A7RM4E4AVCR

2 RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALI- FIED SERVICE PERSONNEL. CAUTION: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. WARNING: WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equip- ment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correcting the interference by one or more of the following measures: - - - - Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance with the FCC Rules could void the user's authority to operate this equipment. CAUTION: ENGLISH 4C93401A-E(C-09)04.10.99, 12:172 3 ENGLISH READ INSTRUCTIONS All the safety and operating instructions should be read before the unit is operated. RETAIN INSTRUCTIONS The safety and operating instructions should be retained for future reference. HEED WARNINGS All warnings on the unit and in the operating instructions should be adhered to. FOLLOW INSTRUCTIONS All operating and use instructions should be followed. CLEANING Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. ATTACHMENTS Do not use attachments not recommended by the unit's manufacturer as they may cause hazards. WATER AND MOISTURE Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool. ACCESSORIES Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may fall, causing serious injury, and serious damage to the unit. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn. VENTILATION Slots and openings in the cabinet and in the back or bottom are provided for ventilation and to ensure reliable operation of the unit and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat source. This unit should not be placed in built-in installa- tions such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to. POWER SOURCES This unit should be operated only from the type of power source indicated on the rating plate. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For units intended to operate from battery power, or other sources, refer to the operating instructions. GROUNDING OR POLARIZATION This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug If your unit is equipped with a 3-wire grounding-type plug, a plug having a third (grounding) pin, this plug will only fit into a grounding-type power outlet. This too, is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug. 1. 2. 3. 4. 5. 6. 7. 8. 8A. 9. 10. 11. IMPORTANT SAFEGUARDS S3125A PORTABLE CART WARNING (symbol provided by RETAC) 4C93401A-E(C-09)04.10.99, 12:173 4 POWER-CORD PROTECTION Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance. LIGHTNING To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power line surges. POWER LINES An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care…

Text truncated - open the document above for the full version.

