ADB9ZWFA70Class B AIS Transponder

CLASS B AIS TRANSPONDER FA-70 OPERATOR'S MANUAL www.furuno.com Model          ⊅       !"#  !$    %$&&#!'"'($)*             Z1 : NOV. 2019 Pub. No. OME-45150-Z1 i IMPORTANT NOTICES General • This manual has been authored with simplified grammar, to meet the needs of international users. • The operator of this equipment must read and follow the descriptions in this manual. Wrong operation or maintenance can cancel the warranty or cause injury. • Do not copy any part of this manual without written permission from FURUNO. • If this manual is lost or worn, contact your dealer about replacement. • The contents of this manual and equipment specifications can change without notice. • The example screens (or illustrations) shown in this manual can be different from the screens you see on your display. The screens you see depend on your system configuration and equipment settings. • Save this manual for future reference. • Any modification of the equipment (including software) by persons not authorized by FURUNO will cancel the warranty. • The following concern acts as our importer in Europe, as defined in DECISION No 768/2008/EC. - Name: FURUNO EUROPE B.V. - Address: Ridderhaven 19B, 2984 BT Ridderkerk, The Netherlands • Microsoft and Windows are registered trademarks or trademarks of the Microsoft Corporation of the USA and other countries. • All brand and product names are trademarks, registered trademarks or service marks of their respective holders. How to discard this product Discard this product according to local regulations for the disposal of industrial waste. For disposal in the USA, see the homepage of the Electronics Industries Alliance (http://www.eiae.org/) for the correct method of disposal. How to discard a used battery Some FURUNO products have a battery(ies). To see if your product has a battery, see the chapter on Maintenance. If a battery is used, tape the + and - terminals of the battery before disposal to pre- vent fire, heat generation caused by short circuit. In the European Union The crossed-out trash can symbol indicates that all types of batteries must not be discarded in standard trash, or at a trash site. Take the used batteries to a battery collection site according to your national legislation and the Batteries Directive 2006/66/EU. In the USA The Mobius loop symbol (three chasing arrows) indicates that Ni-Cd and lead-acid rechargeable batteries must be recycled. Take the used batteries to a battery collection site according to local laws. In the other countries There are no international standards for the battery recycle symbol. The number of symbols can in- crease when the other countries make their own recycle symbols in the future. Cd Ni-CdPb ii SAFETY INSTRUCTIONS The operator and installer must read the applicable safety instructions before attempting to install or operate the equipment. Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could result in minor or moderate injury. WARNING CAUTION WARNING CAUTION Do not open the equipment. This equipment uses high voltage that can cause electrical shock. Only qualified personnel can work inside the equipment. Turn off the power immediately if water leaks into the equipment or smoke or fire is coming from the equipment. Fire or electrical shock can result. Make sure no rain or water splash leaks into the equipment. Fire or electrical shock can result if water leaks into the equipment. Use the correct fuse. Use of a wrong fuse can cause fire or serious damage to the equipment. Do not place liquid-filled containers on or near the equipment. Fire or electrical shock can result if a liquid spills into the equipment. Warning, CautionProhibitive ActionMandatory Action Safety Instructions for the Operator Do not disassemble or modify the equipment. Fire, electrical shock or serious injury can occur. If the equipment does not work properly, contact your dealer. Do not operate the equipment with wet hands. Electrical shock can result. Do not disconnect the power cable while the system is powered. Damage to the equipment can result. SAFETY INSTRUCTIONS iii WARNING CAUTION Turn off the power at the switchboard before beginning the installation. Fire or electrical shock can result if the power is left on. Safety Instructions for the Installer Be sure that the power supply is compatible with the voltage rating of the equipment. Connection of an incorrect power supply can cause fire or damage the equipment. Observe the following compass safe distances to prevent interference to a magnetic compass: Standard compass Steering compass Antenna Unit Power Supply Unit Type PR-240 Do not install the equipment where it may get wet from rain or water splash. Water in the equipment can result in fire, electrical shock or damage to the equipment. ELECTRICAL SHOCK HAZARD Do not open the equipment. Only qualified personnel can work inside the equipment. GPA-017S AIS Transponder FA-70 Radiation Hazard Do not approach the antenna closer than x.x m when it is transmitting. The antenna emits radio waves which can be harmful to the human body, particularly the eyes. WARNING Radiation level 100 W/m 2 10 W/m 2 Distance GPA-017 0.3 m0.3 m 0.3 m0.3 m 0.9 m0.6 m N/A N/A GPA-C01 0.3 m0.3 m 0.3 m0.3 m 2 W/m 2 0.2 m iv TABLE OF CONTENTS FOREWORD ....................................................................................................................v SYSTEM CONFIGURATIONS .......................................................................................vii 1. INSTALLATION .....................................................................................................1-1 1.1 Equipment List .............................................................................…

Text truncated - open the document above for the full version.

