AAO1200687Portable Radio

Date:1999-05-27 TEST REPORT Page 1 of 7 No.: HM100582 ___LAW MAN KIT____ ____KITTY CHOY____ ___PATRICK WONG___ Testing Engineer Verify byPatrick Wong for Managing Director Conditions in issuance of Test Report 1. This Report is issued in confidence to the client and it will be strictly treated as such by the Hong Kong Standards and Testing Centre Ltd. It may not be reproduced either in its entirety or in part and it may not be used for advertising. The client to whom the Report is issued may, however, show or send it, or a certified copy thereof prepared by the Hong Kong Standards and Testing Centre Ltd. to his customer, supplier or other persons directly concerned. The Hong Kong Standards and Testing Centre Ltd. will not, without the consent of the client, enter into any discussion or correspondence with any third party concerning the contents of the Report. 2. The report refers only to the sample tested and does not apply to the bulk, unless the sampling has been carried out by the Hong Kong Standards and Testing Centre Ltd. and is stated as such in the Report. 3. In the event of the improper use of the report, the Hong Kong Standards and Testing Centre Ltd. reserves the rights to withdraw it, and to adopt any other remedies which may be appropriate. 4. Samples submitted for testing are accepted on the understanding that the Report issued cannot form the basis of, or be the instrument for, any legal action against the Hong Kong Standards and Testing Centre Ltd. 5. The Hong Kong Standards and Testing Centre Ltd. will not be liable for or accept responsibility for any loss or damage howsoever arising from the use of information contained in any of its Reports or in any communication APPLICANT: RadioShack, A Division of Tandy Corporation 100 Throckmorton St., Suite 1300, Forth Worth, Texas 76102-2802, USA DATE OF SAMPLES RECEIVED: 1999-03-30 DATE OF TESTING: 1999-04-08 to 1999-05-13 DESCRIPTION OF SAMPLE(S): A sample of product said to be: Product:MULTI-BAND PORTABLE RADIO (AM/FM/TV1/TV2) Manufacturer: Solar Electronics Corp. Ltd. Band Combination:AM/FM/TV1/TV2 Model Number:12-687 Brand Name:RADIO SHACK Rating:120Va.c., 6W, 60Hz 6Vd.c. (“C” size battery × 4) for battery compartment Origin :CHINA INVESTIGATIONS REQUESTED: Measurement to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart B - Unintentional Radiators. RESULT/ REMARK: Please see attached sheet(s). CONCLUSION: From the measurement data obtained, the tested sample was considered to have COMPLIED with the requirement after modification by customer for the relevant clauses of Federal Communication Commission Rules for Radio Receivers. TEST EQUIPMENT AUDIT: Please see Appendix A Date: 1999-05-27 TEST REPORT Page 2 of 7 No.: HM100582 T E S T S U M M A R Y (A)Measurement of Radiated Emissions (On FM, TV1& TV2 BAND) Result -- Satisfactory Data -- See the attached data (B) Measurement of Line-Conducted Voltage (On FM, TV1 & TV2 BAND) Result -- Satisfactory Data -- (The spectrum was checked from 450KHz to 30MHz. All emissions were too low to be measurable and they were all more than 20dB below the permitted limit.) Date: 1999-05-27 TEST REPORT Page 3 of 7 No.: HM100582 ***FM BAND RADIO RECEIVER*** (A) Measurement of Radiated Interference TEST REFERENCE: FCC Rules Part 15 Subpart B section 15.109 TEST CONDITION : FM Broadcast Receiver TEST DATE : 1999-04-16 Freq. to which tuned Freq. of the emission PolarityMeter Reading (including Antenna Factor) at 3m Field Strength (at 3m) FCC Limit @ MHzMHz dB(μV/m)μV/mμV/m 88.399.0Vertical 38.079.4 150 98.3109.0Vertical 40.1101.2150 108.3119.0Vertical 39.089.1150 =========SUMMARY========= All Data is within limit ================================== Broad-band Antennas were used ================================== Remark: IF = 10.70 MHz Date: 1999-05-27 TEST REPORT Page 4 of 7 No.: HM100582 ***TV 1 BAND RADIO RECEIVER*** (A) Measurement of Radiated Interference TEST REFERENCE: FCC Rules Part 15 Subpart B section 15.109 TEST CONDITION : TV 1 BAND RECEIVER TEST DATE : 1999-05-13 Freq. to which tuned Freq. of the emission Polarity Meter Reading (including Antenna Factor) at 3m Field Strength (at 3m) FCC Limit @ MHzMHz dB(μV/m)μV/mμV/m 59.7549.05Vertical 35.358.2 100 65.7555.05Vertical 35.056.2100 71.7561.05Vertical 32.140.3100 81.7571.05Horizontal 28.125.4100 87.7577.05Horizontal 29.830.9100 =========SUMMARY========= All data is within limit ================================== Broad-band Antennas were used ================================== Remark: IF = 10.70 MHz Date: 1999-05-27 TEST REPORT Page 5 of 7 No.: HM100582 ***TV 2 BAND RADIO RECEIVER*** (A) Measurement of Radiated Interference TEST REFERENCE: FCC Rules Part 15 Subpart B section 15.109 TEST CONDITION : TV 2 BAND RECEIVER TEST DATE : 1999-05-13 Freq. to which tuned Freq. of the emission Polarity Meter Reading (including Antenna Factor) at 3m Field Strength (at 3m) FCC Limit @ MHzMHz dB(μV/m)μV/mμV/m 179.75190.45Horizontal 39.291.2 150 185.75196.45Horizontal 38.584.1150 191.75202.45Horizontal 38.887.1150 197.75208.45Horizontal 37.675.9150 203.75214.45Horizontal 38.685.1150 209.75220.45Vertical 39.594.4200 215.75226.45Horizontal 40.1101.2200 =========SUMMARY========= All data is within limit ================================== Broad-band Antennas were used ================================== Remark: IF = 10.70 MHz Date: 1999-05-27 TEST REPORT Page 6 of 7 No.: HM100582 NOTES FOR THE RADIATION MEASUREMENT (1) Test site facility: Open field test site located at Taipo (Hong Kong) with a metal ground plane on filed with the FCC pursuant to section 15.109 of the FCC rules. (2) Distance between the EUT and measuring antenna: 3 meters. (3) Measuring instrumentations: CISPR Quasi-peak type field strength meter (25MHz - 1000MHz) 6 dB bandwidth set at 120KHz. (4) Measuring antenna: Broad band antenna for the frequency range 25 - 1000 MHz, connected with 10 meters coaxial cable. Cable loss of the coaxial cable included in the Antenna Factor for …