ABC D E F GH ABC D E F GH 21345678 21345678 DATE: TEC-HQ TEC-HQ SEC. PUBRICATION: DISTRIBUTE: SECTION: ORION ELECTRIC CO.LTD DWG.NO. FUNCTION CHKD BYDET.CHKD BYDRAWN BYDESIGN BY : ISSU Rev.No: PCB NAME STANDARDMODELDESCRIPTION VMX206 1.0 BLACKWHITE BLADE WIDE CD501 AC120V 60Hz TU6001 10111213 1415161718 2 21222324 25 26 27 28 34568 9 987645321 CP4001 654321 654321 2 1 CP4003 87654321 87654321 7654321 7654321 DANS LA NOMENCLATURE DES PIECESN’UTILISER QUE CELLS DECRITESDANGEREUSES AN POINT DE VUE SECURITE ETANT LES PIECES REPAREES PAR UN ATTENTION: OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE THE TIME THIS INTERCONNECTION DIAGRAM IS THE LATEST AT NOTE: DESCRIBED IN PARTS LIST ONLYCRITICAL FOR SAFETY,USE ONES ARE SINCE THESE PARTS MARKED BY CAUTION: 4 3 2 1 4 3 2 1 4321 4321 S.KIMURA FSC FSC T1 12/04/2000 M4E4IN71 GND KEY B KEY A GND KEY A KEY B S501S502 MICRO MOTOR M2003 MOTOR GND VCO(12V) CAP FG VCC(5V) CAP.M F/R CTL I LIMIT GND FE HEAD (HOT) FE HEAD (GND) H5002 FULL ERASE HEAD ASS’Y 2 1FE HEAD (HOT) FE HEAD (GND) VEX927 CD651 FFC CP651 CD601 OPERATION PCB PCB270 VMX206 CP1002 CAPSTAN DD UNIT M2001 G O VCC MR FG SENSOR ROTOR MAGNET COIL MAIN HALL SENSOR LOGIC SWITCH OUT IN HALL VCCHALL CP4002 AE HEAD(+)AE HEAD(-) CTL-CTL+ AUDIO REC AUDIO PB CD1002 AE HEAD(+)AE HEAD(-) FFC AE AUDIO CONTROL CTL-CTL+ AUDIO REC AUDIO PB H5001 HEAD AUDIO CONTROL ASS’Y PG GNDPG OUT GND M-COMW-OUTV-OUTU-OUT PG GNDPG OUT GND M-COMW-OUTV-OUTU-OUT J4205J4204J4203 HIFI FRONT JACK AUDIO IN (L) VIDEO IN M4E4-04A,B,C 8 NTSC A 1 UL/FCC INTERCONNECTION EP/LP HEADSP HEAD VCCBOT LDM-LDM+ FFC CD1001 CP1003 BOT PCB PCB370VEX907 VEX908 PCB380 LOADING MOTOR PCB M101 LOADING MOTOR LM Q101 BOT SENSOR WHITERED VCCBOTLDM-LDM+ CP101 AUDIO IN (R) FR OUT FR IN NCNC BMDATACLOCKCEPB 5VTU 32V (RF AGC) (BT) CE CLOCK DATA BM PB 5V TU 32V IF TP IF OUT A.IN V.INA.INMBCHCONTROL CHMB V.IN CONTROL NC SIF OUT SIF OUT AFT A.OUT AFT CD4001 FFC CP1001 UN4001 V.OUT J4201 REAR OUT JACK AUDIO OUT(R)VIDEO OUTAUDIO OUT(L) TO OS651 COMMAND TRANSMITTER TM601 DATA B+ TM601 OS651 FROM GND HI-FI HEAD SYSCON PCB PCB010 AND RF CONVERTER TUNER,DEMODULATOR V.OUT EP/LP COM SP COM EP/LP-CH2 (L)EP/LP-CH1 (R) HF2 (L)HF1 (R) HF COM SP-CH2 (L)SP-CH1 (R) 321987546 CD2001 CYLINDER UNIT

DesinatedbyMinistryofInternationalTradeandIndustry ANSAILECTRONICNDUSTRYEVELOPMENTENTERKEIDC HEADOFFICEIKOMA 6-8-7,NISHITEMMATESTINGLABORATORY KITA-KU,OSAKA,530-0047JAPAN12128,TAKAYAMA-CHO IKOMA-CITY,NARA,630-0101JAPANCorporateJuridicalPerson January14,2001FederalCommunicationsCommission KECNo.L-430ApplicationProcessingBranch 7435OaklandMillsRoad Columbia,MD21046 SUBJECT:APPLICATIONFORCERTIFICATIONOFTVINTERFACEDEVICE Reference: FCCID:A7RM4E4A Applicant:ORIONELECTRONICCO.,LTD. (TestforRFModulator)DeviceName:VIDEOCASSETTERECORDER ModelNo.:MVR4040B ApliedRegulation:Part15subpartB Gentlrmen; Inrelationtothecaptionedmodel,wesubmittoyouforcertification. Weencloseherewithfollowingdocuments. 1.TESTREPORT(A-044-00-C) 2.SPECIFICATIONSHEET 3.FCCIDLABEL 4.BLOCKDIAGRAM 5.SCHEMATICDIAGRAM 6.INSTRUCTIONBOOK 7.PHOTOGRAPHS Wearegratefulifyouwouldissuethegrantatyourearliestconvenience Verytrulyyours; SeiichiIzumi Manager IKOMATESTINGLABORATORY E-mail:[email protected]