3. SETTINGS AND STATUS 3-2 3.2Overview of the AIS Setting Tool No.NameDescription 1[Tools]• [Disconnect]: Disconnects from the FA-70. • [Screenshot...]: Takes a screenshot. 2[Help]• [Usage Considerations]: Shows the precautions for use. • [About]: Shows the program version number. 3Port selectionSelect the COM port to connect. 4[Connect]/[Disconnect]• [Connect]: Connects to the FA-70. • [Disconnect]: Disconnects from the FA-70. 5[Refresh All]Obtains the latest data from the FA-70, and then updates all settings of all menu tabs. 6[Apply All]Saves all settings in all tab pages, and then transmits the data to the FA-70. 7Menu tabOpens each menu. 8Setting/Display areaShows the setting values, menu options, status, test results, and so on depend on the selected menu. 9[Apply]Saves all settings in the current tab page, and then transmits the data to the FA-70. 1 2 456 7 8 9 3 1 xx xx denotes minor modifications. 3. SETTINGS AND STATUS 3-3 3.3IO setup (input/output port) You can change the input/output settings from the [IO Setup] menu. [IO Setup] menu for PC For the PC, click [Apply] or [Apply All] to confirm the settings. Menu itemDescription [Common] [Port Priority (Heading)] [1st], [2nd], [3rd] Set the input port priority for heading data. [NMEA2000] [CAN Unique Number]Shows the CAN unique number. [CAN Address]Shows the CAN address. [Output Mode]Select the output mode among [OFF], [AIS], [GNSS], or [AIS + GNSS]. [OFF]: Does not output AIS and GNSS data. [AIS]: Outputs AIS data. [GNSS]: Outputs GNSS data. [AIS + GNSS]: Outputs both AIS and GNSS data. [Format]Select the output PGN format version from [NMEA2000 V2] or [NMEA2000 V1]. [NMEA0183] [NMEA1 Output Mode], [NMEA2 Output Mode] Select the output mode among [OFF], [AIS], [GNSS], or [AIS + GNSS]. [NMEA1 Speed], [NMEA2 Speed] When selecting [OFF] or [GNSS] in the [NMEA1/NMEA2 Output Mode] menu, select the baudrate for NMEA1/NMEA2 from [AIS: 38400 bps] or [Sensor: 4800 bps]. [NMEA1 Output GNSS], [NMEA2 Output GNSS] When selecting [GNSS] or [AIS + GNSS] in the [NMEA1/NMEA2 Output Mode] menu, select the output GNSS sentence for NMEA1/NMEA2 among [OFF], [GGA + VTG (Sentences)], [GLL + VTG (Sentences)] or [RMC (Sentence)]. [OFF]: Does not output GGA, VTG, GLL and RMC sentences. [GGA + VTG (Sentences)]: Outputs GGA and VTG sentences. [GLL + VTG (Sentences)]: Outputs GLL and VTG sentences. [RMC (Sentence)]: Outputs RMC sentence. [CAN Unique Number], [CAN Address]: Display only. 3. SETTINGS AND STATUS 3-4 3.4Own Vessel Data Screen The [Own Vessel Data] screen shows the information of AIS channel, sensor status, and GNSS status. [Own Vessel Data] screen for PC Menu itemDescription [View Channel] [CH A]Shows the channel number and TX/RX mode for channel A. [CH B]Shows the channel number and TX/RX mode for channel B. [Power]Shows the transmission power. [Region List] (for the PC)Shows the channel management information of local sea areas. To take a screenshot, click [Screenshot] at the bottom right of the screen. [Sensor Status]Shows the information about the sensors connected to the FA-70. • Internal DGNSS in Use: DGNSS currently in use. • Internal GNSS in Use: GNSS currently in use. • Internal SOG/COG in Use: SOG/COG currently in use. • Heading Valid: Valid heading data. • Channel Management Parameters Changed (for the PC): Channel parameters have been changed. [GNSS Status] (for the PC) Shows the GNSS information. • [UTC]: Universal Time Coordinated • [LAT]: Latitude • [LON]: Longitude • [SOG]: Speed over ground • [COG]: Course over ground • [PA]: Positioning accuracy • [RAIM] (Receiver autonomous integrity monitoring): Whether to use RAIM or not. • [Mode]*: Positioning mode • [Status]*: Positioning status • [Satellites in View]*: The number of satellites in view. *: These items are not displayed when using the positioning data from the external sensor. Internal DGNSS in Use (Message 17) Internal SOG/COG in Use Heading Valid Channel Management Parameters Changed JAN 3. SETTINGS AND STATUS 3-5 3.5Alert Status The [Alert Status] screen shows the alerts currently occured. [Alert Status] screen for PC • [Time [UTC]]: Shows the time and date when the alert occured. • [ID]: Shows the alert number. • [Alert]: Shows the alert message*. *: For the external display, select the alert ID to display the alert message on the bot- tom of the screen. For the PC, click [Open] of [Alert Log] to show the alerts occured in the past (max. 20 alerts). • [Time [UTC]]: Shows the time and date when the alert occured. • [Alert]: Shows the alert message. • [Reason]: Shows the reason why the alert occured. Click [Screenshot] to take a screenshot. For the alert lists, see page AP-4. 01/JAN/2020 18:30 01/JAN/2020 18:31 01/JAN/2020 18:32 01/JAN/2020 18:35 01/JAN/2020 18:37 01/JAN/2020 18:30 01/JAN/2020 18:31 01/JAN/2020 18:32 01/JAN/2020 18:35 01/JAN/2020 18:37 3. SETTINGS AND STATUS 3-6 3.6IO Monitor The data input from each port can be monitored. Note: This menu appears only on the PC. • [Port]: Select the port that displays the received data. • [Start]: Click to start the receiving data display. The displayed characters are up to 10000 characters. The [Start] button changes to the [Stop] button. • [Stop]: Click to stop the receiving data display. The [Stop] button changes to the [Start] button. Display area of receiving data Character count 4-1 4.MAINTENANCE 4.1Maintenance Regular maintenance helps good performance. Check the items listed below monthly to keep your equipment in good working order. 4.2Replacement of Fuse The fuse (5A) in the cable protects it from overcurrent and equipment fault. If the unit cannot be powered, that is, the POWER LED is off, the fuse may have blown. If this happens, turn off the power to the FA-70, and check the fuse. If the fuse has blown, find out the reason before replacing it. If it blows again after replacement, contact your dealer for advice. ItemCheck point WiringCheck that each cable and wire are securely fastened. Refasten if necessary…

