protection in the event of theft or loss of this product, please fill in the information listed below which is for your own personal records. Por su precaucion en caso de robo o pérdida de este producto, favor de llenar la información listada baja que es para sus inscripciones personales de usted. Date of purchase: Fecha de compra: Serial No.: Número de serie: Place od Purchase : Lugar de compra: TV/CATV MODE SELECTION SELECCION DE MODO DE TV/CATV When shipped from the factory, the TV/CATV menu option is set to the "CATV" (Cable Television) mode. If not using CATV (Cable TV), set this menu option to the "TV" mode. A la salida de fábrica, la opción de menú TV/CATV está en el modo "CATV" (televisión por cable). Si no se va a utilizar el CATV (TV cable), cambie la opción de este menú al modo TV. 4C93401A-E(C-09)04.10.99, 12:171 2 RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALI- FIED SERVICE PERSONNEL. CAUTION: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. WARNING: WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equip- ment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correcting the interference by one or more of the following measures: - - - - Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance with the FCC Rules could void the user's authority to operate this equipment. CAUTION: ENGLISH 4C93401A-E(C-09)04.10.99, 12:172 3 ENGLISH READ INSTRUCTIONS All the safety and operating instructions should be read before the unit is operated. RETAIN INSTRUCTIONS The safety and operating instructions should be retained for future reference. HEED WARNINGS All warnings on the unit and in the operating instructions should be adhered to. FOLLOW INSTRUCTIONS All operating and use instructions should be followed. CLEANING Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. ATTACHMENTS Do not use attachments not recommended by the unit's manufacturer as they may cause hazards. WATER AND MOISTURE Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool. ACCESSORIES Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may fall, causing serious injury, and serious damage to the unit. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn. VENTILATION Slots and openings in the cabinet and in the back or bottom are provided for ventilation and to ensure reliable operation of the unit and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat source. This unit should not be placed in built-in installa- tions such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to. POWER SOURCES This unit should be operated only from the type of power source indicated on the rating plate. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For units intended to operate from battery power, or other sources, refer to the operating instructions. GROUNDING OR POLARIZATION This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug If your unit is equipped with a 3-wire grounding-type plug, a plug having a third (grounding) pin, this plug will only fit into a grounding-type power outlet. This too, is a safety feature. If you are unable to inser…

Text truncated - open the document above for the full version.