ATTACHMENT A - Description of Device FCC File No. Date of Grant Product ID. Code (Model No.) Brand Name Remark Original Model M4E4A(MVR4040B) MEMOREX Additional Model ATTACHMENT H 1/4 ORION ELECTRIC CO., LTD. 41-1 Iehisa-cho, Takefu-shi TEL:(0778) 23-0001 FUKUI 915-8555, JAPAN TELEX:5175-588 ORION J FAX:(0778) 23-7799 ATTACHMENT H --- MEASUREMENT OF THE UHF NOISE FIGURES ON BULLETIN OST MP-2 AND STATISTICAL PLAN. 1. Measurements of TV Tuner Noise Figure This documents is the material of UHF TV Receiver Noise Figure measurement. 1) Measurements Procedure.(ON BULLETIN OST MP-2 JULY 1982) a. The measurements of noise figures are made in a shielded room. b. Before testing, the television receiver and Noise figure test equipment are to be subjected to a warm-up period of sufficient time for stabilization of factors which could affect the measurements. c. Automatic Gain Control bias, preceding the noise output measurement point, is maintained at the level( 4.0V ) existing When there is no input signal with the receivers UHF input terminated in its nominal impedance(75 ohm). d. It must first be ascertained that the noise figure contribution of the I.F. amplifier following the measuring point not exceed 0.3dB. If the influence of the 2nd stage is F(dB), then F2 - 1 F(dB) = 10 log 1 + is given 10 G1F1 so that Tuner Gain : G1 = 39 dB(typical) then the influence of the 2nd stage is to be less than 0.3dB so that influence of the 2nd stage can be ignored. e. N.F. Value = Meter Reading --- Balun Insertion loss Balun Insertion loss is mentioned in ATTACHMENT H-4. Therefor, it can get noise figures of UHF Tuner by correcting Factors of this value. ATTACHMENT H 2/4 ORION ELECTRIC CO., LTD. 41-1 Iehisa-cho, Takefu-shi TEL:(0778) 23-0001 FUKUI 915-8555, JAPAN TELEX:5175-588 ORION J FAX:(0778) 23-7799 2) Test Equipment a. Standard Noise Figure Indicator (Automatic Standard NF Indicator with Solid State Noise Source) * Manufactured by Elena Electronics Co., Ltd.(Japan) * Model ENF-2005 b. Noise Source * Model No. MC1100 Made by M.S.C. and correct proofs. * ENR --- This Indicator has no internal oscillator then can be use no correction of compensation. This Indicator will be send to FCC in November from Elena Electronics, and has already applied for it by KEC. c. UHF Balun * Model No. MP614A (50 to 75 ohm) Made by Anritsu Corporation * Insertion Loss --- Please see Attachment H-4 3) Block Diagram of UHF TV NF measurement. Tuner I.F. out Terminal (Gain Typical 39 dB) Noise Source Balun TV N.F Indicator (2) (3) (Under Test) (1) 50 to 75ohm 28Vp-p ATTACHMENT H 3/4 2. STATISTICAL PLAN TV Receiver UHF Noise Figure --- Certification and Compliance Criteria (July 1982) In reply to yours of Jan. 14, 1980, we have pleasure of stating below: Production Line compliance We carry out QUALITY ASSURANCE for Plan C and submit the annual report of M4E4A(MVR4040B) to the FCC. A. Sampling Size We check Sampling Size by TV Receiver Noise Figure --- Certification and Compliance Criteria 3.12. B. Data Calculation Method When one sampling is 20 sets, measurement data are a total 200 point, that is 20 set multiplied by 10 point/set. We check whether the measurement data comply with statistical condition on X + KS 14, by TV Receiver Noise Figure --- Certification and Compliance Criteria 3.13. ATTACHMENT H 4/4 5) ATTACHED SHEET 1. Block Diagram of Model ENF-2005 --- H-1 Standard Noise Figure Indicator "Elena Electronics". 