FCC ID: AAO1501995 Report No.: B90625B1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 2 of 14 TABLE OF CONTENTS SECTIONTITLEPAGE GENERAL REPORT SUMMARY04 SUMMARY OF TEST RESULTS04 1.PURPOSE05 2.ADMINISTRATIVE DATA06 2.1Location of Testin g06 2.2Traceability Statement06 2.3Co gnizant Personnel06 2.4Date Test Sample was Received06 2.5Disposition of the Test Sample06 2.6Abbreviations and Acron yms06 3.APPLICABLE DOCUMENTS07 4.DESCRIPTION OF TEST CONFIGURATIONS08 4.1Descri ption of Test Configuration - EMI08 4.1.1Cable Construction and Termination09 5.LIST OF EUT, ACCESSORIES AND TEST EQUIPMENT10 5.1EUT and Accessory List10 5.2EMI Test Equipment11 6.TEST SITE DESCRIPTION12 6.1Test Facility Description12 6.2EUT Mountin g, Bonding and Grounding12 7.TEST PROCEDURES13 7.1RF Emissions13 7.1.1Conducted Emissions Test13 8.0CONCLUSIONS14 FCC ID: AAO1501995 Report No.: B90625B1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 3 of 14 LIST OF APPENDICES APPENDIXTITLE AModifications to the EUT BAdditional Models Covered Under This Report CDiagrams, Charts and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors DData Sheets LIST OF FIGURES FIGURETITLE 1 Plot Map And Layout of Test Site FCC ID: AAO1501995 Report No.: B90625B1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 4 of 14 GENERAL REPORT SUMMARY This electromagnetic emissions test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedure described in the test specification given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced in any form unless done so in full. This report must not be used to claim product endorsement by NVLAP or any other agency of the U.S. Government. Device Tested:Radio Shack Remote Control Model: 15-1995 S/N: 2 Modifications:The EUT was not modified during the testing. Product Description: The EUT is the transmitter portion of the RadioShack Remote Control. Manufacturer:Universal Electronics, Inc. 6101 Gateway Drive Cypress, California 90630 Customer:RadioShack, A Division of Tandy Corporation 100 Throckmorton Street, Suite 1300 Fort Worth, Texas 76102-2802 Test Date:June 24, 1999 Test Specifications : EMI requirements FCC Title 47, Part 15 Subpart C, Sections 15.205 and 15.231 Test Procedure:ANSI C63.4: 1992 Test Deviations:The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TESTDESCRIPTIONRESULTS 1Radiated RF Emissions, 10 kHz – 4400 MHz.Complies with the limits of FCC Title 47, Part 15, Subpart B and Subpart C, sections 15.205 and 15.231 2Conducted RF Emissions, 450 kHz – 30 MHzNot performed because the EUT operates on 4 “AAA” batteries only and cannot be powered by any device that would connect to an AC public main. FCC ID: AAO1501995 Report No.: B90625B1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 5 of 14 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) test performed on the Radio Shack Remote Control Model: 15-1995. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4: 1992. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the specification limits defined by FCC Title 47, Part 15, Subpart C, sections 15.205 and 15.231. FCC ID: AAO1501995 Report No.: B90625B1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 6 of 14 2. ADMINISTRATIVE DATA 2.1 Location of Testing The EMI tests described herein were performed at the test facility of Compatible Electronics, 114 Olinda Drive, Brea, California. 2.2 Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST) . 2.3 Cognizant Personnel RadioShack, a Division of Tandy Corporation Dwayne CampbellManager, Engineering and Regulatory Affairs Universal Electronics, Inc. Jesse MendezEngineer Compatible Electronics, Inc. Kyle FujimotoTest Engineer Scott McCutchanLab Manager 2.4 Date Test Sample was Received The test sample was received on June 24, 1999 2.5 Disposition of the Test Sample The test sample was returned to Universal Electronics, Inc. on June 28, 1999. 2.6 Abbreviations and Acronyms The following abbreviations and acronyms may be used in this document. RFRadio Frequency EMIElectromagnetic Interference EUTEquipment Under Test P/NPart Number S/NSerial Number HPHewlett Packard ITEInformation Technology Equipment CMLCorrected Meter Limit LISNLine Impedance Stabilization Network NVLAPNational Voluntary Laboratory Accreditation Program FCC ID: AAO1501995 Report No.: B90625B1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 7 of 14 3. APPLICABLE DOCUMENTS The following documents are referenced or used in the preparation of this EMI Test Report. SPECTITLE FCC Title 47, Part 15 1997 FCC Rules - Radio frequency devices (including digital devices). ANSI C63.4 1992 Methods of measurement of radio-noise emissions from low-voltage electrical and electronic equipment in the range of 9 kHz to 40 GHz. FCC ID: AAO1501995 Report No.: B90625B1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 8 of 14 4. DESCRIPTION OF THE TEST SAMPLE The equipment under test (EUT) was placed on the wooden table. Specifics of the EUT Tested The Radio Shack Remote Control Model: 15-1995 (EUT) was tes…
