Date:1999-03-29 TEST REPORT Page 1 of 6 No.: HM100526 ____LAW_MAN KIT_____ _KITTY CHOY_________ ____PATRICK WONG____ Testing Engineer Verify byPatrick Wong for Managing Director Conditions in issuance of Test Report 1. This Report is issued in confidence to the client and it will be strictly treated as such by the Hong Kong Standards and Testing Centre Ltd. It may not be reproduced either in its entirety or in part and it may not be used for advertising. The client to whom the Report is issued may, however, show or send it, or a certified copy thereof prepared by the Hong Kong Standards and Testing Centre Ltd. to his customer, supplier or other persons directly concerned. The Hong Kong Standards and Testing Centre Ltd. will not, without the consent of the client, enter into any discussion or correspondence with any third party concerning the contents of the Report. 2. The report refers only to the sample tested and does not apply to the bulk, unless the sampling has been carried out by the Hong Kong Standards and Testing Centre Ltd. and is stated as such in the Report. 3. In the event of the improper use of the report, the Hong Kong Standards and Testing Centre Ltd. reserves the rights to withdraw it, and to adopt any other remedies which may be appropriate. 4. Samples submitted for testing are accepted on the understanding that the Report issued cannot form the basis of, or be the instrument for, any legal action against the Hong Kong Standards and Testing Centre Ltd. 5. The Hong Kong Standards and Testing Centre Ltd. will not be liable for or accept responsibility for any loss or damage howsoever arising from the use of information contained in any of its Reports or in any communication APPLICANT: RadioShack, A Division of Tandy Corporation 100 Throckmorton St., Suite 1300, Forth Worth, Texas 76102-2802, USA DATE OF SAMPLES RECEIVED: 1999-03-19 DATE OF TESTING: 1999-03-25 to 1999-03-26 DESCRIPTION OF SAMPLE(S): A sample of product said to be: Product:Pocket Radio Manufacturer: Solar Electronics Corp. Ltd. Band Combination:AM/FM/AIR Model Number:12-615 Brand Name:RADIO SHACK Rating:4.5Vd.c.("AA" size battery × 3), 150mA with Jack Origin :CHINA The AC/DC adaptor used for the tests was a Winstar NA1535 Universal adaptor. INVESTIGATIONS REQUESTED: Measurement to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart B - Unintentional Radiators. RESULT/ REMARK: Please see attached sheet(s). CONCLUSION: From the measurement data obtained, the tested sample was considered to have COMPLIED with the requirement for the relevant clauses of Federal Communication Commission Rules for Radio Receivers. TEST EQUIPMENT AUDIT: Please see Appendix A Date: 1999-03-29 TEST REPORT Page 2 of 6 No.: HM100526 T E S T S U M M A R Y (A)Measurement of Radiated Emissions (On FM & AIR BAND) Result -- Satisfactory Data -- See the attached data (B) Measurement of Line-Conducted Voltage (On FM & AIR BAND) Result -- Satisfactory Data -- (The spectrum was checked from 450KHz to 30MHz. All emissions were too low to be measurable and they were all more than 20dB below the permitted limit.) Date: 1999-03-29 TEST REPORT Page 3 of 6 No.: HM100526 ***FM BAND RADIO RECEIVER*** (A) Measurement of Radiated Interference TEST REFERENCE: FCC Rules Part 15 Subpart B section 15.109 TEST CONDITION : Normal TEST DATE : 1999-03-26 Freq. to which tuned Freq. of the emission PolarityMeter Reading (including Antenna Factor) at 3m Field Strength (at 3m) FCC Limit @ MHzMHz dB(μV/m)μV/mμV/m 88.399.0Horizontal 29.128.5 150 98.3109.0Horizontal 34.452.5150 108.3119.0Horizontal 35.660.3150 =========SUMMARY========= All Data is within limit ================================== Broad-band Antennas were used ================================== Remark: IF = 10.70 MHz Date: 1999-03-29 TEST REPORT Page 4 of 6 No.: HM100526 ***AIR BAND RADIO RECEIVER*** (A) Measurement of Radiated Interference TEST REFERENCE: FCC Rules Part 15 Subpart B section 15.109 TEST CONDITION : AIR BAND RECEIVER TEST DATE : 1999-03-26 Freq. to which tuned Freq. of the emission Polarity Meter Reading (including Antenna Factor) at 3m Field Strength (at 3m) FCC Limit @ MHzMHz dB(μV/m)μV/mμV/m 107.0117.7Horizontal 35.861.7 150 121.5132.2Horizontal 33.849.0150 136.0146.7Horizontal 36.970.0150 293.4Horizontal 33.647.9200 =========SUMMARY========= All data is within limit ================================== Broad-band Antennas were used ================================== Remark: IF = 10.70 MHz Date: 1999-03-29 TEST REPORT Page 5 of 6 No.: HM100526 NOTES FOR THE RADIATION MEASUREMENT (1) Test site facility: Open field test site located at Taipo (Hong Kong) with a metal ground plane on filed with the FCC pursuant to section 15.109 of the FCC rules. (2) Distance between the EUT and measuring antenna: 3 meters. (3) Measuring instrumentations: CISPR Quasi-peak type field strength meter (25MHz - 1000MHz) 6 dB bandwidth set at 120KHz. (4) Measuring antenna: Broad band antenna for the frequency range 25 - 1000 MHz, connected with 10 meters coaxial cable. Cable loss of the coaxial cable included in the Antenna Factor for measurement data. The antenna are capable of measuring both horizontal and vertical polarization. (5) Frequency range scanned: The frequency range from 25 MHz to 1000 MHz had been searched. Readings of the highest emissions relating to the limit were reported as above. (6) Arrangement of EUT: During the test, the sample was operated at rated supply voltage and arranged for maximum emissions. (7) Measuring Procedure: In accordance with the relevant sections of ANSI C63.4:1992. (8) Measuring Uncertainty: The calculated uncertainty for measurement performed at 3M test distance are:- 30MHz to 300MHz = ± 3.7dB, 300MHz to 1000MHz + 3.0dB/-2.7dB. Remark: Purpose of this test is to provide the Applicant with the necessary test data of their device for the submission to FCC with application for Equipment Authorization under FCC Equipment Authorization Program. This test itself…

Text truncated - open the document above for the full version.

Date: 1999-03-29 TEST REPORT Page A1 of A1 No.: HM100526 APPENDIX A TEST EQUIPMENT AUDIT Radiated Emission EQP NO.DESCRIPTIONMANUFACTURERMODEL NO.SERIAL NO.LAST CAL EM007SPECTRUM ANALYZERH PHP85660B3144A2119229/05/98 EM008SPECTRUM ANALYZER DISPLAYH PHP85662A3144A2051429/05/98 EM009QUASI PEAK ADAPTORH PHP85650A3303A0170229/05/98 EM010RF PRESELECTORH PHP85685A3221A0141029/05/98 EM011ATTENNUATOR/SWITCHH PHP11713A2508A1059529/05/98 EM012PRE-AMPLIFIERH PHP8449B3008A0026229/05/98 EM013CONTROLLER (COMPUTER), COLOR MONITOR, KEYBOARD & MOUSE FLOPPY DRIVE H P H P H P HP9000 HPA1097C HP9133L 6226A60314 3151J39517 2623A02468 CM EM016ANTENNAARA INC.LPB-2513/A104718/05/98 EM072SIGNAL GENERATORHP8640B1948A1189230/03/98 EM083HKSTC OPEN AREA TEST SITEHKSTCN/AN/A25/02/99 Line Conducted EQP NO.DESCRIPTIONMANUFACTURERMODEL NO.SERIAL NO.LAST CAL EM078VARIACSHANGHAI VOLTAGETDGC-3/0.5N/ACM EM081SMALL SCREENED ROOMMIKO INST HKN/AN/A06/09/98 EM142PLUSE LIMITERR&SESH-Z20357.8810.5229/01/99 EM119LISNR&SESH3-Z50831.5518.5209/08/98 EM120EMI TEST RECEIVERR&SESHS101004.0401.1002/07/98 EM123NOTEBOOK PCACER350CXP007865N/A EM127ISOLATION TRANSFORMER 220 TO 300 WING SUNN/AN/ACM ABBREVIATIONS: CM = Corrective Maintenance N/A= Not Applicable TBD = To Be Determined