2. Specifications of Standard NF Indicator --- H-2 Model ENF-2005 3. Excess Noise Ration of Noise Source --- H-3 M.S.C. Model MC1100, SN1012 4. Measurements Data --- H-4 Insertion Loss of UHF Balun ATTACHMENT H-C-1 Product ID.Code: M4E4A (Model No.: MVR4040B) Brand Name: MEMOREX TV RECEIVER APPLICATION CHECKLIST (X) 1. A statement identifying the production run plan we will be using to show compliance in meeting "TV Receiver, UHF Noise Figures Certification and Compliance Criteria" (July 1982). : We will use the production run plan C to show compliance in meeting 14dB UHF Noise Figure requirement. (X) 2. A statement that NF measurements were made pursuant to OST MP-2, July 1982. : NF measurements were made pursuant to OST BULLETIN MP-2, July 1982. (X) 3. The names of all manufacturing sources for the VHF and UHF tuners as well as the tuner manufacture's part No. Product ID. Code (Model No.) VHF/UHF 1 PACK TUNER PART NO. SOURCE M4E4A(MVR4040B) 0162600018 ALPS (X) 4.UHF and VHF tuner part numbers assigned by the receiver manufacturer. : There are no tuner part assigned by receiver manufacturer. ATTACHMENT H-C-2 (X) 5. Frequency bands tuned by receiver. VHF : 2 - 13 ch UHF : 14- 69 ch CATV : 1 -125 ch(101 - 845MHz) (X) 6. Pursuant to Section 15.117 of the Rules, a statement specifying the receiver design noise figure, in dB. : Because TV Tuner built in as part of a video tape recorder which uses a power splitter between the antenna terminals of the video tape recorder and input terminals of the TV Tuner, the limits of Noise Figure, pursuant to section 15.117(g)(4), complies with the limits subtracted 4dB from 14dB. ( ) 7. The length of the UHF lead, from antenna input terminal to the tuner. : (X) 8. A numbered electrical schematic for the receiver. : Attached (X) 9. The exact chassis number (MFR'S Model No. instead of chassis No.) (This number is classified with SUFFIX in order to show voltage difference, Radio band difference and so on.) : Mfr's No. : M4E4A ( )10. Picture tube size in inches. : (X)11. Type of receiver - color or black and white. : Color (X)12. A description of the cabinet material. : plastic and metal cover ( )13. Copy of all the information submitted with the original certification for the basic receiver. :Attached ATTACHMENT H-C-3 (X)14. A statement that the contribution not exceed 0.3dB for the channel. F2 - 1 F(dB) = 10 log 1 + 10 G1F1 where F1 : 7.0 dB ---------- typical value F2 : 8.5 dB ---------- N.F. indicator (I.F. Noise Figure) * See ATTACHMENT H 2/4 G1 : 39.0 dB ---------- See ATTACHMENT H …

Text truncated - open the document above for the full version.