ABC D E F GH ABC D E F GH 21345678 21345678 654321 654321 2 1 CP4003 87654321 87654321 7654321 7654321 OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE THE TIME THIS INTERCONNECTION DIAGRAM IS THE LATEST AT NOTE: 4 3 2 1 4321 4 3 2 1 4321 4321 DATE: TEC-HQ TEC-HQ SEC. PUBRICATION: DISTRIBUTE: SECTION: ORION ELECTRIC CO.LTD DWG.NO. FUNCTION CHKD BYDET.CHKD BYDRAWN BYDESIGN BY : ISSU Rev.No: PCB NAME STANDARDMODELDESCRIPTION VMX181A_C_ANKI 3.0 M4C7-A0A,BNTSC Y.OKUMURAM.HAMANO UL/FCC 12/15/99 BLADE WIDE BLACKWHITE 21 CD501 AC120V_60Hz TU6001 10111213 1415161718 2 21222324 25 26 27 28 34568 9 DESCRIBED IN PARTS LIST ONLYCRITICAL FOR SAFETY,USE ONES ARE SINCE THESE PARTS MARKED BY CAUTION: DANS LA NOMENCLATURE DES PIECESN’UTILISER QUE CELLS DECRITESDANGEREUSES AN POINT DE VUE SECURITE ETANT LES PIECES REPAREES PAR UN ATTENTION: INTERCONNECTION DIAGRAM P2 Y.OKUMURAM.HAMANO REAR JACK VEX905PCB270 VMX181 NCNC FSCPB 5V M4C7IN13 M4C7-A1A,B COM CH2 (L) CH1 (R) HEAD FRONT JACK AUDIO INVIDEO IN CD651 CD1002 CD1001 CD4001 MICRO MOTOR M2003 UN4001 CP4001CP1001 CYLINDER UNIT FFC 4321 CYL VCC 5V GND CYL PGCYL +BCYL FGCYL GND CYL DRIVE CYL VCC 5V GND CYL PGCYL +BCYL FGCYL GND CYL DRIVE CH1 CH2 CD2001 FG.PG GND DRIVE CONTROL PG FG GND VCC DRV GND VCC FFC FFC CP4002 H5002 FULL ERASE HEAD ASS’Y CP501 21 4ch3ch SW6001RF SW AUDIO OUTVIDEO OUT J4201J4203 CP1003 CP1002 CP601 GNDGND GND CP651 PCB550 VE8851 DECK PCB M101 LOADING MOTOR LM CP101 Q101 BOT SENSOR VE8851A VCCLDM+LDM-BOT VE8852A WHITERED VCCLDM+LDM-BOT RF IN TO OS651 COMMAND TRANSMITTER TM601 DATA B+ TM601 OS651 FROM GND AE HEAD(+)AE HEAD(-) CTL-CTL+ AUDIO REC AUDIO PB AE HEAD(+)AE HEAD(-) FFC AE AUDIO CONTROL CTL-CTL+ AUDIO REC AUDIO PB H5001 HEAD AUDIO CONTROL ASS’Y M2001 DECK MECHA ASS’YCAPSTAN DD UNIT G O VCC MR FG SENSOR ROTOR MAGNET COIL MAIN HALL SENSOR LOGIC SWITCH OUT IN HALL VCCHALL 2 1FE HEAD (HOT) FE HEAD (GND) VCC(5V) CAP.M F/R FG VCO(12V) CTL I LIMIT MOTOR GND GND A 1 7 UL/FCC NTSC INTERCONNECTION SYSCON PCB PCB010 FE HEAD (HOT) FE HEAD (GND) OPERATION PCB AND RF CONVERTER TUNER,DEMODULATOR KEY B KEY A KEY B GND KEY A NCNC RF OUT V.OUTAFT NC A.OUTTU 32VBMDATACLOCKCEV.INCONTROLA.INMBCH

DesinatedbyMinistryofInternationalTradeandIndustry ANSAILECTRONICNDUSTRYEVELOPMENTENTERKEIDC HEADOFFICEIKOMA 6-8-7,NISHITEMMATESTINGLABORATORY KITA-KU,OSAKA,530-0047JAPAN12128,TAKAYAMA-CHO IKOMA-CITY,NARA,630-0101JAPANCorporateJuridicalPerson March3,2000FederalCommunicationsCommission KECNo.L-397ApplicationProcessingBranch 7435OaklandMillsRoad Columbia,MD21046 SUBJECT:APPLICATIONFORCERTIFICATIONOFTVINTERFACEDEVICE Reference: FCCID:A7RM4C9F Applicant:ORIONELECTRONICCO.,LTD. DeviceName:VIDEOCASSETTERECORDER ModelNo.:MVR4040A ApliedRegulation:Part15subpartB Gentlrmen; Inrelationtothecaptionedmodel,wesubmittoyouforcertification. Weencloseherewithfollowingdocuments. 1.TESTREPORT(A-046-99-C) 2.SPECIFICATIONSHEETandNAMEPLATE(IncludingFCCIDLABEL) 3.BLOCKDIAGRAM 4.SCHEMATICDIAGRAM 5.INSTRUCTIONBOOK 6.PHOTOGRAPHS Wearegratefulifyouwouldissuethegrantatyourearliestconvenience Verytrulyyours; SeiichiIzumi Manager IKOMATESTINGLABORATORY E-mail:[email protected]

ATTACHMENT A - Description of Device FCC File No. Date of Grant Product ID. Code (Model No.) Brand Name Remark Original Model M4C9F(MVR4040A) MEMOREX Additional Model ATTACHMENT H 1/4 ORION ELECTRIC CO., LTD. 41-1 Iehisa-cho, Takefu-shi TEL:(0778) 23-0001 FUKUI 915-8555, JAPAN TELEX:5175-588 ORION J FAX:(0778) 23-7799 ATTACHMENT H --- MEASUREMENT OF THE UHF NOISE FIGURES ON BULLETIN OST MP-2 AND STATISTICAL PLAN. 1. Measurements of TV Tuner Noise Figure This documents is the material of UHF TV Receiver Noise Figure measurement. 1) Measurements Procedure.