Text truncated - open the document above for the full version.

9-52 Ashihara-cho, Nishinomiya, 662-8580, Japan www.furuno.com 14 January 2020 TUV SUD BABT FCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Declaration of Compliance for the Use of Distress and Safety Frequencies IC: 1281B-FA70B Pursuant to RSP-100 Paragraph 4.1, we, Furuno Electric Co., Ltd. hereby declare that the radio equipment does not employ a modulation other than the internationally adopted modulation for maritime use when it operates on the distress and safety frequencies. Sincerely, Name: Akira Yamamoto Furuno Electric Co., Ltd.

9-52 Ashihara-cho, Nishinomiya, 662-8580, Japan www.furuno.com 19 November 2019 TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Confidentiality Request FCC ID: ADB9ZWFA70 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Furuno USA Inc hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation (Description of Circuitry and Devices) Furuno USA Inc also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of 180 days: Internal Photos External Photos User Manual Test Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Akira Yamamoto Telephone Number: +81(0)798-63-1216 Email: [email protected]

Coast Guard Approval Number: 165.156/50/0Expires: 29 April 2025 AUTOMATIC IDENTIFICATION SYSTEM CLASS B Shipborne Automatic Identification System (AIS) Class B Furuno Electric Co., Ltd. 9-52 Ashihara-cho Nishinomyia 662-8580 JAPAN FURUNO, FA-70 Automatic Identification System (AIS) Class B CS and SO FURUNO, FA-70 AIS Class B CS and SO meets the the requirements as set forth in: IMO Resolution A.694(17) IMO Resolution MSC.74(69) Annex 3 IEC 60945 (2002) with Corrigendum 1 (2008) IEC 61162 (applicable part) IEC 62287-1 (2017) IEC 62287-2 (2017) ITU-R M.1371 FURUNO, FA-70 AIS Class B CS and SO consists of the following equipment: Product number: ADB9ZWFA70 Transponder: FA-70 with built in VHF Splitter Software Version: 0550263-01.XX Federal Communications Commission (FCC) certification is required. *** End *** THIS IS TO CERTIFY THAT the above named manufacturer has submitted to the undersigned satisfactory evidence that the item specified herein complies with the applicable laws and regulations as outlined on the reverse side of this Certificate, and approval is hereby given. This approval shall be in effect until the expiration date hereon unless sooner canceled or suspended by proper authority. GIVEN UNDER MY HAND THIS 29ހ஍ DAY OF APRIL 2020, AT WASHINGTON D.C. J. H. MILLER, P.E., CDR CHIEF, SYSTEMS ENGINEERING DIVISION BY DIRECTION OF THE COMMANDANT DEPT. OF HOMELAND SECURITY, USCG, CGHQ-10030 (REV. 3-03) TERMS: The approval of the item described on the face of the Certificate has been based upon the submittal of satisfactory evidence that the item complies with the applicable provisions of the navigation and shipping laws and the applicable regulations in Title 33 and/or Title 46 of the Code of Federal Regulations. The approval is subject to any conditions noted on this Certificate and in the applicable laws and regulations governing the use of the item on vessels subject to Coast Guard inspection or on other vessels and boats. Consideration will be given to an extension of this approval provided application is made 3 months prior to the expiration date of this Certificate. The approval holder is responsible for making sure that the required inspections or tests of materials or devices covered by this approval are carried out during production as prescribed in the applicable regulations. The approval of the item covered by this certificate is valid only so long as the item is manufactured in conformance with the details of the approved drawings, specifications, or other data referred to. No modification in the approved design, construction, or materials is to be adopted until the modification has been presented for consideration by the Commandant and confirmation received that the proposed alteration is acceptable. NOTICE: Where a manufacturer of safety-at-sea equipment is offering for sale to the maritime industry, directly or indirectly, equipment represented to be approved, which fails to conform with either the design details or material specifications, or both, as approved by the Coast Guard, immediate action may be taken to invoke the various penalties and sanctions provided by law including prosecution under 46 U.S.C. 3318, which provides: "A person that knowingly manufactures, sells, offers for sale, or possesses with intent to sell, any equipment subject to this part (Part B. of Subtitle II of Title 46 U.S.C.). and the equipment is so defective as to be insufficient to accomplish the purpose for which it is intended, shall be fined not more than $10,000, imprisoned for not more than 5 years or both."

Labotech International Report no.: LIC 01-19-073, Rev.1 Date of issue: 29 November 2019 - Page 1 of 8 - Photographs of CLASS B AIS TRANSPONDER, FA-70 / AIS RECEIVER, FA-40 1. External view 1.1 Top view (*1) Only FA-70 is provided with VHF RADIO port. (*2) Only FA-70 is provided with the LED for “TX” and “SILENT”. (*1) (*2) Labotech International Report no.: LIC 01-19-073, Rev.1 Date of issue: 29 November 2019 - Page 2 of 8 - 1.2 Front view Labotech International Report no.: LIC 01-19-073, Rev.1 Date of issue: 29 November 2019 - Page 3 of 8 - 1.3 Rear view Labotech International Report no.: LIC 01-19-073, Rev.1 Date of issue: 29 November 2019 - Page 4 of 8 - 1.4 Right view Labotech International Report no.: LIC 01-19-073, Rev.1 Date of issue: 29 November 2019 - Page 5 of 8 - 1.5 Left view Labotech International Report no.: LIC 01-19-073, Rev.1 Date of issue: 29 November 2019 - Page 6 of 8 - 1.6 Bottom view Labotech International Report no.: LIC 01-19-073, Rev.1 Date of issue: 29 November 2019 - Page 7 of 8 - 1.7 ID Label (Name Plate) 1.7.1 FA-70 1.7.2 FA-40 Labotech International Report no.: LIC 01-19-073, Rev.1 Date of issue: 29 November 2019 - Page 8 of 8 - 1.8 Revision History Version Date Page Item Description/ Reason of the change 1 29 Nov. 2019 7 1.7 ID Label (Name Plate) 1.7.2 FA-40 Replaced the photograph of the name plate of FA-40. End of text

WARNING: This device must be programmed with data pertaining to the vessel in which the device is or will be installed. Programming will be carried out by your dealer or instructions for verifying the programming can be found in the user manual. WARNING: It is a violation of the rules of the Federal Communications Commission to input an MMSI that has not been properly assigned to the end user, or to otherwise input any inaccurate data in this device.