ABC D E F GH ABC D E F GH 21345678 21345678 DATE: TEC-HQ TEC-HQ SEC. PUBRICATION: DISTRIBUTE: SECTION: ORION ELECTRIC CO.LTD DWG.NO. FUNCTION CHKD BYDET.CHKD BYDRAWN BYDESIGN BY : ISSU Rev.No: PCB NAME STANDARDMODELDESCRIPTION VMX206A_AHAKKOH 4.0 M4E4-04A,B,CNTSC M4E4 S.KIMURA UL/FCC 12/04/2000 CAUTION: DIGITAL TRANSISTOR Q4003 KRA103RTK SW CP4001TOC-C09X-A1 123456789 CP4002IMSA-9604S-06Z13 123456 CP4003TMC-T02X-E1 12 DURING PLAYBACKMEASURED WITH THE DIGITAL TESTER NOTE: THE DC VOLTAGE AT EACH PART WAS OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME C4014 22 6.3V KA C4012 22 6.3V KA C4004 2206.3VYK C4045 1006.3VYK C4035 150V KA C4031 150VKA C4027 336.3VKA C4009 476.3VKA C4034 1016VKA T4001 1626009 COIL,BIAS OSC 123 4 56 C4002 0.022100VMKT C40190.047 F C40150.047 F C40160.047 F C40330.0012B C4054 0.1 F C4006 0.015 B C4005 0.01B C4023 470PB C4022 0.1 F C4059 0.1 F C4061 0.01 B C4070 0.1 F C4060 0.01 B C4024 470PCH C4044 0.1 B C4038 180P CH C4036 390P B C4037 0.1 F C4032 0.0027 B C4028 0.1 F C40290.01 B C4064 0.022 B C4013 0.1 B C4066 0.022 B C4069 0.1 F R4039 8.2K R4012 820 +-1% R4001 560 R4021 22K R4023 33K R4022 820 R4042 1.5K R4038 680K R4033 2.2K 1/4W R4010 3.3K R4013 5.6K R4043 3.3K R4044 22K R4045 12K R4041 1.8K R4011 22K R4004 15 1/4W R4035 100K R4034 82K R4002 10K R4003 10K R4024 2.2K R4019 330K R4005 10K 1/4W R4046 22K R4047 12K 1/4W R4020 220 1/4W R4049 1M R4025 1.8K R4050 68K R4017 8.2K R4018 8.2K C4051 22 6.3V KA C4052 1 50V KA C4049 1 50V KA C4050 1 50V KA C4058 47 6.3V KA C4063 476.3VKA C4062 150V KA C4065 150VKA C4010 47 6.3V KA C4046 1 50V KA C4030 1016VKA C4053 1 50V KA C4067 150VKA C4048 1 50V KA Q4001 KTC3198 AUDIOPB SW Q4002 KTC3198 AUDIOPB SW Q4006 KTC3203_Y BIAS OSC Q4012 2SC2412K BUFFER W814 W812 TP4001 V.ENV W801 W843 Q4010 2SA1037AK BUFFER Q4005KTA1266 BIAS CTL X4001 3.579545MHz L4003 100uH 0305 L4005 47uH 0305 L4001 22uH 0305 L4004 22uH 0305 L4006 47uH 0305 IC4001 LA71200M-MPB Y/C/A/CCD/H.AMP 1 10111213141516 17 18 19 2 20 212223242526272829 3 30313233343536373839 4 40 41 42 43 44 45 46 47 48 49 5 50 51 52 53 54 55 56 57 58 59 6 60 616263646566676869 7 70717273747576777879 8 80 9 COMP H.SW ENV.DET H.AMP_SW C.ROTARY Y/C_CS Y/C_DATA Y/C_CLK P.CON+5V P.CON+5V AUDIO_MUTE-H FSC P.CON+5V {2,3,4,6} GND {2,3,4,5,6} FSC {3,6}FRONT_V_IN {3}TUNER_V {3} FSC {3,6} TO_NORMAL_A {6} FROM_NORMAL_A {6} HF1 {6} HF_COM {6} HF2 {6} GND {2,3,4,5,6} Y/C_CLK {2}Y/C_CS {2}Y/C_DATA {2}DUMMY_V.SYNC {2}V.REC_ST-H {2,6}C.ROTARY {2}AUDIO_MUTE-H {2,6}OSD_V {2}CTL- {2} P.CON+5V CTL+ {2}H.AMP_SW {2} TUNER_V COMP {2}ENV.DET {2}H.SW {2} FRONT_V_IN OSD_V P.CON+5V DUMMY_V.SYNC P.CON+5V TO_NORMAL_A P.CON+5V V.REC_ST-H CTL+CTL- FROM_NORMAL_A GNDHOT 2 NC PCB010 A T1 Y/C/AUDIO/CCD/H.AMP 2 Y/C/AUDIO/CCD/HEAD AMP SCHEMATIC DIAGRAM (SYSCON PCB) FE HEAD(GND)FE HEAD(HOT) TO FE HEAD FROM/TO HEAD AUDIO CONTROL AUDIO PB AE HEAD(+) CTL-CTL+ AUDIO REC AE HEAD(-) 00 0.7 0.7 00 5 0 FROM/TO CYL EP/LP-CH2 (L)EP/LP-CH1 (R) SP-CH2 (L)SP-CH1 (R) FROM/TO HIFI/DEMODUTATOR HF COM SP COM EP/LP COM HF1 (R)HF2 (L) 0 0 0 0 1 FROM/TO POWER 3 NC NC FROM/TO TUNER FROM/TO SYSCON NC VMX206 + EQ HA PRE GND REC:LP<EP PB:EP AMP MUTE BIAS LINE AMP REC FM-EQ FM PB FM EQ S-EQ MAIN DE-EM LIM DOUBBLE FM DEM SUB LPF EMPHA FIL MAIN Y-VCC V.SYNC SEP SEP 6DB QV/QH AGC TC2 BAL TC1 REG 4V 12 3 VDD 4Fsc CLOCK PLL TIMMING OUT DRIVER AUTO-BIAS CLAMP CCD VSS OUT IN VCA VCA CLAMP ALWAYS 5V 320FH VCO SLD PHASE EQ PHASE EQ Q-ADJ AGC FIL R P FBC VIDEO AGC Y/C MIX NC1 N.L. DEEM Y-LPF CLAMP ENH NL EMPHA NL EMPHA FM MOD YNR/COMB BPF1 B.D PB AMP CNC R P 3.58M BPF2 B-UP AMP Main CONV ACC AMP DET ACC C-LPF 4.21M BPF Sub CONV R P REC AFC PB APC APC C-VCC SERAIL DECODER C-GND C-ROT RF-SW IN AUDIO MUTE HA SW ENV DET ACC DET HA VCC COMP OUT KILL DET DET CHROMA GND HA VSS SYNC DETAIL 2.3V Vref SP,LP AMP PB,EE DETALC LPF ALC A-VCC 132 REC PB,EE VREF AUTO fo-ADJ AGC VHS SOPB TEST R-EQ NORMAL R R PB-C FM Y-GND B S DET 4.7K 1/2 R P R P P R P VCP 3.58M PB-C P R P REC VX01 B P R BGA BEFORE R P AFTER BGA BGA R P R P R P P R P P R P H L H L A-GND P R 4 3.3 5.0 3.9 1.5 0 2.1 0.2 2.6 0 0 0 0.1 5.0 5.0 5.0 0 2.6 3.9 3.4 0.3 0 5.0 5.0 0 2.2 0.8 01.502.60.13.13.02.62.34.02.32.32.3 1.61.70.405.02.91.6 2.3 2.3 2.3 2.3 2.3 2.3 0.1 2.3 2.3 0 0 0 0 1.7 1.6 0 2.5 0 0 2.4 NC 1.9 0 4.01.60.70.70.75.00.10.2 0 2.02.02.0 0 2.34.92.3 0 2.3 5.0 5.0 5.0 5.0 8 YC71 ABC D E F GH ABC D E F GH 21345678 21345678 DATE: TEC-HQ TEC-HQ SEC. PUBRICATION: DISTRIBUTE: SECTION: ORION ELECTRIC CO.LTD DWG.NO. FUNCTION CHKD BYDET.CHKD BYDRAWN BYDESIGN BY : ISSU Rev.No: PCB NAME STANDARDMODELDESCRIPTION VMX206A_AHAKKOH 4.0 M4E4-04A,B,CNTSC M4E4 S.KIMURA UL/FCC 12/04/2000 CP1003 IMSA-9604S-04Z14 1234 Q1010 KRC103RTK FF/REW SW Q1006 PNA2604M010R EOT SENSOR DANS LA NOMENCLATURE DES PIECESN’UTILISER QUE CELLS DECRITESDANGEREUSES AN POINT DE VUE SECURITE ETANT LES PIECES REPAREES PAR UN ATTENTION: DESCRIBED IN PARTS LIST ONLYCRITICAL FOR SAFETY,USE ONES ARE SINCE THESE PARTS MARKED BY CAUTION: D1010 MTZJ5.6B CP1002TMC-J08P-B1 12345678 SW1001 SPVF130100 REC SAFTY SW 12 34 Q1004 RPI-352Q01R MS_SEN B 123 4 Q1005 RPI-352Q01R MS_SEN A 123 4 CP1001IMSA-9604S-07Z14 1234567 D1001 SID1050CM Q1002 RPI-301 REEL SENS 1 234 IC1001 OEC8071A SYSCON/TIMER/SERVO 110 100 11 12 13 14 15 16 17 18 19 2 20 21 22 23 24 25 26 27 28 29 3 30 31 32 33 34 35 36 37 38 39 4 4041 42434445 46 47 48 49 5 50 51 52 53 54 55 56 57 58 59 6 60 61 62 63 64 65 66 67 68 69 7 70 71 72 73 74 75 76777879 8 80818283848586878889 9 90919293949596979899 X1001 14.31818MHz IC1002 LB11880 CYL/LOADING MOTOR DRIVER 1101112131415 16171819 2 2021 2223242526272829 3 30 456789 VR1001 470K PG ADJ DURING PLAYBACKMEASURED WITH THE DIGITAL TESTER NOTE: THE DC VOLTAGE AT EACH PART WAS OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME C1023 2206.3VYK C1021 150V KA C1058 0.01 TF C1017 0.01 B C1054 0.1 F C1044 0.1 F C1020 0.01 B C1037 1F C1013 0.001Y C1048 100PCH C1052…

Text truncated - open the document above for the full version.