(ON BULLETIN OST MP-2 JULY 1982) a. The measurements of noise figures are made in a shielded room. b. Before testing, the television receiver and Noise figure test equipment are to be subjected to a warm-up period of sufficient time for stabilization of factors which could affect the measurements. c. Automatic Gain Control bias, preceding the noise output measurement point, is maintained at the level( 4.0V ) existing When there is no input signal with the receivers UHF input terminated in its nominal impedance(75 ohm). d. It must first be ascertained that the noise figure contribution of the I.F. amplifier following the measuring point not exceed 0.3dB. If the influence of the 2nd stage is F(dB), then F2 - 1 F(dB) = 10 log 1 + is given 10 G1F1 so that Tuner Gain : G1 = 39 dB(typical) then the influence of the 2nd stage is to be less than 0.3dB so that influence of the 2nd stage can be ignored. e. N.F. Value = Meter Reading --- Balun Insertion loss Balun Insertion loss is mentioned in ATTACHMENT H-4. Therefor, it can get noise figures of UHF Tuner by correcting Factors of this value. ATTACHMENT H 2/4 ORION ELECTRIC CO., LTD. 41-1 Iehisa-cho, Takefu-shi TEL:(0778) 23-0001 FUKUI 915-8555, JAPAN TELEX:5175-588 ORION J FAX:(0778) 23-7799 2) Test Equipment a. Standard Noise Figure Indicator (Automatic Standard NF Indicator with Solid State Noise Source) * Manufactured by Elena Electronics Co., Ltd.(Japan) * Model ENF-2005 b. Noise Source * Model No. MC1100 Made by M.S.C. and correct proofs. * ENR --- This Indicator has no internal oscillator then can be use no correction of compensation. This Indicator will be send to FCC in November from Elena Electronics, and has already applied for it by KEC. c. UHF Balun * Model No. MP614A (50 to 75 ohm) Made by Anritsu Corporation * Insertion Loss --- Please see Attachment H-4 3) Block Diagram of UHF TV NF measurement. Tuner I.F. out Terminal (Gain Typical 39 dB) Noise Source Balun TV N.F Indicator (2) (3) (Under Test) (1) 50 to 75ohm 28Vp-p ATTACHMENT H 3/4 2. STATISTICAL PLAN TV Receiver UHF Noise Figure --- Certification and Compliance Criteria (July 1982) In reply to yours of Jan. 14, 1980, we have pleasure of stating below: Production Line compliance We carry out QUALITY ASSURANCE for Plan C and submit the annual report of M4C9F(MVR4040A) to the FCC. A. Sampling Size We check Sampling Size by TV Receiver Noise Figure --- Certification and Compliance Criteria 3.12. B. Data Calculation Method When one sampling is 20 sets, measurement data are a total 200 point, that is 20 set multiplied by 10 point/set. We check whether the measurement data comply with statistical condition on X + KS 14, by TV Receiver Noise Figure --- Certification and Compliance Criteria 3.13. ATTACHMENT H 4/4 5) ATTACHED SHEET 1. Block Diagram of Model ENF-2005 --- H-1 Standard Noise Figure Indicator "Elena Electronics". 2. Specifications of Standard NF Indicator --- H-2 Model ENF-2005 3. Excess Noise Ration of Noise Source --- H-3 M.S.C. Model MC1100, SN1012 4. Measurements Data --- H-4 Insertion Loss of UHF Balun ATTACHMENT H-C-1 Product ID.Code: M4C9F (Model No.: MVR4040A) Brand Name: MEMOREX TV RECEIVER APPLICATION CHECKLIST (X) 1. A statement identifying the production run plan we will be using to show compliance in meeting "TV Receiver, UHF Noise Figures Certification and Compliance Criteria" (July 1982). : We will use the production run plan C to show compliance in meeting 14dB UHF Noise Figure requirement. (X) 2. A statement that NF measurements were made pursuant to OST MP-2, July 1982. : NF measurements were made pursuant to OST BULLETIN MP-2, July 1982. (X) 3. The names of all manufacturing sources for the VHF and UHF tuners as well as the tuner manufacture's part No. Product ID. Code (Model No.) VHF/UHF 1 PACK TUNER PART NO. SOURCE M4C9F(MVR4040A) 0162600018 ALPS (X) 4.UHF and VHF tuner part numbers assigned by the receiver manufacturer. : There are no tuner part assigned by receiver manufacturer. ATTACHMENT H-C-2 (X) 5. Frequency bands tuned by receiver. VHF : 2 - 13 ch UHF : 14- 69 ch CATV : 1 -125 ch(101 - 845MHz) (X) 6. Pursuant to Section 15.117 of the Rules, a statement specifying the receiver design