Labotech International Document number: LIC 01-19-076 Date of issue: 31 October 2019 Form: Q053/01 - Page 1 of 1 - Identification of Equipment for CLASS B AIS TRANSPONDER, FA-70 (FCC Rule, 2.925) 1 ID Label The following nameplate is permanently fixed on the corresponding equipment unit. FCC ID: ADB9ZWFA70 Material of Nameplate: polycarbonate film, 0.25 mm thick 2 ID Label Location ID Label is affixed to on top of the equipment. End of text ID Label

Labotech International Report no.: LIC 01-19-0 74 Date of issue: 31 October 2019 - Page 1 of 6 - Photographs of CLASS B AIS TRANSPONDER, FA-70 / AIS RECEIVER, FA-40 1. Internal view 1.1 Bottom view (with the bottom cover removed, showing VHF SPLITTER board, AIS-MOD board and IF board) (*1) Only FA-70 is provided with VHF SPLITTER board. (*2) Only FA-70 is provided with VHF RADIO port. AIS-MOD board IF board VHF SPLITTER board (*1) (*2) Labotech International Report no.: LIC 01-19-0 74 Date of issue: 31 October 2019 - Page 2 of 6 - 1.2 Bottom view (with VHF SPLITTER board removed, showing PWR&LED board) PWR&LED board Labotech International Report no.: LIC 01-19-0 74 Date of issue: 31 October 2019 - Page 3 of 6 - 1.3 Bottom view (with PWR&LED board removed) Labotech International Report no.: LIC 01-19-0 74 Date of issue: 31 October 2019 - Page 4 of 6 - 1.4 Bottom view (with AIS-MOD board removed) Labotech International Report no.: LIC 01-19-0 74 Date of issue: 31 October 2019 - Page 5 of 6 - 1.5 Rear view (showing IF board) Labotech International Report no.: LIC 01-19-0 74 Date of issue: 31 October 2019 - Page 6 of 6 - 1.6 Bottom view (with IF board removed) End of text

Labotech International Report no.: LIC 01-19-075 Date of issue: 31 October 2019 - Page 1 of 8 - Photographs of CLASS B AIS TRANSPONDER, FA-70 / AIS RECEIVER, FA-40 1. PCB 1.1 VHF SPLITTER board 05P0897, Front side Note: Only FA-70 is provided with VHF SPLITTER board. Labotech International Report no.: LIC 01-19-075 Date of issue: 31 October 2019 - Page 2 of 8 - 1.2 VHF SPLITTER board 05P0897, Rear side Note: Only FA-70 is provided with VHF SPLITTER board. Labotech International Report no.: LIC 01-19-075 Date of issue: 31 October 2019 - Page 3 of 8 - 1.3 AIS-MOD board 05P0896, Front side Labotech International Report no.: LIC 01-19-075 Date of issue: 31 October 2019 - Page 4 of 8 - 1.4 AIS-MOD board 05P0896, Rear side Labotech International Report no.: LIC 01-19-075 Date of issue: 31 October 2019 - Page 5 of 8 - 1.5 PWR&LED board, Front side Labotech International Report no.: LIC 01-19-075 Date of issue: 31 October 2019 - Page 6 of 8 - 1.6 PWR&LED board, Rear side Labotech International Report no.: LIC 01-19-075 Date of issue: 31 October 2019 - Page 7 of 8 - 1.7 IF board, Front side Labotech International Report no.: LIC 01-19-075 Date of issue: 31 October 2019 - Page 8 of 8 - 1.8 IF board, Rear side End of text