A-044-00-C Page 1 of 33 KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan Designated by Ministry of international Trade and industry KANSAI ELECTRONIC INDUSTRY DEVELOPMENT CENTER HEAD OFFICE IKOMA TESTING LABORATORY 6-8-7 NISHITENMA 12128 TAKAYAMA-CHO KITA-KU OSAKA 530-0047 JAPAN IKOMA-CITY NARA 630-0101 JAPAN Corporate Juridical Person TEST REPORT Report No.A-044-00-C Date: 27 November 2000 This test report is to certify that the tested device properly complies with the requirements of: FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. All the tests necessary to show compliance to the requirements were performed and these results met the specifications of requirement. The results of this report should not be construed to imply compliance of equipment other than that, which was tested. Unless the laboratory permission, this report should not be copied in part. 1. Applicant Company Name : ORION ELECTRIC CO., LTD. Mailing Address : 41-1 IEHISA-CHO, TAKEFU-SHI FUKUI 915-8555 JAPAN 2. Identification of Tested Device Type of Device : TV Interface Device Kind of Equipment Authorization : : DoC : Certification : Verification FCC ID : A7RM4E4A Device Name : VIDEO CASSETTE RECORDER (Test for RF Modulator) Trade Name : MEMOREX Model Number : MVR4040B Serial Number : ID-112-1303 : Prototype : Pre-production : Production Date of Manufacture : October 2000 3. Test Items and Procedure : AC Power Line Conducted Emission Measurement : Radiated Emission Measurement : Output Signal Level Measurement : Output Terminal Conducted Spurious Emission Measurement : Transfer Switch Measurement Above all tests were performed under: ANSI C63.4 – 1992 : without deviation, : with deviation(details are found inside of this report) 4. Date of Test Receipt of Test Sample : 11 October 2000 Test Completed on : 21 November 2000 Fumitoshi Nagaoka Associate Director/ Ikoma Testing Laboratory A-044-00-C Page 2 of 33 KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan Table of Contents 0. NVLAP ACCREDITATION AND MEASUREMENT UNCERTAINTY..................... 3 0.1. NVLAP Accreditation................................................................................................ 3 0.2. Measurement Uncertainty ....................................................................................... 3 1. CERTIFICATION OF THE COMPLIANCE ............................................................... 3 2. GENERAL INFORMATION ........................................................................................ 4 2.1. Product Description................................................................................................... 4 2.2. Description for Equipment Authorization ............................................................... 5 2.3. Test Facility ............................................................................................................... 5 3. TESTED SYSTEM ........................................................................................................ 6 3.1. Test Mode ................................................................................................................... 6 3.2. Operation of EUT System......................................................................................... 7 3.3. Characterization and condition of EUT System ..................................................... 7 3.4. Block Diagram of EUT System................................................................................. 8 4. AC POWER LINE CONDUCTED EMISSION MEASUREMENT.......................... 11 4.1. Test Procedure ......................................................................................................... 11 4.2. Test Results ............................................................................................................. 12 4.3. Photographs of EUT System Configuration .......................................................... 14 5. RADIATED EMISSION MEASUREMENT .............................................................. 17 5.1. Test Procedure ......................................................................................................... 17 5.2. Test Results ............................................................................................................. 18 5.3. Photographs of EUT System Configuration .......................................................... 19 6. OUTPUT SIGNAL LEVEL MEASUREMENT ......................................................... 22 6.1. Test Procedure ......................................................................................................... 22 6.2. Test Results ............................................................................................................. 23 6.3. Photographs of EUT System Configuration .......................................................... 24 7. OUTPUT TERMINAL CONDUCTED SOURIOUS EMISSION EASUREMENT 26 7.1. Test Procedure ......................................................................................................... 26 7.2. Test Results ............................................................................................................. 27 7.3. Photographs of EUT System Configuration .......................................................... 28 8. TRANSFER SWITCH MEASUREMENT ................................................................. 29 8.1. Test Procedure ......................................................................................................... 29 8.2. Test Results ............................................................................................................. 30 8.3. Photographs of EUT System Configuration .......................................................... 31 9. USED TEST EQUIPMENTS AND CALIBRATION STATUS ................................. 32 A-044-00-C Page 3 of 33 KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-…