noise figure, in dB. : Because TV Tuner built in as part of a video tape recorder which uses a power splitter between the antenna terminals of the video tape recorder and input terminals of the TV Tuner, the limits of Noise Figure, pursuant to section 15.117(g)(4), complies with the limits subtracted 4dB from 14dB. ( ) 7. The length of the UHF lead, from antenna input terminal to the tuner. : (X) 8. A numbered electrical schematic for the receiver. : Attached (X) 9. The exact chassis number (MFR'S Model No. instead of chassis No.) (This number is classified with SUFFIX in order to show voltage difference, Radio band difference and so on.) : Mfr's No. : M4C9F ( )10. Picture tube size in inches. : (X)11. Type of receiver - color or black and white. : Color (X)12. A description of the cabinet material. : plastic and metal cover ( )13. Copy of all the information submitted with the original certification for the basic receiver. :Attached ATTACHMENT H-C-3 (X)14. A statement that the contribution not exceed 0.3dB for the channel. F2 - 1 F(dB) = 10 log 1 + 10 G1F1 where F1 : 7.0 dB ---------- typical value F2 : 8.5 dB ---------- N.F. indicator (I.F. Noise Figure) * See ATTACHMENT H 2/4 G1 : 39.0 dB ---------- See ATTACHMENT H …

Text truncated - open the document above for the full version.

ATTACHMENT A - Description of Device FCC File No. Date of Grant Product ID. Code (Model No.) Brand Name Remark Original Model M4C9F(MVR4040A) MEMOREX Additional Model ATTACHMENT H 1/4 ORION ELECTRIC CO., LTD. 41-1 Iehisa-cho, Takefu-shi TEL:(0778) 23-0001 FUKUI 915-8555, JAPAN TELEX:5175-588 ORION J FAX:(0778) 23-7799 ATTACHMENT H --- MEASUREMENT OF THE UHF NOISE FIGURES ON BULLETIN OST MP-2 AND STATISTICAL PLAN. 1. Measurements of TV Tuner Noise Figure This documents is the material of UHF TV Receiver Noise Figure measurement. 1) Measurements Procedure.(ON BULLETIN OST MP-2 JULY 1982) a. The measurements of noise figures are made in a shielded room. b. Before testing, the television receiver and Noise figure test equipment are to be subjected to a warm-up period of sufficient time for stabilization of factors which could affect the measurements. c. Automatic Gain Control bias, preceding the noise output measurement point, is maintained at the level( 4.0V ) existing When there is no input signal with the receivers UHF input terminated in its nominal impedance(75 ohm). d. It must first be ascertained that the noise figure contribution of the I.F. amplifier following the measuring point not exceed 0.3dB. If the influence of the 2nd stage is F(dB), then F2 - 1 F(dB) = 10 log 1 + is given 10 G1F1 so that Tuner Gain : G1 = 39 dB(typical) then the influence of the 2nd stage is to be less than 0.3dB so that influence of the 2nd stage can be ignored. e. N.F. Value = Meter Reading --- Balun Insertion loss Balun Insertion loss is mentioned in ATTACHMENT H-4. Therefor, it can get noise figures of UHF Tuner by correcting Factors of this value. ATTACHMENT H 2/4 ORION ELECTRIC CO., LTD. 41-1 Iehisa-cho, Takefu-shi TEL:(0778) 23-0001 FUKUI 915-8555, JAPAN TELEX:5175-588 ORION J FAX:(0778) 23-7799 2) Test Equipment a. Standard Noise Figure Indicator (Automatic Standard NF Indicator with Solid State Noise Source) * Manufactured by Elena Electronics Co., Ltd.