AAO6004257

JAPAN QUALITY ASSURANCE ORGANIZATION 21-25, KINUTA 1-CHOME, SETAGAYA-KU, TOKYO 157-8573 JAPAN PHONE (03) 3416-0111, TELEX 242-2531 JQA J FAX (03) 3416-9691 JQA APPLICATION NO.: 400-00120 Issue Date : June 6, 2000 Page 1 of 28 EMI TEST REPORT JQA APPLICATION NO. : 400-00120 Model No. : AAO6004257 Type of Equipment : Radio Controlled Toy Regulations Applied : CFR 47 FCC Rules and Regulations Part 15 FCC ID : AAO6004257 Applicant : NIKKO CO., LTD. Address : 1-7-14, Mizumoto, Katsushika-ku, Tokyo 125-0032, Japan Manufacture : NIKKO ELECTRONICS BHD. Address : Plot 497 Prai Free Trade Zone, Prai Industrial Estate, 13600 Prai, Penang, Malaysia Received date of EUT : May 17, 2000 Final Judgment : Passed TEST RESULTS IN THIS REPORT are obtained in use of equipment that is traceable to Electrotechnical Lab. of MITI Japan and Communications Research Lab. of MPT Japan. The test results only respond to the tested sample. It is not allowed to copy this report even partly without the allowance of the JQA EMC Engineering Dept. Testing Div. C O P Y JQA Application No. :400-00120 FCC ID :AAO6004257 Model No. :AAO6004257 Issue Date :June 6, 2000 Standard :CFR 47 FCC Rules Part 15 Page 2 of 28 JQA QUALITY ASSURANCE ORGANIZATION TABLE OF CONTENTS Page 1 Documentation 1.1 Test Regulation 3 1.2 General Information 3 1.3 Test Condition 4 – 7 1.4 EUT Modifications / Deviation from Standard 8 1.5 Test results 9 1.6 Summary 10 1.7 Test Configuration / Operation of EUT 11 1.8 Preliminary Test and Test-setup (Drawings) 12 – 16 1.9 EUT Arrangement (Photographs) 17 2 Test Data 2.1 AC Power Line Conducted Emission 0.45 MHz – 30 MHz N/A 2.2 Radiated Emission (Electric Field) 18 – 20 2.3 Frequency Stability N/A 2.4 Occupied Bandwidth 21 – 28 C O P Y JQA Application No. :400-00120 FCC ID :AAO6004257 Model No. :AAO6004257 Issue Date :June 6, 2000 Standard :CFR 47 FCC Rules Part 15 Page 3 of 28 JQA QUALITY ASSURANCE ORGANIZATION 1 DOCUMENTATION 1.1 TEST REGULATION FCC Rules and Regulations Part 15 Subpart A and C (June 23, 1989) Intentional Radiators Test procedure : AC power line conducted emission, radiated emission, frequency stability and occupied bandwidth tests were performed according to the procedures in ANSI C63.4-1992. 1.2 GENERAL INFORMATION 1.2.1 Test facility : 1) Test Facility located at EMC Engineering Dept. Testing Div. : - No.2 and 3 Anechoic Chambers( 3 meters Site ). - Shielded Enclosure. Expiration date of FCC test facility filing : June 04, 2002 2) EMC Engineering Dept. Testing Div. is recognized under the National Voluntary Laboratory accreditation Program for satisfactory compliance established in title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200189-0 (Effective through : June 30, 2000) 1.2.2 Description of the Equipment Under Test (EUT) : 1) Type of Equipment : Radio Controlled Toy 2) Product Type : Pre-Production 3) Category : Low Power Communication Device Transmitter 4) EUT Authorization : Certification 5) FCC ID : AAO6004257 6) Trade Name : Radio Shack 7) Model No. : AAO6004257 8) Operating Frequency Range : 26.995 MHz – 27.255 MHz 9) Highest Frequency Used in the EUT : 27.145 MHz 10) Serial No. : None 11) Date of Manufacture : - 12) Power Rating : DC 9.0V(Battery) 13) EUT Grounding : None 1.2.3 Definitions for symbols used in this test report : x - indicates that the listed condition, standard or equipment is applicable for this report. - indicates that the listed condition, standard or equipment is not applicable for this report. C O P Y JQA Application No. :400-00120 FCC ID :AAO6004257 Model No. :AAO6004257 Issue Date :June 6, 2000 Standard :CFR 47 FCC Rules Part 15 Page 4 of 28 JQA QUALITY ASSURANCE ORGANIZATION 1.3 TEST CONDITION 1.3.1 The measurement of the AC Power Line Conducted Emission - was performed in the following test site. x - was not applicable. Test location : Safety Testing Center EMC Engineering Dept. Testing Div. 21-25, Kinuta 1-chome, Setagaya-ku, Tokyo 157-8573, Japan - Shielded Enclosure - Anechoic Chamber No. 2 (portable Type) Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Test Receiver ESH-2 Rohde & Schwarz 880370/016 Sep. 1999 1 Year - Test Receiver ESH-3 Rohde & Schwarz 881460/030 Jun. 1999 1 Year - LISN(for Peripheral) KNW-407 Kyoritsu Electrical 8-833-6 Apr. 2000 1 Year - LISN(for EUT) KNW-407 Kyoritsu Electrical 8-855-2 Apr. 2000 1 Year - LISN KNW-407 Kyoritsu Electrical 8-757-1 Apr. 2000 1 Year - RF Cable 3D-2W Fujikura 155-21-006E0 Apr. 2000 1 Year - RF Cable 3D-2W Fujikura 155-21-007E0 Apr. 2000 1 Year - 50ohm Termination - SUHNER 154-06-501E0 Jan. 2000 1 Year - 50ohm Termination - SUHNER 154-06-502E0 Jan. 2000 1 Year C O P Y JQA Application No. :400-00120 FCC ID :AAO6004257 Model No. :AAO6004257 Issue Date :June 6, 2000 Standard :CFR 47 FCC Rules Part 15 Page 5 of 28 JQA QUALITY ASSURANCE ORGANIZATION 1.3.2 The measurement of the Radiated Emission(30 MHz – 1000 MHz) x - was performed in the following test site. - was not applicable. Test location : Safety Testing Center EMC Engineering Dept. Testing Div. 21-25, Kinuta 1-chome, Setagaya-ku, Tokyo 157-8573, Japan x - Anechoic Chamber No. 2 (3 meters) - Anechoic Chamber No. 3 (3 meters) Validation of Site Attenuation : 1) Last Confirmed Date :March, 2000 2) Interval :1 year Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Test Receiver ESH-2 Rohde & Schwarz 880370/016 Sep. 1999 1 Year - Test Receiver ESV Rohde & Schwarz 872148/039 May 2000 1 Year - Test Receiver ESVS10 Rohde & Schwarz 826148/002 Jun. 1999 1 Year x - Test Receiver ESVP Rohde & Schwarz 881487/004 May 2000 1 Year - Test Receiver ESVP Rohde & Schwarz 881487/005 Dec. 1999 1 Year x - Antenna KBA-511A Kyoritsu Electrical 0-170-1 Nov. 1999 1 Year - Antenna KBA-511A Kyoritsu Electrical 0-201-13 Nov. 1999 1 Year x - Antenna KBA-611 Kyoritsu Electrical 0-147-14 Nov. 1999 1 Year - Antenna KBA-611 Kyoritsu Electrical 0-210-5 Nov. 1999 1 Year - Biconical Antenna BBA9106 Sc…