Furuno Electric Co.,Ltd. Osamu Dohi FA-70 Radiation Hazard Calculation Result Standards applied: Industry Canada RSS-102 FCC Rule 47 CFR § 2.1091 Device Description: The FA-70 is Class B AIS transponder. The output of the transmitter is 5W and frequency range is 156.025 MHz to 162.025 MHz. The transponder connects to a VHF Marine antenna through a cable and connector. The antenna is typically mounted more than 0.2 m away from person. EUT CLASS B AIS TRANSPONDER MODEL FA-70 Maximum conducted power 5 W Duty cycle 0.53 % ( *TX period : 26.67msec, TX minimum Interval : 5 sec ) Averaged output power 0.0267 W Distance 0.2 m Antenna Gain 2.14dBi Frequency 156.025 MHz ~ 162.025MHz *Refer to IEC 62287-2/ 12.2.3 Reference Levels: Frequency Range Power Density Limit Reference 48-300 MHz 1.291 W/m^2 RSS-102 Table 4 30-300 MHz 0.2 mW/cm^2 FCC 47 CFR §1.1310 Table 1 (b) Furuno Electric Co.,Ltd. Osamu Dohi 1. Calculation Formula The power density S at a point on the axis at a distance d from a transmitting antenna is given by the Friis free-space transmission formula Sൌ ୔ ౐ ୋ ସ஠ୢ మ （1） Where P T is the net power delivered to the antenna, G is the effective antenna gain with respect to an isotropic antenna Reference document :IEEE Std C95.3 -2002/ 5.5.1.1 Free-space standard field method 2. Calculation Result a) From (1), the following formula is used to calculate the distance dൌ ට ୔ ౐ ୋ ସ஠ୗ (2) considering the antenna thickness (CX4-3/FEC: φ18 mm) d ᇱ ൌ ට ୔ ౐ ୋ ସ஠ୗ െ0.009 (3) Result Distance at 0.2 mW/cm^2 (=2 W/m^2 ) 0.03 m Distance at 1.291 W/m^2 0.04 m Power density at 0.2 m 0.095 W/m^2 Furuno Electric Co.,Ltd. Osamu Dohi TX On/Off Timing plot 156.025MHz Furuno Electric Co.,Ltd. Osamu Dohi 162.025MHz Note : Selection interval ( SI )= 1 sec. Refer to ITU-R M.1375-5 Table 16 ( RI=5 sec )