(Japan) * Model ENF-2005 b. Noise Source * Model No. MC1100 Made by M.S.C. and correct proofs. * ENR --- This Indicator has no internal oscillator then can be use no correction of compensation. This Indicator will be send to FCC in November from Elena Electronics, and has already applied for it by KEC. c. UHF Balun * Model No. MP614A (50 to 75 ohm) Made by Anritsu Corporation * Insertion Loss --- Please see Attachment H-4 3) Block Diagram of UHF TV NF measurement. Tuner I.F. out Terminal (Gain Typical 39 dB) Noise Source Balun TV N.F Indicator (2) (3) (Under Test) (1) 50 to 75ohm 28Vp-p ATTACHMENT H 3/4 2. STATISTICAL PLAN TV Receiver UHF Noise Figure --- Certification and Compliance Criteria (July 1982) In reply to yours of Jan. 14, 1980, we have pleasure of stating below: Production Line compliance We carry out QUALITY ASSURANCE for Plan C and submit the annual report of M4C9F(MVR4040A) to the FCC. A. Sampling Size We check Sampling Size by TV Receiver Noise Figure --- Certification and Compliance Criteria 3.12. B. Data Calculation Method When one sampling is 20 sets, measurement data are a total 200 point, that is 20 set multiplied by 10 point/set. We check whether the measurement data comply with statistical condition on X + KS 14, by TV Receiver Noise Figure --- Certification and Compliance Criteria 3.13. ATTACHMENT H 4/4 5) ATTACHED SHEET 1. Block Diagram of Model ENF-2005 --- H-1 Standard Noise Figure Indicator "Elena Electronics". 2. Specifications of Standard NF Indicator --- H-2 Model ENF-2005 3. Excess Noise Ration of Noise Source --- H-3 M.S.C. Model MC1100, SN1012 4. Measurements Data --- H-4 Insertion Loss of UHF Balun ATTACHMENT H-C-1 Product ID.Code: M4C9F (Model No.: MVR4040A) Brand Name: MEMOREX TV RECEIVER APPLICATION CHECKLIST (X) 1. A statement identifying the production run plan we will be using to show compliance in meeting "TV Receiver, UHF Noise Figures Certification and Compliance Criteria" (July 1982). : We will use the production run plan C to show compliance in meeting 14dB UHF Noise Figure requirement. (X) 2. A statement that NF measurements were made pursuant to OST MP-2, July 1982. : NF measurements were made pursuant to OST BULLETIN MP-2, July 1982. (X) 3. The names of all manufacturing sources for the VHF and UHF tuners as well as the tuner manufacture's part No. Product ID. Code (Model No.) VHF/UHF 1 PACK TUNER PART NO. SOURCE M4C9F(MVR4040A) 0162600018 ALPS (X) 4.UHF and VHF tuner part numbers assigned by the receiver manufacturer. : There are no tuner part assigned by receiver manufacturer. ATTACHMENT H-C-2 (X) 5. Frequency bands tuned by receiver. VHF : 2 - 13 ch UHF : 14- 69 ch CATV : 1 -125 ch(101 - 845MHz) (X) 6. Pursuant to Section 15.117 of the Rules, a statement specifying the receiver design noise figure, in dB. : Because TV Tuner built in as part of a video tape recorder which uses a power splitter between the antenna terminals of the video tape recorder and input terminals of the TV Tuner, the limits of Noise Figure, pursuant to section 15.117(g)(4), complies with the limits subtracted 4dB from 14dB. ( ) 7. The length of the UHF lead, from antenna input terminal to the tuner. : (X) 8. A numbered electrical schematic for the receiver. : Attached (X) 9. The exact chassis number (MFR'S Model No. instead of chassis No.) (This number is classified with SUFFIX in order to show voltage difference, Radio band difference and so on.) : Mfr's No. : M4C9F ( )10. Picture tube size in inches. : (X)11. Type of receiver - color or black and white. : Color (X)12. A description of the cabinet material. : plastic and metal cover ( )13. Copy of all the information submitted with the original certification for the basic receiver. :Attached ATTACHMENT H-C-3 (X)14. A statement that the contribution not exceed 0.3dB for the channel. F2 - 1 F(dB) = 10 log 1 + 10 G1F1 where F1 : 7.0 dB ---------- typical value F2 : 8.5 dB ---------- N.F. indicator (I.F. Noise Figure) * See ATTACHMENT H 2/4 G1 : 39.0 dB ---------- See ATTACHMENT H …

Text truncated - open the document above for the full version.