Text truncated - open the document above for the full version.

Date: 1999-05-27 TEST REPORT Page A1 of A1 No.: HM100582 APPENDIX A TEST EQUIPMENT AUDIT Radiated Emission EQP NO.DESCRIPTIONMANUFACTURERMODEL NO.SERIAL NO.LAST CAL EM007SPECTRUM ANALYZERH PHP85660B3144A2119229/05/98 EM008SPECTRUM ANALYZER DISPLAYH PHP85662A3144A2051429/05/98 EM009QUASI PEAK ADAPTORH PHP85650A3303A0170229/05/98 EM010RF PRESELECTORH PHP85685A3221A0141029/05/98 EM011ATTENNUATOR/SWITCHH PHP11713A2508A1059529/05/98 EM012PRE-AMPLIFIERH PHP8449B3008A0026229/05/98 EM013CONTROLLER (COMPUTER), COLOR MONITOR, KEYBOARD & MOUSE FLOPPY DRIVE H P H P H P HP9000 HPA1097C HP9133L 6226A60314 3151J39517 2623A02468 CM EM016ANTENNAARA INC.LPB-2513/A104718/05/98 EM072SIGNAL GENERATORHP8640B1948A1189230/03/98 EM083HKSTC OPEN AREA TEST SITEHKSTCN/AN/A25/02/99 Line Conducted EQP NO.DESCRIPTIONMANUFACTURERMODEL NO.SERIAL NO.LAST CAL EM078VARIACSHANGHAI VOLTAGETDGC-3/0.5N/ACM EM081SMALL SCREENED ROOMMIKO INST HKN/AN/A06/09/98 EM142PLUSE LIMITERR&SESH-Z20357.8810.5229/01/99 EM119LISNR&SESH3-Z50831.5518.5209/08/98 EM120EMI TEST RECEIVERR&SESHS101004.0401.1002/07/98 EM123NOTEBOOK PCACER350CXP007865N/A EM127ISOLATION TRANSFORMER 220 TO 300 WING SUNN/AN/ACM ABBREVIATIONS: CM = Corrective Maintenance N/A= Not Applicable TBD = To Be Determined