This report shall not be reproduced except in full, without the written approval of Labotech International Co., Ltd. Test Report CFR Title 47 Sections: Part 2 (2.1046, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057), Part 80 (80.209, 80.211, 80.215, 80.217) for Trade name: Furuno Model: CLASS B AIS TRANSPONDER Type: FA-70 Report No.: LIC 12-19-199 Date of Issue: 31 October 2019 Labotech International Co., Ltd. 1-16, Fukazu-cho, Nishinomiya-shi, Hyogo, 663-8203 Japan Tel: +81 (0) 798 63 1094 Fax: +81 (0) 798 63 1098 URL: https://www.labotech-intl.co.jp/ Labotech International Report no.: LIC 12-19-199 Form: LQ053/11 - Page 2 of 53 - Report Summary LIC project number: LIC 04-19-0293 Test report number of initial issue: LIC 12-19-199 Date of initial issue 31 October 2019 Test report number of revised/replaced issue: -- Date of revised/replaced issue -- Test report revision/ replacement history: Test standard(s)/ Test specifications: CFR Title 47 Sections: 2.1046 - RF Power Output 2.1049 - Occupied Bandwidth 2.1051 - Spurious Emissions at Antenna Terminals 2.1053 - Field Strength of Spurious Radiation 2.1055 - Measurements required: Frequency Stability 2.1057 - Frequency spectrum to be investigated 80.209 - Transmitter frequency tolerances 80.211 - Emission limitations 80.215 - Transmitter power 80.217 - Suppression of Interference Aboard Ships (the latest version on the first day of the testing period) Customer: Furuno Electric Co., Ltd. 9-52, Ashihara-cho, Nishinomiya-city, Hyogo, 662-8580 Japan Manufacturer: Furuno Electric Co., Ltd. 9-52, Ashihara-cho, Nishinomiya-city, Hyogo, 662-8580 Japan Trade name: Furuno Model: CLASS B AIS TRANSPONDER Type: FA-70 Product function and intended use: Class B AIS transponder Number of samples tested: One Serial number: 1001-0610-0006 Power rating: 12–24 VDC, 1.8–0.9 A Product status: Pre-production model Modifications made to samples during testing: See Clause 1.3 of this report. Date of receipt of samples: 17 July 2019 and 3 September 2019 Test period: From 22 July 2019 to 8 October 2019 Place of test: Labotech International Co., Ltd. FCC Test firm Designation Number: JP2007 FCC Test firm Registration #: 838049 - Nishinomiya Lab. 9-52, Ashihara-cho, Nishinomiya-shi, Hyogo, 662-8580 Japan - Nishinomiya-Hama Lab. 2-20, Nishinomiya-Hama, Nishinomiya-shi, Hyogo, 662-0934 Japan Test results/Compliance: Passed. The test results of this report relate only to the samples tested. Labotech International Report no.: LIC 12-19-199 Form: LQ053/11 - Page 3 of 53 - Tested by: Koji Kawai Written by: Arisa Ogino Verified by: Atsushi Takagi Approved by: Date: 31 October 2019 Name: Atsushi Takajgi Title: Manager, Technical Department, Labotech International Co., Ltd. Signature: Labotech International Report no.: LIC 12-19-199 Form: LQ053/11 - Page 4 of 53 - Testing Laboratory S tatus Labotech International Co., Ltd. (hereafter called “LIC”) has been holding the following status after having been assessed according to the provisions of ISO/IEC 17025 and/or the relevant rules: (1) JAB Accredited