ABC D E F GH ABC D E F GH 21345678 21345678 DATE: TEC-HQ TEC-HQ SEC. PUBRICATION: DISTRIBUTE: SECTION: ORION ELECTRIC CO.LTD DWG.NO. FUNCTION CHKD BYDET.CHKD BYDRAWN BYDESIGN BY : ISSU Rev.No: PCB NAME STANDARDMODELDESCRIPTION VMX181A_D_ANKI RECORD COLOR SIGNALRECORD LUMINANCE SIGNAL PLAYBACK COLOR SIGNALPLAYBACK LUMINANCE SIGNALAUDIO SIGNAL(PB)AUDIO SIGNAL(REC) L4005 47uH0305 L4001 100uH0305 L4002 100uH0305 L4003 100uH L4008 100uH 0305 X4001 3.579545MHz Q4009 2SA1015Y BUFFER Q4005 2SA1318 BIAS CTL L4007 100uH W821 TP4001 W802 W805 W801 Q4007 2SC1815Y BUFER Q4002 2SC3331 AUDIOPB SW Q4001 2SC3331 AUDIOPB SW Q4004 2SC1815Y BUFFER Q4006 2SD734 BIAS OSC Q4008 2SC1815Y BUFFER C4037 150V KA C4033 150V KA C4021 336.3VKA C4023 22 6.3V KA C4057 22 6.3V KA C4035 1006.3VKA C4022 1016V KA C4060 1 50V KA C4059 4.7 25V KA C4026 226.3VKA C4061 1 50V KA C4019 150V KA C4070 476.3VKA C4045 476.3VKA C4039 150VKA C4062 1 50V KA C4030 1016VKA C4031150V KA R4001 560 R4043 3.3K R4047 18K R4044 8.2K R4018 6.8K R4029 2.2M R4055 100K R4045 1.8K R4067 47K R4069 47K R4010 3.3K R4015 2.2 R4048 4.7K R4049 1.5K R4025 330K R4012 18K R4072 18K R4008 12K R4004 2.7K R4021 47K R4013 10K R4023 8.2K R4033 1K1/4W R4003 10K R4002 10K R4046 1.5K R4017 10K R4009 2.2K R4016 15 1/4W R4063 3.3M R4062 220K 1/4W R4060 220K R4059 1K R4027 1801/4W R4051 33K R4065 2.2K R4053 1.8K R403227K R4020 10K R4068 47K R4034 820 R4022 6.8K R4011 22K R4057 1.8K R4070 1K R4050680K C4018 0.0012 B C4055 0.022 F C4032 0.022 B C4003 0.1 F C4006 0.015 B C4005 0.01B C4047 18PCH C4049 200PCH C4038 0.1 F C4041 390PCH C40200.01 B C4067 470P CH C4013 15P CH C4012 15PCH C4044 0.1F C4002 0.022100VTF C4028 0.1 B C4029 0.047 F C4036 0.022 B C4053 0.01 BC4052 0.1 F C4009 0.1 F C4027 820PCH C4025 0.0022 B C4074 470PCH C4068 0.001 B C4056 0.1 F C40480.01 B C4050 0.01 F T4001 1626007 COIL,BIAS OSC 123 4 56 C4011 1 50V KA C4034 150V KA C4001 476.3VKA C4043 150V KA C4058 22 6.3V KA C4016 4.7 25V KA C4004 476.3VKA C4024 4.725VKA C4017 150V KA C4010 47 6.3V KA C4071 1006.3VKA OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME DURING PLAYBACKMEASURED WITH THE DIGITAL TESTER NOTE: THE DC VOLTAGE AT EACH PART WAS CP4003TMC-T02X-E1 12 IC4001 LA71077BM-MPB Y/C/AUDIO/CCD/HEAD AMP IC 110 100 11 12 13 14 15 16 17 18 19 2 20 21 22 23 24 25 26 27 28 29 3 30 31 3233 34 35 36 3738 39 4 40 41 42 43 44 45 46 47 48 49 5 50 51 52 53 54 55 56 57 58 59 6 60 61 62 63 64 65 66 67 68 69 7 70 71 72 73 74 75 76 77 78 79 8 80 818283848586878889 9 90919293949596979899 TUNER VIDEO SIGNAL CP4002IMSA-9604S-06Z13 123456 CP4001TOC-C09X-A1 123456789 Q4003 DTA124EKA SW CAUTION: DIGITAL TRANSISTOR P.CON+5V SP/LP/EP-H INPUT_SEL TO_NORMAL_A P.CON+5V {2,3,4,6} GND {2,3,4,5,6} FSC {3,6} FSC {3,6} TO_NORMAL_A {6} FRONT_V_IN {3} FROM_NORMAL_A {6} 4FSC HF1 {6} HF_COM {6} TUNER_V {3} HF2 {6} GND {2,3,4,5,6} FROM_NORMAL_A {6}4FSC {2}DUMMY_V.SYNC {2}C.SYNC {2}SP/LP/EP-H {2}TRICK_PB-H/EE-H {2} P.CON+5V V.REC_ST-H {2,6}C.ROTARY {2}AUDIO_MUTE-H {2,6} TUNER_V REC/EE/PB {2}OSD_V {2} FRONT_V_IN CTL- {2}CTL+ {2}DOC_XO_CTL {2} ENV.DET INPUT_SEL {2}H.AMP_SW {2} OSD_V COMP {2} COMP ENV.DET {2}H.SW {2} FROM_NORMAL_A C.SYNC DUMMY_V.SYNC P.CON+5V V.REC_ST-H CTL+CTL- TRICK_PB-H/EE-H AUDIO_MUTE-H V.REC_ST-H H.SW C.ROTARY H.AMP_SW REC/EE/PB DOC_XO_CTL P.CON+5V W4C9YC11 6 1 H.IMADATEW.PHON NC 0 NC EQ AMP PB/EE REC PB:EPEP/LPREC: AMP Vref PB /EE ALC Vref2.3V A-Vcc P A.GND MUTE AUTOBIAS LINE AMP H.A GNDH.A VCCENV DETCOMP OUTREC AGCFILT Y/C R/P AUDIO R/P R/P AUDIO MUTE RF SW C ROT HA SW R CTLAMP IN IN AGCAMP + PB FM-EQDELAY AGC FM WCDC FM-EQ REC FM MOD Sub CONV BALANCER 4.21M BPF MainCONV AMP GCA B.D. KILKIL KILDET REG C-GND B-UP AMP ACCDET BGA C-LPF VX01 320FH VCO SLD ALWAYS 5V C-VCC VDD CLAMP VCA CLAMP VCP CLAMP V-AGC AGCTC2 FBC 1/2 SYNC SEP 6DB Chara INS. YNR/COMB Y-LPF DOUBLE LIM NL EMPHA DETAIL ENH LPFSUB FM DEM V/I CONV 3.58M BPF2 3.58M BPF1 REC APC PB APC RECAFC S-EQ FM-EQ DRIVER CCD OUT PULL CLOCK PB PHASE-EQ R-EQTEST BGABGA C.SYNC OUT IN 4Fsc Y-GND Y-Vcc H.A GND HL H L CH4 CH2 CH1 H L H.AMP H.AMP SW SW SQPB VHS NOMAL R P R TEST PR PR R P HA TEST NOMAL PR KIL PR P R BEFORE AFTER R P P R 23 1 PB-C Y/CMIX N.L. DEEN NC1 P R PB-Y ALC-LEVEL REC EP OUT REC SP OUT CH3 H.A PB AMP ACC TIMMING P R VSSVSS AUTO-BIAS SYNC DET AFC VIDEO OUT 2.4 2.4 2.4 2.4 0 2.4 2.4 1.5 5.0 NC 5.0 0 0 0.8 0.8 0.8 0 0 4.9 0 1.6 5.0 1.0 0.2 2.0 3.4 2.8 0 2.1 1.0 4.8 4.6 0 4.4 4.33.01.01.52.53.52.84.92.82.83.23.02.52.700 0.1 2.3 5.0 5.0 5.0 3.4 4.9 3.4 4.1 3.0 2.2 2.3 4.0 1.4 0 0 2.0 1.5 2.3 2.8 2.3 2.3 5.0 2.4 0 2.4 2.4 2.4 0 1.81.81.81.8 0 5.11.81.81.81.8 0 1.0 0 2.80.3 0 5.12.4 2.5 1.9 2.6 0 00 0 0 0.7 0.7 00 5.1 0 0 NC 5 4 3 SP-CH1 (R)SP-CH2 (L) EP/LP-CH1 (R)EP/LP-CH2 (L) HF1(R)HF2(L) AE HEAD(-) AUDIO REC CTL+CTL- AE HEAD(+) AUDIO PB FE HEAD(HOT)FE HEAD(GND) 2.4 3.0 5.2 1 NC NC NC NC NC 5.2 3.7 3.0 5.2 5.2 0 5.2 0 5.3 A 3.7 1.9 0 (SYSCON PCB) Y/C/AUDIO/CCD/HEAD AMP SCHEMATIC DIAGRAM T3 FROM POWER FROM/TO HI-FI/DEMODUTATOR FROM/TO CYL HF_COM SP_COM EP/LP_COM FROM/TO HEAD AUDIO CONTROL TO FE HEAD FROM/TO TUNER FROM/TO SYSCON Y/C/AUDIO/CCD/HEAD AMP PCB010VMX181 2 ABC D E F GH ABC D E F GH 21345678 21345678 DATE: TEC-HQ TEC-HQ SEC. PUBRICATION: DISTRIBUTE: SECTION: ORION ELECTRIC CO.LTD DWG.NO. FUNCTION CHKD BYDET.CHKD BYDRAWN BYDESIGN BY : ISSU Rev.No: PCB NAME STANDARDMODELDESCRIPTION VMX181A_D_ANKI D1008 1SS133 D1004 1N4005E D1009 1SS133 D1002 1N4005E CP1003IMSA-9604S-04Z14 1234 Q1007 DTC124EKA CENT SW D1001 SID1050CM X1001 10MHz IC1003 RE5VS31A SYSTEM RESET IC 123 CP1001 IMSA-9604S-07Z14 1234567 Q1005 RPI-352Q01R MS_SEN A 123 4 Q1004 RPI-352Q01R MS_SEN B 123 4 Q1001 SG-260 REEL SENSOR 1 23 4 Q1002 SG-260 REEL SENSOR 1 23 4 SW1001 SPVF130100 1 23 4 IC1002 BA6955AN LOADING MOTOR DRIVER IC 12345678 CP1002TMC-J08P-B1 12345678 D1003 TMPG06-12A DESCRIBED IN PARTS LIST ONLYCRITICAL FOR SAFETY,USE ONES ARE SINCE THESE PARTS MARKED BY CAUTION: DANS LA NOMENCLATURE DES PIECESN’UTILISER QUE CELLS DECRITESDANGEREU…

Text truncated - open the document above for the full version.

A-046-99-CPage 1 of 32 KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan Designated by Ministry of international Trade and industry KANSAI ELECTRONIC INDUSTRY DEVELOPMENT CENTER HEAD OFFICE IKOMA TESTING LABORATORY 6-8-7 NISHITENMA 12128 TAKAYAMA-CHO KITA-KU OSAKA 530-0047 JAPAN IKOMA-CITY NARA 630-0101 JAPAN Corporate Juridical Person TEST REPORT Report No.A-046-99-CDate: 7 February 2000 This test report is to certify that the tested device properly complies with the requirements of: FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. All the tests necessary to show compliance to the requirements were performed and these results met the specifications of requirement. The results of this report should not be construed to imply compliance of equipment other than that, which was tested. Unless the laboratory permission, this report should not be copied in part. 1. Applicant Company Name:ORION ELECTRIC CO., LTD. Mailing Address:41-1 IEHISA-CHO, TAKEFU-SHI FUKUI 915-8555 JAPAN 2. Identification of Tested Device Type of Device:TV Interface Device Kind of Equipment Authorization:: DoC : Certification: Verification FCC ID:A7RM4C9F Device Name:VIDEO CASSETTE RECORDER (Test for RF Modulator) Trade Name: MEMOREX Model Number: MVR4040A Serial Number:ID-112-1269: Prototype : Pre-production: Production Date of Manufacture:December 1999 3. Test Items and Procedure : AC Power Line Conducted Emission Measurement : Radiated Emission Measurement : Output Signal Level Measurement : Output Terminal Conducted Spurious Emission Measurement : Transfer Switch Measurement Above all tests were performed under: ANSI C63.4 – 1992 : without deviation, : with deviation(details are found inside of this report) 4. Date of Test Receipt of Test Sample:17 January 2000 Test Completed on: 1 February 2000 Fumitoshi Nagaoka Associate Director/ Ikoma Testing Laboratory A-046-99-CPage 2 of 32 KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan Table of Contents 0.NVLAP ACCREDITATION AND MEASUREMENT UNCERTAINTY....................3 0.1.NVLAP Accreditation.........................................................................................3 0.2.Measurement Uncertainty.................................................................................3 1.CERTIFICATION OF THE COMPLIANCE...........................................................3 2.GENERAL INFORMATION..................................................................................4 2.1.Product Description...........................................................................................4 2.2.Description for Equipment Authorization...........................................................5 2.3.Test Facility.......................................................................................................5 3.TESTE…

Text truncated - open the document above for the full version.