Testing Laboratory: - accredited by Japan Accreditation Board (JAB) - Laboratory accreditation number: RTL03220 (Date of initial accreditation: 14 January 2011 (*)) - Scope of accreditation: Electrical testing - EMC, Climatic, Vibration and Radio tests (2) Telefication Listed Testing Laboratory: - listed by Telefication B. V., (The Netherlands) - Laboratory assignment number: L116 (Date of initial listing: 26 July 1999 (*)) - for testing the following product categories/ test standards: EN 60945, IEC 61162-1/-2, IEC/EN 61162-450, IEC 62288, ETSI EN 301 843-1 / -2, ETSI EN 301 489-1 / -3 / -17 (3) TÜV Appointed EMC Test Laboratory: - appointed by TÜV Rheinland Japan Ltd., - Laboratory assignment number: UA 50046428 (Date of initial appointment: 21 December 1998 (*)) - for carrying out the tests of EMC emission and immunity (4) RMRS Recognized Testing Laboratory: - recognized by Russian Maritime Register of Shipping (Russia) - Laboratory recognition number: 17.13259.170 (Date of initial recognition: 27 January 2009 (*) ) - for carrying out testing in the field of: Electrical measurements and tests, EMC tests, Mechanical measurements and tests, Equipment protection degree tests, and Climatic tests for Ship’s radio and navigational equipment and IEC 60945: 2002 (5) RRR Recognized Test Laboratory: - recognized by Russian River Register (Russia) - Certificate number: 131927 (- Date of initial recognition: 31 May 2013 (*) ) - for carrying out of tests of ships radio and navigation equipment (6) DNV GL Recognized Environmental Test Laboratory: - recognized by Det Norske Veritas AS, Germanischer Lloyd (Norway) - Recognition certificate number: 262.1-015854-J-12 (Date of initial recognition: 12 July 2013 (*)) - Scope of recognition: Testing according to the standards IEC 60945, IEC 61162-1/-2/-450, IEC 62288, IEC 62388 and IEC 62252 Annex E - Application: Provisions of Environmental, interface and safety testing. (7) CCS Recognized Test Agency: - recognized by China Classification Society - Recognition certificate number : DB13A00001 (Date of initial recognition : 29 January 2014 (*) ) - Scope of recognition : Performance/Environmental/EMC/Special purpose/Safety precautions tests for Electrical & Electronic Product including Maritime Navigation and Radio-communication Equipment & Systems (8) SABS EMC A-Lab program Laboratory: - recognized by South African Bureau of Standards - Assigned Lab number : SABS/A-LAB/0042/2018 (Date of initial recognition : 5 July 2018 (*) ) - Approved List of EMC Standards : SANS 211 / 214-1 / 214-2 / 222 / 2332 / 2335, CISPR 11 / 14-1 / 14-2 / 22 / 32 / 35, SANS/IEC 60601-1-2, SANS/IEC 61326-1, IEC 61326-2-6, SANS/IEC 61000-3-2 / -3-3 / -4-2 / -4-3 / -4 -4 / -4-5 / -4-6 / -4-8 / -4-11 / -6-1 / -6-2 / -6-3 / -6-4 (9) A2LA accreditted Testing Laboratory: - accredited by American Association of Laboratory (A2LA) - Certificate number: 5241.01 (Date of initial accreditation: …

Text truncated - open the document above for the full version.

Labotech International Report no.: LIC 12-19-199 Photograph of Test…
